Nickel-Electro Clifton Range NE9S Series User manual

NE9S SERIES
Fan Circulation Drying Ovens
NICKEL-ELECTRO LIMITED
Oldmixon Crescent
Weston Super Mare
North Somerset BS24 9BL
United Kingdom
Clifton R ange
®

Contents
General Notes 3
Specimen Safety 3
User Safety 4
Do’s and Don’ts 4
Unpacking 5
Power Lead and Connection to Electrical Supply 5
Positioning and Levelling 5
Front View 6
Rear View 6
Specication      7
Cleaning and Maintenance Instructions 8
Portable Appliance Testing 8
Operating Instructions 9
Turning On 9
Standby Mode 10
Controls Guide 11
Editing and Setting the Temperature Program 12
Editing and Setting the Temperature Program Continued 13
Starting the Temperature Program 14
Immediately Starting Program Option 14
Delay Starting Program Option 14
Date Time Starting Program Option 15
Program Running, Controls Locked 16
Stopping the Program 16
Alarm 16
Logger 16
EditingandSettingtheExhaustAirFlap   17
Editing and Setting the Exhaust Air Flap Continued 18
Editing and Setting the Date and Time 19
Editing and Setting the Date and Time Continued 20
Warranty Terms and Conditions 21
Warranty Terms and Conditions Continued 22
Non Warranty Information 22
EC Declaration of Conformity 23
CLIFTON RANGE DRYING OVEN NE9 SERIES
2

Dear Customer,
Thank you for purchasing this piece of Clifton Range laboratory equipment.To get the
best performance from your equipment and for your own safety please read these
instructions carefully before use.
General Notes
1. This product is designed for laboratory use only. Always follow good laboratory
practice.
2. If this product is not used in accordance with these instructions then basic safety
protection may be affected.
3. Themainssupplycordttedtothisproductisheatresistantandshouldbere-
placed with an equivalent type.
4. BeforeusinganycleaningordecontaminationmethodpleaserefertotheMainte-
nance and Cleaning section to ensure the proposed method will not damage the
unit.
5. Connectonlytoapowersupplywiththecorrespondingvoltagetothatspecied
on the rating label positioned on the rear of the unit.
6. Ensure that the power supply has an earth (ground) terminal.
Amendments
Issue 1: March 2013 (Initial Issue)
Symbols
This symbol appears in documents and on equipment to warn
the user that there are hot surfaces on the equipment.
This symbol appears in documents and on equipment to warn
the user that instructions must be followed to ensure correct
or safe operation.
Specimen Safety
It is the users responsibility, to ensure that the temperature set on the instrument, is at a
level where no damage is caused to diagnostic specimens used with the equipment. In the
event of this instrument malfunctioning, all specimens within the device should be checked
to ensure no harm or damage to the specimen has been caused.
CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
This symbol appears in documents and on equipment to warn
the user that instructions must be followed to ensure correct
or safe operation.
!
3

User Safety
The equipment you have purchased complies with the following European Directives
EMCDirective89/336/EECandLowVoltageDirective73/23/EECasindicatedintheEC
Declaration of Conformity included in the document.This instrument has been designed
and constructed in a manner which minimises the risk of electrical shock to the operator,
offers maximum protection from overheating and provides clear and adequate labelling of
instrument controls.
Do not touch any electrical contacts or open any closure plates.
RISK OF ELECTRIC SHOCK!!
DO NOT:
1. Block ventilation slots during use.
2. Use metal instruments or scouring agents to clean the interior of the oven.
3. Installtheinstrumentoutside,indampenvironmentsorareaswhichcanbeooded.
4. Installtheinstrumentnearammableorvolatilesubstances,acidsorincorrosive
environments.
5. Storeinammableorvolatilesubstancesinsidetheinstrument,touchlivepartsofthe
instrument,operatetheinstrumentwithdamphands,placevesselscontaininguids
on the instrument, climb or place any objects on the instrument.
6. Do not use without appropriate training.
DO:
1. Ensure the mains switch and power supply connector are accessible during use.
2. Disconnect from the power supply before moving the instrument.
3. Ensurethatthemainssupplycordttedisreplacedwithanequivalenttypeif
damaged.
4. Follow the installation instructions.
5. Follow the operating and maintenance instructions. If the instrument is not used in
accordancewiththeseinstructions,thenbasicsafetyprotectionofferedbytheequip-
ment may be affected.
6. Always follow good laboratory practice by ensuring substances being heated present
noriskofhazard(explosion,implosionorreleaseoftoxicorammablegases).
Do not touch any electrical contacts or open any closure plates.
RISK OF ELECTRIC SHOCK!!
!
CLIFTON RANGE DRYING OVEN NE9 SERIES
4

Unpacking
Prior to opening the packaging check the Tip and Tell Label to ensure the instrument
has not been tipped during transit. If tipped please notify Nickel Electro Ltd or your
local distributor immediately. Remove the product from it packaging. Any damage to the
product notify Nickel Electro Ltd or your local distributor immediately. Retain packaging
over warranty period.
DO NOT LIFT USING THE DOOR OR DOOR HANDLE
Remove the unit from its packaging . Check its condition and
accessories.
Power Lead and Connection to Electrical Supply
Check the electrical supply is compatible with the rating label.
IF IN DOUBT CONSULT AND ELECTRICIAN.THE PRODUCT
MUST BE EARTHED!
Where the mains supply or plug connection differs refer to local
regulations or consult an electrician.
POSITIONING AND LEVELLING
1. The instrument should be placed on a hard surface, in a dry, airy place with low
relative air humidity (maximum 60% RH, no condensation).The ambient temperature
shouldbe+10to+28˚C.
2. The instrument should not be placed in direct sunlight and near energy sources.
3. The instrument has not been designed to work in highly dusty environments.
4. Once the instrument has been positioned, it needs leveling. Afterwards it should be
inspectedusingaspiritlevelputonaatpartoftheunit.
5. The instrument should be placed at least 100mm away from the wall.
6. The instrument should be placed in such a place as to ensure at least a 300mm gap
between the top of the unit and the ceiling.
7. Theinstrumentmustnotbebuilt-in.
Remove the unit from its packaging . Check its condition and
accessories.
!
Check the electrical supply is compatible with the rating label.
IF IN DOUBT CONSULT AND ELECTRICIAN.THE PRODUCT
MUST BE EARTHED!
Where the mains supply or plug connection differs refer to local
regulations or consult an electrician.
!
CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
5

Front View
Rear View
Sockets and connections can be found in the top of the rear of the instrument, these are
indicated below:
Exhaustap.
Mains power lead.
Fuse socket.
Controls, cooling fan.
USB connection.
RS232 connection.
Mains power switch, on far
side.
Fan for Drying Oven chamber
heating.
CLIFTON RANGE DRYING OVEN NE9 SERIES
6
CLIFTON RANGE DRYING OVEN NE9 SERIES

Specication
TheCliftonRangeDryingOvensaredesignedforefcientremovalofmoisturefromtissue
sections. The instrument provides maximum drying area whilst taking up a minimum of
bench space in a laboratory. The instrument has ‘wipe clean’ digital touch pad controls
which provide accurate control of the drying temperature coupled with an ultra fast
heating system for rapid warm up. A wire shelf is supplied which increases drying capacity
andallowsefcientdryingoftissue sections.Digitaldisplaywith0.1˚Caccuracy,voltage
220-240V50-60Hz.
NE9-15S
Dimensions: External: 440w x 350d x 520h mm, Internal: 320w x 200d x 240h mm
Capacity: 15L
Weight: 30Kg (66lbs)
Temperature Range:Ambient to 250oC+/-0.7oC at 105oC
Heater Power: 600 Watts
NE9-32S
Dimensions: External 520 x 400 x 600h mm, Internal: 400 x 250 x 320mm
Capacity: 32L
Weight:37Kgs(81lbs)
TemperatureRange:Ambientto250˚C+/-0.4˚Cat105˚C
Heater Power: 1100 Watts
NE9-56S
Dimensions: External 590w x 560d x 690h mm, Internal: 395w x 360d x 395h mm
Capacity: 56L
Weight: 61Kgs (135lbs)
TemperatureRange:Ambientto250˚C+/-0.3˚Cat105˚C
Heater Power: 1600 Watts
NE9-112S
Dimensions: External: 650w x 650d x 835hmm, Internal: 460w x 450d x 540h mm
Capacity: 112L
Weight85Kgs(187lbs)
TemperatureRange:Ambientto250˚C+/-0.5˚Cat105˚C
Heater Power: 2400 Watts
NE9-240S
Dimensions:External:815wx710dx1140hmm,Internal:600wx510dx800hmm
Capacity: 240L
Weight: 150Kgs (330lbs)
TemperatureRange:Ambientto250˚C+/-0.5˚Cat105˚C
Heater Power: 3000 Watts
NE9-400S
Dimensions:External:1015wx710dx1385hmm,Internal:800wx510dx1040hmm
Capacity: 400L
Weight: 250Kgs (551lbs)
TemperatureRange:Ambientto250˚C+/-0.5˚Cat105˚C
Heater Power: 3900 Watts
NE9-750S
Dimensions: External: 1250w x 810d x 1620h mm, Internal: 1040h x 600d x 1200h mm
Capacity:750L
Weight:320Kgs(705lbs)
TemperatureRange:Ambientto250˚C+/-0.5˚Cat105˚C
Heater Power: 5400 Watts
CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
7

Cleaning and Maintenance Instructions
Before cleaning the instrument, it needs to be disconnected from the electrical supply!
Cleaning the Exterior of the Instrument
1. The housing of the instrument and control panel should be cleaned at least once a
week (depending on working conditions) a small quantity of mild detergent applied
using a soft cloth.
2. Electrical parts should not be in contact with water or detergent.
Cleaning the Interior of the Instrument
1. The heating chamber should be emptied of any sample before cleaning.
2. Only water or water with mild detergent should be used, and should be applied with
a soft cloth.
3. Havingnishedcleaning,youshouldallowtheinstrumenttofullydryandre-tall
accessories which were removed prior to cleaning.
4. During cleaning care should be taken not to damage the internal temperature sensor.
5. The base of the drying chamber can become discoloured over time due to the
heaters located under the metal base.This is completely normal and does not effect
performance of the Drying Oven.
6. Electrical parts should not be in contact with water or detergent.
WARNING:
   SCOURINGPADSORDE-SCALINGAGENTSMUSTNOT 
BE USED TO CLEAN THIS INSTRUMENT.
Taking Care of the Instrument When Not in Use:
1. Remove all objects from the drying chamber.
2. Disconnect the instrument from the main power supply.
3. Clean and dry the heating chamber.
4. Leave the door open to avoid nasty smells.
5. Store in temperature between 0oC and 50oC and a maximum relative humidity of
70%.
PAT Testing
   Portableappliancetestingshouldbecarriedoutbyaqualied
   person.Thisequipmentshouldnotbeashtested!
   SCOURINGPADSORDE-SCALINGAGENTSMUSTNOT 
BE USED TO CLEAN THIS INSTRUMENT.
!
   Portableappliancetestingshouldbecarriedoutbyaqualied
   person.Thisequipmentshouldnotbeashtested!
!
CLIFTON RANGE DRYING OVEN NE9 SERIES
8

Operating Instructions
Before using the instrument, it is recommended to heat the drying chamber. Before the
heating process, please clean the drying chamber in order to avoid permanent stains.Turn
on the unit and set the temperature at maximum. Let the unit work for 3 hours. During the
heating,theunitislikelytoproduceaspecicmetallicsmell.
Turning On
Switch the Clifton Range Drying Oven on using the mains switch located top right hand
sidecontrols,theinstrumentwillenteranautodiagnosticsroutine-ifanerrorisfoundthe
instrument stops or an appropriate screen is shown.
Once the diagnostic procedure concludes,the display shows an operation status screen and
measurement of temperature, which is calibrated to show the actual temperature in the
geometrical midpoint of the heating chamber.
The unit is inactive; nothing is running, display is just indicating chamber temperature with
date and time information.
CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
9

Note:
Onlytouchthecontrolkeyswithyourngersadjustingsettings,donotusepens,pencilsor
othertools.Abeepcanbeheardconrmingyouhaveactivatedthekey.
Standby mode
Touch the ON/OFF key and the unit enters standby mode, temperature display
off, keypads illuminated.
Resume from standby, touch the ON/OFF key and following the screen
instruction.
If the unit is left unattended and not used, a clock face will appear in the display. Should
it continue to be left unused it will enter standby mode, the keypads are illuminated and
display is OFF, the keypads are locked.
Touch and hold CANCEL/EXIT key to unlock following on screen instruction.
CLIFTON RANGE DRYING OVEN NE9 SERIES
10

Controls Guide
Over-temperaturealarm
indicator or control
error.
Current temperature in
the chamber
Status information,
heating and fan
indicators.
Turn OFF/ON standby
keypad.
Program and set
temperature status
Date and Time
CANCEL/EXIT
keypad.
ACCEPT/ENTER
keypad.
SCROLL UP keypad.
SCROLL DOWN
keypad.
CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
11

Touch and repeat , then touch or tohighlight“PROGRAMS”,conrm
selection with enter key.
Touch to highlight “list”, then “Program1”, then “edit”.
Editing and Setting the Temperature Program
The following instructions are for editing and setting the temperature.
CLIFTON RANGE DRYING OVEN NE9 SERIES
12

Touch toedit“40.0”settemperature,therstdigit“4”willashonandoff;adjust
the value up or down using the arrow keys.
Touch toedittheseconddigit“0”willashonandoff;adjustthevalueupordown
using the arrow keys.Touch to enter and save the value.
Touch to exit Program1, touch toconrmandsavechanges.
A protection screen appears should you need to set an alarm value. Otherwise it will
automaticallyseta+5˚Calarm.
CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
You can edit two further programs if required and store ready for use and selection.
13

Starting the Temperature Program
Touch and repeat , then touch or tohighlight“Run”,conrm
selection with enter.There are three options to choose from to run the program
“immediately” start,“delay” start or “date time” to start.Touch or to select the
option and then enter.
-“Immediately” starting program option
Program1 status screen indicating set temperature, heating, fan speed and actual chamber
temperature.
-“Delay” starting program day(s), hour(s), minute(s) in the future
Touch , to enter setting, border appears around ‘dd:hh:mm’ [day:hour:minute], touch
to highlight the day value ‘dd’, then touch either or to adjust and then
CLIFTON RANGE DRYING OVEN NE9 SERIES
14

CLIFTON RANGE DRYING OVEN NE9 SERIES
to acknowledge new hour value. Repeat to update hour and or minute setting as required
and touch to acknowledge.
Program1 running message appears, followed by status screen indicating when Program1
will start.An hourglass indicates Program1 is waiting to start.
-“Date time” starting program in the future, setting date and time
Touch , to enter settings, a border appears around time value ‘hh:mm’, touch to
highlight the hour value ‘hh’, then touch either or to adjust and then to
acknowledge new hour value.
Now ‘mm’ is highlighted, touch or to adjust highlighted ‘mm’, touch to
acknowledge new minute value.With border around time touch to move border to
yyyy:mm:dd values, touch to highlight the year value ‘yyyy’, then touch either
or to adjust and then to acknowledge new hour value and continue with ‘mm’
month and ‘dd’ day values.
CLIFTON RANGE DRYING OVEN NE9 SERIES
15

Program1 running message appears, followed by status screen indicating date and time
when Program1 will start.An hourglass indicates Program1 is waiting to start.
Program running, controls locked
When any program is running the touch controls are locked, preventing accidental
interruption or changes to Drying Oven operation.To unlock follow on screen advice,
touch and hold until cleared.
Stopping the program
1.Touch twice and “stop” appears in menu, touch toconrm.
ALARM
If an alarm has been triggered a warning triangle appears in top left hand display.
Touch twice and you will enter the “events” log for information.To delete the alarm
touch .
Logger
The “events” log automatically records events such as starting, stopping and ending a
program, power on and power off, in chronological order.The second option “data”
records temperature values when selected.
CLIFTON RANGE DRYING OVEN NE9 SERIES
16

CLIFTON RANGE DRYING OVEN NE9 SERIES
The following instructions are for accessing “events” log..
Touch and repeat , then touch or to highlight “LOGGER”, follow the
on screen menu guidance for “events” or “data”.
Editing and setting the exhaust air ap – factory pre-set 0%,
closed
The following instructions are for editing and setting the exhaust, which allows air from
the chamber to escape; settings 0% closed to 100% open. Recommend left closed at 0% c
losed. For instructions how to adjust:
Touch and repeat , then touch or tohighlight“PROGRAMS”,conrm
selection with enter key.
Touch to highlight “list”, then “Program1”, then “edit”.
CLIFTON RANGE DRYING OVEN NE9 SERIES
17

Program screen appears, touch underneath“S1-FLA”,then “set”.
Touch under “+” to increase or “-“todecrease,then “set”, to exit to
“save changes?” acknowledge “yes” or “no”.
CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
18

CLIFTON RANGE DRYING OVEN NE9 SERIES
CLIFTON RANGE DRYING OVEN NE9 SERIES
Editing and Setting the Date and Time
The following instructions are for editing and setting date and time.
Touch and repeat , then touch or tohighlight“SETUP”,conrm
selection with enter key.
Touch to highlight “Clock”, then , to enter clock settings.A border appears
around time value ‘hh:mm’, touch to highlight the hour value ‘hh’, then touch either
or to adjust and then to acknowledge new hour value.
19

Now ‘mm’ is highlighted, touch or to adjust highlighted ‘mm’, touch to
acknowledge new minute value.With border around time touch to move border to
yyyy:mm:dd values, touch to highlight the year value ‘yyyy’, then touch either
or to adjust and then to acknowledge new hour value and continue with ‘mm’
month and ‘dd’ day values.
When changes have been completed touch and to exit.
Door Open
CLIFTON RANGE DRYING OVEN NE9 SERIES
Open door: indication on display and audible beep.
When a program is running if the door is left open the red warning indicator will illuminate
with audible beeping until the door is closed.
20
CLIFTON RANGE DRYING OVEN NE9 SERIES
