DeviceNet® Interface
Interface for the 1280 and 880 Indicators
Installation and
Programming Manual
PN 156783 Rev CJanuary 7, 2020

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or registered
trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete
and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to
make changes to the technology, features, specifications and design of the equipment
without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction ................................................................................ 1
1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2.0 Installation .................................................................................. 2
2.1 LED Status Indicators and Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.0 Commands.................................................................................. 8
3.1 Output Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1.1 BYTE Swapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Input Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.1 Command number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.2 Status Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.3 Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2.4 Setting a Float Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2.5 Reading a Float Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3 Command Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.0 Specifications ........................................................................... 23

DeviceNet Interface
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars.

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
The DeviceNet interface can be used to read and write data to the indicator using a PLC or
another primary controller. This manual provides information for installation and use of this
product.
The DeviceNet interface is installed inside the indicator enclosure and installation in NEMA
Type 4X stainless steel enclosures permits use in washdown environments.
See the indicator installation manual for additional installation information and detailed
descriptions of indicator functions.
Some procedures described in this manual require work inside the indicator
enclosure. These procedures are to be performed by qualified service
personnel only.
Manuals and additional resources are available on the Rice Lake Weighing Systems
website at www.ricelake.com
Warranty information can be found on the website at www.ricelake.com/warranties
1.1 Overview
The DeviceNet Interface returns weight and status information from an indicator to a primary
controller and provides limited control of indicator functions to the programmer. Indicator
configuration and calibration cannot be performed through the DeviceNet Interface.
The Installation functions as a Communications Adapter Device (ODVA profile 12) on a
DeviceNet network. It acts as a group-two-only server on the network. At this time only one
polled I/O connection is supported, though DeviceNet also supports explicit, bit-strobed, and
change-of-state/cyclic connections. These connections may be included at a later date.
The primary controller sends commands to the indicator through the DeviceNet Interface by
writing the commands in the output command format. The Installation returns the weight and
status data in the input command format. These actions are referred to as polled I/O.
See Section 3.0 on page 8 for descriptions of the polled I/O commands.
WARNING

DeviceNet Interface
2 Visit our website www.RiceLake.com
2.0 Installation
DeviceNet Interface specific functions are provided by a DeviceNet module.
The module plugs into an open option card slot on the CPU board and provides power and
access from the indicator bus to the DeviceNet module.
See the indicator Technical Manual for installation instructions.
The interface option cards of the 1280 Enterprise Series and 880 universal and panel mount
indicators share the same carrier board (PN 164756). The carrier board plugs into an open slot
on the CPU board and provides power and access from the indicator bus to the module.
The assembly steps of the carrier board and modules vary between the 1280, 880 universal
mount, and 880 panel mount.
• 1280 interface option card kits are shipped with the module and the carrier board already
assembled
• 880 interface option card kits are shipped with the module and carrier board separated
― 880 universal mount module can be assembled to the carrier board before
installing
― 880 panel mount carrier board must be installed before assembling the module to
the carrier board
Figure 2-1. Interface Option Card Kit
The indicator automatically recognizes all installed option cards when the unit is powered on.
No hardware-specific configuration is required to identify an installed card to the system.
Always disconnect the power before opening an enclosure.
Interface option cards are not hot swappable.
A grounding wrist strap must be worn to protect components from
electrostatic discharge (ESD) when working inside an enclosure or controller
assembly.
IMPORTANT
Carrier Board with ModuleCarrier Board
WARNING
CAUTION

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 3
1280 Installation Instructions
1. Disconnect power to the indicator.
2. See the 1280 technical manual (PN 167659) to gain access to the Controller Assembly
box for the specific model.
3. Remove the screw securing the intended slot cover plate of the Controller Assembly box,
set the slot cover plate aside and save the screw.
4. Mount the faceplate on module and slide module board assembly into place within the
slot.
5. Secure the faceplate and module board assembly into place with the previously removed
screw.
Interface cable is routed through a cord grip in Universal and Wall mount
enclosures.
Alternately, a chassis mounted connect can be installed in the enclosure.
6. See 1280 technical manual to reinstall the Controller Assembly box.
Figure 2-2. Existing Cover Plate Removal
Figure 2-3. Installed Interface Option Card
Note
Slot Cover Plate
Installed Option Card

DeviceNet Interface
4 Visit our website www.RiceLake.com
880 Universal Installation Instructions
1. Disconnect power to the indicator.
2. Remove the backplate of the universal enclosure to access the CPU board.
3. Carefully slide the module into the J1 connector on the carrier board, ensuring that the
pins of J1 are not bent.
4. Ensure that the module is fully seated in the carrier board with the board hooks on the
bottom of the module aligned with the carrier board.
5. Tighten module screws on the front of the module to lock the board clamps of the module
to the carrier board.
Figure 2-4. Bottom of Carrier Card with Module Installed
Screws are tightened with a T9 Torx bit.
If the module is not fully seated on the carrier board, the clamps will push the
module away from the board rather than securing the board to the module.
This can potentially cause damage to the connector.
6. Carefully align the J5 connector on the bottom of the carrier board with the J8 option card
slot on the CPU board.
7. Press down on the carrier board with module until it is seated on the CPU board
connector.
8. Use the screws provided in the option kit to secure the carrier board to the threaded
standoffs on the CPU board (faceplate not needed).
9. Connect and properly run necessary cable.
10. Reinstall the enclosure backplate.
Board Hooks
T9 Torx Screws
J5 Connector
Board Clamps
Note

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 5
880 Panel Mount Installation Instructions
1. Disconnect power to the indicator and then disconnect the display cable.
2. Remove the backplate of the panel mount enclosure to access the CPU board.
3. Carefully align the J5 connector on the bottom of the carrier board (module currently not
attached) with J8 option card slot on the CPU board.
4. Press down on the carrier board until it is seated on the CPU board connector.
5. Use the screws provided in the option kit to secure the carrier board and faceplate to the
threaded standoffs on the CPU board.
6. Carefully slide the module through the faceplate to the J1 connector on the carrier board,
ensuring that the pins of J1 are not bent.
7. Ensure that the module is fully seated in the carrier board with the board hooks on the
bottom of the module aligned with the carrier board.
8. Tighten T9 Torx screws on the front of the module to lock the board clamps of the module
to the carrier board.
Screws are tightened with a T9 Torx bit.
If the module is not fully seated on the carrier board, the clamps will push the
module away from the board rather than securing the board to the module.
Figure 2-5. 880 Panel Mount Interface Option Card Installation
9. Reinstall the enclosure backplate and then reconnect the display cable.
Note
Standoff Screws
Faceplate
Threaded Standoffs
Module
J1 Connector
T9 Torx Screws
Board Hooks

DeviceNet Interface
6 Visit our website www.RiceLake.com
2.1 LED Status Indicators and Connector
An LED array on the 720i module provides status information for troubleshooting.
• LED 1 provides network status
• LED 2 provides status indication for the DeviceNet module
Figure 2-6. DeviceNet Status LED Module
Network Status LED (Item 1)
Module Status LED (Item 2)
Status Description
Off Not powered or not online
Green Online, connected
Green, Flashing Online, not connected
Red Critical link failure
Red, Flashing Connection time-out
Alternating Red and Green Self test
Table 2-1. Network Status LED Indications
Status Description
Off No power to module
Green Module operational
Green, Flashing Missing or incomplete configuration,
device needs commissioning
Red Unrecoverable fault
Red, Flashing Recoverable fault
Alternating Red and Green Self test
Table 2-2. Module Status LED
1
2
3

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 7
DeviceNet Connector (Item 3)
This connector provides 720i connectivity.
Figure 2-7. DeviceNet Connector Pinout
Pin Signal Description
1 V- Negative bus supply voltage
2 CAN_L CAN low bus line
3 SHIELD Cable shield
4 CAN_H CAN high bus line
5 V+ Positive bus supply voltage
Table 2-3. DeviceNet Connector Pins
12345

DeviceNet Interface
8 Visit our website www.RiceLake.com
3.0 Commands
Commands are used by the primary device to send and receive data from the interface as
integer or floating-point data. The primary sends eight bytes in the output format to write
commands to the indicator and reads eight bytes in the input format to read data from the
indicator.
Decimal Point Handling
Integer commands return no decimal point information to the primary.
For example, a value of 750.1 displayed on the indicator is returned to the primary as 7501.
Floating point commands support decimal point information with no special handling.
3.1 Output Data Format
To perform a command, the primary uses the output command format to send four
16-bit words to the interface. These four words contain the command and any parameters
necessary to execute it. The output command format is shown in Table 3-1.
See Section 3.1.1 on page 11 for BYTE swapping parameters.
A lockout feature, incorporated into the indicator receive mechanism, looks for
change in the output format data to prevent inundation by the same command.
See affected commands noted in Table 3-3 on page 9 with an (*).
Repeated commands must be separated by any other valid command/parameter/
value combination.
Word Description
Word 1 Command Number
Word 2 Parameter
Word 3 Value (MSW)
Word 4 Value (LSW)
Table 3-1. 880 Output Data Format
Byte Description
Byte 0 Command Number
Byte 1
Byte 2 Parameter
Byte 3
Byte 4 Value (MSW)
Byte 5
Byte 6 Value (LSW)
Byte 7
Table 3-2. 1280 Output Data Format
Note

Commands
© Rice Lake Weighing Systems ● All Rights Reserved 9
Parameter Value
In communication with a multi-scale indicator, the scale number is sent in the second word of
the output command format. Zero (0) represents the current scale. Certain commands require
a parameter other than a scale number, such as a slot number, setpoint number, or other
selection parameter. See the command descriptions in Section 3.3 on page 15 for specific
command requirements.
Value
The third and fourth words of the output format are used to pass value data on certain
commands. Values entered in these words are treated as unsigned long integers or
floating-point values, depending on the command.
Command Number
The number representing the indicator command is sent in the first word.
Table 3-3 lists the commands that can be specified for indicators.
Some commands may not be available on all indicators.
Decimal Hex Command
0 0x000 Return Status and Weight (integer)
1 0x001 Display Channel
2 0x002 Display Gross Weight
3 0x003 Display Net Weight
9 0x009 Gross/Net key press (toggle)
10 0x00A Zero*
11 0x00B Display Tare*
12 0x00C Enter Tare*
13 0x00D Acquire Tare*
14 0x00E Clear Tare*
16 0x010 Primary Units
17 0x011 Secondary Units
18 0x012 Tertiary Units
19 0x013 Units key press (toggle units)
20 0x014 Print Request
21 0x015 Display Accumulator
22 0x016 Clear Accumulator
23 0x017 Push Weight to Accumulator
32 0x020 Return Gross (integer)
33 0x021 Return Net (integer)
34 0x022 Return Tare (integer)
Table 3-3. Remote Commands

DeviceNet Interface
10 Visit our website www.RiceLake.com
37 0x025 Return Current Display (integer)
38 0x026 Return Accumulator (integer)
39 0x027 Return Rate of Change (integer) 1280 only
95 0x05F Set Batching State
96 0x060 Batch Start
97 0x061 Batch Pause
98 0x062 Batch Reset
99 0x063 Batch Status
112 0x070 Lock Indicator Front Panel
113 0x071 Unlock Indicator Front Panel
114 0x072 Set Digital Output ON
115 0x073 Set Digital Output OFF
116 0x074 Read Digital I/O Status
128 0x80 Enable Bus Command Handler
253 0x0FD No operation
254 0x0FE Reset Indicator
256 0x100 Return Status and Weight (float)
268 0x10C Enter Tare (float)
288 0x120 Read Gross (float)
289 0x121 Read Net (float)
290 0x122 Read Tare (float)
293 0x125 Read Current Display (float)
294 0x126 Read Accumulator (float)
295 0x127 Read Rate of change (float) 1280 only
304 0x130 Set Setpoint Value (float)
305 0x131 Set Setpoint Hysteresis (float)
306 0x132 Set Setpoint Bandwidth (float)
307 0x133 Set Setpoint Preact (float)
320 0x140 Read Setpoint Value (float)
321 0x141 Read Setpoint Hysteresis (float)
322 0x142 Read Setpoint Bandwidth (float)
323 0x143 Read Setpoint Preact (float)
Decimal Hex Command
Table 3-3. Remote Commands (Continued)

Commands
© Rice Lake Weighing Systems ● All Rights Reserved 11
3.1.1 BYTE Swapping
See the Ports Menu in the indicator manual.
The indicator sends and receives data in integer format.
The standard format is as follows for all input and output values:
High BYTE – Low BYTE
If the indicator FLDBUS/SWAP parameter is set to YES, then the BYTE order changes to:
Low BYTE – High BYTE
Example: If the weight on the scale reads 10 lbs and a value of 2560 is
displayed in the PLC, either swap the BYTES in the PLC or change the SWAP
parameter to YES
3.2 Input Data Format
The interface returns data and status information to the primary as four 16-bit words in
response to a command. The input command format is shown in Table 3-4.
The value type can be set for commands not specifying integer or floating point data by
sending the command 0x000 to specify integer data, or sending command 0x100 to specify
floating-point data. The value type is returned in the status word (bit 14) of the input format.
See Section 3.1.1 for BYTE swapping parameters.
Word Description
Word 1 Command Number
Word 2 Status
Word 3 Value (MSW)
Word 4 Value (LSW)
Table 3-4. 880 Input Data Format
Byte Description
Byte 0 Command Number
Byte 1
Byte 2 Status
Byte 3
Byte 4 Value (MSW)
Byte 5
Byte 6 Value (LSW)
Byte 7
Table 3-5. 1280 Input Data Format
Note
Note

DeviceNet Interface
12 Visit our website www.RiceLake.com
3.2.1 Command number
The first word echoes the command number. If the command fails or is not recognized, the
negative of the command number is returned to signal the error.
3.2.2 Status Data
Indicator status data is returned in the second word (Table 3-6).
Batch commands return batch status in place of the low byte (Table 3-7 on page 13).
Setpoint commands return batch status in the low byte of the status word and the setpoint
number in the high byte.
Word 2
Bit
Indicator Status Data
Value=0 Value=1
00 Error **
(Bit-0 Errors on page 13)
No error
01 Tare not entered Tare entered
02 Not center of zero Center of zero
03 Weight invalid Weight OK
04 Standstill In motion
05 Primary units Other units
06 Tare not acquired Tare acquired
07 Gross weight Net weight
08
Channel number
NOTE: Least significant bit first.
09
10
11
12
13 Not used
14 Integer data Floating point data
15 Positive weight Negative weight
This error condition does not necessarily mean the weight being reported is invalid.
Refer to the “Weight invalid” bit.
Table 3-6. Indicator Status Data Format

Commands
© Rice Lake Weighing Systems ● All Rights Reserved 13
Bit-0 Errors
• PLC command failed to execute
• No configuration has taken place
• Scale parameter is out of range
• Print error has occurred
• Load error has occurred
• Memory error has occurred
• Analog to digital converter error
• Tare error
• Scale over range error
• Scale under range error
• Non-recoverable configuration store error
• Indicator in configuration mode
Word 2
Bit
Batch Function Status Data
Value=0 Value=1
00 Digital input 4 OFF Digital input 4 ON
01 Digital input 3 OFF Digital input 3 ON
02 Digital input 2 OFF Digital input 2 ON
03 Digital input 1 OFF Digital input 1 ON
04 Batch not paused Batch paused
05 Batch not running Batch running
06 Batch not stopped Batch stopped
07 Alarm OFF Alarm ON
08
Setpoint number
09
10
11
12
13 Not used
14 Integer data Floating point data
15 Positive weight Negative weight
Table 3-7. Batch Function Status Data Format

DeviceNet Interface
14 Visit our website www.RiceLake.com
3.2.3 Value
Weight data is returned to the primary in the third and fourth words of the input command
format, depending on the command and the value type. The weight data returned is the
displayed weight after the command is executed, unless the command specifies otherwise.
A negative value is returned in the two’s compliment format.
3.2.4 Setting a Float Value
Setting a float value in a setpoint requires the value to be sent in two separate integer values.
Most PLCs have a mechanism to take a float value and separate it into to integer values.
Example: The following must be sent in the output words to set the value of
Setpoint #1 to 10000.
Command word = 304
Parameter word = 1
MSW = 17948
LSW = 16384
3.2.5 Reading a Float Value
When a float value is read it will be returned in two integers representing the float value.
The PLC must combine MSW and LSW integer values back into a float value.
Example: The following is returned in the input words if the weight on the scale
is 800.5.
Command Word = 288
Status word = Scale status
MSW= 17480
LSW = 8192

Commands
© Rice Lake Weighing Systems ● All Rights Reserved 15
3.3 Command Descriptions
Return Status and Current Weight as Integer
Command: 0, 0x000
Parameter: Scale number
Command 0 returns the status and gross or net scale weight (per scale configuration) of the
specified scale in integer format, without changing the display. This command also causes the
format-independent commands to return a value in the integer format.
Display Channel
Command: 1, 0x001
Parameter: Scale number
Command 1 causes the weight of the specified scale to be displayed and returned in its current
mode and format.
Display Gross Weight
Command: 2, 0x002
Parameter: Scale number
Command 2 causes the gross weight of the specified scale to be displayed and returned.
Display Net Weight
Command: 3, 0x003
Parameter: Scale number
Command 3 causes the net weight of the specified scale to be displayed and returned.
Gross/Net Key Press (Toggle Mode)
Command: 9, 0x009
Parameter: Scale number
Command 9 toggles between gross and net mode (and count mode, if enabled).
If a scale number other than 0 is specified, the action will not be seen until the specified scale is
displayed.
Zero
Command: 10, 0x00A
Command 10 performs a ZERO operation on the current scale.
Display Tare
Command: 11, 0x00B
Parameter: Scale number
Command 11 causes the tare weight on the specified scale to be displayed.
If a scale number other than 0 is specified, the indicator first causes the specified scale to be
displayed. Display returns to the prior mode after checking the indicator.

DeviceNet Interface
16 Visit our website www.RiceLake.com
Enter Tare (Integer)
Command: 12, 0x00C
Parameter: Scale number
Value: Tare weight
Command 12 enters a tare for the scale selected. Tare data must be in integer format.
The indicator continues to return weight data in the current mode for the specified scale.
Acquire Tare (Simulate TARE Key Press)
Command: 13, 0x00D
Parameter: Scale number
Command 13 acquires a tare based on the weight currently on the specified scale.
The indicator continues to return weight data in the current mode for the specified scale.
Clear Tare
Command: 14, 0x00E
Parameter: Scale number
Command 14 clears the tare for the specified scale. The indicator continues to return weight
data in the current mode for the specified scale.
Primary Units
Command: 16, 0x010
Parameter: Scale number
Command 16 switches the current format of the specified scale to the primary units configured
for that scale.
Secondary Units
Command: 17, 0x011
Parameter: Scale number
Command 17 switches the current format of the specified scale to the secondary units
configured for that scale.
Tertiary Units
Command: 18, 0x012
Parameter: Scale number
Command 18 switches the current format of the specified scale to the tertiary units configured
for that scale, if available.
Units Key Press (Toggle Units)
Command: 19, 0x013
Parameter: Scale number
Command 19 toggles between primary and secondary units of the specified scale.
