Rice Lake EtherNet/ IP Assembly instructions

Interface Option Cards
Interface for the 882IS/882IS Plus Indicator
Installation and
Programming Manual
EtherNet/IP™
DeviceNet®
PROFINET
Modbus® TCP
EtherCAT®
PROFIBUS DP
PN 195260
June 7, 2019

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or registered
trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete
and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to
make changes to the technology, features, specifications and design of the equipment
without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction ................................................................................ 1
1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1.1 EtherNet/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1.2 DeviceNet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1.3 EtherCAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.0 Installation .................................................................................. 3
2.1 Installing the Interface Option Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.0 Status LEDs and Connectors.................................................... 5
3.1 EtherNet/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1.1 Network Status LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1.2 Module Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1.3 Link/Activity LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1.4 EtherNet/IP Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 PROFINET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2.1 Network Status LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2.2 Module Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2.3 Link/Activity LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2.4 PROFINET Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3 PROFIBUS DP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3.1 Operation Mode LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3.2 Module Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3.3 DB9F Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4 Modbus TCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.1 Network Status LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.2 Module Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.3 Link/Activity LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4.4 Modbus TCP Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5 DeviceNet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5.1 Network Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5.2 Module Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.5.3 DeviceNet Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.6 EtherCAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.6.1 Run Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.6.2 Error Status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.6.3 Port Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.6.4 EtherCAT Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

882IS Interface Option Cards
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars.
4.0 Data Structure .......................................................................... 15
4.1 882IS Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.1 882IS Status Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.2 882IS Error Status Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 882IS Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.2.1 882IS Command Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.0 Network Settings...................................................................... 19
5.1 Configuring the Network settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.2 Configuring a Generic EtherNet Module . . . . . . . . . . . . . . . . . . . . . . . . 22

© Rice Lake Weighing Systems ● All Rights Reserved 1
Introduction
1.0 Introduction
This manual provides information on the installation and use of the following
interface option cards.
• EtherNet/IP™
• PROFINET
• PROFIBUS DP
• Modbus®
TCP
• DeviceNet®
• EtherCAT®
The EtherNet/IP, PROFINET, PROFIBUS DP and Modbus TCP interface option
cards can be used to read and write data to the 882IS using a PLC or another
primary controller.
The DeviceNet interface option card allows the 882IS to communicate with a
primary controller on a DeviceNet network, while the EtherCAT interface option
card allows the 882IS to communicate with an EtherCAT network.
Some procedures described in this manual require work inside
the 882IS enclosure. These procedures are to be performed by
qualified service personnel only.
All of the interface option cards are installed inside the 882IS enclosure and
installation in NEMA Type 4X stainless steel enclosures permits use in washdown
environments.
See the 882IS technical manual for additional installation information and detailed
descriptions of the 882IS functions.
Manuals can be viewed or downloaded from the Rice Lake Weighing
Systems website at www.RiceLake.com/manuals
Warranty information can be found at www.RiceLake.com/warranties
882IS configuration and calibration cannot be performed through an
interface option card.
WARNING
Note

2 Visit our website www.RiceLake.com
882IS Interface Option Cards
1.1 Overview
The primary controller communicates by sending commands through the
PROFINET, PROFIBUS DP and Modbus TCP interface option cards to an 882IS.
The 882IS responds to the primary controller with data and status depending on
the command sent. These actions are referred to as polled response.
A CD-ROM containing the GSD file used to configure the primary
device is supplied with the PROFIBUS DP interface option card.
The EtherNet/IP and DeviceNet interface option card returns weight and status
information from an 882IS to the network and provides limited control of 882IS
functions to the programmer.
1.1.1 EtherNet/IP
EtherNet/IP (Ethernet Industrial Protocol) is an open industrial networking
standard allowing control applications to make use of Ethernet communications
components and physical media.
EtherNet/IP is based on the IEEE 802.3 Ethernet standard, the TCP/IP protocol
suite and CIP™ (Common Industrial Protocol), the real-time I/O and information
protocol used by both DeviceNet™ and ControlNet™ networks.
1.1.2 DeviceNet
The installation functions as a communications adapter device on a DeviceNet
network. It acts as a group-two-only server on the network. Supports one polled
I/O connection.
The primary controller sends commands to the 882IS through the DeviceNet
interface by writing the commands in the output command format. The installation
returns the weight and status data in the input command format. These actions
are referred to as polled I/O.
1.1.3 EtherCAT
The EtherCAT communication module provides instant EtherCAT conformance
tested connectivity via the Anybus-CompactCom host interface. Any device
supporting this standard can take advantage of the features provided by the
module, allowing seamless network integration regardless of network type.
The EtherCAT card should not be used to communicate between
buildings. The Ethernet port is not suitable for connection to
circuits used outside the building and is subject to lightning or
power faults.
Note
IMPORTANT

© Rice Lake Weighing Systems ● All Rights Reserved 3
Installation
2.0 Installation
Interface option card specific functions are provided by the option card module.
The module must plug into option card slot 1 on the CPU board and provides
power and access from the 882IS bus to the interface option card module.
See the 882IS Technical Manual (PN 183532) for additional
installation instructions.
2.1 Installing the Interface Option Card
All the cards connect the same way. The interface option cards described in this
manual only work in slot 1 of the 882IS CPU board (other available options work
in either slot).
Always disconnect power before removing 882IS backplate.
A grounding wrist strap must be worn to protect components
from electrostatic discharge (ESD) when working inside the
882IS enclosure.
Installation Procedure
1. Disconnect power from the unit.
2. Remove the backplate from the enclosure.
3. Connect interface board to slot 1 of the CPU board.
4. Use three provided screws to secure the interface board.
5. Connect and properly run cables.
6. Reinstall the enclosure backplate.
7. Reconnect power to the unit.
The 882IS automatically recognizes all installed option cards when the unit is
powered on. No hardware-specific configuration is required to identify the newly-
installed card to the system.
IMPORTANT
WARNING
CAUTION

4 Visit our website www.RiceLake.com
882IS Interface Option Cards
Board Diagram
Figure 2-1. Interface Option Card Board
Environmental Specifications
Temperature: 14° to 104° F (-10° to +40° C)
Conformance
The EtherNet/IP and EtherCAT interfaces have been found in accordance with
EMC directive 89/336/EEC for European standards EN 50081-2 and EN 61000-6-2.
LED2
R10
CDRDY
J4
CTX
R43
L1
L2
R34
VINP
C40
CMISO
CBUSY
MH1
C41
R49
R33
TP1
VINN
CRX
TVS2
C1
TVS1
CSSEL
CMOSI CSCLK
J6
MH3
R9
MH2
D9
R17
LED5
49 50
25 2 1
2627
24
J1
J3
IC1
LED1
C2
Pb
U1
R55
C19
Carrier Board
PN 164756
Kit Numbers
PN 190530 – EtherNet/IP
PN 190531 – DeviceNet
PN 190532 – PROFINET
PN 190533 – Modbus TCP
PN 190534 – PROFIBUS DP
PN 190535 – EtherCAT

© Rice Lake Weighing Systems ● All Rights Reserved 5
Status LEDs and Connectors
3.0 Status LEDs and Connectors
Always disconnect power before removing 882IS backplate.
A grounding wrist strap must be worn to protect components
from electrostatic discharge (ESD) when working inside the
882IS enclosure.
3.1 EtherNet/IP
To configure an IP Address, refer to Section 5.1 on page 19.
Figure 3-1. EtherNet/IP Module
3.1.1 Network Status LED
A test sequence is performed on this LED during startup.
LED State Description
Off No power or no IP address
Green On-line, one or more connections established (CIP Class 1 or 3)
Green, flashing On-line, no connections established
Red Duplicate IP address, FATAL error
Red, flashing One or more connections timed out (CIP Class 1 or 3)
Table 3-1. Network Status LED Descriptions
WARNING
CAUTION
Note
EtherNet/IP Connector
Module Status LED
Network
Status LED
Link/Activity LED
Note

6 Visit our website www.RiceLake.com
882IS Interface Option Cards
3.1.2 Module Status LED
A test sequence is performed on this LED during startup.
3.1.3 Link/Activity LED
3.1.4 EtherNet/IP Connector
The Ethernet interface supports 10/100 Mbps, full or half duplex operation.
LED State Description
Off No power
Green Controlled by a scanner in run state
Green, flashing Not configured, or scanner in idle state
Red Major fault (EXCEPTION state, FATAL error etc.)
Red, flashing Recoverable fault(s)
Table 3-2. Module Status LED Descriptions
LED State Description
Off No link, no activity
Green Link established
Green, flickering Activity
Table 3-3. Link/Activity LED Descriptions
Note

© Rice Lake Weighing Systems ● All Rights Reserved 7
Status LEDs and Connectors
3.2 PROFINET
Figure 3-2. PROFINET Module
3.2.1 Network Status LED
A test sequence is performed on this LED during startup.
3.2.2 Module Status LED
A test sequence is performed on this LED during startup.
LED State Description
Off No power or connection with IP controller
Green, flashing Connection with IP controller established
I/O controller in STOP state
Table 3-4. Network Status LED Descriptions
LED State Description
Off Not initialized – no power or module in SETUP or NW_INIT state
Green Normal operation – module has shifted from the NW_INIT state
Green, 1 flash Diagnostic event(s) present
Green, 2 flashes Blink used by engineering tools to identify the node on the network
Red Exception error – module in EXCEPTION state
Red, 1 flash Configuration error – expected identification differs from real identification
Red, 2 flashes IP address error – IP address not set
Red, 3 flashes Station name error – station name not set
Red, 4 flashes Internal error – module has encountered a major internal error
Table 3-5. Module Status LED Descriptions
Module Status LED
Network
Status LED
Connector Status LEDs
PROFINET Connectors
Note
Note

8 Visit our website www.RiceLake.com
882IS Interface Option Cards
3.2.3 Link/Activity LED
3.2.4 PROFINET Connectors
The PROFINET interface supports 10/100 Mbps, full or half duplex operation.
Update rate is dependent on the configured baud rate and the number of network
nodes.
3.3 PROFIBUS DP
Figure 3-3. PROFIBUS Module
3.3.1 Operation Mode LED
LED State Description
Off No link, no activity
Green Link established
Green, flickering Activity
Table 3-6. Link/Activity LED Descriptions
Status Description
Off No powered or not online
Steady Green Data exchange
Flashing Green Clear
Flashing Red (1-flash) Parametrization error
Flashing Red (2-flash) PROFIBUS configuration error
Table 3-7. Operation Mode LED Descriptions
DB9F Connector
Module Status LED
Operation
Mode LED

© Rice Lake Weighing Systems ● All Rights Reserved 9
Status LEDs and Connectors
3.3.2 Module Status LED
3.3.3 DB9F Connector
Figure 3-4. DB9F Pinout Orientation
Status Description Comments
Off Not initialized Anybus state = SETUP or NW_INIT
Steady Green Initialized Anybus module has left the NW_INIT state
Flashing Green Initialized, diagnostic
event(s) present Extended diagnostic bit is set
Steady Red Exception error Anybus state = EXCEPTION
Table 3-8. Module Status LED Descriptions
Pin Signal Description
1 -
2 -
3 B Line Positive RxD/TxD, RS485 level
4 RTS Request to send
5 GND Bus Ground (isolated)
6 +5 V Bus Output +5 V termination power (isolated, short-circuit protected)
7 -
8 A Line Negative RxD/TxD, RS485 level
9 -
Housing Cable Shield Internally connected to the Anybus protective ground via cable
shield filters according to the PROFIBUS standard.
Table 3-9. PROFIBUS Connector Pinout Descriptions
12345
6789

10 Visit our website www.RiceLake.com
882IS Interface Option Cards
3.4 Modbus TCP
Figure 3-5. Modbus TCP Module
3.4.1 Network Status LED
A test sequence is performed on this LED during startup.
3.4.2 Module Status LED
A test sequence is performed on this LED during startup.
LED State Description
Off No power or no IP address
Green Module is in process active or idle state
Green, flashing Waiting for connections
Red Duplicate IP address, FATAL event
Red, flashing Process active timeout
Table 3-10. Network Status LED Descriptions
LED State Description
Off No power
Green Normal operation
Red Major fault; module is in EXCEPTION state (or FATAL event)
Red, flashing Minor fault in diagnostic object; IP conflict
Table 3-11. Module Status LED Descriptions
Modbus Connector
Module Status LED
Network
Status LED
Link/Activity LED
Note
Note

© Rice Lake Weighing Systems ● All Rights Reserved 11
Status LEDs and Connectors
3.4.3 Link/Activity LED
3.4.4 Modbus TCP Connector
The Modbus interface supports 10/100 Mbps, full or half duplex operation.
The Modbus TCP connection uses holding registers to transfer data between the
882IS and the PLC or primary device. See Section 4.0 on page 15 for output and
input data structure.
3.5 DeviceNet
Figure 3-6. DeviceNet Module
3.5.1 Network Status LED
LED State Description
Off No link, no activity
Green Link established
Green, flickering Activity
Table 3-12. Link/Activity LED Descriptions
LED Status Description
Off Not powered or not online
Steady Green Online, connected
Flashing Green Online, not connected
Steady Red Critical link failure
Flashing Red Connection time-out
Table 3-13. Network Status LED Descriptions
12345
DeviceNet Connector
Module Status LED
Network
Status LED

12 Visit our website www.RiceLake.com
882IS Interface Option Cards
3.5.2 Module Status LED
3.5.3 DeviceNet Connector
See Figure 3-6 for connector pinout orientation.
LED Status Description
Off No power to module
Steady Green Module operational
Flashing Green Missing or incomplete configuration, device
needs commissioning
Steady Red Unrecoverable fault
Flashing Red Recoverable fault
Table 3-14. Module Status LED Descriptions
Pin Signal Description
1 V- Negative bus supply voltage
2 CAN_L CAN low bus line
3 SHIELD Cable shield
4 CAN_H CAN high bus line
5 V+ Positive bus supply voltage
Table 3-15. DeviceNet Connector Pinout

© Rice Lake Weighing Systems ● All Rights Reserved 13
Status LEDs and Connectors
3.6 EtherCAT
Figure 3-7. EtherCAT Module
3.6.1 Run Status LED
3.6.2 Error Status LED
Status Description
Off CoE device in INIT state or has no power
Steady green CoE device in operational state
Flashing green CoE device in pre-operational state
Green, single flash CoE device in safe-operational state
Red Fatal event, forcing the bus interface to a physically
passive state; contact technical support.
Table 3-16. Run Status LED Descriptions
Status Description
Off No error (or no power)
Red, blinking Invalid configuration, state change received from primary is
not possible due to invalid register or object settings
Red, double flash Application (sync manager) watchdog timeout
Red Fatal event, forcing the bus interface to a physically passive
state; contact technical support.
Table 3-17. Error Status LED Descriptions
Connector Status LEDs
Error Status LED
Run Status
LED
EtherCAT Connectors

14 Visit our website www.RiceLake.com
882IS Interface Option Cards
3.6.3 Port Status LEDs
3.6.4 EtherCAT Ports
The EtherCAT interface supports 10/100 Mbps, full or half duplex operation. Port
1 is for incoming communications and Port 2 is for outgoing communications.
Status Description
Off Link not sensed (or no power)
Green Link sensed, no activity
Green, flickering Link sensed, activity detected
Table 3-18. Port Status LED Descriptions

© Rice Lake Weighing Systems ● All Rights Reserved 15
Data Structure
4.0 Data Structure
The data structure describes the output and input format that is used by the PLC
or primary device to communicate with the 882IS.
Decimal Point Handling
Integer commands return no decimal point information to the primary. All values
are 32-bit with an assumed decimal place. Floating point commands support
decimal point information with no special handling.
Example: A value of 750.1 displayed on unit is returned to the primary as 7501.
4.1 882IS Output
The output data is what is sent to the PLC or other primary device. Some of the
data is sent continuously where other data is dependent on what input data is
sent from the PLC.
Modbus
Address Word Description
40257 0 Error status; Section 4.1.2 on page 17
40259 1 882IS status; Section 4.1.1 on page 16
40261 2 Gross weight
40263 3 Tare weight
40265 4 Net weight
40267 5 Accumulator value
40269 6 Current mode
0 = primary, 1 = secondary
Table 4-1. 882IS Output

16 Visit our website www.RiceLake.com
882IS Interface Option Cards
4.1.1 882IS Status Bits
Word Bit
882IS Status Data
Value = 0 Value = 1
00 In weigh mode In setup mode
01 Weight OK Weight over/Under range
02 Not in zero band In zero band
03 Not used Not used
04 Not in warmup In warmup
05 Heartbeat low Heartbeat high
06 Not used Not used
07 Not used Not used
08 Not used Not used
09 Gross positive value Gross negative value
10 Tare positive value Tare negative value
11 Net positive value Net negative value
12 No motion Scale in motion
13 Tare not acquired Tare acquired
14 Tare not entered Tare entered
15 Unused Unused
16 Unused Unused
17 Unused Unused
18 Unused Unused
19 Unused Unused
20 Unused Unused
21 Unused Unused
22 Unused Unused
23 Unused Unused
24 Unused Unused
25 Unused Unused
26 Unused Unused
27 Unused Unused
28 Unused Unused
29 Unused Unused
30 Unused Unused
31 Unused Unused
32 Unused Unused
Table 4-2. 882IS Status Bits
