Rice Lake RS-130 User manual

PN 85772
RS-130
Price Computing Retail Scale
Version 1.0
Operation Manual

© 2004 Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America.
Specifications subject to change without notice.
Version 1.0, September 2004
Contents
About This Manual................................................................................................................................... 1
1.0 Introduction.................................................................................................................................. 1
1.1 Start-up Self Check............................................................................................................................ 1
1.2 Power Supply..................................................................................................................................... 1
1.3 Battery Recharging............................................................................................................................. 1
1.4 Setting the Auto-Off Feature............................................................................................................... 1
2.0 Operation...................................................................................................................................... 2
2.1 RS-130 Keypad.................................................................................................................................. 2
2.2 Display Windows and Annunciators.................................................................................................... 3
2.3 Error Messages .................................................................................................................................. 3
RS-130 Limited Warranty......................................................................................................................... 4

2 R-30 Operation Manual

Introduction 1
About This Manual
This manual contains operating procedures for the
RS-130 retail scale and provides you with all the
information necessary for set up and operation.
This manual is organized based on the procedures you
will likely follow when setting up and using your
retail scale.
When using this manual, front panel keys are shown
in
BOLD
characters.
Authorized distributors and their
employees can view or download this
manual from the Rice Lake Weighing
Systems retail distributor site at
www.ricelakeretail.com
.
1.0 Introduction
The RS-130 retail scale offers practical solutions for a
full range of point-of-sale weighing and price
computing applications. Its compact design makes it
easy to transport and the customer display on the rear
of the RS-130 offers extra convenience.
Standard features of the RS-130 include:
•NTEP-certified Legal-For-Trade
•Customer display on rear of unit
•Operates on 110 VAC or 6V internal battery
•Configurable for lb, kg or oz
•Calculates customer change
1.1 Start-up Self Check
When you turn on the scale with the ON/OFF switch,
which is located on the bottom of the scale, the main
program provides the following display check. The
display turns on and shows the total capacity in the
WEIGHT display. Counts from 1 to 9 in each display
window, displays the total capacity in the
WEIGHT
display again, and displays
0.00
for operation.
1.2 Power Supply
The RS-130 can use power supplied by either a
plug-in 110 VAC or the internal sealed lead-acid
rechargable battery with a life expectancy of five years
under normal use.
•AC - 110V/60Hz ±10%.
• DC - 6V / 25mA; P=0.2W (max) 4Ah
•If AC power is available, use the supplied
power cord.
1.3 Battery Recharging
The battery has 100+ hours of use before it needs
recharging. When the battery is low, the
TOTAL $
display shows -LO-
and there is a continuous beep.
Press the
CLEAR
key to remove
-LO-
and end the
beep. After the initial warning of low battery, the scale
has aproximately two to three hours of battery life left.
Every 30 minutes a beep sounds and
TOTAL $
display shows
-LO-.
If the battery is not charged, the
TOTAL $ display shows -OFF-
and the scale beeps
continuously. Turn the scale off and recharge the
battery. Allow eight to ten hours to fully charge. Table
1-1 describes the meaning of the Charge LED colors.
1.4 Setting the Auto-Off Feature
NOTE:
Work inside scale enclosure not required.
1. Turn on the scale and press and hold the
CHANGE
key until
6.3
(version) shows in the
WEIGHT display (approximately three
seconds).
2. Press and hold the
ZERO
key until the
WEIGHT display shows SEtUP
(approx.
three seconds).
3. Press the
3
key,
WEIGHT display shows
USUAL
.
4. Press the
2
key to enter the Auto-Off mode.
WEIGHT display shows -30-
(minutes).
5. Use the CLEAR key to select -30-, -15-, -5-,
-OFF-.
6. Press the
CHANGE
key to confirm setting.
Scale will automatically restart.
LED Color Description
Red Initial connection
Orange Charging
Green Fully-charged
Table 1-1. Battery Charge LED’s

2 RS-130 Operation Manual
2.0 Operation
The following section describes the front panel keys, annunciators, and display functions (displayed in Figure
2-1 on page 3) of the RS-130. Key functions are described in Table 2-1 below. To turn on the scale, toggle the
On/Off switch located on the bottom of the scale.
2.1 RS-130 Keypad
Key Function/Description
M1 - M8 8 direct PLU’s for saving different unit prices or figures. For example: to save 7.50 in the
M8 setting,
1. Key in 750
2. Press and hold the M8 key until the scale beeps (approximately three seconds)
• Every time you press the M8 key the UNIT PRICE $ display shows 7.50
• To change the setting of one of the memory keys, follow the steps above.
PLU Set up to 89 different indirect PLU’s. (10-99 allowed)
1. Key in the unit price
2. Press the PLU key once
3. Enter the first digit of the PLU number, when entering the second digit hold the
button until the scale beeps (approximately three seconds)
• The PLU is displayed in the WEIGHT display
• To recall a PLU, press PLU and enter the number you want to recall.
• To change the PLU settings, key in the new unit price and follow steps 2 - 3
UNIT This key selects the unit of measure (kg, lb or oz) in weighing mode.
1. Press the UNIT key, WEIGHT display shows ch9-
2. Press: 1 to select kg, 2 to select lb or 3 to select oz. (default is lb)
• The annunciator will flash above the selected unit of measure in the
UNIT PRICE $ display.
TARE Acquire the net weight value of the object being weighed.
1. Place the package or container on the platter, the weight appears on the
WEIGHT display.
2. Press the TARE key, the WEIGHT display returns to zero. A cursor appears above
NET in the WEIGHT display.
CHANGE Compute the amount of change to be given back to a customer for their purchase. For
example: when TOTAL $ shows 15.00 and you receive $20.00 from the customer;
Press the CHANGE key and enter 2000 . The
UNIT PRICE $
display shows C 5.00
(change due). The TOTAL $ display shows 20.00 (cash received).
ZERO Resets gross weight to zero.
CLEAR
Press the CLEAR key to erase the figure shown in the UNIT PRICE $ display.
• Sets the decimal point.
0 - 9 Numeric
Keys
Enter the numeric value required.
• Use the numeric keys to enter the price-per-unit, PLU number, cash received
Press and hold the 0 key to show the battery voltage in the WEIGHT display.
• 6.1 - 6.5 means the battery is fully-charged.
• Less than 5.6 means the battery is in low-charge.
• Press the CLEAR key to return the display to normal operating mode.
Table 2-1. Function Keys

Operation 3
2.2 Display Windows and Annunciators
Figure 2-1. Front Display Annunciators
2.3 Error Messages
Table 2-3 describes error messages that may be shown on the RS-130 display.
Display Window Description
WEIGHT
Displays the weight of the object on the platter
UNIT PRICE $
Displays the unit price of the object on the platter
TOTAL $
Displays the total amount owed (weight multiplied by unit price)
Table 2-2. Display Windows
Indicates scale
is in NET mode Indicates scale
is at ZERO Indicates weight
is in either lb, kg,
or oz
Status of battery charging
Red: initial charge
Orange: charging
Green: fully charged
Indicates the
amount of cash
received
Indicates the
amount of
change due
Display Description Corrective Action
WEIGHT
display shows
"Err-1"
IC93C66 data-loss or
IC93C66 damaged/faulty Contact your nearest RLWS dealer
WEIGHT
display shows
"Err-3
"
At power-up, the weight on
the platter is more than 5% of
the maximum capacity
Remove the weight from the scale, or to under 5% of capacity and
restart the scale
TOTAL $
display shows
"E"
The total price value is larger
than 9999.99 Remove the measured object from the platter and press
CLEAR to clear
the unit price setting
Table 2-3. Error Messages and Troubleshooting

4 RS-130 Operation Manual
RS-130 Limited Warranty
Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a
Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by
the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in
materials and workmanship for one year.
RLWS warrants that the equipment sold hereunder will conform to the current written specifications authorized
by RLWS. RLWS warrants the equipment against faulty workmanship and defective materials. If any equipment
fails to conform to these warranties, RLWS will, at its option, repair or replace such goods returned within the
warranty period subject to the following conditions:
•Upon discovery by Buyer of such nonconformity, RLWS will be given prompt written notice with a
detailed explanation of the alleged deficiencies.
•Individual electronic components returned to RLWS for warranty purposes must be packaged to prevent
electrostatic discharge (ESD) damage in shipment. Packaging requirements are listed in a publication,
“Protecting Your Components From Static Damage in Shipment,” available from RLWS Equipment
Return Department.
•Examination of such equipment by RLWS confirms that the nonconformity actually exists, and was not
caused by accident, misuse, neglect, alteration, improper installation, improper repair or improper
testing; RLWS shall be the sole judge of all alleged non-conformities.
•Such equipment has not been modified, altered, or changed by any person other than RLWS or its duly
authorized repair agent.
•RLWS will have a reasonable time to repair or replace the defective equipment. Buyer is responsible for
shipping charges both ways.
•In no event will RLWS be responsible for travel time or on-location repairs, including assembly or
disassembly of equipment, nor for repairs made by others.
THESE WARRANTIES EXCLUDE ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WITHOUT LIMITATION WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. NEITHER RLWS NOR DISTRIBUTOR WILL, IN ANY EVENT, BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
RLWS AND BUYER AGREE THAT RLWS’S SOLE AND EXCLUSIVE LIABILTY HEREUNDER IS LIMITED
TO REPAIR OR REPLACEMENT OF SUCH GOODS. IN ACCEPTING THIS WARRANTY, THE BUYER
WAIVES ANY AND ALL OTHER CLAIMS TO WARRANTY.
SHOULD THE SELLER BE OTHER THAN RLWS, THE BUYER AGREES TO LOOK ONLY TO THE SELLER
FOR WARRANTY CLAIMS.
No terms, conditions, understanding, or agreements purporting to modify the terms of this warranty shall have
any legal effect unless made in writing and signed by a corporate officer of RLWS and the Buyer.
© 2004 Rice Lake Weighing Systems, Inc. Rice Lake, WI. All Rights Reserved.
RICE LAKE WEIGHING SYSTEMS • 230 WEST COLEMAN STREET • RICE LAKE, WISCONSIN 54868 USA
