Richway & Fuji Bio BioAcoustic Mat User manual

BIOACOUSTIC MAT™
USER MANUAL
Vibro Acoustic Therapy system
Sleep, Relax, Renew and Energize
RICHWAY & FUJI BIO INC.
1314 South King Street Suite 520, Honolulu, HI 96814 USA Tel: [phone] Toll-Free: 855-338-6410 Fax: [phone]
www.richwayandfujibio.com

1
A. Safety Precautions
Read and follow all of the instructions in this manual before using. Proper use of the BioAcoustic Mat™ will
prevent harm to the user and damage to private property. Only use the BioAcoustic Mat™ for the purposes
specied in this manual.
Danger, to reduce the risk of electrocution:
Do not use or store near water. If the BioAcoustic Mat™ gets wet, unplug it immediately.
Do not alter, change, modify or disassemble the product.
Use proper voltage.
Do not use if the power cord or plug appears damaged.
Do not expose the cord to hot material.
Warning, to reduce the risk or injury or product malfunction:
If you do not feel well due to the BioAcoustic Mat™, stop using it and consult a physician.
Unplug the BioAcoustic Mat™ when not in use or when cleaning.
Never leave the BioAcoustic Mat™ unattended.
Only competent adults should operate the BioAcoustic Mat™.
The elderly and children should be monitored.
Do not use outdoors.
Do not pull or yank on the power cord.
Do not stand or place heavy objects on the BioAcoustic Mat™.
Do not place sharp objects on or near the BioAcoustic Mat™.
Avoid external shocks to the device, such as dropping or striking it with force.
Consult your doctor prior to using this product if:
You are pregnant, have a pacemaker, or have any concerns regarding your health.
Never use this product directly on swollen or inamed areas or skin eruptions.
Stop using the BioAcoustic Mat™ if it is not functioning properly.
Call Customer Service at [phone].
BioAcoustic Mat™
User Manual
Vibroacoustic Therapy System.
Sleep, Relax, and Renew
A. Safety Precautions 1
B. Soundtracks 2
C.Product Components 4
D.Product Features 5
E. Setting up the BioAcoustic Mat™ 6
F. Product Operation 6
G.Using an External Sound Source 7
H.Using Headphones 8
I. Useful Information 8
J. Detailed Specications and Standards 9
K. Customer Service and Warranty 9
L. Product Warranty 10
Contents
I BIoAcoustIc MAt™

2 3
I BIoAcoustIc MAt™
B. Soundtracks
Vibroacoustic Conguration
(SET 1)ENERGIZE
(SET 3)SLEEP
Guitar, piano, digital sound, bass
Mono and binaural high alpha and beta
entrainment
1. Energize (track length 5:18)
Low pitch 41 Hz - 73 Hz
Peak wavelength 41Hz
2. Energize (track length 4:40)
Low pitch 36 Hz - 61 Hz
Peak wavelength 41Hz
3. Energize (track length 5:55)
Low pitch 36 Hz - 65 Hz
Digital sound
Mono and binaural delta entrainment
1. Sleep (track length 4:58)
Low pitch – 32 Hz
2. Deep sleep (track length 5:00)
Low pitch – multiple between 27.5 – 44 Hz
3. Deep sleep (track length 6:05)
Low pitch – multiple between 34 – 52 Hz
(SET 4)STRESS RELIEF
Piano, ute, digital sound
1. Stress relief (track length 3:30)
Low frequencies – 36 Hz – 41 Hz
Mono and binaural theta entrainment 4 Hz – 6 Hz
2. Stress relief (track length 3:00)
Low frequencies – 32 Hz – 65 Hz
Mono and binaural theta entrainment 4 Hz – 6 Hz
3. Stress relief (track length 3:40)
Low frequencies – 27.5 Hz – 55 Hz
Mono entrainment at delta, theta and alpha.
Binaural theta entrainment 4 Hz – 6 Hz
(SET 2) RELAX
Digital ocean, surf, and nature sounds
1. Relax (track length 5:15)
Low pitches centered around 40 Hz, 52 Hz and
68 Hz (34 Hz)
Mono and binaural alpha and theta entrainment
(5 Hz - 8 Hz)
2. Relax (track length 4:40)
Low pitch – 36 Hz
Binaural alpha, and theta entrainment
3. Relax (track length 5:35)
Low pitch – 32 Hz
Binaural alpha, and theta entrainment
Delta wave (0.5-4.0 Hz)
Delta waves are associated with the deepest levels of
physical relaxation. Delta is the rhythm of dreamless
sleep and its presence usually corresponds with physical
rejuvenation and healing.
Theta wave (4.0-7.0 Hz)
Theta waves reflect a state of mind that is attuned to
intense creativity, visualization, and subconscious problem
solving in a non-sleep state, as well as emotional healing in
the sleep state.
Theta waves are produced during deep meditation,
dreaming and daydreaming.
Alpha wave (7.0-12.0 Hz)
Alpha waves indicate an alert state with a quiet mind (e.g.
a person who has completed a task and sits down to rest is
often in an Alpha state).
Increased Alpha is often present in the brainwaves of
people who practice meditation, yoga, and tai chi.
Beta wave (12.0-27.0 Hz)
Beta waves are associated with normal waking states that
we experience from day to day at work and play. In Beta
states, we are highly alert and focused – busy computing,
arranging, and organizing – making sense of the external
world.
Beta is increased in moments of stress or anxiety, enabling
us to manage situations and solve immediate problems.

4 5
I BIoAcoustIc MAt™
C. Product Components
BioAcoustic Mat™ Professional and Single will come with the following components.
Mat
Controller Power adapter
& Audio cable
Bag User’s Guide
D. Product Features
BioAcoustic Mat™
1. Display window
2. Track selection button
3. Vibration control button
4. Power button
5. Volume button
6. Timer button
7. Power adapter
8. Audio cable
Controller
1. Stereo audio speaker
2. Low frequency generator
3. Power adapter jack
4. Controller jack
5. Headphone jack

6 7
I BIoAcoustIc MAt™
E. Setting up the BioAcoustic Mat™
F. Product Operation
Selecting the Soundtrack
●
When using the BioAcoustic Mat™ with any heating mat, be sure to use a thin blanket
between the two.
Warning
●
Stretching is a natural characteristic of new vinyl, and the rst few times you use the mattress, some
stretching will occur. The product is simply stretching under your body weight, and this is normal for
the rst few uses.
Notice
1. Lay the BioAcoustic Mat™ on a at surface.
2. Plug the controller into the controller jack located on the
front top left of the BioAcoustic Mat™.
3. Connect the power adapter to the power adapter jack.
Then plug in the BioAcoustic Mat™ to an outlet.
1. Press and hold the power button down for one second to turn on the unit. The
BioAcoustic Mat™ will automatically start on the Energize therapy soundtrack. It will be
displayed on the controller’s display window. You can adjust the intensity or volume to
the desired level. (See page 11)
2. If you leave it on the Energize therapy session, the BioAcoustic Mat™ will
automatically play the three Energize therapy soundtracks.
3. To play Energy therapy session track two, press the Energize button again.
4. To play Energy therapy session track three, press the Energize button again.
5. When you press the Energize therapy session button after track three, the Energize
therapy session will reappear on the display screen. Energize tracks one, two, and
three will begin to play on repeat.
Controller jack
Power adapter jack
●
If you do not set the timer or change the soundtracks, the session will repeat itself.
Notice
Adjusting the vibration’s intensity
The BioAcoustic Mat™ provides low frequency vibrations. To increase the intensity, press the + button. To decrease the
intensity, press the – button.
Adjusting the volume
When changing the volume, press the + Volume button to increase the volume, and press the – Volume button to decrease
the volume.
Timer
Press the timer button to select your desired run time.
The BioAcoustic Mat™ can be set to run for 15, 30, 45, or 60 minutes.
The BioAcoustic Mat™ will automatically shut down after desired time.
Display Shows
First Press 60 minutes
Second Press 45 minutes
Third Press 30 minutes
Fourth Press 15 minutes
Fifth Press Timer Off
G. Using an External Sound Source
Play your own music with the BioAcoustic Mat™.
Operating
1. Using the 3.5mm cable (audio cable included), plug the
cable from your audio device into the external sound
input located on the left side of your BioAcoustic Mat™
controller.
2. The BioAcoustic Mat™ will start playing the music from
your audio device. Adjust the volume on the connected
device to near maximum. Then use the Volume + and -
buttons on the controller to adjust the volume level.
External sound input

8 9
I BIoAcoustIc MAt™
H. Using Headphones
You can connect your headphones to the BioAcoustic Mat™ and listen to music
without disturbing others.
I. Useful Information
●
Before cleaning the product, be sure to turn off the power and unplug the power cord.
●
When wiping the outside of the product, use a damp cloth with soap or mild detergent.
●
Do not use strong chemical detergent, as it may damage the plastic or cushion area.
●
Do not stand or place heavy objects on the BioAcoustic Mat™.
● Store in a cool dry area.
Operating
1. Connect your headphones to the
headphone jack located on the
front top left of the BioAcoustic
Mat™. Adjust the volume with
the Volume + and – buttons on
the BioAcoustic Mat™ controller.
Headphone jack
J. Detailed Specications and Standards
BioAcoustic Mat™ PROFESSIONAL
Product Name BioAcoustic Mat™
Model Name BTC 7000MX™ Professional
Country of Manufacture Republic of Korea
Product Size ( L x W x H) 73” X 28” X 3” (1850 X 700 x 80 mm)
Serial Number Separately marked
Weight 32 lbs
Adapter Input(100-240V~50/60Hz 0.5A MAX), Output(12V, 2500mA)
Manufacturer’s Company Name
and Address
Company Name: R&L Co., Ltd.
Address: (Soha-dong, Ace Gwangmyung Tower, 11th oor) 108, Haan-ro, Gwangmyeong-si, Gyeonggi-do, Republic
Item Contents
BioAcoustic Mat™ SINGLE
Product Name BioAcoustic Mat™
Model Name BTC 7000MX™ Single
Country of Manufacture Republic of Korea
Product Size ( L x W x H) 79” x 39” X 3” (2000 x 1000 x 80 mm)
Serial Number Separately marked
Weight 37 lbs
Adapter Input(100-240V~50/60Hz 0.5A MAX), Output(12V, 2500mA)
Manufacturer’s Company Name
and Address
Company Name: R&L Co., Ltd.
Address: (Soha-dong, Ace Gwangmyung Tower, 11th oor) 108, Haan-ro, Gwangmyeong-si, Gyeonggi-do, Republic
Item Contents
●
Use high quality headphones to get the most out of your BioAcoustic Mat™ experience.
Notice
K. Customer Service and Warranty
Customer Center Information
If your BioAcoustic Mat™ is not working properly call our
Customer Service Center.
CUSTOMER SERVICE CENTER
North America
Richway & Fuji Bio Inc.
Tel: [phone]
Toll-Free: 1-855-338-6410
(USA, Canada, Guam, Saipan)
Homepage: www.richwayandfujibio.com
Email: [email protected]
How to Discard a Product
Please follow your city or state laws regarding disposing or
recycling your BioAcoustic Mat™.
FCC Notice
This equipment complies with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
Operation is subject to the following two (2) conditions:
(1) This device may not cause harmful interference; and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.

DOC# 7100-003-E REV 2 | PUBLISHED 02052019
Hear and Feel
the therapy
Music and Vibration
Richway BioAcoustic Mat
Vibroacoustic Therapy System User Manual
RICHWAY & FUJI BIO INC. 1314 South King Street Suite 520, honolulu, hi 96814 uSA
tel: [phone] toll-Free: [phone] FAX: [phone] www.richwAyAndFujibio.com
SHAOxINg RICHWAY TRAdINg CO., LTd. room 2703, ZhongyAng building, yumin roAd, KeqiAo diStrict, ShAoXing, ZhejiAng, chinA 312000
tel: [phone] FAX: [phone]
RICHWAY & LIFe JApAN CORp. 2-6-41 nAKAhAtA, onojo-Shi, FuKuoKA, jApAn 816-0921 tel: [phone] FAX: [phone]
R&L CORpORATION 11F, Ace gwAngmyeong tower b, 108 hAAn-ro, gwAngmyeong-Si, gyeonggi-do, KoreA 14319
tel: [phone] FAX: [phone] www.richwAyKoreA.com
L. Product Warranty
Richway & Fuji Bio warrants the covered product to be free from defects and malfunctions at the time sold. “Defects” as used in this warranty, is
dened as imperfections, which impair or impede the function and use of the product.
How Long the Warranty Lasts
This warranty lasts 1 year from the date of delivery. This warranty extends to the original purchaser only. Coverage terminates if you sell or
otherwise transfer ownership.
What This Warranty Covers
This warranty covers any defects or malfunctions in the electronic components and top cover replacement. If Richway & Fuji Bio determines that
such goods are defective, within the period of this warranty, Richway & Fuji Bio will repair or replace the parts free of charge for the rst year. Repair
or replacement is the sole and exclusive remedy available to the buyer and shall constitute the fulllment of all Richway & Fuji Bio obligations in
respect to the goods furnished under this agreement.
What This Warranty Does Not Cover
This warranty does not cover abuse, misuse, natural disaster, insufcient or excessive electrical supply, ordinary wear, fading, failure to follow
instructions and improper maintenance. Richway & Fuji Bio shall not be liable for any incidental or consequential damages as a direct result of
negligence or misuse. This warranty does not extend to the purchase of opened, used, repaired, repackaged, and/or resealed products, including
but not limited to sale of such products on internet sites and/or sales of such products on internet auction sites and/or sales of such products
by surplus or bulk re-sellers. Any warranties or guarantees shall immediately cease and terminate as to any products or parts thereof which are
repaired, replaced, altered, or modied, without the prior express and written consent of Richway & Fuji Bio.
How to Get Service
To obtain service under this warranty, contact your local Customer Service Center and provide the purchaser’s name, RI (Richway Invoice) number,
and a detailed description of the problem you are experiencing. They will provide you with a return merchandise authorization number (RMA). This
number is required and must be placed in a visible area on the front of the package. Ship your product postage paid, include a copy of the original
sales slip, credit card receipt or other proof of the date of the original retail purchase. If servicing within the rst two (2) months, we will send you a
prepaid shipping label to cover your shipping costs. If servicing from the third month and on, the customer is responsible for shipping costs to return
the product for repair or replacement. We will cover the shipping costs to return the product back to the customer.
How Do State Laws Apply
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. Any implied warranties last the
duration of this warranty. Some states do not allow limitations on how long an implied warranty lasts and some states do not allow the exclusion or
limitation of incidental or consequential damages, so the limitations or exclusions may not apply to you.
Product Name
Place of
Purchase
Customer
Information
BioAcoustic Mat™ Model Name BTC 7000MX™
Warranty Period 1 year from delivery date Serial Number
Date of purchase Place of Purchase
Name Purchase price
10
