Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
System Specifications
General Specifications
Warm-Up Time Less than 360 seconds
Paper Weights 16lb. – 40 lb. Bond
50lb. – 80 lb. Cover
90lb. – 110 lb. Index
Standard Paper Capacity 3,000 sheets
Tray 1: 2 x 1,000-Sheet Tray
Tray 2: 1 x 500-Sheet Tray
Tray 3: 1 x 500-Sheet Tray
Power Requirements 208 – 240V, 50/60 Hz, 20A
(dedicated outlet)
Power Consumption Pro 906EX/Pro 1106EX:
(Engine/FIN/LCT) Less than 3,500W
Pro 1356EX: Less than 4,000W
Dimensions (WxDxH) 34.3" x 33.9" x 58.2" (engine)
Weight 672.4 lbs. (engine)
System Specifications
Speed Pro 906EX: 90 pages-per-minute
Pro 1106EX: 110 pages-per-minute
Pro1356EX: 135 pages-per-minute
First Copy Pro 906EX: 3.5 seconds
Pro 1106EX: 3.2 seconds
Pro 1356EX: 3.0 seconds
Throughput Size 5.5" x 8.5" to 13" x 18"
HDD Capacity 320 GB (160 GB x 2)
Memory Capacity 256 MB (standard)
512 MB (maximum, with printer
option)
Reduction/Enlargement 25% – 400% (1% increments)
System Accessories
Document Feeder
Original Paper Weights 11 – 34 lb. Bond (simplex)
14–28 lb. Bond (duplex)
RT5000 LT/LCT Large Capacity Tray
Paper Sizes Supported 5.5" x 8.5" to 8.5" x 11"
Paper Capacity 1,000 sheets (Tray 4)
1,000 sheets (Tray 5)
2,550 sheets (Tray 6)
Paper Weights 16 lb. Bond – 80 lb. Cover (Tray 4/5)
16lb. Bond – 90 lb. Index (Tray 6)
Dimensions (WxDxH) 21.2" x 28.8" x 38.6"
Weight 194 lbs.
RT5010 DLT/LCT Large Capacity Tray
Paper Sizes Supported 5.5" x 8.5" to 13" x 18"
Paper Capacity 1,000 sheets (Tray 4)
2,000 sheets (Tray 5)
1,000 sheets (Tray 6)
Paper Weights 16 lb. Bond – 80 lb. Cover
(Tray 4/5/6)
Dimensions (WxDxH) 34.7" x 28.8" x 38.6"
Weight 364 lbs.
SR5000 100-Sheet Finisher
Paper Weights 16 lb. Bond – 80 lb. Cover
Shift Tray 3,000 sheets (8.5" x 11")
1,500 sheets (8.5" x 14"/11" x 17")
1,000 sheets (13" x 18")
Proof Tray 500 sheets (8.5" x 11")
250 sheets (8.5" x 14" or larger)
Staple Capacity 100 sheets (based on 8.5" x 11")
Dimensions (WxDxH) 31.5" x 28.7" x 38.5"
Weight 165 lbs.
BK5000 Saddle Stitch Unit
Paper Sizes Folded 8.5" x 11" to 12" x 18"
Paper Weights Folded 20 – 24 lb. Bond
Dimensions (WxDxH) 23.6" x 28.7" X 38.5"
Weight 154 lbs.
CI5010 Cover Interposer
Paper Sizes Supported 5.5" x 8.5" to 13" x 18"
Paper Capacity 2 x 200 sheets
Paper Weights 17lb. Bond – 80 lb. Cover
Dimensions (WxDxH) 27.9" x 28.7" x 50"
Weight 99.2 lbs.
BY5000 Multi Bypass Tray
Paper Capacity 500 sheets (based on 8.5" x 11")
Paper Sizes Supported 5.5" x 8.5" to 12" x 18"
(RT5000)
5.5" x 8.5" to 13" x 18"
(RT5010)
PU5000 Punch Unit
Punch Type 2or 3 holes (user-selectable)
Weights Punched 16lb. Bond – 90 lb. Index
Systems Supported Pro 906EX/Pro 1106EX
Ring Binder RB5000
Paper Sizes Supported 8.5" x 11" (LEF only)
Maximum Binding 100 sheets/booklet
Capacity
Ring Sizes Supported 50-sheet/100-sheet
Capacity of Ring Bind 2–100 sheets
Paper Weight Punched 17lb. Bond – 80 lb Cover
Paper Weight Bound 17 lb. Bond – 80 lb Cover
Dimensions (WxDxH) 34.25" x 28.7" x 38.5"
Power Requirements 110/115V, 50/60 Hz
Weight 319.6 lbs.
Perfect Binder GB5000
Maximum Booklet 200 sheets (400 pages in
Capacity duplex mode)
Paper Sizes Supported Width 10.11" – 12.59", Length
7.16" – 9"; 17 lb. Bond – 90 lb.
Index (Body Pages); Width 10.11"
–13", Length 14.3" – 19.20",
17lb. Bond – 80 lb. Cover (Cover
Pages); Width 10.1" – 13",
Length 14.3" – 19.28"
(Finished Booklet Size)
Dimensions (WxDxH) 42.91" x 31.14" x 54.60"
Interposer Tray Capacity: 2 x 200 sheets
Paper Weight: 24 lb. Bond
Power Requirements 220V,50/60 Hz
Weight 738.5 lbs.
GBC StreamPunch III
Punch Type Customer-replaceable die sets
Paper Size Supported 8.5" x 11", long edge feed
(11" side only)
Systems Supported Ricoh Pro 906EX/Pro 1106EX/
Pro 1356EX
Dimensions (WxDxH) 12" x 28.5" x 38.5"
Weight 154 lbs.
BK5010 Booklet Maker
Paper Sizes Supported 8.1" x 10.8" (min.) to
12.6" x 18" (max.)
Paper Weights 16 lb. Bond – 80 lb. Cover
(on-line mode)
Up to 172 lb. Cover
(off-line mode)
Folding Specifications 1 – 30 sheets (stapled, based on
20 lb. Bond)
1–2sheets (non-stapled)
Weight 286.6 lbs.
Power Requirements 110/115V,50/60 Hz
Dimensions (WxDxH) 55.9" x 27.6" x 35.4"
Additional Options CF5010 Cover Feeder
TR5010 Trimmer Unit
BF5010 Book Fold Unit
BK5010 Rail Unit
Network Connectivity Options
Printer/Scanner Kit Type 1356
Windows Drivers (RPCS) Windows 2000, XP, Server 2003
Vista
Windows Drivers (PCL5e) Windows 2000, XP, Server 2003,
Vista
Windows Drivers (PCL6) Windows 2000, XP, Server 2003,
Vista
Windows Drivers (Adobe Windows 2000, XP, Server 2003,
PostScript3 option) Vista
Utilities Supported Web Image Monitor,
Web SmartDeviceMonitor,
SmartDeviceMonitor, Printer Utility
for Mac, IEEE 1394 Utility, USB
Printing Support, PDF Direct
Printing (through DeskTopBinder),
DeskTopBinder
Printer Options IEEE 1284 Interface, IEEE 1394
Interface, IEEE 802.11b Wireless
Interface Gigabit Ethernet, Bluetooth
Interface
Host Printing Options RA2K Integration for IPDS,
Dataworks3Support, OMS400
Scanner Specifications
Scan Speed 80 spm in black & white or color
Optical Resolution 100/150/200/300/400/600 dpi
Resolution for 100/150/200/300/400/600 dpi
Delivery Scanner
TWAIN Resolution 100 – 1200 dpi (black & white or
color)
File Formats TIFF/JPEG/PDF and High
Compression PDF
Scan-to-Email
Requirement SMTP Gateway and TCP/IP
E-mail Addresses 2,000 addresses
Maximum Addresses/Send 500 addresses
Address Support via LDAP 100 addresses
Scan-to-Folder
Protocol Support SMB/FTP/NCP
Resolution 100/150/200/300/400/600 dpi
Max. Client Folders 50
Per Send
File Types Supported Single Page TIFF/JPEG/PDF,Multi-
Page TIFF/PDF, High Compression
PDF
Security
Authentication (Windows, LDAP, Basic)
Secure Socket Layer Support
Network Protocol On/Off
SNMP v3 Support
PDF Encryption
Driver Encryption Key (PCL/RPCS Driver)
Data Overwrite Security System
Copy Data Security
Additional Options
Fiery EB-135 v 1.1 Print Controller
PrintStation 0135R MicroPress Connectivity
Copy Connect Kit Type 3260
For maximum performance and yield, we recommend
using genuine Ricoh parts and supplies.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
Digital Imaging System
Professional-Quality Output,
Production-Grade Reliability
Scan, preview and distribute full-color documents
across your organization in seconds with color
Scan-to-Email capabilities.
All three systems feature eight Trained Customer
Replaceable Units (TCRUs), which trained operators
can replace quickly and easily to maintain maximum
uptime in certain environments.
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh®and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. Windows®and Windows 2000/XP/Server 2003/Vista are registered trademarks of
Microsoft Corporation. Macintosh®is a registered trademark of Apple Computer, Inc. PCL is a registered trademark of Hewlett-Packard Company. Adobe®and
PostScript®are registered trademarks of Adobe Systems, Inc. RPCS™is a trademark of Ricoh Company, Ltd. All other trademarks are the property of their respective
owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice.
Products are shown with optional features.
www.ricoh-usa.com
R2761
production
durability
speed
Choice of Connectivity: Choose the
Printer/Scanner Kit Type 1356 to enable printing
and scanning in offices and workgroups. Or select
the EFI Fiery EB-135 v1.1 controller to streamline
digital workflow in more controlled production
environments. For environments that require
maximum workflow management, add
PrintStation 0135R Connectivity for MicroPress.
Base Unit :Pro 906EX: 90 ppm;
Pro 1106EX: 110 ppm; Pro 1356EX: 135 ppm
RT5000LT/LCT: Customize the system with your
choice of Large Capacity Trays for feeding all types
and sizes of documents, including paper sizes up
to 13" x 18".
CI5010 Cover Interposer: Energize black & white documents with preprinted
color covers or color insert sheets. Each tray holds up to 200 sheets, up to
13" x 18" in size.
ZF4000 Z-Fold Unit: Incorporate larger sheets of paper—such as
engineering specifications and schematics—into traditionally sized
presentations with the Z-Folding Unit.
New Ring Binder RB5000: Produce
finished ring-bound books
completely on-line. Users can even
open the binding to insert or
remove pages at will.
SR5000 Finisher: Staple
up to 100 sheets in
multiple positions with a
3,000-sheet finisher.
High-Speed Color Scanner: Scan black & white or
color documents rapidly,up to 80 sides-per-minute.

Create professional-quality, perfect bound books at
the touch of a button. The new Perfect Binder
GB5000 makes it easy to produce books up to 200
sheets (400 pages in duplex mode), and includes
one- or three-edge knife trimming for a clean,
attractive finish.
Use the GBC StreamPunch III to produce clean,
precisely punched documents in a range of styles.
Unprecedented Speed
The Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
systems are not only the fastest we offer—
they are among the fastest multifunction
systems available anywhere.
•Maximize productivity and throughput with copying and printing
speeds of 90, 110 and 135 pages-per-minute.
•Reduce turnaround time in centralized reproduction departments (CRDs),
in-plant printers and print-for-pay shops—especially for critical rush orders.
•Empower users in fast-paced workgroups to complete jobs quickly and
devote more time to core activities.
•Create professionally finished documents without losing valuable
production time. Finish completely bound books at the touch of a button.
•Complete high-volume runs of large, multi-page documents without
pausing to reload trays with the virtually limitless paper supply.
•Expand in-house capabilities and reduce the need for outsourcing.
The systems handle a wide variety of paper stocks and sizes, up to
13" x 18" and 80 lb. Cover.
Enhanced Reliability
Engineered to run harder and last longer,
these workhorse systems maximize uptime
and reduce downtime—even in challenging
production environments.
•Expect outstanding long-term reliability and top-notch quality—
the result of carefully considered design enhancements to the drum,
fuser and other key components.
•Automatically identify and correct multiple-sheet feeding before it
compromises efficiency with the Multi-Feed Detection System.
Flexible Finishing
Create an incredible variety of finished documents
completely in-line—without sending jobs to other
vendors or finishing output manually.
•Ricoh’s new industry-exclusive Ring Binder Unit produces ready-to-
distribute, ring-bound booklets that are seamlessly punched and
bound completely on-line.
•Create perfect-bound books up to 400 pages long (in duplex mode),
such as technical manuals, training materials and operation guides,
with the new in-line Perfect Binder.
•Handle a variety of conventional jobs with high-speed stapling,
saddle-stitching and Z-fold options.
•Significantly reduce labor costs when printing bound books with the
GBC StreamPunch™III, which offers on-line punching in a variety of patterns.
•Deliver professional-quality, saddle-stitched booklets with square-edge
folds when you add the BK5010 Production Booklet Maker and the
optional BF5010 Book Fold Unit.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
Dependable performance for your demanding workload.
The RICOH®Pro 906EX/Pro 1106EX/Pro 1356EX digital imaging
systems deliver fast performance, seamless operation, professional-
grade finishing, and more. These reliable systems produce crisp
black & white output at speeds up to 135 pages-per-minute. They
are remarkably easy to use, and they offer a full slate of high-end
finishing options. All of which makes them ideal for meeting tight
deadlines, keeping more jobs in-house and maximizing uptime.
Set up complex jobs in
seconds with the Super VGA
Color Touch Panel Display.
ProductivityQualityPerformanceDurability CopyScanPrintFinish
In-Line Ring Binding—with the new Ring Binder
RB5000—eliminates the time and expense of
inserting binding elements off-line, dramatically
saving time and labor.
Superior Security
Safeguard sensitive documents and
the system itself from unauthorized
use with a complete line of advanced
security features.
•Manage system access with internal and
external user authentication, including
options for Windows and LDAP.
•Control which features authorized
users can employ via access restriction.
•Protect data from interception,
analysis and tampering via encrypted
communication with Secure Socket
Layer (SSL) support.
•Automatically overwrite latent
information on the hard drive after
every copy, print and scan job with
the optional DataOverwriteSecurity
System (DOSS).
•Prevent Denial of Service (DoS) attacks,
reduce the risk of virus relay and defend
against user name/password theft with
the Network Protocol On/Offfunction.
•Embed an invisible masking patternin
originals that shows up if unauthorized
users attempt to copy or scan documents
on any system with this same feature.
User-Friendly Design
The Ricoh Pro 906EX/Pro 1106EX/
Pro 1356EX systems are easy to
operate, whether you are the
newest workgroup member or a
seasoned production professional.
•Navigate to the exact copy or scan features you need
in moments with the help of the Super VGA Color Touch
Panel Display, which offers large graphics and an intuitive
menu design.
•Eliminate errors by previewing and approving thumbnails of
scanned documents before final output or e-mail distribution.
•Accommodate last-second document changes right at the
system. Use creep adjustment to improve registration of
booklets. Mix one- and two-sided originals without scanning
blank pages. Or use Bates Numbering to stamp documents
sequentially as they arescanned and output.
•Perform administrative tasks remotely with the Web Image
Monitor utility, which makes it easy to check toner and
paper levels, change print queues, merge jobs and receive
error notifications by e-mail.
•Automatically report usage meter data with the Ricoh
@Remote Intelligent Remote Management System,
which facilitates remote device management.
•Promote multi-tasking and minimize time spent at the
system with high-speed scanning—up to 80 sides-per-
minute—for both black & white and color images.
Your Partner in
Environmental
Solutions
Ricoh continues its long-standing
commitment to developing office
solutions with environmentally
friendly and superior energy- and
supply-saving features, without
compromising productivity,including:
•Quick Start-Up (QSU) Technology
•Power-Saving Sleep Mode
•Duplex and Combine Copy Modes
•Toner Recycling
•Low Noise Levels
•Minimal Ozone Emissions
•Restriction of Hazardous Substances (RoHS) Compliant

Create professional-quality, perfect bound books at
the touch of a button. The new Perfect Binder
GB5000 makes it easy to produce books up to 200
sheets (400 pages in duplex mode), and includes
one- or three-edge knife trimming for a clean,
attractive finish.
Use the GBC StreamPunch III to produce clean,
precisely punched documents in a range of styles.
Unprecedented Speed
The Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
systems are not only the fastest we offer—
they are among the fastest multifunction
systems available anywhere.
•Maximize productivity and throughput with copying and printing
speeds of 90, 110 and 135 pages-per-minute.
•Reduce turnaround time in centralized reproduction departments (CRDs),
in-plant printers and print-for-pay shops—especially for critical rush orders.
•Empower users in fast-paced workgroups to complete jobs quickly and
devote more time to core activities.
•Create professionally finished documents without losing valuable
production time. Finish completely bound books at the touch of a button.
•Complete high-volume runs of large, multi-page documents without
pausing to reload trays with the virtually limitless paper supply.
•Expand in-house capabilities and reduce the need for outsourcing.
The systems handle a wide variety of paper stocks and sizes, up to
13" x 18" and 80 lb. Cover.
Enhanced Reliability
Engineered to run harder and last longer,
these workhorse systems maximize uptime
and reduce downtime—even in challenging
production environments.
•Expect outstanding long-term reliability and top-notch quality—
the result of carefully considered design enhancements to the drum,
fuser and other key components.
•Automatically identify and correct multiple-sheet feeding before it
compromises efficiency with the Multi-Feed Detection System.
Flexible Finishing
Create an incredible variety of finished documents
completely in-line—without sending jobs to other
vendors or finishing output manually.
•Ricoh’s new industry-exclusive Ring Binder Unit produces ready-to-
distribute, ring-bound booklets that are seamlessly punched and
bound completely on-line.
•Create perfect-bound books up to 400 pages long (in duplex mode),
such as technical manuals, training materials and operation guides,
with the new in-line Perfect Binder.
•Handle a variety of conventional jobs with high-speed stapling,
saddle-stitching and Z-fold options.
•Significantly reduce labor costs when printing bound books with the
GBC StreamPunch™III, which offers on-line punching in a variety of patterns.
•Deliver professional-quality, saddle-stitched booklets with square-edge
folds when you add the BK5010 Production Booklet Maker and the
optional BF5010 Book Fold Unit.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
Dependable performance for your demanding workload.
The RICOH®Pro 906EX/Pro 1106EX/Pro 1356EX digital imaging
systems deliver fast performance, seamless operation, professional-
grade finishing, and more. These reliable systems produce crisp
black & white output at speeds up to 135 pages-per-minute. They
are remarkably easy to use, and they offer a full slate of high-end
finishing options. All of which makes them ideal for meeting tight
deadlines, keeping more jobs in-house and maximizing uptime.
Set up complex jobs in
seconds with the Super VGA
Color Touch Panel Display.
ProductivityQualityPerformanceDurability CopyScanPrintFinish
In-Line Ring Binding—with the new Ring Binder
RB5000—eliminates the time and expense of
inserting binding elements off-line, dramatically
saving time and labor.
Superior Security
Safeguard sensitive documents and
the system itself from unauthorized
use with a complete line of advanced
security features.
•Manage system access with internal and
external user authentication, including
options for Windows and LDAP.
•Control which features authorized
users can employ via access restriction.
•Protect data from interception,
analysis and tampering via encrypted
communication with Secure Socket
Layer (SSL) support.
•Automatically overwrite latent
information on the hard drive after
every copy, print and scan job with
the optional DataOverwriteSecurity
System (DOSS).
•Prevent Denial of Service (DoS) attacks,
reduce the risk of virus relay and defend
against user name/password theft with
the Network Protocol On/Offfunction.
•Embed an invisible masking patternin
originals that shows up if unauthorized
users attempt to copy or scan documents
on any system with this same feature.
User-Friendly Design
The Ricoh Pro 906EX/Pro 1106EX/
Pro 1356EX systems are easy to
operate, whether you are the
newest workgroup member or a
seasoned production professional.
•Navigate to the exact copy or scan features you need
in moments with the help of the Super VGA Color Touch
Panel Display, which offers large graphics and an intuitive
menu design.
•Eliminate errors by previewing and approving thumbnails of
scanned documents before final output or e-mail distribution.
•Accommodate last-second document changes right at the
system. Use creep adjustment to improve registration of
booklets. Mix one- and two-sided originals without scanning
blank pages. Or use Bates Numbering to stamp documents
sequentially as they arescanned and output.
•Perform administrative tasks remotely with the Web Image
Monitor utility, which makes it easy to check toner and
paper levels, change print queues, merge jobs and receive
error notifications by e-mail.
•Automatically report usage meter data with the Ricoh
@Remote Intelligent Remote Management System,
which facilitates remote device management.
•Promote multi-tasking and minimize time spent at the
system with high-speed scanning—up to 80 sides-per-
minute—for both black & white and color images.
Your Partner in
Environmental
Solutions
Ricoh continues its long-standing
commitment to developing office
solutions with environmentally
friendly and superior energy- and
supply-saving features, without
compromising productivity,including:
•Quick Start-Up (QSU) Technology
•Power-Saving Sleep Mode
•Duplex and Combine Copy Modes
•Toner Recycling
•Low Noise Levels
•Minimal Ozone Emissions
•Restriction of Hazardous Substances (RoHS) Compliant

Create professional-quality, perfect bound books at
the touch of a button. The new Perfect Binder
GB5000 makes it easy to produce books up to 200
sheets (400 pages in duplex mode), and includes
one- or three-edge knife trimming for a clean,
attractive finish.
Use the GBC StreamPunch III to produce clean,
precisely punched documents in a range of styles.
Unprecedented Speed
The Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
systems are not only the fastest we offer—
they are among the fastest multifunction
systems available anywhere.
•Maximize productivity and throughput with copying and printing
speeds of 90, 110 and 135 pages-per-minute.
•Reduce turnaround time in centralized reproduction departments (CRDs),
in-plant printers and print-for-pay shops—especially for critical rush orders.
•Empower users in fast-paced workgroups to complete jobs quickly and
devote more time to core activities.
•Create professionally finished documents without losing valuable
production time. Finish completely bound books at the touch of a button.
•Complete high-volume runs of large, multi-page documents without
pausing to reload trays with the virtually limitless paper supply.
•Expand in-house capabilities and reduce the need for outsourcing.
The systems handle a wide variety of paper stocks and sizes, up to
13" x 18" and 80 lb. Cover.
Enhanced Reliability
Engineered to run harder and last longer,
these workhorse systems maximize uptime
and reduce downtime—even in challenging
production environments.
•Expect outstanding long-term reliability and top-notch quality—
the result of carefully considered design enhancements to the drum,
fuser and other key components.
•Automatically identify and correct multiple-sheet feeding before it
compromises efficiency with the Multi-Feed Detection System.
Flexible Finishing
Create an incredible variety of finished documents
completely in-line—without sending jobs to other
vendors or finishing output manually.
•Ricoh’s new industry-exclusive Ring Binder Unit produces ready-to-
distribute, ring-bound booklets that are seamlessly punched and
bound completely on-line.
•Create perfect-bound books up to 400 pages long (in duplex mode),
such as technical manuals, training materials and operation guides,
with the new in-line Perfect Binder.
•Handle a variety of conventional jobs with high-speed stapling,
saddle-stitching and Z-fold options.
•Significantly reduce labor costs when printing bound books with the
GBC StreamPunch™III, which offers on-line punching in a variety of patterns.
•Deliver professional-quality, saddle-stitched booklets with square-edge
folds when you add the BK5010 Production Booklet Maker and the
optional BF5010 Book Fold Unit.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
Dependable performance for your demanding workload.
The RICOH®Pro 906EX/Pro 1106EX/Pro 1356EX digital imaging
systems deliver fast performance, seamless operation, professional-
grade finishing, and more. These reliable systems produce crisp
black & white output at speeds up to 135 pages-per-minute. They
are remarkably easy to use, and they offer a full slate of high-end
finishing options. All of which makes them ideal for meeting tight
deadlines, keeping more jobs in-house and maximizing uptime.
Set up complex jobs in
seconds with the Super VGA
Color Touch Panel Display.
ProductivityQualityPerformanceDurability CopyScanPrintFinish
In-Line Ring Binding—with the new Ring Binder
RB5000—eliminates the time and expense of
inserting binding elements off-line, dramatically
saving time and labor.
Superior Security
Safeguard sensitive documents and
the system itself from unauthorized
use with a complete line of advanced
security features.
•Manage system access with internal and
external user authentication, including
options for Windows and LDAP.
•Control which features authorized
users can employ via access restriction.
•Protect data from interception,
analysis and tampering via encrypted
communication with Secure Socket
Layer (SSL) support.
•Automatically overwrite latent
information on the hard drive after
every copy, print and scan job with
the optional DataOverwriteSecurity
System (DOSS).
•Prevent Denial of Service (DoS) attacks,
reduce the risk of virus relay and defend
against user name/password theft with
the Network Protocol On/Offfunction.
•Embed an invisible masking patternin
originals that shows up if unauthorized
users attempt to copy or scan documents
on any system with this same feature.
User-Friendly Design
The Ricoh Pro 906EX/Pro 1106EX/
Pro 1356EX systems are easy to
operate, whether you are the
newest workgroup member or a
seasoned production professional.
•Navigate to the exact copy or scan features you need
in moments with the help of the Super VGA Color Touch
Panel Display, which offers large graphics and an intuitive
menu design.
•Eliminate errors by previewing and approving thumbnails of
scanned documents before final output or e-mail distribution.
•Accommodate last-second document changes right at the
system. Use creep adjustment to improve registration of
booklets. Mix one- and two-sided originals without scanning
blank pages. Or use Bates Numbering to stamp documents
sequentially as they arescanned and output.
•Perform administrative tasks remotely with the Web Image
Monitor utility, which makes it easy to check toner and
paper levels, change print queues, merge jobs and receive
error notifications by e-mail.
•Automatically report usage meter data with the Ricoh
@Remote Intelligent Remote Management System,
which facilitates remote device management.
•Promote multi-tasking and minimize time spent at the
system with high-speed scanning—up to 80 sides-per-
minute—for both black & white and color images.
Your Partner in
Environmental
Solutions
Ricoh continues its long-standing
commitment to developing office
solutions with environmentally
friendly and superior energy- and
supply-saving features, without
compromising productivity,including:
•Quick Start-Up (QSU) Technology
•Power-Saving Sleep Mode
•Duplex and Combine Copy Modes
•Toner Recycling
•Low Noise Levels
•Minimal Ozone Emissions
•Restriction of Hazardous Substances (RoHS) Compliant

ProductivityQualityPerformanceDurability
Printed in U.S.A. on recycled paper because Ricoh cares.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
System Specifications
General Specifications
Warm-Up Time Less than 360 seconds
Paper Weights 16lb. – 40 lb. Bond
50lb. – 80 lb. Cover
90lb. – 110 lb. Index
Standard Paper Capacity 3,000 sheets
Tray 1: 2 x 1,000-Sheet Tray
Tray 2: 1 x 500-Sheet Tray
Tray 3: 1 x 500-Sheet Tray
Power Requirements 208 – 240V, 50/60 Hz, 20A
(dedicated outlet)
Power Consumption Pro 906EX/Pro 1106EX:
(Engine/FIN/LCT) Less than 3,500W
Pro 1356EX: Less than 4,000W
Dimensions (WxDxH) 34.3" x 33.9" x 58.2" (engine)
Weight 672.4 lbs. (engine)
System Specifications
Speed Pro 906EX: 90 pages-per-minute
Pro 1106EX: 110 pages-per-minute
Pro1356EX: 135 pages-per-minute
First Copy Pro 906EX: 3.5 seconds
Pro 1106EX: 3.2 seconds
Pro 1356EX: 3.0 seconds
Throughput Size 5.5" x 8.5" to 13" x 18"
HDD Capacity 320 GB (160 GB x 2)
Memory Capacity 256 MB (standard)
512 MB (maximum, with printer
option)
Reduction/Enlargement 25% – 400% (1% increments)
System Accessories
Document Feeder
Original Paper Weights 11 – 34 lb. Bond (simplex)
14–28 lb. Bond (duplex)
RT5000 LT/LCT Large Capacity Tray
Paper Sizes Supported 5.5" x 8.5" to 8.5" x 11"
Paper Capacity 1,000 sheets (Tray 4)
1,000 sheets (Tray 5)
2,550 sheets (Tray 6)
Paper Weights 16 lb. Bond – 80 lb. Cover (Tray 4/5)
16lb. Bond – 90 lb. Index (Tray 6)
Dimensions (WxDxH) 21.2" x 28.8" x 38.6"
Weight 194 lbs.
RT5010 DLT/LCT Large Capacity Tray
Paper Sizes Supported 5.5" x 8.5" to 13" x 18"
Paper Capacity 1,000 sheets (Tray 4)
2,000 sheets (Tray 5)
1,000 sheets (Tray 6)
Paper Weights 16 lb. Bond – 80 lb. Cover
(Tray 4/5/6)
Dimensions (WxDxH) 34.7" x 28.8" x 38.6"
Weight 364 lbs.
SR5000 100-Sheet Finisher
Paper Weights 16 lb. Bond – 80 lb. Cover
Shift Tray 3,000 sheets (8.5" x 11")
1,500 sheets (8.5" x 14"/11" x 17")
1,000 sheets (13" x 18")
Proof Tray 500 sheets (8.5" x 11")
250 sheets (8.5" x 14" or larger)
Staple Capacity 100 sheets (based on 8.5" x 11")
Dimensions (WxDxH) 31.5" x 28.7" x 38.5"
Weight 165 lbs.
BK5000 Saddle Stitch Unit
Paper Sizes Folded 8.5" x 11" to 12" x 18"
Paper Weights Folded 20 – 24 lb. Bond
Dimensions (WxDxH) 23.6" x 28.7" X 38.5"
Weight 154 lbs.
CI5010 Cover Interposer
Paper Sizes Supported 5.5" x 8.5" to 13" x 18"
Paper Capacity 2 x 200 sheets
Paper Weights 17lb. Bond – 80 lb. Cover
Dimensions (WxDxH) 27.9" x 28.7" x 50"
Weight 99.2 lbs.
BY5000 Multi Bypass Tray
Paper Capacity 500 sheets (based on 8.5" x 11")
Paper Sizes Supported 5.5" x 8.5" to 12" x 18"
(RT5000)
5.5" x 8.5" to 13" x 18"
(RT5010)
PU5000 Punch Unit
Punch Type 2or 3 holes (user-selectable)
Weights Punched 16lb. Bond – 90 lb. Index
Systems Supported Pro 906EX/Pro 1106EX
Ring Binder RB5000
Paper Sizes Supported 8.5" x 11" (LEF only)
Maximum Binding 100 sheets/booklet
Capacity
Ring Sizes Supported 50-sheet/100-sheet
Capacity of Ring Bind 2–100 sheets
Paper Weight Punched 17lb. Bond – 80 lb Cover
Paper Weight Bound 17 lb. Bond – 80 lb Cover
Dimensions (WxDxH) 34.25" x 28.7" x 38.5"
Power Requirements 110/115V, 50/60 Hz
Weight 319.6 lbs.
Perfect Binder GB5000
Maximum Booklet 200 sheets (400 pages in
Capacity duplex mode)
Paper Sizes Supported Width 10.11" – 12.59", Length
7.16" – 9"; 17 lb. Bond – 90 lb.
Index (Body Pages); Width 10.11"
–13", Length 14.3" – 19.20",
17lb. Bond – 80 lb. Cover (Cover
Pages); Width 10.1" – 13",
Length 14.3" – 19.28"
(Finished Booklet Size)
Dimensions (WxDxH) 42.91" x 31.14" x 54.60"
Interposer Tray Capacity: 2 x 200 sheets
Paper Weight: 24 lb. Bond
Power Requirements 220V,50/60 Hz
Weight 738.5 lbs.
GBC StreamPunch III
Punch Type Customer-replaceable die sets
Paper Size Supported 8.5" x 11", long edge feed
(11" side only)
Systems Supported Ricoh Pro 906EX/Pro 1106EX/
Pro 1356EX
Dimensions (WxDxH) 12" x 28.5" x 38.5"
Weight 154 lbs.
BK5010 Booklet Maker
Paper Sizes Supported 8.1" x 10.8" (min.) to
12.6" x 18" (max.)
Paper Weights 16 lb. Bond – 80 lb. Cover
(on-line mode)
Up to 172 lb. Cover
(off-line mode)
Folding Specifications 1 – 30 sheets (stapled, based on
20 lb. Bond)
1–2sheets (non-stapled)
Weight 286.6 lbs.
Power Requirements 110/115V,50/60 Hz
Dimensions (WxDxH) 55.9" x 27.6" x 35.4"
Additional Options CF5010 Cover Feeder
TR5010 Trimmer Unit
BF5010 Book Fold Unit
BK5010 Rail Unit
Network Connectivity Options
Printer/Scanner Kit Type 1356
Windows Drivers (RPCS) Windows 2000, XP, Server 2003
Vista
Windows Drivers (PCL5e) Windows 2000, XP, Server 2003,
Vista
Windows Drivers (PCL6) Windows 2000, XP, Server 2003,
Vista
Windows Drivers (Adobe Windows 2000, XP, Server 2003,
PostScript3 option) Vista
Utilities Supported Web Image Monitor,
Web SmartDeviceMonitor,
SmartDeviceMonitor, Printer Utility
for Mac, IEEE 1394 Utility, USB
Printing Support, PDF Direct
Printing (through DeskTopBinder),
DeskTopBinder
Printer Options IEEE 1284 Interface, IEEE 1394
Interface, IEEE 802.11b Wireless
Interface Gigabit Ethernet, Bluetooth
Interface
Host Printing Options RA2K Integration for IPDS,
Dataworks3Support, OMS400
Scanner Specifications
Scan Speed 80 spm in black & white or color
Optical Resolution 100/150/200/300/400/600 dpi
Resolution for 100/150/200/300/400/600 dpi
Delivery Scanner
TWAIN Resolution 100 – 1200 dpi (black & white or
color)
File Formats TIFF/JPEG/PDF and High
Compression PDF
Scan-to-Email
Requirement SMTP Gateway and TCP/IP
E-mail Addresses 2,000 addresses
Maximum Addresses/Send 500 addresses
Address Support via LDAP 100 addresses
Scan-to-Folder
Protocol Support SMB/FTP/NCP
Resolution 100/150/200/300/400/600 dpi
Max. Client Folders 50
Per Send
File Types Supported Single Page TIFF/JPEG/PDF,Multi-
Page TIFF/PDF, High Compression
PDF
Security
Authentication (Windows, LDAP, Basic)
Secure Socket Layer Support
Network Protocol On/Off
SNMP v3 Support
PDF Encryption
Driver Encryption Key (PCL/RPCS Driver)
Data Overwrite Security System
Copy Data Security
Additional Options
Fiery EB-135 v 1.1 Print Controller
PrintStation 0135R MicroPress Connectivity
Copy Connect Kit Type 3260
For maximum performance and yield, we recommend
using genuine Ricoh parts and supplies.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
Digital Imaging System
Professional-Quality Output,
Production-Grade Reliability
Scan, preview and distribute full-color documents
across your organization in seconds with color
Scan-to-Email capabilities.
All three systems feature eight Trained Customer
Replaceable Units (TCRUs), which trained operators
can replace quickly and easily to maintain maximum
uptime in certain environments.
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh®and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. Windows®and Windows 2000/XP/Server 2003/Vista are registered trademarks of
Microsoft Corporation. Macintosh®is a registered trademark of Apple Computer, Inc. PCL is a registered trademark of Hewlett-Packard Company. Adobe®and
PostScript®are registered trademarks of Adobe Systems, Inc. RPCS™is a trademark of Ricoh Company, Ltd. All other trademarks are the property of their respective
owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice.
Products are shown with optional features.
www.ricoh-usa.com
R2761
production
durability
speed
Choice of Connectivity: Choose the
Printer/Scanner Kit Type 1356 to enable printing
and scanning in offices and workgroups. Or select
the EFI Fiery EB-135 v1.1 controller to streamline
digital workflow in more controlled production
environments. For environments that require
maximum workflow management, add
PrintStation 0135R Connectivity for MicroPress.
Base Unit :Pro 906EX: 90 ppm;
Pro 1106EX: 110 ppm; Pro 1356EX: 135 ppm
RT5000LT/LCT: Customize the system with your
choice of Large Capacity Trays for feeding all types
and sizes of documents, including paper sizes up
to 13" x 18".
CI5010 Cover Interposer: Energize black & white documents with preprinted
color covers or color insert sheets. Each tray holds up to 200 sheets, up to
13" x 18" in size.
ZF4000 Z-Fold Unit: Incorporate larger sheets of paper—such as
engineering specifications and schematics—into traditionally sized
presentations with the Z-Folding Unit.
New Ring Binder RB5000: Produce
finished ring-bound books
completely on-line. Users can even
open the binding to insert or
remove pages at will.
SR5000 Finisher: Staple
up to 100 sheets in
multiple positions with a
3,000-sheet finisher.
High-Speed Color Scanner: Scan black & white or
color documents rapidly,up to 80 sides-per-minute.

ProductivityQualityPerformanceDurability
Printed in U.S.A. on recycled paper because Ricoh cares.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
System Specifications
General Specifications
Warm-Up Time Less than 360 seconds
Paper Weights 16lb. – 40 lb. Bond
50lb. – 80 lb. Cover
90lb. – 110 lb. Index
Standard Paper Capacity 3,000 sheets
Tray 1: 2 x 1,000-Sheet Tray
Tray 2: 1 x 500-Sheet Tray
Tray 3: 1 x 500-Sheet Tray
Power Requirements 208 – 240V, 50/60 Hz, 20A
(dedicated outlet)
Power Consumption Pro 906EX/Pro 1106EX:
(Engine/FIN/LCT) Less than 3,500W
Pro 1356EX: Less than 4,000W
Dimensions (WxDxH) 34.3" x 33.9" x 58.2" (engine)
Weight 672.4 lbs. (engine)
System Specifications
Speed Pro 906EX: 90 pages-per-minute
Pro 1106EX: 110 pages-per-minute
Pro1356EX: 135 pages-per-minute
First Copy Pro 906EX: 3.5 seconds
Pro 1106EX: 3.2 seconds
Pro 1356EX: 3.0 seconds
Throughput Size 5.5" x 8.5" to 13" x 18"
HDD Capacity 320 GB (160 GB x 2)
Memory Capacity 256 MB (standard)
512 MB (maximum, with printer
option)
Reduction/Enlargement 25% – 400% (1% increments)
System Accessories
Document Feeder
Original Paper Weights 11 – 34 lb. Bond (simplex)
14–28 lb. Bond (duplex)
RT5000 LT/LCT Large Capacity Tray
Paper Sizes Supported 5.5" x 8.5" to 8.5" x 11"
Paper Capacity 1,000 sheets (Tray 4)
1,000 sheets (Tray 5)
2,550 sheets (Tray 6)
Paper Weights 16 lb. Bond – 80 lb. Cover (Tray 4/5)
16lb. Bond – 90 lb. Index (Tray 6)
Dimensions (WxDxH) 21.2" x 28.8" x 38.6"
Weight 194 lbs.
RT5010 DLT/LCT Large Capacity Tray
Paper Sizes Supported 5.5" x 8.5" to 13" x 18"
Paper Capacity 1,000 sheets (Tray 4)
2,000 sheets (Tray 5)
1,000 sheets (Tray 6)
Paper Weights 16 lb. Bond – 80 lb. Cover
(Tray 4/5/6)
Dimensions (WxDxH) 34.7" x 28.8" x 38.6"
Weight 364 lbs.
SR5000 100-Sheet Finisher
Paper Weights 16 lb. Bond – 80 lb. Cover
Shift Tray 3,000 sheets (8.5" x 11")
1,500 sheets (8.5" x 14"/11" x 17")
1,000 sheets (13" x 18")
Proof Tray 500 sheets (8.5" x 11")
250 sheets (8.5" x 14" or larger)
Staple Capacity 100 sheets (based on 8.5" x 11")
Dimensions (WxDxH) 31.5" x 28.7" x 38.5"
Weight 165 lbs.
BK5000 Saddle Stitch Unit
Paper Sizes Folded 8.5" x 11" to 12" x 18"
Paper Weights Folded 20 – 24 lb. Bond
Dimensions (WxDxH) 23.6" x 28.7" X 38.5"
Weight 154 lbs.
CI5010 Cover Interposer
Paper Sizes Supported 5.5" x 8.5" to 13" x 18"
Paper Capacity 2 x 200 sheets
Paper Weights 17lb. Bond – 80 lb. Cover
Dimensions (WxDxH) 27.9" x 28.7" x 50"
Weight 99.2 lbs.
BY5000 Multi Bypass Tray
Paper Capacity 500 sheets (based on 8.5" x 11")
Paper Sizes Supported 5.5" x 8.5" to 12" x 18"
(RT5000)
5.5" x 8.5" to 13" x 18"
(RT5010)
PU5000 Punch Unit
Punch Type 2or 3 holes (user-selectable)
Weights Punched 16lb. Bond – 90 lb. Index
Systems Supported Pro 906EX/Pro 1106EX
Ring Binder RB5000
Paper Sizes Supported 8.5" x 11" (LEF only)
Maximum Binding 100 sheets/booklet
Capacity
Ring Sizes Supported 50-sheet/100-sheet
Capacity of Ring Bind 2–100 sheets
Paper Weight Punched 17lb. Bond – 80 lb Cover
Paper Weight Bound 17 lb. Bond – 80 lb Cover
Dimensions (WxDxH) 34.25" x 28.7" x 38.5"
Power Requirements 110/115V, 50/60 Hz
Weight 319.6 lbs.
Perfect Binder GB5000
Maximum Booklet 200 sheets (400 pages in
Capacity duplex mode)
Paper Sizes Supported Width 10.11" – 12.59", Length
7.16" – 9"; 17 lb. Bond – 90 lb.
Index (Body Pages); Width 10.11"
–13", Length 14.3" – 19.20",
17lb. Bond – 80 lb. Cover (Cover
Pages); Width 10.1" – 13",
Length 14.3" – 19.28"
(Finished Booklet Size)
Dimensions (WxDxH) 42.91" x 31.14" x 54.60"
Interposer Tray Capacity: 2 x 200 sheets
Paper Weight: 24 lb. Bond
Power Requirements 220V,50/60 Hz
Weight 738.5 lbs.
GBC StreamPunch III
Punch Type Customer-replaceable die sets
Paper Size Supported 8.5" x 11", long edge feed
(11" side only)
Systems Supported Ricoh Pro 906EX/Pro 1106EX/
Pro 1356EX
Dimensions (WxDxH) 12" x 28.5" x 38.5"
Weight 154 lbs.
BK5010 Booklet Maker
Paper Sizes Supported 8.1" x 10.8" (min.) to
12.6" x 18" (max.)
Paper Weights 16 lb. Bond – 80 lb. Cover
(on-line mode)
Up to 172 lb. Cover
(off-line mode)
Folding Specifications 1 – 30 sheets (stapled, based on
20 lb. Bond)
1–2sheets (non-stapled)
Weight 286.6 lbs.
Power Requirements 110/115V,50/60 Hz
Dimensions (WxDxH) 55.9" x 27.6" x 35.4"
Additional Options CF5010 Cover Feeder
TR5010 Trimmer Unit
BF5010 Book Fold Unit
BK5010 Rail Unit
Network Connectivity Options
Printer/Scanner Kit Type 1356
Windows Drivers (RPCS) Windows 2000, XP, Server 2003
Vista
Windows Drivers (PCL5e) Windows 2000, XP, Server 2003,
Vista
Windows Drivers (PCL6) Windows 2000, XP, Server 2003,
Vista
Windows Drivers (Adobe Windows 2000, XP, Server 2003,
PostScript3 option) Vista
Utilities Supported Web Image Monitor,
Web SmartDeviceMonitor,
SmartDeviceMonitor, Printer Utility
for Mac, IEEE 1394 Utility, USB
Printing Support, PDF Direct
Printing (through DeskTopBinder),
DeskTopBinder
Printer Options IEEE 1284 Interface, IEEE 1394
Interface, IEEE 802.11b Wireless
Interface Gigabit Ethernet, Bluetooth
Interface
Host Printing Options RA2K Integration for IPDS,
Dataworks3Support, OMS400
Scanner Specifications
Scan Speed 80 spm in black & white or color
Optical Resolution 100/150/200/300/400/600 dpi
Resolution for 100/150/200/300/400/600 dpi
Delivery Scanner
TWAIN Resolution 100 – 1200 dpi (black & white or
color)
File Formats TIFF/JPEG/PDF and High
Compression PDF
Scan-to-Email
Requirement SMTP Gateway and TCP/IP
E-mail Addresses 2,000 addresses
Maximum Addresses/Send 500 addresses
Address Support via LDAP 100 addresses
Scan-to-Folder
Protocol Support SMB/FTP/NCP
Resolution 100/150/200/300/400/600 dpi
Max. Client Folders 50
Per Send
File Types Supported Single Page TIFF/JPEG/PDF,Multi-
Page TIFF/PDF, High Compression
PDF
Security
Authentication (Windows, LDAP, Basic)
Secure Socket Layer Support
Network Protocol On/Off
SNMP v3 Support
PDF Encryption
Driver Encryption Key (PCL/RPCS Driver)
Data Overwrite Security System
Copy Data Security
Additional Options
Fiery EB-135 v 1.1 Print Controller
PrintStation 0135R MicroPress Connectivity
Copy Connect Kit Type 3260
For maximum performance and yield, we recommend
using genuine Ricoh parts and supplies.
Ricoh Pro 906EX/Pro 1106EX/Pro 1356EX
Digital Imaging System
Professional-Quality Output,
Production-Grade Reliability
Scan, preview and distribute full-color documents
across your organization in seconds with color
Scan-to-Email capabilities.
All three systems feature eight Trained Customer
Replaceable Units (TCRUs), which trained operators
can replace quickly and easily to maintain maximum
uptime in certain environments.
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh®and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. Windows®and Windows 2000/XP/Server 2003/Vista are registered trademarks of
Microsoft Corporation. Macintosh®is a registered trademark of Apple Computer, Inc. PCL is a registered trademark of Hewlett-Packard Company. Adobe®and
PostScript®are registered trademarks of Adobe Systems, Inc. RPCS™is a trademark of Ricoh Company, Ltd. All other trademarks are the property of their respective
owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice.
Products are shown with optional features.
www.ricoh-usa.com
R2761
production
durability
speed
Choice of Connectivity: Choose the
Printer/Scanner Kit Type 1356 to enable printing
and scanning in offices and workgroups. Or select
the EFI Fiery EB-135 v1.1 controller to streamline
digital workflow in more controlled production
environments. For environments that require
maximum workflow management, add
PrintStation 0135R Connectivity for MicroPress.
Base Unit :Pro 906EX: 90 ppm;
Pro 1106EX: 110 ppm; Pro 1356EX: 135 ppm
RT5000LT/LCT: Customize the system with your
choice of Large Capacity Trays for feeding all types
and sizes of documents, including paper sizes up
to 13" x 18".
CI5010 Cover Interposer: Energize black & white documents with preprinted
color covers or color insert sheets. Each tray holds up to 200 sheets, up to
13" x 18" in size.
ZF4000 Z-Fold Unit: Incorporate larger sheets of paper—such as
engineering specifications and schematics—into traditionally sized
presentations with the Z-Folding Unit.
New Ring Binder RB5000: Produce
finished ring-bound books
completely on-line. Users can even
open the binding to insert or
remove pages at will.
SR5000 Finisher: Staple
up to 100 sheets in
multiple positions with a
3,000-sheet finisher.
High-Speed Color Scanner: Scan black & white or
color documents rapidly,up to 80 sides-per-minute.
