Ricoh Pentax K-S1 Guide

Start Guide
Thank you for purchasing the PENTAX K-S1
digital camera
This Start Guide provides information on how
to get your PENTAX K-S1 ready for use and
its basic operations To ensure proper operation,
please read this Start Guide before using
the camera
For details on how to use the various shooting
methods and settings, please refer to the
Operating Manual (PDF) posted on our website
Refer to p 52 for details on the Operating Manual
SLR Digital Camera
e_kb558_sg.book Page i Tuesday, September 9, 2014 2:22 PM

Checking the Contents of the Package
Hot shoe cover FK
(Installed on camera)
Eyecup FR
(Installed on camera)
Body mount cover
(Installed on camera)
Rechargeable Lithium-ion
Battery -LI109
Battery charger
-BC109
AC plug cord Strap
O-ST132
Software (C -ROM)
S-SW151
Start Guide (this manual)
Lenses you can use
Lenses that can be used with this camera are A, A L, FA and FA J lenses and lenses that have an 9 (Auto) position
on the aperture ring. To use any other lens or accessory, see p.37.
e_kb558_sg.book Page ii Tuesday, September 9, 2014 2:22 PM

1
Names and Functions of the Working Parts ...........3
Operating Controls ......................................................... 4
Monitor ........................................................................... 6
Viewfinder ...................................................................... 9
How to Change Function Settings ........................10
Using the irect Keys .................................................. 10
Using the Control Panel ............................................... 10
Using the Menus .......................................................... 11
Menu ist ..............................................................12
Rec. Mode Menus ........................................................ 12
Movie Menu ................................................................. 15
Playback Menu ............................................................ 15
Set-up Menus .............................................................. 16
Custom Setting Menus ................................................ 18
Getting Your Camera Ready for Use ....................20
Attaching the Strap ...................................................... 20
Attaching a Lens .......................................................... 20
Charging the Battery .................................................... 21
Inserting/Removing the Battery and Memory Card ...... 21
Setting the isplay Language and ate/Time ............. 22
Formatting a Memory Card .......................................... 24
Basic Shooting Operation .....................................24
Shooting with the Viewfinder ....................................... 24
Shooting While Viewing the Live View Image .............. 25
Capture Modes for Still Pictures .................................. 26
Recording Movies ........................................................ 30
Setting the Flash Mode ................................................ 31
Setting the rive Mode ................................................ 32
Setting the White Balance ........................................... 32
Reviewing Images ................................................ 33
Playback Mode Palette ................................................ 34
Restrictions on Each Capture Mode .................... 35
Restrictions on the Combinations of Special
Functions ..................................................................... 36
Functions Available with Various enses ............. 37
Main Specifications .............................................. 38
Operating Environment for USB Connection
and Provided Software ................................................. 42
For Using Your Camera Safely ............................ 44
Care to be Taken During Handling ....................... 46
WARRANTY PO ICY .......................................... 49
Information on the Operating Manual ................... 52
There is a possibility that the illustrations and the display screen
of the monitor in this manual are different from the actual ones.
Contents
e_kb558_sg.book Page 1 Tuesday, September 9, 2014 2:22 PM

2
Regarding copyrights
Images taken with this camera that are for anything other
than personal enjoyment cannot be used without permission
according to the rights as specified in the Copyright Act.
Please take care, as there are cases where limitations
are placed on taking pictures even for personal enjoyment
during demonstrations, performances or of items on display.
Images taken with the purpose of obtaining copyrights also
cannot be used outside the scope of use of the copyright
as laid out in the Copyright Act, and care should be taken
here also.
To users of this camera
• o not use or store this camera in the vicinity of equipment
that generates strong electromagnetic radiation or
magnetic fields. Strong static charges or the magnetic
fields produced by equipment such as radio transmitters
could interfere with the monitor, damage the stored data,
or affect the camera’s internal circuitry and cause camera
misoperation.
• The liquid crystal panel used for the monitor is
manufactured using extremely high precision technology.
Although the level of functioning pixels is 99.99% or better,
you should be aware that 0.01% or fewer of the pixels may
not illuminate or may illuminate when they should not.
However, this has no effect on the recorded image.
• In this manual, the generic term “computer(s)” refers
to either a Windows PC or a Macintosh.
• In this manual, the term “battery(ies)” refers to any type
of batteries used for this camera and its accessories.
Regarding User Registration
In order to better serve you, we request that you complete
the user registration, which can be found on the C -ROM
supplied with the camera or on our website.
Thank you for your cooperation.
http://www.ricoh-imaging.com/registration/
e_kb558_sg.book Page 2 Tuesday, September 9, 2014 2:22 PM

3
Names and Functions of the Working Parts
Tripod
socket Battery/memory card cover
Remote control receiver
AF coupler
Mirror
Lens unlock button
Lens information
contacts
Strap lug
ot shoe
Lens mount index
Speaker
Strap lug
AF assist light
Card access lamp
USB terminal (micro B)
Terminal cover
Diopter adjustment lever
DMI terminal (type D)
Microphone
Image plane indicator
Viewfinder
Monitor
Built-in flash
Connection cable cover
Microphone
Battery/memory card cover unlock lever
e_kb558_sg.book Page 3 Tuesday, September 9, 2014 2:22 PM

4
1EV Compensation utton (J/J)
Press to change the exposure compensation value. (p.29)
In K/L mode, use this button to switch the value to be
changed between shutter speed and aperture value.
In playback mode, the last JPEG image taken can also
be saved in RAW format.
2Green utton (M)
Resets the value being adjusted.
Switches to [ISO AUTO] when adjusting the sensitivity.
Also, you can assign other functions to this button.
3Shutter release utton (0)
Press to capture images. (p.25)
In playback mode, press halfway to switch to capture mode.
4Main switch
Turns the power on/off, or switches to C (movie) mode.
(p.30)
When the camera is turned on, it enters A (still picture)
mode and the lamp lights green. When the switch is turned
to C, the camera enters C mode and the lamp lights red.
5Grip lamps
The five lamps light up green during Self-timer shooting
or shooting with a remote control unit, or when faces
are detected during Live View.
6Lens unlock utton
Press to detach the lens on the camera. (p.20)
7Flash pop-up utton (1)
Press to pop up the built-in flash. (p.31)
8Focus mode switch
Turn to change the focus mode.
9Live View/Delete utton (K/L)
isplays the Live View image. (p.25)
In playback mode, press to delete images. (p.33)
Operating Controls
6
2
a
8
c
d
b
7
4
3
5
1
9
0
e
f
g
e_kb558_sg.book Page 4 Tuesday, September 9, 2014 2:22 PM

5
0Play ack utton (3)
Switches to playback mode. (p.33)
Press the button again to switch to capture mode.
aMENU utton (F)
isplays a menu. Press this button while the menu
is displayed to return to the previous screen. (p.11)
bINFO utton (G)
Changes the style of the display on the monitor. (p.6, p.8)
cE-dial (V)
Changes the values for camera settings such as exposure.
(p.28)
You can change the menu tabs when a menu screen
is displayed. (p.11)
You can change the camera settings when the control panel
is displayed. (p.10)
In playback mode, use this to magnify an image or display
multiple images at the same time. (p.33)
dAF/AE Lock utton (f)
Available for adjusting focus, instead of pressing 0
halfway, and for locking the exposure value before shooting.
eFour-way controller (ABCD)
isplays the Sensitivity, White Balance, Flash Mode
or rive Mode setup menu. (p.10)
When a menu or the control panel is displayed, use this
to move the cursor or change the item to set.
Press B in single image display of the playback mode
to display the playback mode palette. (p.34)
fOK utton (E)
When a menu or the control panel is displayed,
press this button to confirm the selected item.
Press this button when [AF Active Area] is set to E or 8,
or when [Contrast AF] is set to g or h to change
the focusing area.
When the power is turned on, the lamp lights blue.
When the focusing area can be changed, the lamp turns off.
gMode dial
Changes the capture mode. (p.24)
When the power is turned on, the lamp lights white, and
the icon of the set capture mode lights green on the dial.
A out the indicator lamps
The main switch lamp, grip lamps, mode dial lamp and E
lamp turn off in the following situations.
• From the time when 0 is pressed halfway until
the end of shooting
• While f is pressed
• uring playback mode
• While a menu is displayed
• uring Auto Power Off
You can set the lamp lighting settings in [Indicator Lamps]
of the D3 menu. (p.17)
A out the four-way controller
In this manual, each button of the four-
way controller is indicated as shown
in the illustration on the right.
e_kb558_sg.book Page 5 Tuesday, September 9, 2014 2:22 PM

6
With this camera, you can take pictures while looking through
the viewfinder or while viewing the image on the monitor.
When using the viewfinder, you can take pictures while
checking the status screen displayed on the monitor and looking
through the viewfinder. When not using the viewfinder, you can
take pictures while viewing the Live View image displayed on
the monitor.
The camera is in “standby mode” when it is ready to shoot, such
as when the status screen or Live View image is displayed.
Press G in standby mode to display the “control panel” and
change settings. (p.10) You can change the type of information
displayed in standby mode by pressing G while the control
panel is displayed.
Monitor
Capture Mode
1 /
1/
2 5 0
250
1 6 0 0
1600
F
F
5.6
5.6
9 9 9 9 9
99999
G
G
10:23
10:23
99999
99999
1 /
1/
2 5 0
250
1 6 0 0
1600
F
F
5.6
5.6
9 9 9 9 9
99999
Status Screen
Status Screen
Status Screen
Custom Image
Custom Image
Custom Image
Bright
Bright
Bright
07 /07/2014
07/07/2014
Standby mode
(Status screen)
Shooting Info Display selection screen
Control panel
Status Screen
1Capture mode 16 Sensitivity
2AE Lock 17 Flash Exposure
Compensation
3Focus Method
4Custom Image 18 White Balance
fine-tuning
5igital Filter/
H R Capture 19 Flash Mode
6GPS positioning status 20 Focusing area (AF point)
7Wireless LAN status 21 rive Mode
8AE Metering 22 White Balance
9Shake Reduction 23 File Format
10 Battery level 24 Memory card
11 E-dial guide 25 Image storage capacity
12 Shutter speed 26 ASTROTRACER
maximum tracking
duration
13 Aperture value
14 EV Compensation/
Exposure Bracketing 27 Operation guide
15 EV bar scale
123
11
11
11
11
12
13
16
15
14
19 21 22
2726
19 2120
16
22
17 18
252324
45 678910
1 /
1/
2 5 0
250
1 6 0 0
1600
F
F
5.6
5.6
1 2 3 4 5
12345
5´0 0 ˝
5´00˝
+ 1 . 0
+1.0
G1A1
G1A1
e_kb558_sg.book Page 6 Tuesday, September 9, 2014 2:22 PM

7
A mode
Live View
1Capture mode 13 Histogram
2Flash Mode 14 EV Compensation
3rive Mode 15 EV bar scale
4White Balance 16 Operation guide
5Custom Image 17 AE Lock
6igital Filter/
H R Capture
18 Shutter speed
19 Aperture value
7GPS positioning status 20 Sensitivity
8Wireless LAN status 21 File Format
9AE Metering 22 Memory card
10 Shake Reduction/
Movie SR
23 Image storage capacity
24 Face detection frame
(when [Contrast AF] is
set to [Face etection])
11 Battery level
12 Temperature warning
+1.7
EV
+1.7
EV
1/ 20 00 1/2000 F2.8F2.8 16001600 9999999999
±0EV±0EV
1/ 20 00 1/2000 F2.8F2.8 16001600 9999999999
123456 91011
21
87
15
14
16
22 2317 18 19 20 24
12
13
Control Panel
1Function name 7H R Capture
2Setting 8Highlight Correction
3Memory card 9Shadow Correction
4Number of recordable
still pictures/Movie
recordable time
10 istortion Correction
11 Lateral Chromatic
Aberration Adjustment
5Custom Image/Scene
Mode/Effects Mode
12 Peripheral Illumination
Correction
6igital Filter 13 iffraction Correction
10 :23
10:23
1 2 3 4 5
12345
1
2
34
98
11
16
21
10
15
20
12
657
17
22
13
18
23
14
19
24
27 28
Custom Image
Custom Image
Custom Image
Bright
Bright
Bright
07/07/2014
07/07/2014
10 :23
10:23
1 2 3 4 5
12345
1
2
34
98
11
16
21
10
15
20
12
657
17
22
13
18
23
14
19
24
27 28
07/07/2014
07/07/2014
Custom Image
Custom Image
Custom Image
Bright
Bright
Bright
When shooting with Live View
1
2
34
98
16
23
15
26
17
6514
21 25
27 28
10:23
10:23
1 : 2 3 '4 5 "
1:23'45"
07/07/2014
07/07/2014
Custom Image
Custom Image
Custom Image
Bright
Bright
Bright
C mode
e_kb558_sg.book Page 7 Tuesday, September 9, 2014 2:22 PM

8
The captured image and shooting information are displayed
in single image display of the playback mode.
Press G to change the type of information displayed in
single image display. Use CD to select the type and press E.
14 AE Metering 22 JPEG Quality
15 AF Mode/Contrast AF 23 Shake Reduction/
Movie SR
16 AF Active Area/
Focus Peaking 24 AA Filter Simulator
17 AF Assist Light 25 Framerate
18 High-ISO NR 26 Recording Sound Level
19 Slow Shutter Speed NR 27 Current date and time
20 File Format 28 estination
21 JPEG Recorded Pixels/
Movie Recorded Pixels
Playback Mode
1/
20 00
1/
2000
F2 .8
F2.8
20 0
200
+0 .3
+0.3
10 0-0001
100-0001
1/
20 00
1/
2000
F2 .8
F2.8
20 0
200
+0 .3
+0.3
10 0-0001
100-0001
G
Standard Information Display
Standard Information Display
Single image display
(Standard Information
Display)
Playback Info Display
selection screen
e_kb558_sg.book Page 8 Tuesday, September 9, 2014 2:22 PM
