Ricoh Mp c6502 series User manual

MP C8002

ppm

monochrome

and full-color

MP C6502

ppm

monochrome

and full-color

Copier Printer Facsimile Scanner

Multifunction Color

RICOH

MP C6502/MP C8002

Handle everything with superior, high-quality color

The combination of speed and quality has never offered clearer advantages. The RICOH®MP C6502/

MP C8002 color digital MFP uses cutting-edge laser technology to produce fast, exceptional color output

in high-volume offices and graphics departments. This innovative MFP offers intuitive end-to-end control

to improve workflow for everyday tasks. Take advantage of outstanding image quality, enhanced paper

handling and robust finishing by keeping more jobs in house. Transform your MFP into an information portal

by connecting to the cloud from your smartphone, tablet or other mobile device and use these systems to

print, share and discover the value of customized convenience. Use it as your standalone, primary system

— or as an integral part of a Ricoh Managed Document Services (MDS) strategy and improve productivity

throughout your organization.

• Print full-color or black-and-white documents at speeds of 65 or 80 ppm

• Deliver impressive color with image resolution up to 1200 x 4800 dpi

• Produce documents in sizes up to 13" x 19.2"

• Advanced scanning capabilities

• Paper capacity up to 8,100 sheets

• Comprehensive inline finishing options

Transform everyday into the extraordinary

Enhance performance with high-impact, high-volume features

See unprecedented image quality

Bring production print quality to any office. Achieve the highest

resolution available — up to 1200 x 4800 dpi — from the first print

to the last with the Ricoh MP C6502/MP C8002. New and innovative

technology called Vertical Cavity Surface Emitting Laser (VCSEL) helps

deliver precise registration and fill on text and images for superior

clarity. The system emits 40 laser beams simultaneously to ensure

accurate color density for impressive output every time. It also adjusts

the paper automatically so graphics match more closely on the front

and back of every sheet.

Be more productive

Productivity comes standard with the Ricoh MP C6502/MP C8002. It

produces up to 80 prints per minute for fast, high-volume color output.

Take advantage of its quick one-pass duplex scanning that scans both

sides of any original in a single pass. Reload paper and replace toner

without interrupting print runs for continuous uptime and maximum

productivity. Use the embedded Web Browser option and connect

to the Ricoh Integrated Cloud Environment (ICE) to scan documents,

send files to popular Web services, print on the go and more with the

touch of a button — without on-premise software solutions.

Integrate processes to streamline workflow

Combine advanced printing, copying, faxing and scanning capabilities

in a single system designed to reduce space, unnecessary steps and

operating costs. The Ricoh MP C6502/MP C8002 includes Distributed

Scan Management (DSM) for centralized scanning control that automates

document tasks for faster, more efficient workflow while following specific

user permissions, rules, delivery preferences and more. Use the new

embedded Optical Character Recognition (OCR) scanning to create

searchable PDF files for advanced indexing and retrieval of scanned

documents. Send large, full-color files easily as high-compression

PDFs. ID card copy lets users replicate both sides of documents,

forms and ID cards onto one side of paper.

Complete everyday projects with ease

A large, full-color touch-screen control panel lets users set up shortcuts

for convenient, one-step access to specific jobs and functions. Bring

projects with you via a convenient USB memory or SD card slot on the

control panel. Featuring a range of technologies to minimize paper

misfeeds, these models deliver stable operation even when printing at

high speed. Advanced, real-time animated graphics and other features

also ensure that when a misfeed does occur, troubleshooting is quick,

easy and stress free.

Designed to showcase the best ideas

Add color to add impact

New PxP®-EQ formulated toner expands the color space for

advanced color management. Because the toner melts at lower

temperatures, it requires less energy and minimizes operating

costs — making it ideal for in-house graphics departments that

are conscious of both quality and budget. The Ricoh MP C6502/

MP C8002 provides consistently stable color recognition that

significantly minimizes banding, gaps and shock jitter. Advanced

print drivers offer incredible flexibility, so users can adjust colors,

brightness, saturation and more to meet any color demand.

Plus, users can take advantage of the powerful, user-friendly

Fiery®E-22B Print Controller for more complex color workflows

in either Windows or Mac environments for effortless, high-grade

print and color control.

Manage multiple media

Produce more jobs in-house — including direct mail, proposals,

booklets, manuals and more — with a wide range of paper

handling features. The high-capacity Ricoh MP C6502/MP C8002

can hold up to 8,100 sheets to ensure even the largest workgroups

keep moving efficiently. It accepts thicker paper stocks for

duplex printing in weights up to 142 lb. Index (256 g/m2). It can

accept up to 110 lb. Cover (300 g/m2) for non-duplex printing

via the RT4030 large capacity tray or via the bypass tray. The

system can run and finish up to 13" x 18" sized paper with full

bleed up to 11" x 17" for posters and signage.

Finish what you start

Use the Ricoh MP C6502/MP C8002 to create a wide range of

impressive, professional-grade documents on demand and eliminate

expensive outsourcing. Craft highly compelling pieces with multiple

folding options using the FD4000 Multi-Folding Unit. Take advantage

of stapling, hole-punching, saddle stitching and more to meet unique

requirements and quick turnarounds. Newly designed, flat fold

booklet finishing ensures that booklets are neat, thin and significantly

easier to handle.

End-to-end control for larger workgroups

Sustain energy efficiency for your environment

The Ricoh MP C6502/MP C8002 lets users perform more tasks

while reducing Typical Electricity Consumption (TEC). The system

can be programmed to power on and off with a Weekly Timer to

fit the way you want to work — and save. Default duplex printing

reduces paper and operating costs without compromising quality.

Protect document integrity

The Ricoh MP C6502/MP C8002 has enhanced features that help

organizations meet today’s growing security needs. The device

includes user authentication to restrict access to critical MFP functions

to only those with a valid user name and password. Likewise, stored

documents are released only to authorized users. Administrators can

set quotas for individual users or workgroups to curb excessive color

printing and to restrict access to specific functions. In addition, the

DataOverwriteSecurity System (DOSS) feature destroys latent images

and data on the HDD.

Manage performance easily, remotely

The new Remote User Interface supports panel monitoring, which helps

speed problem resolution and maximizes IT personnel productivity.

Administrators can also monitor usage of the Ricoh MP C6502/

MP C8002 — or an entire fleet — with the built-in Embedded @Remote

device management functionality, or it can be managed by one of

the other @Remote fleet solutions. Administrators can monitor usage

trends, collect and report meter data and generate an array of usage

reports, including @Remote Green Reports, to ensure eco-friendly

initiatives are meeting targets.

Innovative features for fast,

ﬂexible and affordable workﬂow

Ricoh MP C6502/MP C8002

10 11 12 13 17

CI4010 and CI4020 Cover Interposers (Optional):

Feed pre-printed

sheets from one or two sources for front and back covers.

CS4010 9-Bin Mailbox (Optional):

Keep documents from multiple

users separate with the 9-Bin Mailbox.

SR4100 2,000-Sheet Booklet Finisher (Optional):

Produce full-color

booklets cost-effectively with the in-line Booklet Finisher. Also

available with an optional Hole Punch Unit.

SR4090 and SR4110

(shown)

3,000-Sheet Finishers (Optional):

Choose from 65- or 100-sheet stapling with the ability to output

documents up to 13" x 19.2". Add the optional Hole Punch Unit

for even more flexibility.

FD4000 Multi-Folding Unit (Optional):

Execute several different

folds to create a variety of finished documents.

BK5010e Production Booklet Maker (Optional):

Saddle stitch up

to 30 sheets to create 120-page booklets.

GBC StreamPunch™(Optional):

Create professional-quality bound

books with in-line punching in a variety of patterns.

220-Sheet Single Pass Duplex Feeder (Standard):

Offers single-pass

color duplex scanning at 220 spm.

Full-Color WVGA Control Panel with SD/USB Slot (Standard):

Navigate from job to job easily with fingertip control via the intuitive

touch screen featuring a user-friendly slot for SD/USB cards.

Power On/Off Timer (Standard):

Saves energy and minimizes waiting

by automatically turning the MFP on or off at pre-determined times.

Automatic Duplexing (Standard):

Save paper and filing space

with standard automatic duplexing that runs at the same speed

as one-sided output.

VCSEL and PxP-EQ Toner Technology (Standard):

Vertical Cavity

Surface Emitting Laser and high-quality toner provide more vivid

colors and smooth gradations for improved text, fine lines, graphics

and photographic reproductions.

640GB Hard Disk Drive (Standard):

Secure documents with

DataOverwriteSecurity System (DOSS), Data Encryption, Locked

Print and more (capacity for Locked Print is 170GB).

Oversize and Heavy Media Support:

Accepts 13" x 19.2" paper

sizes and heavy media (up to 110 lb. Cover stock through the

Bypass Tray and the RT4030 LCT) to give you many more options

for in-house production.

Paper Trays (Standard):

Standard paper sources include the tandem

2 x 1,250-sheet Paper Tray, two 550-sheet Paper Trays and 100-sheet

Bypass Tray for a total paper capacity of 3,700 sheets. With additional

paper sources, this system can hold up to 8,100 sheets.

RT403 0

(shown)

and RT4020 Large Capacity Trays (Optional):

The RT4030 2,200-sheet LCT utilizes the system Bypass Tray

for a straight paper path to help reliably feed up to 110 lb. Cover

stock (300 g/m2) and up to 13" x 19.2" sheets. Choose the RT4020

4,400-sheet LCT to handle paper sizes up to 8.5" x 11" and up to

80 lb. Cover stock (216 g/m2).

Broad Compatibility:

Quickly integrate these systems with built-in

compatibility for PC and Mac environments in LAN or wireless networks.

SYStem SpecificationS

Ricoh MP C6502/MP C8002

Specifications

Output Speed (LTR) MP C6502: 65 ppm (FC/B&W)

MP C8002: 80 ppm (FC/B&W)

Document Feeder Standard 220-Sheet SPDF with single-

pass color duplex scanning

Control Panel Full-color 9" WVGA touch panel

Copy Resolution 600 dpi

Color/Grayscale 256 Levels

Quantity Indicator 1 – 9,999

Original Size Up to 11" x 17" (279.4 x 431.8 mm)

(from platen)

Warm-Up Time 50 sec. (from main switch)

Recovery Time MP C6502: 50 sec. (from sleep mode)

MP C8002: 45 sec. (from sleep mode)

First Copy Speed MP C6502: 5.3/7.2 sec. (B&W/FC)

MP C8002: 4.6/6.2 sec. (B&W/FC)

Paper Capacity Tray 1: 1,250 sheets x 2

Trays 2 – 3: 550 sheets x 2

Bypass Tray: 100 sheets

Total Paper Capacity 3,700 (std.) /8,100 sheets (max.)

Paper Size Tray 1: 8.5" x 11"

Trays 2 – 3: 5.5" x 8.5" to 13" x 19.2"

Bypass Tray: 5.5" x 8.5" to 13" x 19.2"

Paper Weight Tray 1/2/3: 14 lb. Bond – 142 lb. Index

(52 – 256 g/m

)

Bypass Tray: 14 lb. Bond – 110 lb. Cover

(52 – 300 g/m

)

Duplex: 14 lb. Bond – 142 lb. Index

(52 – 256 g/m

)

Magnification 7 reduction and 5 enlargement

Zoom 25% to 400% in 1% increments

Power Requirements MP C6502: 120V/20A/60Hz (dedicated)

MP C8002: 208–240V/20A/60Hz (dedicated)

Typical Electricity MP C6502: 5.08 kWh/week

Consumption (TEC) MP C8002: 6.37 kWh/week

Max. Power Consumption MP C6502: 1,920W or less

MP C8002: 2,400W or less

Dimensions (WxDxH) 29.5" x 34.9" x 48.3"

(750 x 886 x 1,226 mm) (incl. SPDF)

Weight Less than 531 lbs. (241 kg)

Copier Features

Eco-Friendly Indicator, Power On/Off Timer, Auto Off Timer,

Simplified Display, Auto Paper Selection, Auto Start, Auto Tray

Switching, Auto Image Density, Auto Color Calibration, Color

Erase/Convert/Overlay, Image Rotation, Rotate Sorting, Interrupt

Copy, Job Presets, Tabs, Color/Image Creation, Color Balance

Adjustment/Program, Shift/Erase/Margin Adjustment, Multiple

Security Features (DOSS, Data Encryption (AES256bit/SHA2),

Authentication, Unauthorized Copy Control, Quota Setting,

SMTP over SSL, Common Criteria Certification (IEEE2600.1),

Import/Export of Preference Settings, Remote User Interface

Printer Specifications (Standard)

CPU Intel

Celeron

Processor P4505 –

1.86 GHz

RAM 2.5 GB

HDD 640GB (320GB x 2) (Shared)

Max. Print Resolution 1200 x 4800 dpi via VCSEL

Standard Interfaces Ethernet (10/100/1000Base-TX), USB2.0

Type A/Type B, SD slot

Optional Interfaces IEEE 1284/ECP, Wireless LAN

(IEEE802.11a/b/g/n)

Network Protocol TCP/IP (IPv4, IPv6), IPX/SPX (w/option)

Network Operating Windows XP/Vista/7/Server 2003/Server

Systems 2003R2/Server 2008/Server 2008R2;

Netware 6.5; Unix Sun Solaris, HP-UX,

SCO OpenServer, RedHat Linux, IBM

AIX; MAC OS X 10.2 or later; SAP R/3;

NPDS Gateway; IBM iSeries AS/400 using

OS/400 Host Print Transform

Print Drivers PCL5c, PCL6, PDF, Adobe PS3 (optional),

XPS, IPDS (optional)

Fonts PCL: 45 scalable + 13 international; PDF:

136 Roman; IPDS: 108 Roman (optional)

Printer Features Sample/Locked/Hold/Scheduled/Stored

Print, PDF Direct Print, CLP Simulation,

Mail to Print, Bonjour (Rendezvous)

Support, Media Direct Print (Print from

USB/SD), Mobile Driver, Poster Print,

Auto Job Promotion, WS Print, WPS

(Wi-Fi Protected Setup), XPS

Scanner Specifications (Standard)

Scanning Resolution Up to 600 dpi

Scan Area Up to 11.7" x 17" (297 x 432 mm)

Scan Speed (B&W/FC) Simplex: 120 ipm; Duplex: 220 ipm

Output Format Single Page: TIFF/JPEG/PDF/

High Compression PDF/PDF-A

Multi Page: TIFF/PDF/High Compression

PDF/PDF-A

Compression B&W – 1bit (MH/MR/MMR/JBIG2),

Grayscale (JPEG), Full Color – JPEG

Interface Support 10/100/1000Base-TX, Wireless LAN

(IEEE802.11 a/b/g/n), USB2.0 Type A,

SD card slot

Authentication SMTP/POP before SMTP

Scanner Features: B&W/FC Photo, B&W/FC Text, ACS,

Auto Density, Image Rotation, Mixed Size/

SADF/Batch Mode, Reduce and Enlarge,

Split Scan, Scan-to Email/SMB/FTP/

URL/NCP/ PDF/A/Digitally Signed PDF/

Searchable PDF, TWAIN Scanning, USB/

SD2.0 Scanning, LDAP Support, Universal

Send, Distributed Scan Management,

Preview Before Transmission, WS-Scanner

Document Server Specifications (Standard)

Max. Stored Documents 3,000

Max. Pages per Document 3,000

Max. Stored Pages 15,000

Folder Management Yes (password protectable)

Fax Specifications (Optional)

Circuit PSTN, PBX

Compatibility ITU-T (CCITT) G3, Additional G3 opt.

Resolution 200 x 100/200 dpi (400 dpi w/opt.

SAF memory)

Compression Method MH, MR, MMR, JBIG

Modem Speed 33.6 K – 2,400 bps

Transmission Speed G3: Approx. 2 sec.

Memory Backup 1 hour

Quick/Speed Dials 2,000 numbers

Group Dials 100 groups (500 per group)

SAF Memory Capacity Standard: 4MB (approx. 320 pages),

Maximum: 28MB (approx. 2,240 pages

with memory option)

Fax Features Detection of Misplaced Document,

Direct SMTP, Internet Fax (T.37),

LAN Fax, IP Fax (T.38), Remote Fax

(option), Forward to Email/Folder,

Paperless Fax, LDAP Support

Accessories

RT4030 DLT Large Capacity Tray (LCT)

Paper Capacity 2,200 sheets

Paper Size Up to 13" x 19.2"

Paper Weight 14 lb. – 110 lb. Cover (52 - 300 g/m

)

Size 34.2" x 28.7" x 25.9" (869 x 730 x 658 mm)

Weight 180 lbs. (82 kg)

RT4020 Large Capacity Tray (LCT)

Paper Capacity 4,400 sheets

Paper Size 8.5" x 11"

Paper Weight 14 lb. – 80 lb. Cover (52 - 216 g/m

)

Size 19.7" x 21.3" x 24.6" (500 x 540 x 625 mm)

(with LG unit)

Weight 44 lbs. (20 kg)

CI4010 Single Source Cover Interposer

Paper Size 5.5" x 8.5" - 11" x 17"

Paper Weight 17 lb. Bond – 80 lb. Cover (64 – 216 g/m

)

Stack Capacity 200 sheets x 1 tray

CI4020 Dual Source Cover Interposer

Paper Size 5.5" x 8.5" – 13" x 19"

Paper Weight 17 lb. Bond – 80 lb. Cover (64 – 216 g/m

)

Stack Capacity 200 sheets x 2 trays

SR4090 3,000-Sheet Finisher with 65-Sheet Stapler

Capacity (Proof Tray) 250 sheets (8.5" x 11" or smaller)

50 sheets (8.5" x 14" or larger)

Capacity (Shift Tray) 8.5" x 11" – 3,000 sheets

8.5" x 14" – 13" x 19.2" – 1,500 sheets

Paper Size 5.5" x 8.5" – 13" x 19.2"

Paper Weight Proof Tray: 14 lb. Bond – 80 lb. Cover

(52 – 220 g/m

)

Shift Tray: 14 lb. Bond – 110 lb. Cover

(52 – 300 g/m

)

Staple 8.5" x 11" – 11" x 17" – 65 pages

Size 25.8" x 24.1" x 37.8" (657 x 613 x 960 mm)

Weight 117 lbs. (53 kg)

SR4110 3,000-Sheet Finisher with 100-Sheet Stapler

Capacity (Proof Tray) 500 sheets (8.5" x 11" or smaller)

250 sheets (8.5" x 14" or larger)

Capacity (Shift Tray) 8.5" x 11" – 3,000 sheets (LEF)

8.5" x 11" – 11" x 17" – 1,500 sheets (LEF)

12" x 18" – 13" x 19" – 1,000 sheets (SEF)

Paper Size 5.5" x 8.5" – 13" x 19"

Paper Weight Proof Tray: 14 lb. Bond – 80 lb. Cover

(52 – 216 g/m

)

Shift Tray: 14 lb. Bond – 110 lb. Cover

(52 – 300 g/m

)

Staple 8.5" x 11" – 100 pages

8.5" x 14" – 11" x 17" – 50 pages

Size 31.7" x 28.7" x 38.5" (806 x 730 x 980 mm)

Weight 165 lbs. (75 kg)

SR4100 2,000-Sheet Booklet Finisher

Capacity (Proof Tray) 250 sheets (8.5" x 11" or smaller)

50 sheets (8.5" x 14" or larger)

Capacity (Shift Tray) 8.5" x 11" – 2,000 sheets (LEF)

8.5" x 11" – 13" x 19.2" –1,000 sheets (SEF)

Paper Size 5.5" x 8.5" – 13" x 19.2"

Paper Weight 14 lb. Bond – 80 lb. Cover (52 – 220 g/m

)

Staple 8.5" x 11" – 11" x 17" – 65 pages

Saddle Stitch Staple 8.5" x 11" – 13" x 18" – 20 pages

Size 25.8" x 24.1" x 37.8" (657 x 613 x 960 mm)

Weight 117 lbs. (53 kg)

FD4000 Multi-Folding Unit

Folding Type: Single Sheet Mode: Z-Fold, Half-Fold,

Letter Fold-in, Letter Fold-out, Double

Parallel, Gate-Fold

Multiple Sheet Mode: same as Single

Sheet mode; up to 3 sheets.

Paper Size: Single Sheet Mode: Z folding: 8.5" x 11" –

12" x 18"; Half folding: 8.5" x 11" – 13" x

19.2"; Letter folding: 8.5" x 11" – 12" x 18";

Double Parallel/ Gate folding: 8.5" x 11" –

12" x 18"

Multiple Sheet Mode: Half folding: 8.5" x 11"

– 13" x 19.2"; Letter Fold-out: 8.5" x 11" – 8.5"

x 14"; Letter Fold-in: 8.5" x 11" – 12" x 18"

Size 18.5" x 38.5" x 28.75" (470 x 980 x 730 mm)

Weight 203 lbs. (92 kg)

GBC StreamPunch

™

Paper Size Punched 8.5" x 11" (LEF)

Paper Weight 20 lb. Bond – 110 lb. Index (216 g/m

)

Die Sets CombBind

, Twin Loop Wire (2:1 or 3:1),

ColorCoil

, VeloBind

, Three-Ring, ProClick

BK5010e Production Booklet Maker

Paper Size 8.5" x 11" – 11" x 17"

Paper Weight 16 lb. Bond – 110 lb. Index (216 g/m

)

Additional Accessories

PU5000 Punch Unit; PU3060 Punch Unit; 11" x 17" Tray Unit Type

M2; Copy Data Security Kit Type G; Adobe PostScript3 Unit Type

M2; IEEE802.11a/g/n Type M2; IEEE1284 I/F Board Type A;

G3 Interface Kit Type M2; Copy Tray Type M2; FAX Memory Unit

Type B 32MB; OCR Unit Type M2; IPDS Unit Type M2; SD Card for

Netware Printing Type M2; Fax Option Type M2; Fax Connection

Unit Type M2; Smart Card Reader Type M2, DataOverwriteSecurity

System Unit (DOSS) Type H(ISO15408 certified), CS4010 9-Bin

Mailbox Unit, Web Browser (option) for Ricoh Integrated Cloud

Environment (ICE) integration (option), Device Manager NX

integration (option)

Fiery E-22B Color Controller Specifications

Controller Type Embedded Type

Fiery Platform FS100

Maximum Continuous MP C6502: 65 ppm B/W and Color

Print Speed MP C8002: 80 ppm B/W and Color

CPU Intel Processor G850 2.9GHz

Host Interface 1000Base-T/100Base-TX/10Base-T

Memory 2 GB

Internal HDD 500 GB

Operating System Linux

Network Protocol TCP/IP (IPv4/IPv6), SMB, Bonjour

Printer Description Adobe PostScript 3 (std.), PCL6/5c (std.)

Language

Max Print Resolution Up to 1200 dpi (2 bit)

Max Scan Resolution Up to 600 dpi

Fonts PS3: 138 fonts/PCL: 81 AGFA fonts

Operation Panel Via touch panel display on the MFP

Utilities Standard: Command WorkStation 5,

Fiery Scan, Printer Delete Utility, Fiery

Web Tools, Fiery Bridge, Fiery VUE,

Secure Erase

Optional: Fiery Impose, Fiery Compose,

Color Profiler Suite ES-2000, Auto

Trapping, Spot-On, Hot Folders/Virtual

Printers, Productivity Package

Color Management Tools ICC Profile, Color Chart, CMYK Color

Reference Pages, RGB Color Tests,

Trapping Support

Calibration Color Cal, ES-2000 (opt.)

For maximum performance and yield, we recommend using genuine

Ricoh parts and supplies.

R3437

Ricoh Americas Corporation, 70 Valley Stream Parkway, Malvern, PA 19355, 1-800-63-RICOH

reserved. The content of this document, and the appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products are

shown with optional features. While care has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or adequacy

of the information contained herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the

conditions and factors affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.

www.ricoh-usa.com

Other manuals for MP C6502 Series

This manual suits for next models

Other Ricoh MFP manuals
