RidgeMonkey ESCAPE BIVVY XF1 User manual
XF1 & XF1 COMPACT
ESCAPE
BIVVY INSTRUCTIONS
2
XF1 Assembly:
1. Remove the Escape XF1 from the carry bag and with the door facing upwards, lay the it in the
required position and peg the two rear corners into place. Carefully open the outer arms.
2. Standing in front of the doorway and holding the front crossbar, pull the Escape XF1 upwards
and towards you to raise the bivvy into position. Stand inside the bivvy and lock the two internal
X-Framebossesintoplacebyslidingthemupwardsalongtheinternalsidebarsuntilrmly
seated in the location point.
3. Clip the two short non-adjustable tension bars into their corresponding position to extend the
front peak. Clip the long curved non-adjustable tension bar across the two shorter bars to ensure
no rainwater can pool in the peak area.
4. Pegtheperimeterofthebivvytothegroundandzipontheysheetifrequired
(seettinginstructions).
5. UnfoldthegroundsheetinsidetheEscapeXF1andafxtotheskirtusingthevelcroxing
points. Note that the small RidgeMonkey logo indicates the front of the groundsheet and
should be placed in the door area.
6. Clip the four adjustable tension bars between the rear bars of the inner X-Frame. These only
require light pressure to operate effectively, DO NOT over-extend.
3
XF1 Disassembly:
1. Removeysheet,allperimeterpegsexceptthetworearcornersandgroundsheet.Removeall
tension bars.
2. Firmly depress the two X-Frame locking bosses downward along the side bars to unseat them
and release tension from the canopy. Holding the front crossbar of the Escape XF1, carefully
lowerthebivvytotheoorensuringallmaterialisfoldedneatlybetweenthecrossbars.
3. WiththeEscapeXF1nowcompletelyontheoorandstartingwitharm#1,carefullyfoldthe
outer arms inwards until they meet the crossbars. Unpeg the two rear corners.
4. Ensuring all material is folded neatly, your Escape XF1 can now be placed inside the carry bag until
your next session*
*Note: see storage information
4
Flysheet:
1. ZiptheysheettothecorrespondingzipontherearoftheEscapeXF1,assemblethe
elasticatedcurvedysheetsupportbarandattachittotheinsideoftheysheetusingthe
velcrotabssewnintotheysheetmaterial.
2. Screwthesuppliedstormpolesontoeachendofthecurvedysheetbar,locatetheupright
stormpolesinthevelcroretainingapsoftheEscapeXF1andattachtheysheethooksto
the retaining rings on the upright storm poles.
3. AdjusttheheightofthestormpolesandpegtheysheettothegroundattherearoftheEscape
XF1,ensuringagenerousgapbetweenysheetandbivvyforoptimumprotection.
4. Removalisareverseoftting.
5
Storage & Aftercare:
Proper storage is one of the most vitally important aspects of caring for your new Escape XF1 Bivvy
and every effort should be taken to ensure the bivvy is packed away dry. If you need to pack away
the bivvy when it is wet, it is of paramount importance that it is unpacked and dried completely
within 24 hours before being repacked dry. If stored when damp or wet mildew and rust will be able
to form, both of which can severely damage the product and its accessories.
Always store in a cool, dark, dry place away from sources of heat or moisture. If storing for extended
periods, we recommend unzipping the carry bag to allow fresh dry air to circulate.
RegularlycleaningandreproongyourEscapeXF1bivvywillmaintainitsabilitytorepelwater.
Use only clean, fresh water and a soft brush or cloth to clean your Escape XF1 bivvy. Do not use
detergents or chemicals of any sort and never machine wash or tumble dry your bivvy.
Warranty:
RidgeMonkey provides customers with a comprehensive warranty of two years from the date of
purchase. Please keep your receipt in a safe place as it may be needed in the event of a claim. Your
warranty covers repair or replacement at our discretion in the event of a manufacturing fault. Cover
excludesdamagearisingfrom(butnotlimitedto)misuse,neglect,improperstorage,improper
cleaning, Acts of God and cover is valid when your product is being used for recreational purposes
only. No consequential loss may be claimed. This warranty is provided in addition to your statutory
consumer rights in the country of purchase.
6
Warning:
• NEVER use any fuel-burning products inside or within close proximity of your Escape XF1 bivvy.
Doing so can result in the accumulation of dangerous concentrations of carbon monoxide
which can be fatal.
• WhiletheEscapeXF1isbuiltusingCPAI-84ameresistantfabric,itisnotreproofandwill
burnifleftincontinuouscontactwithanopenameorotherheatsource.Failuretokeep
ameandheatsourcesawayfromtheEscapeXF1canleadtorewhichmayresultinserious
injury or death.
• Always peg down your Escape XF1 properly to reduce the risk of loss or injury. Enough pegs
and guy ropes are supplied to safely secure your Escape XF1 in most situations, however
it may be necessary to purchase additional pegs and ropes for use in extreme conditions.
Tightly tensioning your Escape XF1 with the included guy ropes further increases its strength
and stability and we recommend that you do so whenever possible.
• Always maintain adequate ventilation inside your Escape XF1 at all times to help reduce
thebuild-upofcondensation,moistureandodour.Useoftheysheetwillalsohelptomaintain
temperature and prevent the build-up of condensation inside the Escape XF1.
7
Contact Us:
For any enquiries or comments concerning our products, please use the contact form on
www.ridgemonkey.co.uk or call our dedicated Customer Services team on +44 151 486 7070, and
we will respond to you as soon as possible.
Statement:
• Intherstinstance,we’reonlyabletoprovideafter-salesserviceforpurchasesmadedirectly
from RidgeMonkey. If you purchased your product through an authorised retailer, please
contact them for any warranty issues and they will manage the claim on your behalf. Your
statutory rights are unaffected.
• Please note that unauthorised trade reselling of RidgeMonkey products is prohibited. If you are an
established high street retailer and wish to apply for a RidgeMonkey trade account, please contact
HeadOfceon +44 151 486 7070
• All brand names and trademarks used in this instruction manual are property of their
respectiveownersandinnowayendorse(orimplyendorsement)ofanyproductdescribedin
this instruction manual.
• This instruction manual and all literature contained within remains copyright of
RidgeMonkey®. Any unauthorised copying, lending or reproduction without prior written
permission is strictly prohibited.
