RIDGID 1620RV0 User manual

1620RV0
16 U.S. GALLON/ 60 LITER
PROFESSIONAL WET/DRY
BLOWER VAC
FOR QUESTIONS OR INFORMATION CONTACT US AT
1-800-4-RIDGID (1-800-474-3443) from the US and Canada
01-800-701-9811 from Mexico
www.ridgidvacs.com
Part No. SP6953 Printed in Mexico
OWNER’S MANUAL
SAVE THIS MANUAL FOR FUTURE REFERENCE
WARNING:
To reduce the risk of injury, the user must read and understand the owner’s manual
before using this product.
!
Thank you for buying a RIDGID product. • Español - página 21
• Français - page 41
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 1

2
Table of Contents
Safety is a combination of common sense,
staying alert, and knowing how your
Wet/Dry Vacuum cleaner (“Vac”) works.
Safety Signal Words
DANGER: Indicates a hazardous
situation which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury, or
property damage.
When using your Vac, always follow basic
safety precautions including the following:
WARNING
- To reduce the risk of fire, electric
shock, or injury:
• Read and understand this manual and
all labels on the Vac before operating.
• Use only as described in this manual.
• Do not leave Vac running while
unattended - you may fail to notice
important signs indicating abnormal
operation such as loss of suction,
debris/liquid exiting exhaust, or
abnormal motor noises. Immediately
stop using Vac if you notice these signs.
• Do not leave Vac when plugged in.
Unplug from outlet when not in use and
before servicing.
• Sparks inside the motor can ignite
flammable vapors or dust. To reduce
the risk of fire or explosion, do not
IMPORTANT SAFETY INSTRUCTIONS
!
!
!
!
vacuum or use near combustible
liquids, gases, or dusts, such as
gasoline or other fuels, lighter fluid,
cleaners, oil-based paints, natural gas,
coal dust, magnesium dust, grain dust,
aluminum dust, or gun powder.
• Do not vacuum anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
• Do not vacuum drywall dust, cold
fireplace ash, or other fine dusts with
standard filter. These may pass through
the filter and be exhausted back into the
air. Use a fine dust filter instead.
• To reduce the risk of inhaling toxic
vapors, do not vacuum or use near
toxic or hazardous materials.
• To reduce the risk of electric shock, do
not expose to rain or allow liquid to
enter motor compartment. Store
indoors.
• This Wet/Dry Vac is not intended for
use by persons (including children) with
reduced physical, sensory, or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Do not allow to be used as a toy. Close
attention is necessary when used by or
near children.
• Do not use with a torn filter or without
the filter installed except when
vacuuming liquids as described in this
manual. Dry debris ingested by the
impeller may damage the motor or be
exhausted back into the air.
• Turn off Vac before unplugging.
Section Page
Introduction . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking and Checking
Carton Contents . . . . . . . . . . . . . . . 4
Drum/Caster Foot Assembly . . . . . . . . . 5
Accessory Storage Holder. . . . . . . . . . . 6
Accessory Storage . . . . . . . . . . . . . . . . 6
Wet/Dry Vac Assembly . . . . . . . . . . . . . 7
Positioning Detachable Blower
(Power Head Assembly). . . . . . . . . . . 8
Operation. . . . . . . . . . . . . . . . . . . . . . . . 9
Vacuuming Dry Materials . . . . . . . . . 10
Vacuuming Liquids . . . . . . . . . . . . . . 10
Emptying the Drum . . . . . . . . . . . . . 10
Moving the Wet/Dry Vac. . . . . . . . . . 11
Blowing Feature . . . . . . . . . . . . . . . . 11
Using the Detachable Blower
for “Blowing” . . . . . . . . . . . . . . . . . 12
Detachable Blower Intake . . . . . . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . 14
Repair Parts. . . . . . . . . . . . . . . . . . . . . 18
Servicing of Double-Insulated Wet/Dry Vac . 18
Warranty . . . . . . . . . . . . . . . . . . . . . . . 20
Section Page
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 2

3
CAUTION:
• To reduce the risk of hearing damage,
wear ear protectors when using for
extended time or in a noisy area.
• For dusty operations, wear dust mask.
• Static shocks are common when the
relative humidity of the air is low.
Vacuuming fine debris with your Vac
can deposit static charge on the hose
or Vac. To reduce the frequency of
static shocks in your home or when
using this Vac, add moisture to the air
with a humidifier.
• To reduce the risk of injury from
accidental starting, unplug power cord
before changing or cleaning filter.
• Do not unplug by pulling on cord.
To unplug, grasp the plug, not the cord.
• Do not use with damaged cord, plug or
other parts. If your Vac is not working
as it should, has missing parts, has
been dropped, damaged, left outdoors,
or dropped into water, contact RIDGID
Customer Service.
• Do not pull or carry by cord, use cord
as handle, close a door on cord, or pull
cord around sharp edges or corners.
Do not run Vac over cord. Keep cord
away from heated surfaces.
• Do not handle plug, switch, or the Vac
with wet hands.
• Use only extension cords that are rated
for outdoor use. Extension cords in
poor condition or too small in wire size
can pose fire and shock hazards.
To reduce the risk of these hazards,
be sure the cord is in good condition
and that liquid does not contact the
connection. Do not use an extension
cord with conductors smaller than
16 gauge (AWG) in size. To reduce
power loss, use a 14 gauge extension
cord if 25 to 50 ft. long and 12 gauge
for 50 ft. or longer.
• This Wet/Dry Vac is double-insulated,
eliminating the need for a separate
grounding system. Use only identical
replacement parts. Read the
instructions for Servicing Double-
Insulated Wet/Dry Vacs before
servicing.
• Do not put any object into ventilation
openings. Do not vacuum with any
ventilation openings blocked; keep free
of dust, lint, hair or anything that may
reduce air flow.
• Keep hair, loose clothing, fingers, and
all parts of body away from openings
and moving parts.
• To reduce the risk of falls, use extra
care when cleaning on stairs.
• To reduce the risk of back injury or
falls, do not lift a Vac that is heavy with
liquid or debris. Partially empty the
Vac by scooping debris or draining
liquid to make it comfortable to lift.
• To reduce the risk of personal injury or
damage to Vac, use only Ridgid
recommended accessories.
• When using as a detached blower:
- Direct air discharge only at work area.
- Turn unit off before setting on ground
or releasing grasp from handle.
- Do not set down in liquid; electric
shock could occur.
- Do not direct air at bystanders.
- Keep children away when blowing.
- Do not use blower for any job except
blowing dirt and debris.
- Do not use as a sprayer.
• To reduce the risk of eye injury, wear
safety eyewear. The operation of any
utility Vac or blower can result in foreign
objects being blown into the eyes, which
can result in severe eye damage.
Observe the following warnings that
appear on the motor housing of your Vac:
DOUBLE INSULATED
GROUNDING NOT REQUIRED.
WHEN SERVICING USE ONLY
IDENTICAL REPLACEMENT PARTS.
!
WARNING: When using blower:
Wear safety goggles labeled “ANSI
Z87.1” on the package. Turn unit off
before setting on ground or
releasing grasp from handle.
Electric shock could occur if used
on wet surfaces. Direct tool
discharge only at work area. Do not
direct discharge at bystandaders,
Keep children away.
WARNING: To reduce the risk of
electric shock - do not expose to
rain - store indoors.
!
!
SAVE THIS MANUAL
WARNING:
• For your own safety, read and
understand owner's manual.
• Do not run unattended.
• Do not pick up hot ashes, coals,
toxic, flammable or other
hazardous materials.
• Do not use around explosive
liquids or vapors.
!
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 3

4
Introduction
This Wet/Dry Vac with Detachable Blower
is intended for household use. It may be
used for vacuuming wet or dry media and
may be used as a blower.
Read this owner’s manual to familiarize
yourself with the product features and to
understand the specific usage of your
new Vac.
Unpacking and Checking Carton Contents
Carton Contents List
Key Description Qty
A Wet/Dry Vac . . . . . . . . . . . . . . . . . 1
B Accessory Storage Holder . . . . . . 1
C Extension Wands . . . . . . . . . . . . . 2
D Qwik Lock™ Filter. . . . . . . . . . . . . 1
E Pro-Hose. . . . . . . . . . . . . . . . . . . . 1
F Caster Feet . . . . . . . . . . . . . . . . . 2
G Caster Feet with Storage . . . . . . . 2
H #10 x 1-3/4” screws . . . . . . . . . . . 4
I Caster Wheel . . . . . . . . . . . . . . . . 4
J Car Nozzle . . . . . . . . . . . . . . . . . . 1
K Utility Nozzle . . . . . . . . . . . . . . . . . 1
L Wet Nozzle . . . . . . . . . . . . . . . . . . 1
M Blower Wand. . . . . . . . . . . . . . . . . 1
N Owner’s Manual . . . . . . . . . . . . . . 1
A
B
E
G
H
J
K
L
M
N
I
D
C
F
Remove contents of carton. Check each
item against the Carton Contents List.
Call 1-800-4-RIDGID (1-800-474-3443)
from the US & Canada, 01-800-701-9811
from Mexico, or E-mail us at
[email protected] if any parts are
damaged or missing.
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 4

5
If any parts are missing or damaged
contact Customer Service.
Do not assemble until you have all the
parts.
1. Insert the front and rear caster feet into
the bottom of drum as shown. Light
taps with a mallet or hammer may be
needed to fully seat both caster feet.
2. Install (4) #10 x 1-3/4” screws into
matching holes on both front and rear
caster feet, securing them to the
bottom of the drum. Tighten screws
until just snug. Do not over tighten as
this may tend to deform the caster feet.
3. Insert the caster stem into each of the
caster feet, as shown.
4. Push on the caster until the ball on the
caster stem is inserted all the way into
the socket. You will be able to hear the
ball snap into the socket and the caster
will swivel easily when positioning is
correct.
Drum/Caster Foot Assembly
Rear
Caster
Foot
Drain
Front
Caster
Foot
Drum
Front
Caster
Foot
Drain
#10 x 1-3/4"
Screw (4)
Rear
Caster
Foot
Socket
Caster Stem
Caster Ball
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 5

6
Accessory
Storage
Holder
Accessory
Holder
Receptacles
Accessory Storage
Holder Clips
Accessory
Holder
Receptacles
Accessory
Storage
Holder
Accessory Storage
Holder Clips
Installing Accessory Storage
Holder
1. Position rods of accessory storage
holder directly over accessory rod
receptacles in dust drum.
2. Slide accessory storage holder into
accessory rod receptacles until fully
seated with holder clips locked.
Accessory Storage Holder
Removing Accessory Storage
Holder
Push in both accessory storage holder
clips and then pull straight up on rods of
accessory storage holder.
Accessory Storage
Your accessory storage holder has been
designed to hold all the accessories
included with your Vac. The accessories
should be stored as shown.
NOTE: Insert female end of extension
wand into the holder sleeve as shown.
Accessory
Storage
Holder
Accessories
Pro-Hose
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 6

7
Cord
Wrap
Detachable
Blower
Power
Cord
Cord Swivel
Accessory Storage (continued)
Cord Wrap
When vacuuming is complete, unplug the
cord and wrap it around the detachable
blower as shown.
Wet/Dry Vac Assembly
Vacuum
Inlet
Detachable
Blower
Handle
Lid Assembly with
Detachable Blower
Drum Latch
Drum Catch
Inlet
Drain Cap
Dust Drum
Assembly
1. Locate the lid assembly and the drum
assembly (assembled earlier).
2. Position the lid assembly with the
detachable blower handle of the unit
located above the vacuum inlet on the
dust drum.
3. To assemble the lid assembly to the
drum assembly, lower the lid assembly
onto the dust drum. Rotate both
latches down until you hear them snap
over the drum latch catches of the
drum.
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 7

8
Positioning Detachable Blower
(Power Head Assembly)
Release
Button
Press and Pull
Pro-Hose
1. To remove the detachable blower from
the lid assembly, press down on the
detachable blower latch under the
detachable blower handle and lift the
blower off the lid of the Vac.
Detachable
Blower Handle
Detachable
Blower
Latch
3. Lightly press down on the carry handle
of the detachable blower until you
hear the “snap” of the detachable
blower latch engaging the detachable
blower. The detachable blower is now
latched to the lid assembly.
4. Your new Wet/Dry Vac is ready for
use. With the Wet/Dry Vac completely
assembled and ready for use, insert
the push button end of the Pro-Hose
into the inlet of the Vac. The hose
should snap into place. To remove the
hose from the Vac, press the release
button in the hose assembly and pull
the hose out of the Vac inlet, as
shown.
Detachable
Blower
Molded
Leads
2. To replace the detachable blower onto
the lid assembly, position detachable
blower above the indented area of the
lid assembly. Rotate the detachable
blower down until the travel of the unit
stops.
Detachable
Blower
Detachable
Blower Latch
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 8

9
To reduce the risk of electric shock, this
Vac has a polarized plug (one blade is
wider than the other). Except for 230 volt
models, this plug will fit in a polarized
outlet only one way. If the plug does not
fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified
electrician to install the proper outlet.
Do not change the plug in any way.
Operation
Extension Wands - These wands can be
connected together and provides
additional length for more reach.
Utility Nozzle - General purpose nozzle for
most vacuuming applications.
Car Nozzle - Dry pickup nozzle for car
interiors and most upholstery cleaning.
Wet Nozzle - Used for wet pickup on
smooth surfaces to pick up liquid and dry
the surface in one stroke.
Blower Wand - Attaches directly to the
power assembly concentrates the air for
blowing applications.
Pro-Hose - Provides transfer of vacuum
or blowing capability to work site. Provides
the means of attaching extension wands
and nozzles.
Accessory Storage Holder - Store all
the accessories with your Vac.
Caster Feet - Store accessories with
your Vac.
Familiarize yourself with the accessories
included with the Vac. Each accessory may
be used in various ways for vacuuming
and blowing debris. Here is a list of the
accessories and their uses.
After you plug the power cord into the
outlet, turn the unit on by sliding the
switch from position "O" to position "l":
=OFF =ON
WARNING: To reduce the risk of fire, explosion, or damage to Vac:
• Do not leave Vac running while unattended - you may fail to notice important
signs indicating abnormal operation such as loss of suction, debris/liquid
exiting the exhaust, or abnormal motor noises. Immediately stop using Vac
if you notice these signs.
• Do not leave Vac plugged in when not in use.
• Do not continue running when float has cut off suction.
• Sparks inside the motor can ignite airborne flammables. Do not operate Vac
near flammable liquids or in areas with flammable gases, vapors, or
explosive/airborne dust. Flammable liquids, gases, and vapors include:
lighter fluid, solvent-type cleaners, oil-based paints, gasoline, alcohol, and
aerosol sprays. Explosive dusts include: coal, magnesium, aluminum,
grain, and gun powder.
• Do not vacuum up explosive dusts, flammable liquids, or hot ashes.
WARNING: To reduce the risk of electric shock or injury:
• Do not expose to rain or allow liquid to enter motor compartment. Store
indoors.
• Do not handle plug, switch, or Vac with wet hands.
• Unplug Vac before servicing. If your Vac is not working as it should, has
missing parts, has been dropped, damaged, left outdoors, or dropped into
water, return it to an independent service center or call customer service.
• When using an extension cord, use only outdoor-rated cords that are in
good condition. Do not allow the connection to come into contact with
liquid.
!
!
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 9

10
Operation (continued)
Vacuuming Dry Materials
1. The filter must always be in correct
position at all times to avoid leaks and
possible damage to Vac.
2. When using your Vac to pick up very
fine dust, it will be necessary for you to
empty the drum and clean the filter at
more frequent intervals to maintain
peak Vac performance.
NOTE: A dry filter is necessary to pick up
dry material. If you use your Vac to pick
up material when the filter is wet, the filter
will clog quickly and be very difficult to
clean.
Vacuuming Liquids
1. When picking up small amounts of
liquid the filter may be left in place.
2. When picking up large amounts of
liquid we recommend that the filter be
removed. If the filter is not removed,
it will become saturated and misting
may appear in the exhaust.
3. When the liquid in the drum reaches a
predetermined level, the float
mechanism will rise automatically to cut
off air-flow. You will know that the float
has risen because Vac airflow ceases
and the motor noise will become higher
in pitch, due to increased motor speed.
When this happens, turn off the Vac,
unplug the power cord, and empty the
drum.
4. After using the Vac to pick up liquids,
the filter must be dried to avoid possible
mildew and damage to the filter.
IMPORTANT: To reduce the risk of
damage to the Vac, do not run motor
with float in raised position.
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before emptying
the drum.
WARNING: To reduce the risk of
back injury or falls, do not lift a Vac
heavy with liquid or debris. Scoop
or drain enough contents out to
make the Vac light enough to lift
comfortably.
Emptying the Drum
3. Dump the drum contents into the proper
waste disposal container.
4. If the contents are liquid, you may
dispose by using the drain provided in
the drum for easy emptying. Simply
unscrew the drain cap and allow the
liquid to drain completely out of the Vac
drum.
WARNING: Do not operate
without filter cage and float, as they
prevent liquid from entering the
impeller and damaging the motor.
Drum
Latch
1. To remove the lid to empty contents of
the dust drum simply lift the two drum
latches on the sides of the dust drum
and lift the lid assembly up and off the
dust drum and set to the side.
2. Lay the lid assembly upside down on a
clean area while emptying drum or
changing the filter.
!
!
!
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 10

11
Operation (continued)
CAUTION: Wear a dust mask if
blowing creates dust which might
be inhaled.
1. Familiarize yourself with the detachable
blower portion of your Wet/Dry Vac.
2. Remove the detachable blower of
your Vac by pressing down on the
detachable blower latch under the
handle of the detachable blower and
lift by the handle to remove.
CAUTION: To reduce the risk of
hearing damage, wear ear protectors
when using the Vac/Blower for
extended time or in a noisy area.
!
!
WARNING: To reduce the risk of
injury to bystanders, keep them
clear of blowing debris.
!
Detachable
Blower Handle
Detachable
Blower
Latch
Detachable
Blower
Molded
Leads
Blowing Feature
Your Wet/Dry Vac has a “detachable
blower.” It has the capability to be used
as a dedicated blower for yard work,
patio cleanup, and garage applications
to blow dust and other debris.
WARNING: Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
using as a Blower.
!
Moving the Wet/Dry Vac
Should it become necessary to pick the
Vac up to move it, the handles on the
sides of the dust drum are used to lift.
To maneuver the Vac, the handle above
the inlet can be used.
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 11

- OR -
2. The Wet/Dry Vac may also be used for
blowing using the seven-foot hose
supplied with the Wet/Dry Vac. Install
the push button end of the Vac hose in
the blowing port of the detachable
blower. For added control, an
extension wand and/or car nozzle can
be added to the opposite end of the
hose. The unit is ready for blowing
applications.
12
Operation (continued)
Using the Detachable Blower
for “Blowing”
Two suggested methods of using the
blower are:
1. Insert the round end of the blower wand
into the blowing port of the detachable
blower and turn clockwise to lock.
Male-Male
Adapter
Car Nozzle
Goggles
Dusk Mask
Blowing
Port
Blower
Wand
TURN CLOCKWISE
TO LOCK
3. Turn the blower “ON” by sliding the
switch in the handle of the blower to
the “I” position.
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 12

13
Maintenance
Detachable Blower Intake
After using the detachable blower of your
Wet/Dry Vac, examine the bottom of the
blower for dust and debris. Check to see
if the intake to the blower has debris
stuck to the plastic vents and foam pad.
To clean the foam pad under the intake
shield of the detachable blower:
1. Remove the three screws holding the
intake shield.
2. Lift the intake shield off and set aside.
3. Lift the foam pad away from the
detachable blower.
4. Remove the foam pad and clean in
warm soapy water or brush debris
away. Allow foam pad to dry.
5. Examine foam pad for reuse. If you
need to replace it, check the service
part section of this manual.
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before changing
or cleaning filter or foam pad.
Foam Pad
Intake
Shield
Screws(3)
6. Replace foam pad by reversing steps
1 thru 4.
7. Reinstall intake shield and 3 screws.
The unit is ready for use.
!
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 13

14
Maintenance (continued)
Qwik
Lock™Stud
Filter
Tabs(2)
Integrated Filter
Plate with Center
Hole
PUSH
DOWN
PULL
UP
Rubber
Gasket at
Bottom of
Filter
(cutaway
view)
Float
Lid
Filter
Cage
WARNING: Do not operate
without filter cage and float, as they
prevent liquid from entering the
impeller and damaging the motor.
!
Filter
NOTE: The filter is made of high quality
paper designed to stop very small
particles of dust. The filter can be used
for dry debris or small amounts of liquid.
Handle the filter carefully when removing
or installing. Creases in the filter pleats
may occur from installation but will not
affect the performance of the filter.
Filter Cleaning
Your filter should be cleaned often to
maintain peak Vac performance.
Be sure to dry the filter before storing or
picking up dry debris.
IMPORTANT: After cleaning, check the
filter for tears or small holes. Do not use
a filter with holes or tears in it. Even a
small hole may allow a lot of dust to
come out of the exhaust port of your Vac.
Replace it immediately.
IMPORTANT: To avoid damage to the
blower wheel and motor, always reinstall
the filter before using the Vac for dry
material pickup.
Filter Removal and Installation
of the Qwik Lock™ Filter
Filter Removal:
1. Hold the filter tabs of the Qwik Lock™
filter in each hand.
2. With one thumb on the Qwik Lock™
stud, which protrudes through the
integrated filter plate, lift up on the filter
tabs while pushing down on the stud.
3. This action will cause the filter to
release from the filter cage. Slide filter
off cage.
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before changing
or cleaning filter.
!
Filter Installation:
1. Carefully slide the Qwik Lock™ filter
over the filter cage and press down on
the outside edge of the filter until the
rubber gasket on the bottom of the filter
seats securely around the base of the
filter cage and against the lid.
2. Align the small center hole in the top of
the filter over the Qwik Lock™ stud on
the filter cage. Press firmly on top of
the filter near the stud to allow the filter
to snap over the ball on the end of the
stud. The filter is now attached.
NOTE: Failure to properly seat the
bottom gasket could result in debris
bypassing the filter.
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 14

15
Maintenance (continued)
Cleaning A Dry Filter
1. Light cleaning of some dry debris can
be accomplished without removing the
filter from the Vac. Simply slap your
hand on top of the lid while the Vac is
turned off.
2. Clean the filter in an open area.
Cleaning SHOULD be done outdoors
and not in the living quarters.
3. Remove filter from Vac. Gently tap
filter against the inside wall of your
dust drum. The debris will loosen and
fall.
4. For thorough cleaning of dry filter with
fine dust (no debris), run water
through it as described under
"Cleaning A Wet Filter".
Cleaning A Wet Filter
Remove filter from Vac and run water over
it to remove the dirt. Take care that water
pressure does not damage the filter
material.
Filter Installation
Allow the filter to dry before reinstalling
and storing the Vac.
Cleaning and Disinfecting the
Wet/Dry Vac
To keep your Wet/Dry Vac looking its
best, clean the outside with a cloth
dampened with warm water and mild
soap.
To clean the drum:
1. Dump debris out.
2. Wash drum thoroughly with warm
water and mild soap.
3. Wipe out with dry cloth.
Before prolonged storage, or as needed,
(i.e.; waste water pick up) the drum
should be disinfected.
To disinfect the drum:
1. Pour 1 gallon of water and 1 teaspoon
chlorine bleach into the drum.
2. Let solution stand for 20 minutes,
carefully swishing every few minutes,
making sure to wet all inside surfaces
of the drum.
3. Empty drum after 20 minutes. Rinse
with water until bleach smell is gone.
Allow drum to dry completely before
sealing the motor on the drum.
Cord Maintenance
When vacuuming is complete, unplug the
cord and wrap it around the hooks on the
side of the detachable blower. If the
power cord is damaged, it must be
replaced by the manufacturer or their
service agent or by similarly qualified
personnel to reduce the risk of accident.
Cord
Wrap
Detachable
Blower
Power
Cord
Cord Swivel
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 15

16
Maintenance (continued)
Storage
Before storing your Vac, the drum should
be emptied and cleaned. The cord and
hose should be stored as described in
this manual. Accessories should be kept
in the same area as the Vac so they can
be readily available. The Vac should be
stored indoors.
Casters
If your casters are noisy, you may put a
drop of oil on the roller shaft to make
them quieter.
WARNING: To assure product
SAFETY and RELIABILITY, any other
maintenance, repairs or adjustments
should be performed by Authorized
service centers, always using
RIDGID replacement parts.
!
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 16

17
Notes
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:00 AM Page 17

Key
No. Part No. Description
1 509488 Float
2 823201-3 Filter Cage
3 VF4000 Qwik Lock™ Filter
4 833170-1 Drum Assembly
5 73185 Drain Cap
6 830715 Caster Foot, Front
7 830716 Caster Foot, Rear
8 73102 Caster Wheel
9 833132 Accessory Storage Holder
10 826387 Drum Latch
11 510344 Lid (Includes Key No. 10 & 17)
12 510345 Blower Assembly
13 6833167 Foam Pad
14 818961 Spacer
Key
No. Part No. Description
15 818413 Blower Wheel
16 315534-1 Washer
17 826817 Nut
18 826388 Latch Detachable Blower
19 VT2509 Utility Nozzle
20 VT2503 Car Nozzle
21 833169 Blower Wand
22 VT2510 Wet Nozzle
23 822256 Squeegee
24 VT2508 Extension Wand
25 833177 Cord Swivel
26 831337-9 Pro-Hose
27 SP6953 Owner’s Manual
Repair Parts
16 Gallon Professional Wet/Dry Blower Vac
Model Number 1620RV0
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
† These replacement parts may be available where you purchased your Vac.
18
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) may also be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
!
†
†
†
†
†
†
†
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:01 AM Page 18

Repair Parts (continued)
16 Gallon Professional Wet/Dry Blower Vac
Model Number 1620RV0
RIDGID parts are available on-line at www.ridgidparts.com
9
5
4
3
2
1
11
17
10
18
19
20
21
22
23
26
27
24
7
8
6
12
25
13
14
15
16
24
19
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:01 AM Page 19

Part No. SP6953 Form No. SP6953 Printed in Mexico 01/15
FOR QUESTIONS OR INFORMATION CONTACT US AT
1-800-4-RIDGID (1-800-474-3443) from the US and Canada
01-800-701-9811 from Mexico
www.ridgidvacs.com
Please have your Model Number and Serial Number on hand when calling.
Stock No. 1620RV
Model No. 1620RV0
Serial Number
Model and serial numbers may be found on the back of power head assembly.
You should record both model and serial numbers in a safe place for future use.
c 2015 Emerson
• What is covered
RIDGID®Wet/Dry Vacs are warranted to be free of defects in workmanship and material.
• How long coverage lasts
This warranty lasts for the lifetime of the RIDGID®Wet/Dry Vac.
• How to obtain service
To obtain the benefit of this warranty, deliver via prepaid transportation the complete product to
RIDGE TOOL COMPANY, Elyria, Ohio, or any authorized RIDGID® INDEPENDENT SERVICE
CENTER. Pipe wrenches and other hand tools should be returned to the place of purchase.
• What we will do to correct problems
Warranted Wet/Dry Vacs will be repaired or replaced, at Ridge Tool Company's option, and returned
at no charge; or, if after three attempts to repair or replace during the warranty period the Wet/Dry
Vac is still defective, you can elect to receive a full refund of your purchase price.
• What is not covered
Failures due to misuse, abuse or normal wear and tear are not covered by this warranty. RIDGE
TOOL COMPANY SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
• How local laws relate to the warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific rights, and you
may also have other rights which vary from state to state, province to province, or country to
country.
• No other express warranty applies
This FULL LIFETIME WARRANTY is the sole and exclusive warranty for RIDGID®Wet/Dry Vacs.
No employee, agent, dealer, or other person is authorized to alter this warranty or make any other
warranty on behalf of Ridge Tool Company.
SP6953 Ridgid 1620RV0_SP6542.qxd 1/16/15 10:01 AM Page 20
