RIDGID WD64250 User manual

WD64250
6 U.S. GALLON/22.5 LITER
STAINLESS STEEL WET/DRY VAC
Part No. SP6932 Printed in Mexico
OWNERʼS ANUAL
SAVE THIS ANUAL FOR FUTURE REFERENCE
Thank you for buying a R DG D product.
FOR QUESTIONS OR INFOR ATION CONTACT US AT
1-800-4-RIDGID (1-800-474-3443) from the USand Canada
01-800-701-9811 from exico
www.ridgidvacs.com
• Español - página 17
WARNING:
To reduce the risk of injury, the user must read and understand the owner’s manual
before using this product.
!
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 1

2
Table of Contents
Section Page
Section Page
I PORTANT SAFETY INSTRUCTIONS
Safety is a combination of using common
sense, staying alert, and knowing how your
wet/dry vacuum cleaner (“Vac”) works.
Safety Signal Words
DANGER: ndicates a hazardous
situation which, if not avoided, will result
in death or serious injury.
WARNING: ndicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION: ndicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
When using your Vac, always follow basic
safety precautions including the following:
WARNING
- To reduce the risk of fire, electric
shock, or injury:
• Read and understand this manual and
all labels on the Wet/Dry Vac before
operating.
• Use only as described in this manual.
• Do not leave Vac running while
unattended - you may fail to notice
important signs indicating abnormal
operation such as loss of suction,
debris/liquid exiting exhaust, or
abnormal motor noises. mmediately
stop using Vac if you notice these
signs.
• Do not leave Vac when plugged in.
Unplug from outlet when not in use and
before servicing.
• Sparks inside the motor can ignite
flammable vapors or dust. To reduce
the risk of fire or explosion, do not use
near combustible liquids, gases, or
!
!
!
!
dusts, such as gasoline or other fuels,
lighter fluid, cleaners, oil-based paints,
natural gas, coal dust, magnesium
dust, grain dust, aluminum dust, or gun
powder.
• Do not vacuum anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
• Do not vacuum drywall dust, cold
fireplace ash, or other fine dusts with
standard filter. These may pass through
the filter and be exhausted back into
the air. Use a fine dust filter instead.
• To reduce the risk of inhaling toxic
vapors, do not vacuum or use near
toxic or hazardous materials.
• To reduce the risk of electric shock,
do not expose to rain or allow liquid to
enter motor compartment. Store
indoors.
• This Wet/Dry Vac is not intended for
use by persons (including children) with
reduced physical, sensory, or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
• Do not use with a torn filter or without
filter installed except when vacuuming
liquids as described in this manual.
Dry debris ingested by the impeller
may damage the motor or be
exhausted into the air.
• Turn off Vac before unplugging.
ntroduction . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking and Checking
Carton Contents. . . . . . . . . . . . . . . . . 4
CasterAssembly. . . . . . . . . . . . . . . . . . . 5
Carry Handle Assembly. . . . . . . . . . . . . 5
Wet/Dry Vac Assembly . . . . . . . . . . . . . 6
Accessory Storage . . . . . . . . . . . . . . . . 7
Operation . . . . . . . . . . . . . . . . . . . . . 7-10
Vacuuming Dry Materials . . . . . . . . . . 8
Vacuuming Liquids . . . . . . . . . . . . . . . 9
Emptying the Drum . . . . . . . . . . . . . . 9
Moving the Wet/Dry Vac . . . . . . . . . . 10
Blowing Feature . . . . . . . . . . . . . . . . 10
Maintenance. . . . . . . . . . . . . . . . . . 11-13
Repair Parts . . . . . . . . . . . . . . . . . . 14-15
Warranty . . . . . . . . . . . . . . . . . . . . . . . 16
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 2

3
• To reduce the risk of personal injury or
damage to Vac, use only Ridgid
recommended accessories.
• When using as a blower:
- Direct air discharge only at work
area.
- Do not direct air at bystanders.
- Keep children away when blowing.
- Do not use blower for any job except
blowing dirt and debris.
- Do not use as a sprayer.
• To reduce the risk of eye injury, wear
safety eyewear. The operation of any
utility Vac or blower can result in
foreign objects being blown into the
eyes, which can result in severe eye
damage.
• To reduce the risk of injury from
accidental starting, unplug power cord
before changing or cleaning filter.
• Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
• Do not use with damaged cord, plug or
other parts. f your Vac is not working
as it should, has missing parts, has
been dropped, damaged, left outdoors,
or dropped into water, call customer
service.
• Do not pull or carry by cord, use cord
as handle, close a door on cord, or pull
cord around sharp edges or corners.
Do not run Vac over cord. Keep cord
away from heated surfaces.
• Do not handle plug, switch, or the Vac
with wet hands.
• Use only extension cords that are rated
for outdoor use. Extension cords in
poor condition or too small in wire size
can pose fire and shock hazards. To
reduce the risk of these hazards, be
sure the cord is in good condition and
that liquid does not contact the
connection. Do not use an extension
cord with conductors smaller than
16 gauge (AWG) in size. To reduce
power loss, use a 14 gauge extension
cord if 25 to 50 ft. long and 12 gauge
for 50 ft. or longer.
• This Wet/Dry Vac is double-insulated,
eliminating the need for a separate
grounding system. Use only identical
replacement parts. Read the instructions
for Servicing Double- nsulated Wet/Dry
Vacs before servicing.
• Do not put any object into ventilation
openings. Do not vacuum with any
ventilation openings blocked; keep free
of dust, lint, hair or anything that may
reduce air flow.
• Keep hair, loose clothing, fingers, and
all parts of body away from openings
and moving parts.
• To reduce the risk of falls, use extra
care when cleaning on stairs.
• To reduce the risk of back injury or
falls, do not lift a Vac that is heavy with
liquid or debris. Partially empty by
scooping debris or draining liquid.
Observe the following warnings that
appear on the motor housing of your Vac:
WARNING: For your own safety,
read and understand ownerʼs
manual. Do not run unattended.
Do not pick up hot ashes, coals,
toxic, flammable or other hazardous
materials. Do not use around
explosive liquids or vapors.
WARNING: To reduce the risk of
electric shock - do not expose to
rain - store indoors.
DOUBLE NSULATED
GROUND NG NOT REQU RED.
WHEN SERV C NG USE ONLY
DENT CAL REPLACEMENT PARTS.
!
!
SAVE THIS ANUAL
CAUTION:
• To reduce the risk of hearing damage,
wear ear protectors when using for
extended hours or in a noisy area.
• For dusty operations, wear dust mask.
• Static shocks are common when the
relative humidity of the air is low.
Vacuuming fine debris with your Vac can
deposit static charge on the hose or
Vac. To reduce the frequency of static
shocks in your home or when using this
Vac, add moisture to the air with a
humidifier.
!
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 3

Unpacking and Checking Carton Contents
4
Introduction
This Wet/Dry Vac is intended for
house-hold use. t may be used for light
vacuuming of wet or dry media and may
be used as a blower. The light weight
design allows usage for most small
household vacuuming chores.
Carton Contents List
Key Description Qty
A Wet/Dry Vac .................................1
B Carry Handle................................1
C Tug-A-Long Hose .........................1
D Extension Wands ........................2
E Casters .......................................4
F Utility Nozzle ................................1
G 1-7/8” Wet Nozzle ........................1
H* Float ............................................1
* Filter Cage ...................................1
J* VF4000 Cartridge Filter ...............1
K Owner’s Manual ...........................1
* tems may come preassembled.
A
B
F
G
E
K
D
C
J
I
H
Familiarize yourself with the following
product and features and read the entire
owner’s manual for specific usage of your
new Wet/Dry Vac.
Remove contents of carton. Check each
item against the Carton Contents List.
Contact 1-800-4-R DG D (1-800-474-3443)
from the US and Canada, 01-800-701-9811
from Mexico. E-mail us [e-mail]
or www.ridgidvacs.com if any parts are
damaged or missing.
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 4

5
Caster
Socket
Drum
Caster
Caster
Stem
1. Turn the dust drum upside down on
the floor.
2. nsert the caster feet into the bottom of
drum, as shown (4 places).
3. Push on the caster foot until the foot is
flush with bottom of the dust drum.
4. nsert the caster stem into the socket
of the caster foot, as shown (4 places).
5. Push on the caster until the ball on the
caster stem is inserted all the way into
the socket. You will hear the ball snap
into the socket and the caster will
swivel easily when positioning is
correct.
6. Turn the drum upright.
Caster Assembly
Power Head
Assembly
Carry
Handle
Screw (2)
1. Place the carry handle on the Wet/Dry
Vac power head assembly.
2. Tighten both screws to assemble the
carry handle on the power head
assembly.
Carry Handle Assembly
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 5

6
Dust
Drum
Drum
Latch
Power
Head
Assembly
Hook
Power Head Assembly
Power Head
Assembly
Drum Latch
Dust Drum
Assembling the Power Head:
1. Align the front of the power head
assembly with the vacuum port
located on the front of the dust drum,
as shown.
2. Place the power head assembly on
top of the dust drum.
3. Ensure the power head assembly
completely covers the top of the dust
drum so leakage does not occur.
4. Rotate the drum latch up and over the
power head assembly hook to engage
the two latches.
5. To remove the power head assembly,
reverse these directions.
Vacuum
Port
Hose
Inserting Hose:
1. nsert the larger end of the hose into
the vacuum port.
2. Optional: Place the utility nozzle
securely on the opposite end of the
hose. The Vac is ready for use.
Wet/Dry Vac Assembly
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 6

7
1. Slide the extension wands onto the
posts of the caddy feet for storage.
2. Place each accessory (utility nozzle
and wet nozzle) onto the top of each
extension wand for storage.
3. To remove wands and accessories,
lightly rotate and pull upward.
Accessory Storage
Extension
Wands (2)
Caddy Feet
Utility
Nozzle
Wet
Nozzle
Operation
WARNING: To reduce the risk of fire, explosion, or damage to Vac:
• Do not leave Vac running while unattended - you may fail to notice
important signs indicating abnormal operation such as loss of suction,
debris/liquid exiting the exhaust, or abnormal motor noises. Immediately
stop using Vac if you notice these signs.
• Do not leave Vac plugged in when not in use.
• Do not continue running when float has cut off suction.
• Sparks inside the motor can ignite airborne flammables. Do not operate Vac
near flammable liquids or in areas with flammable gases, vapors, or
explosive/airborne dust. Flammable liquids, gases, and vapors include:
lighter fluid, solvent-type cleaners, oil-based paints, gasoline, alcohol, and
aerosol sprays. Explosive dusts include: coal, magnesium, aluminum,
grain, and gun powder.
• Do not vacuum up explosive dusts, flammable liquids, or hot ashes.
WARNING: To reduce the risk of electric shock or injury:
• Do not expose to rain or allow liquid to enter motor compartment. Store
indoors.
• Do not handle plug, switch, or Vac with wet hands.
• Unplug Vac before servicing. If your Vac is not working as it should, has
missing parts, has been dropped, damaged, left outdoors, or dropped into
water, return it to an independent service center or call customer service.
• When using an extension cord, use only outdoor-rated cords that are in
good condition. Do not allow the connection to come into contact with
liquid.
!
!
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 7

8
After you plug the power cord into the
outlet, turn the unit on by pushing the
ON/OFF switch from position “0” to
position “ ”.
=OFF =ON
Familiarize yourself with the accessories
included with the Vac. Each accessory
may be used in various ways for
vacuuming and blowing debris. Here is
a list of the accessories and their uses.
Hose - Provides transfer of vacuum or
blowing capability to work site. Provides
the means of attaching extension wands
and nozzles.
Extension Wands - Connect the wands
together to provide additional length.
Utility Nozzle - General purpose nozzle
for most vacuuming applications.
Wet Nozzle - Used for wet pickup on
smooth surfaces to pick up liquid and dry
the surface in one stroke.
To reduce the risk of electric shock,
this appliance has a polarized plug
(one blade is wider than the other except
230 volt models). This plug will fit in a
polarized outlet only one way. f the plug
does not fit fully in the outlet, reverse the
plug. f it still does not fit, contact a qualified
electrician to install the proper outlet. Do
not change the plug in any way.
Operation (continued)
Vacuuming Dry aterials
1. The filter must always be in correct
position at all times to avoid leaks and
possible damage to Vac.
2. When using your Vac to pick up very
fine dust, it will be necessary for you
to empty the drum and clean the filter
at more frequent intervals to maintain
peak Vac performance.
NOTE: A dry filter is necessary to pick up
dry material. f you use your Vac to pick
up dust when the filter is wet, the filter will
clog quickly and be very difficult to clean.
3. f your filter is wet but you need to use
the Vac to pick up dry material, you
must first allow the filter to dry.
ON/OFF
Switch
Cartridge
Filter
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 8

9
Operation (continued)
Emptying the Drum
1. Remove the power head assembly.
Rotate the latch handle out ward so
that the latch unclamps the motor
cover and rotate the latch away from
the motor cover.
2. Lift the power head assembly up and
away from the drum. Lay power head
assembly upside down on a clean area
while emptying drum or changing filter.
3. Dump the drum contents into the
proper waste disposal container.
Vacuuming Liquids
1. When picking up small amounts of
liquid the filter may be left in place.
2. When picking up large amounts of
liquid we recommend that the filter be
removed. f the filter is not removed, it
will become saturated and misting may
appear in the exhaust.
WARNING: Do not operate
without filter cage and float, as they
prevent liquid from entering the
impeller and damaging the motor.
!
3. When the liquid in the drum reaches a
predetermined level, the float
mechanism will rise automatically to
cut off airflow. You will know that the
float has risen because Vac airflow
ceases and the motor noise will
become higher in pitch, due to
increased motor speed. When this
happens, turn off the Vac, unplug the
power cord, and empty the drum.
4. After using the Vac to pick up liquids,
the filter must be dried to avoid
possible mildew and damage to the
filter.
Power Head
Assembly
Latch
Handle (2)
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 9

Blowing Feature
Your Wet/Dry Vac features “Full Blowing”.
t can blow sawdust and other debris.
Follow the steps below to use your Vac
as a blower.
1. Locate the blowing port of your
Wet/Dry Vac.
2. nsert the larger end of the hose into
the blowing port of the Vac.
3. (Optional) Attach the extension wand
to the swivel end of the hose.
4. Turn the Vac on and you are ready to
use your Vac as a blower.
oving the Wet/Dry Vac
Should it become necessary to pick the
Vac up to move it, DO NOT pick the Vac
up by the carry handle unless the dust
drum is empty. To avoid dropping the Vac,
due to latches releasing or possible part
breakage, pick the Vac up by the dust
drum.
WARNING: Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
using as a Blower.
CAUTION: Wear a dust mask if
blowing creates dust which might
be inhaled.
CAUTION: To reduce the risk of
hearing damage, wear ear protectors
when using the Vac/Blower for
extended time or in a noisy area.
WARNING: To reduce the risk of
injury to bystanders, keep them
clear of blowing debris.
!
!
!
!
Operation (continued)
10
Carry
Handle
Dust Drum
Power Head
Assembly
Blowing
Port
Hose
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 10

11
aintenance
To Remove Power Head Assembly:
1. Grasp the drum latches on both the
right and left side of the power head
assembly. Slowly pull the drum latches
away from the drum. Lift the power
head assembly off the drum. Place the
lid and blower assembly upside down
on the dust drum.
WARNING: For your own safety,
never connect plug to power source
outlet until all assembly steps are
complete and you have read and
understood the safety and operation
instructions. Do not operate Vac
with any parts damaged or missing.
Drum
Latch
Power
Head
Assembly
Hook
Power Head
Assembly
!
WARNING: Do not operate
without a filter cage and float, as
they prevent liquid from entering
the impeller and damaging the
!
Removal and Installation
of the Qwik Lock™ Filter
Filter Removal:
1. Hold the filter tabs of the Qwik Lock™
filter in each hand.
2. With one thumb on the Qwik Lock™
stud, which protrudes through the
integrated filter plate, lift up on the
filter tabs while pushing down on the
stud.
3. This action will cause the filter to
release from the filter cage. Slide filter
off cage.
Filter Installation:
1. Carefully slide the Qwik Lock™ filter
over the filter cage and press down on
the outside edge of the filter until the
rubber gasket on the bottom of the
filter seats securely around the base
of the filter cage and against the lid.
2. Align the small center hole in the top
of the filter over the Qwik Lock™ stud
on the filter cage. Press firmly on top
of the filter near the stud to allow the
filter to snap over the ball on the end
of the stud. The filter is now attached.
Qwik Lock™
Stud
Filter
Tabs (2)
Integrated Filter
Plate with Center
Hole
PUSH
DOWN
PULL
UP
Rubber
Gasket at
Bottom of
Filter
(cutaway
view)
Float
Power
Head
Assembly
Filter Cage
Filter Removal and Installation
NOTE: Failure to properly seat the
bottom gasket could result in debris
bypassing the filter.
I PORTANT: To avoid damage to the
blower wheel and motor, always reinstall
the filter before using the Vac for dry
material pick-up.
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 11

12
aintenance (continued)
Cleaning A Dry Filter
1. Some removal of dry debris can be
accomplished without removing the
filter from the Vac. Slap your hand on
top of the lid while the Vac is turned
off.
2. For best cleaning results due to
accumulated dust, clean the filter in an
open area. Clean the filter outdoors
and not in the living quarters.
3. After filter removal from the Vac,
remove the dry debris by gently
tapping the filter against the inside wall
of your dust drum. The debris will
loosen and fall.
4. For thorough cleaning of a dry filter
with fine dust (no debris), run water
through it as described under
"Cleaning A Wet Filter".
Cleaning A Wet Filter
After the filter is removed, run water
through the filter from a hose or spigot.
Take care that water pressure from the
hose is not strong enough to damage the
filter.
Filter Replacement
Refer to page 11 "Filter Removal and
nstallation" section of this manual.
Allow the filter to dry before reinstalling
and storing the Vac or picking up dry
debris.
Filter
NOTE: The filter is made of high quality
paper designed to stop very small
particles of dust. The filter can be used
for dry pick up or small amounts of liquid.
Handle the filter carefully when removing
to clean or installing it. Creases in the
filter pleats may occur from installation
but will not affect the performance of the
filter.
Cleaning Vac Filter
Your filter should be cleaned often to
maintain peak Vac performance.
Allow the filter to dry before storing or
picking up dry debris.
I PORTANT: After cleaning, check the
filter for tears or small holes. Do not use a
filter with holes or tears in it. Even a small
hole can allow dust to come out of your
Vac. Replace it immediately.
WARNING: To reduce the risk of
injury from accidental starting,
unplug the power cord before
changing or cleaning the filter.
!
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 12

13
Cleaning and Disinfecting the
Wet/Dry Vac
To keep your Wet/Dry Vac looking its
best, clean the outside with a cloth
dampened with warm water and mild
soap.
To clean the drum:
1. Dump debris out.
2. Wash drum thoroughly with warm
water and mild soap.
3. Wipe out with dry cloth.
Before prolonged storage or as needed
(i.e., waste water pick up) the drum
should be disinfected.
To disinfect the drum:
1. Pour 1 gallon of water and 1 teaspoon
chlorine bleach into the drum.
2. Let solution stand for 20 minutes,
carefully swishing every few minutes,
making sure to wet all inside surfaces
of the drum.
3. Empty drum after 20 minutes. Rinse
with water until bleach smell is gone.
Allow drum to dry completely before
sealing the motor on the drum.
Storage
Before storing the Vac, empty and clean
the dust drum. Wrap the power cord
around the carry handle. Keep acces-
sories in the same area as the Vac so
that they are readily available. Store the
Vac indoors.
f the power cord is damaged, it must be
replaced by the manufacturer or their
service agent or by similarly qualified
personnel to reduce the risk of accident.
Casters
f your casters are noisy, you may put a
drop of oil on the roller shaft to make
them quieter.of accident.
aintenance (continued)
WARNING: To assure product
SAFETY and RELIABILITY, any other
servicing or repairs and adjust-
ments should be performed by
Authorized Service Centers, always
using RIDGID replacement parts.
!
Cord
Cord Wrap
Area
Carry Handle
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 13

14
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) may also be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
Repair Parts
RIDGID 6 Gallon Stainless Steel Wet/Dry Vac
odel Number WD64250
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
† These replacement parts may be available where you purchased your Vac.
!
Key No. Part No. Description
1 832086 Rocker Switch
2 835172 Carry Handle
3 510205 Filter Cage Assembly
4 VF4000 Cartridge Filter
5 510277-2 Latch Assembly
6 835179 Caddy
7 73137 Caster
8 VT1709 Utility Nozzle
9 VT1710 Wet Nozzle
10 VT1708 Extension Wand
11 VT1720 Hose
12 SP6932 Owner’s Manual
†
†
†
†
†
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 14

15
Repair Parts (continued)
RIDGID 6 Gallon Stainless Steel Wet/Dry Vac
odel Number WD64250
RIDGID parts are available on-line at www.ridgidparts.com
3
1
4
5
6
7
9
10
11
12
2
8
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 15

Part No. SP6932 Form No. SP6932 Printed in Mexico 10/14
Stock No. WD6425
odel No. WD64250
Serial No.
The serial number and model number may be found on the serial plate located near
the blower port of the power head. You should record both model and serial numbers
in a safe place for future use.
c 2014 Emerson
• What is covered
R DG D®Wet/Dry Vacs are warranted to be free of defects in workmanship and material.
• How long coverage lasts
This warranty lasts for the lifetime of the R DG D®Wet/Dry Vac.
• How to obtain service
To obtain the benefit of this warranty, deliver via prepaid transportation the complete product to
R DGE TOOL COMPANY, Elyria, Ohio, or any authorized R DG D®NDEPENDENT SERV CE
CENTER. Pipe wrenches and other hand tools should be returned to the place of purchase.
• What we will do to correct problems
Warranted Wet/Dry Vacs will be repaired or replaced, at Ridge Tool Company's option, and returned
at no charge; or, if after three attempts to repair or replace during the warranty period the Wet/Dry
Vac is still defective, you can elect to receive a full refund of your purchase price.
• What is not covered
Failures due to misuse, abuse or normal wear and tear are not covered by this warranty. RIDGE
TOOL CO PANY SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DA AGES.
• How local laws relate to the warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific rights, and you
may also have other rights which vary from state to state, province to province, or country to
country.
• No other express warranty applies
This FULL L FET ME WARRANTY is the sole and exclusive warranty for R DG D®Wet/Dry Vacs.
No employee, agent, dealer, or other person is authorized to alter this warranty or make any other
warranty on behalf of Ridge Tool Company.
FOR QUESTIONS OR INFOR ATION CONTACT US AT
1-800-4-RIDGID (1-800-474-3443) from the USand Canada
01-800-701-9811 from exico
www.ridgidvacs.com
Please have your odel Number and Serial Number on hand when calling.
SP6932 WD64250 6 Gallon 10/31.qxp_SP6585 WD4050EX 10/31/14 12:00 PM Page 16

WD64250
ASPIRATEUR DE LIQUIDES ET
DE POUSSIÈRES E ACIER
I OXIDABLE DE 6 GALLO S
DES ÉTATS-U IS / 22,5 LITRES
MODE D’EMPLOI
Pièce N° SP6932F Imprimé au Mexique
CO SERVER CE MA UEL POUR RÉFÉRE CE FUTURE
Merci d’avoir acheté un produit RIDGID.
E CAS DE QUESTIO S OU POUR OBTE IR DES I FORMATIO S,
VEUILLEZ OUS CO TACTER AU :
1-800-4-RIDGID (1-800-474-3443) depuis les États-Unis et le Canada
01-800-701-9811 depuis le Mexique
www.ridgidvacs.com
AVERTISSEME T :
Pour réduire le risque de blessure, l’utilisateur doit lire et comprendre le mode d’emploi
avant d’utiliser ce produit.
!
SP6932 WD64250 6 Gallon_FR 10/31.qx _SP6585 WD4050EX 10/31/14 12:06 PM Page 1

2
Table des matières
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Déballage et contrôle du contenu du carton . . . . . 4
Assemblage des roulettes . . . . . . . . . . . . . . . . . . . 5
Ensemble de poignée de transport . . . . . . . . . . . . . 5
Assemblage de l’aspirateur de liquides
et de poussiéres . . . . . . . . . . . . . . . . . . . . . . . 6
Rangement des accessoires . . . . . . . . . . . . . . . . . . 7
Fonctionnement. . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Aspiration de matériaux secs . . . . . . . . . . . . . . . 8
Aspiration de liquides . . . . . . . . . . . . . . . . . . . . . 9
Vidage du tambour . . . . . . . . . . . . . . . . . . . . . . . 9
Transport de l’aspirateur de liquides
et de poussières . . . . . . . . . . . . . . . . . . . . . . . 10
Fonction de souffleuse . . . . . . . . . . . . . . . . . . . 10
Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13
Pièces de rechange . . . . . . . . . . . . . . . . . . . . . 14-15
Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Section Page
Section Page
I STRUCTIO S IMPORTA TES RELATIVES À LA SÉCURITÉ
La sécurité est une combinaison de faire preuve de
bon sens, rester vigilant et savoir comment votre
aspirateur de liquides et de poussières
(l’« aspirateur ») fonctionne.
Termes de signalisation de questions
de sécurité
DA GER : indique une situation dangereuse qui,
si elle n’est pas évitée, causera la mort ou une
blessure grave.
AVERTISSEME T : indique une situation
dangereuse qui, si elle n’est pas évitée, risque de
causer la mort ou une blessure grave.
MISE E GARDE : indique une situation
dangereuse qui, si elle n’est pas évitée, pourrait
causer une blessure légère ou modérée.
Prenez toujours des précautions élémentaires,
notamment les précautions suivantes, lorsque vous
utilisez votre aspirateur de liquides et de poussières :
AVERTISSEME T
– Pour réduire le risque d’incendie, de choc
électrique ou de blessure:
• Lisez et comprenez ce manuel et toutes les étiquettes
placées sur l’aspirateur avant de mettre celui-ci en
marche.
• N’utilisez l’aspirateur que comme cela est décrit dans
ce mode d’emploi.
• Ne laissez pas en marche pendant que vous êtes
absent – vous vous risqueriez de manquer des
signes importants indiquant un fonctionnement
anormal, comme une perte de puissance d’aspira -
tion, la sortie de débris ou de liquides par la bouche
de soufflage d’air ou des bruits anormaux en pro ve -
nance du moteur. Cessez immédiatement d’utiliser
l’aspirateur si vous constatez de tels signes.
• Ne laissez pas l’aspirateur sans surveillance
quand il est branché dans une prise de courant.
Débranchez-le de la prise quand il n’est pas utilisé et
avant toute opération de maintenance.
• Des étincelles à l’intérieur du moteur risquent de
mettre feu à des vapeurs ou poussières
inflammables. Pour réduire le risque d’incendie ou
!
!
!
!
d’explosion : n’utilisez pas à proximité de gaz ou de
liquides inflammables ou combustibles, ou de
poussières explosives, comme de l’essence
automobile ou d’autres fiouls, de l’essence à briquet,
des produits de nettoyage, de la peinture à l’huile, du
gaz naturel, de l’hydrogène, de la poussière de
charbon, de la poussière de magnésium, de la
poussière d’aluminium, de la poussière de céréales
ou de la poudre.
• N’aspirez jamais de matières en train de brûler ou
des matières fumigènes, telles que des cigarettes,
des allumettes ou des cendres chaudes.
• N’aspirez jamais de poussières de plaques de plâtre,
de suie ou de cendres de cheminée froides lorsqu’un
filtre pour aspirateur de liquides et de poussières
standard. Il s’agit de poussières très fines qui
risqueraient d’être projetées à nouveau dans l’air
ambiant. Utilisez un filtre à poussières fines à la
place.
• Pour réduire le risque d’inhalation de vapeurs
toxiques, n’aspirez pas de matériaux toxiques ou
dangereux, et n’utilisez pas à proximité de tels
matériaux.
• Pour réduire le risque de choc électrique, n’exposez
pas à la pluie et empêchez l’entrée de liquides dans
le compartiment du moteur. Rangez à l’intérieur.
• Cet aspirateur de liquides et de poussières n'est pas
conçu pour emploi par des personnes
(y compris des enfants) ayant des capacités
physiques, sensorielles ou mentales réduites,
ou qui n'ont pas l'expérience ou les connaissances
nécessaires, sauf en cas de supervision ou
d'instructions sur l'utilisation de cet appareil par une
personne responsable de leur sécurité.
• Ne laissez pas les enfants se servir de l’aspirateur
comme d’un jouet. Il faut surveiller de très près
quand il est utilisé par des enfants ou à proximité
d’enfants.
• N’utilisez pas avec un filtre déchiré ou sans avoir
installé de filtre, sauf quand vous aspirez des
liquides, comme cela est décrit dans ce mode
d’emploi. Des débris secs capturés par la roue
risquent d’endommager le moteur ou d’être expulsés
à nouveau dans l’air ambiant.
• Éteignez l’aspirateur avant de le débrancher.
SP6932 WD64250 6 Gallon_FR 10/31.qx _SP6585 WD4050EX 10/31/14 12:06 PM Page 2

3
• En cas d’utilisation de l’aspirateur comme soufflante :
- Ne dirigez la décharge d’air que vers la zone de
travail.
- Ne dirigez pas l’air vers des personnes présentes
à proximité.
- Gardez les enfants à distance lors du fonction -
nement de la soufflante.
- N’utilisez la soufflante que pour souffler des
saletés et des débris.
- N’utilisez pas en guise de pulvérisateur.
•Pour réduire le risque de blessure pour les yeux,
portez des lunettes de sécurité. L’utilisation de toute
soufflante ou de tout aspirateur utilitaire peut
toujours causer la projection de corps étrangers
dans les yeux, ce qui risque d’entraîner des
blessures graves aux yeux.
• Pour réduire le risque de blessure pouvant être
causée par une mise en marche accidentelle,
débranchez le cordon d’alimentation avant de
changer le filtre ou de le nettoyer.
• Ne débranchez pas en tirant sur le cordon. Pour
débrancher, saisissez la fiche – pas le cordon.
• N’utilisez pas l’aspirateur avec une fiche, un cordon
ou un autre composant endommagé. Si votre
aspirateur ne fonctionne pas comme il faut, s’il
manque des pièces, s’il quelqu’un l’a laissé tomber,
s’il est endommagé, s’il a été laissé à l’extérieur ou
s’il est tombé dans de l’eau, téléphonez au service
d’assistance à la clientèle.
• Ne tirez pas l’aspirateur et ne le portez pas par son
cordon, n’utilisez pas le cordon pour servir de
poignée, ne fermez pas une porte sur le cordon et ne
laissez pas le cordon tendu passer sur des bords ou
des coins tranchants. Ne traînez pas l’aspirateur sur
son cordon. Maintenez le cordon à distance des
surfaces chauffées.
• Ne touchez pas la fiche, l’interrupteur ou l’aspirateur
avec des mains mouillées.
• Utilisez seulement des cordons de rallonge qui sont
conçus pour emploi à l’extérieur. Les cordons de
rallonge en mauvais état ou trop petits en termes de
calibre des fils peuvent poser des risques d’incendie
et de choc électrique. Pour réduire le risque de tels
dangers, inspectez les cordons pour vous assurer
qu’ils sont en bon état et que le liquide n’entre pas en
contact avec le raccordement. N’utilisez pas de
cordons de rallonge dont les conducteurs ont un
calibre inférieur à 16 AWG. Pour réduire la perte
d’énergie, utilisez un cordon de rallonge de calibre 14
s’il mesure entre 7,5 et 15 mètres de long, ou de
calibre 12 s’il mesure 15 mètres de long ou plus.
• Cet aspirateur de liquides et de poussières a une
double isolation, ce qui élimine le besoin d’un
système de mise à la terre séparé. Utilisez seule ment
des pièces de rechange identiques. Lisez les
instructions concernant l’entretien des aspirateurs de
liquides et de poussières à double isolation avant
toute opération d’entretien.
• Ne mettez aucun objet dans les orifices de venti -
lation. N’aspirez pas quand de quelconques orifices
de ventilation sont obstrués ; assurez-vous que ces
orifices ne sont pas bloqués par de la poussière, de
la peluche, des cheveux ou de quel conques objets
pouvant réduire la circulation de l’air.
• Gardez les cheveux, les vêtements flottants, les
doigts et toutes les parties du corps à distance des
orifices et des pièces mobiles.
• Pour réduire le risque de chute, faites très attention
lorsque vous utilisez l’aspirateur dans des escaliers.
• Pour réduire le risque de vous faire mal au dos ou de
tomber, ne soulevez pas un aspirateur qui est lourd
en raison de la présence de liquides ou de débris
aspirés. Videz partiellement l’aspirateur en écopant
ou en purgeant.
• Pour réduire le risque de blessure ou le risque
d’endommagement de l’aspirateur, n’utilisez que des
accessoires recommandés par Ridgid.
CO SERVER CE MA UEL
MISE E GARDE :
• Pour réduire le risque de perte auditive, portez des
protecteurs d’oreilles lorsque vous vous servez de
l’aspirateur pendant plusieurs heures ou quand
vous l’utilisez dans un environnement bruyant.
• Portez un masque antipoussières en cas d’utilisa -
tion dans un environnement poussiéreux.
• Les décharges statiques sont fré quentes dans les
endroits secs ou lorsque l’humidité relative de l’air
ambiant est faible. L’aspiration de débris fins avec
votre aspirateur peut déposer une charge statique
sur le tuyau ou sur l’aspirateur. La meilleure chose
à faire pour réduire la fréquence des décharges
statiques chez vous ou lorsque vous utilisez cet
aspirateur consiste à ajouter de l’humidité dans l’air
avec un humidificateur.
!
Observez les avertissements suivants qui figurent sur
le carter du moteur de votre aspirateur :
DOUBLEMENT ISOLÉ.
MISE À LA TERRE NON NÉCESSAIRE.
POUR L’ENTRETIEN, N’UTILISEZ QUE DES
PIÈCES DE RECHANGE IDENTIQUES L’ENTRETIEN.
AVERTISSEME T : pour votre propre sécurité,
lisez et comprenez le manuel de l’opérateur. e
laissez jamais l’aspirateur en marche sans
surveillance. e ramassez pas de cendres
chaudes, de charbon ou de matières toxiques,
inflammables ou dangereuses. ’utilisez pas à
proximité de vapeurs ou de liquides explosifs.
AVERTISSEME T : pour réduire le risque de
choc électrique – n’exposez pas à la pluie –
rangez à l’intérieur.
!
!
SP6932 WD64250 6 Gallon_FR 10/31.qx _SP6585 WD4050EX 10/31/14 12:06 PM Page 3

4
A
B
F
G
E
K
D
C
J
I
H
Introduction
Cet aspirateur de liquides et de poussières a été
conçu pour une utilisation ménagère
uniquement. Il peut être utilisé de façon non
commerciale ou industrielle pour l’aspiration de
débris humides ou secs, mais aussi comme
une soufflerie. Sa conception légère lui permet
d’être utilisé pour la plupart des travaux
ménagers d’aspiration.
Familiarisez-vous avec les fonctions suivantes
de ce produit, et lisez le manuel de l’opérateur
du début à la fin pour des détails spécifiques
quant à l’utilisation de votre nouvel aspirateur
de liquides et poussières.
Inspection du contenu du carton
Retirez tous les éléments se trouvant dans la
boîte en carton. Inspectez chaque élément en le
comparant à la liste incluse dans la boîte en
carton. Téléphonez au 1-800-4-RIDGID
(1-800-474-3443) depuis les États-Unis et le
Canada, 01-800-701-9811 depuis le Mexique.
Envoyez-nous un courriel à [e-mail]
ou rendez-vous sur le site www.ridgidvacs.com
si de quelconques composants sont
endommagés ou manquants.
Liste du contenu de la boîte en carton
Légende Description Qté
A Aspirateur de liquides et de poussières....1
B Poignée de transport................................1
C Tuyau flexible Tug-A-Long........................1
D Baguettes de rallonge...............................2
E Roulettes ..................................................4
F Suceur à usages multiples .......................1
G Suceur humide de 1-7/8 po......................1
H* Flotteur ....................................................1
I* Cage du filtre ...........................................1
* Filtre à cartouche VF4000.........................1
K Mode d’emploi ..........................................1
* Ces composants peuvent avoir été
assemblés à l’usine.
SP6932 WD64250 6 Gallon_FR 10/31.qx _SP6585 WD4050EX 10/31/14 12:06 PM Page 4
