RIDGID 4500RV0 User manual

4500RV0
4.5 U.S. GALLONS/15 LITERS
PRO PACK WET/DRY VAC
FOR QUESTIONS OR INFORMATION CONTACT US AT
CALL 1-800-4-RIDGID (1-800-474-3443) OR
www.ridgidvacs.com
Part No. SP6951 Printed in Mexico
OWNER’S MANUAL
SAVE THIS MANUAL FOR FUTURE REFERENCE
Thank you for buying a RIDGID product.
WARNING:
To reduce the risk of injury, the user must read and understand the owner’s manual
before using this product.
!
• Español - página 15
• Français - page 29
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 1

2
Table of Contents
Section Page
Important Safety Instructions. . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking and Checking
Carton Contents List . . . . . . . . . . . . . 4
Getting to Know Your Vac . . . . . . . . . . . 5
Installing Extension Wand Clips . . . . . . 6
Filter Removal and Installation . . . . . . . 6
Cord, Hose & Accessory Storage . . . . . 7
Operation. . . . . . . . . . . . . . . . . . . . . . . . 8
Vacuuming Dry Materials . . . . . . . . . . 9
Vacuuming Liquids . . . . . . . . . . . . . . . 9
Emptying the Dust Drum . . . . . . . . . . 9
Section Page
Cord Storage . . . . . . . . . . . . . . . . . . . 9
Blowing Feature . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . 10
Filter . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning and Disinfecting
the Wet/Dry Vac . . . . . . . . . . . . . . 11
Cord Maintenance . . . . . . . . . . . . . . 11
Storage . . . . . . . . . . . . . . . . . . . . . . . 11
Repair Parts. . . . . . . . . . . . . . . . . . . . . 12
Servicing of Double Insulated
Wet/Dry Vacs . . . . . . . . . . . . . . . . 12
Warranty . . . . . . . . . . . . . . . . . . . . . . . 14
IMPORTANT SAFETY INSTRUCTIONS
Safety is a combination of using common
sense, staying alert, and knowing how your
wet/dry vacuum cleaner (“Vac”) works.
Safety Signal Words
DANGER: Indicates a hazardous
situation which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
When using your Vac, always follow basic
safety precautions including the following:
WARNING
- To reduce the risk of fire, electric
shock, or injury:
• Read and understand this manual and
all labels on the Vac before operating.
• Use only as described in this manual.
• Do not leave Vac running while
unattended - you may fail to notice
important signs indicating abnormal
operation such as loss of suction,
debris/liquid exiting exhaust, or
abnormal motor noises. Immediately
stop using Vac if you notice these signs.
• Do not leave Vac when plugged in.
Unplug from outlet when not in use and
before servicing.
• Sparks inside the motor can ignite
flammable vapors or dust. To reduce the
!
!
!
!
risk of fire or explosion, do not use near
combustible liquids, gases, or dusts,
such as gasoline or other fuels, lighter
fluid, cleaners, oil-based paints, natural
gas, coal dust, magnesium dust, grain
dust, aluminum dust, or gun powder.
• Do not vacuum anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
• Do not vacuum drywall dust, cold
fireplace ash, or other fine dusts with
standard filter. These may pass through
the filter and be exhausted back into the
air. Use a fine dust filter instead.
• To reduce the risk of inhaling toxic
vapors, do not vacuum or use near
toxic or hazardous materials.
• To reduce the risk of electric shock,
do not expose to rain or allow liquid to
enter motor compartment. Store
indoors.
• Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
• Do not use with a torn filter or without
filter installed except when vacuuming
liquids as described in this manual.
Dry debris ingested by the impeller may
damage the motor or be exhausted into
the air.
• Turn off Vac before unplugging.
• To reduce the risk of injury from
accidental starting, unplug power cord
before changing or cleaning filter.
• Do not unplug by pulling on cord.
To unplug, grasp the plug, not the cord.
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 2

3
• To reduce the risk of eye injury, wear
safety eyewear. The operation of any
utility Vac or blower can result in foreign
objects being blown into the eyes, which
can result in severe eye damage.
• Do not store or stack items on top of
Vac.
• Do not use with damaged cord, plug or
other parts. If your Vac is not working as
it should, has missing parts, has been
dropped, damaged, left outdoors, or
dropped into water, call customer
service.
• Do not pull or carry by cord, use cord as
handle, close a door on cord, or pull
cord around sharp edges or corners.
Keep cord away from heated surfaces.
• Do not handle plug, switch, or the Vac
with wet hands.
• Use only extension cords that are rated
for outdoor use. Extension cords in poor
condition or too small in wire size can
pose fire and shock hazards. To reduce
the risk of these hazards, be sure the
cord is in good condition and that liquid
does not contact the connection. Do not
use an extension cord with conductors
smaller than 16 gauge (AWG) in size.
To reduce power loss, use a 14 gauge
extension cord if 25 to 50 ft. long and 12
gauge for 50 ft. or longer.
• This Vac is double-insulated, eliminating
the need for a separate grounding
system. Use only identical replacement
parts. Read the instructions for
Servicing Double-Insulated Wet/Dry
Vacs.
• Do not put any object into ventilation
openings. Do not vacuum with any
ventilation openings blocked; keep free
of dust, lint, hair or anything that may
reduce air flow.
• Keep hair, loose clothing, fingers, and all
parts of body away from openings and
moving parts.
• To reduce the risk of falls, use extra
care when cleaning on stairs.
• To reduce the risk of personal injury or
damage to Vac, use only Ridgid
recommended accessories.
• When using as a blower:
- Direct air discharge only at work
area.
- Do not direct air at bystanders.
- Keep children away when blowing.
- Do not use blower for any job except
blowing dirt and debris.
- Do not use as a sprayer.
Observe the following warnings that
appear on the motor housing of your Vac:
DOUBLE INSULATED
GROUNDING NOT REQUIRED.
WHEN SERVICING USE ONLY
IDENTICAL REPLACEMENT PARTS.
SAVE THIS MANUAL
CAUTION:
• To reduce the risk of hearing damage,
wear ear protectors when using for
extended time or in a noisy area.
• For dusty operations, wear dust mask.
• Static shocks are common when the
relative humidity of the air is low.
Vacuuming fine debris with your Vac can
deposit static charge on the hose or
Vac. To reduce the frequency of static
shocks in your home or when using this
Vac, add moisture to the air with a
humidifier.
!
WARNING: To reduce the risk of
electric shock - do not expose to
rain - store indoors.
WARNING: Do not step, stand or
sit on vacuum. Improper use may
cause injury.
WARNING: To reduce the risk of
fire, do not store foreign objects in
this compartment. Only store Vac
Accessories.
WARNING: For your own safety,
read and understand owner's
manual. Do not run unattended.
Do not pick up hot ashes, coals,
toxic, flammable or other hazardous
materials. Do not use around
explosive liquids or vapors.
!
!
!
!
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 3

Unpacking and Checking Carton Contents
4
Remove contents of carton. Check each
item against the Carton Contents List.
Contact 1-800-4-RIDGID (www.ridgid
vacs.com) if any parts are damaged or
missing.
Carton Contents List
Key Description Qty
A 4.5-Gallon PRO PACK Vac..........1
B Extension Wand Clip (Left) ..........1
C Extension Wand Clip (Right)........1
D Extension Wands .........................2
E Crevice Tool .................................1
F Dusting Brush ..............................1
G Utility Nozzle ................................1
H Superflex Hose ............................1
I Owner’s Manual...........................1
A
E
F
G
C
I
D
H
B
Introduction
This PRO PACK Wet/Dry Vac is intended
for household use. It may be used for
vacuuming wet or dry media and may be
used as a blower.
Read this owner’s manual to familiarize
yourself with the product features and to
understand the specific usage of your
new Vac.
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 4

5
Getting to Know Your Vac
1. Familiarize yourself with the controls and features of your Vac before operating.
Drum Latch (2)
Drum
Left
Cover Right
Cover
Accessory
Storage Area
Blowing
Port
Handle
Cord & Hose
Storage Area
Vacuum
Port Inlet
Power Switch
Hose
Storage
Crevice
Tool
Storage
Power Cord
Storage
Dusting
Brush
Storage
Utility
Nozzle
Storage
Blowing
Port
Left
Extension
Wand Clip
Right
Extension
Wand Clip
Extension
Wand
BACK VIEW OF UNIT
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 5

6
Installing Extension Wand Clips
NOTE: The extension wand clips are
marked “L” and “R” and should be installed
on the back of the PRO PACK unit.
NOTE: While viewing the unit from behind,
the clip marked “L” goes on the left side
and the clip marked “R” goes on the right
side.
R
L
Left
Extension
Wand Clip
Right Extension
Wand Clip
Hook the tab on the bottom of the
extension wand clip into the depression
in the bottom of the drum. Rotate the clip
upwards until the extension wand clip
snaps into the slots in the drum, as
shown.
Slot
Rotate
Hook
Under Vac
Filter Removal:
1. Hold the filter tabs of the Qwik Lock™
filter in each hand.
2. With one thumb on the Qwik Lock™
stud, which protrudes through the
integrated filter plate, lift up on the filter
tabs while pushing down on the stud.
3. This action will cause the filter to
release from the filter cage. Slide filter
off cage.
Filter Installation:
1. Carefully slide the Qwik Lock™ filter
over the filter cage and press down on
the outside edge of the filter until the
rubber gasket on the bottom of the filter
seats securely around the base of the
filter cage and against the lid.
2. Align the small center hole in the top of
the filter over the Qwik Lock™ stud
on the filter cage. Press firmly on top of
the filter near the stud to allow the filter
to snap over the ball on the end of the
stud. The filter is now attached.
Filter Removal and Installation
Integrated Filter
Plate with Center
Hole
PULL
Filter
Cage
Rubber
Gasket at
Bottom of
Filter
(cutaway
view)
PUSH
DOWN
NOTE: Failure to properly seat the
bottom gasket could result in debris
bypassing the filter.
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 6

Cord, Hose & Accessory Storage
1. Your Vac has convenient locations to
store your power cord, Vac hose, and
accessories.
2. Under the left cover of your Wet/Dry
Vac (as shown) is a storage location
meant to hold your superflex hose,
crevice tool and power cord. For ease
of storage, the hose should be folded
as shown and placed in the storage bin
to the far left. You will also notice a
rectangular feature in the bottom of this
bin. The crevice tool will easily store
standing up in this feature, tapered
side down. Additionally, the power cord
will also fit in this bin to the far right
side. Fold or wrap the cord in
approximately 1-foot lengths until you
get within a foot of the storage bin. The
folded cord should now fit neatly into
the storage bin.
3. Under the right cover of your Wet/Dry
Vac (as shown) is a storage location for
the dusting brush and utility nozzle.
Each of these nozzles has a specific
location molded into the housing. Only
these two nozzles should be stored in
this location. Also located inside this
compartment is the blowing port.
Please see the “Blowing” section for
blowing directions.
4. To store the extension wands, snap
each extension wand into the extension
wand clips on the back of the unit.
Hose
Storage
Crevice
Tool
Storage
Power Cord
Storage
Dusting
Brush
Storage
Utility
Nozzle
Storage
Blowing
Port
Extension
Wand
Extension
Wand Clip
Correct
Hose
Wrap for
Storage
7
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 7

8
Operation
To reduce the risk of electric shock, this
appliance has a polarized plug (one
blade is wider than the other). This plug
will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit,
contact a qualified electrician to install the
proper outlet. Do not change the plug in
any way.
After you plug the power cord into the
outlet, turn the unit on by pushing the
switch from position "O" to position "l".
The symbols used on the switch actuator
are international "On & Off" symbols.
=OFF =ON
NOTE: When using the unit in the
vacuuming mode, the accessory storage
lid can be used as an air diffuser by
closing this lid.
Familiarize yourself with the accessories
included with the Vac. Each accessory
may be used in various ways for
vacuuming and blowing debris. Here is a
list of the accessories and their uses.
Dusting Brush - Use for sweeping up
areas with fine dust or debris. Great for
detailed cleaning.
Crevice Tool - Use to pick up debris in
hard to reach locations.
When operating your vacuum with the
storage lids closed, take care to make
sure that the power cord is positioned
through the cord opening in the cover.
Left Cover
Power Cord
Opening
Drum Power
Cord Opening Power
Cord
WARNING: To reduce the risk of fire, explosion, or damage to Vac:
• Do not leave Vac running while unattended - you may fail to notice important
signs indicating abnormal operation such as loss of suction, debris/liquid
exiting the exhaust, or abnormal motor noises. Immediately stop using Vac
if you notice these signs.
• Do not leave Vac plugged in when not in use.
• Do not continue running when float has cut off suction.
• Sparks inside the motor can ignite airborne flammables. Do not operate Vac
near flammable liquids or in areas with flammable gases, vapors, or
explosive/airborne dust. Flammable liquids, gases, and vapors include:
lighter fluid, solvent-type cleaners, oil-based paints, gasoline, alcohol, and
aerosol sprays. Explosive dusts include: coal, magnesium, aluminum,
grain, and gun powder.
• Do not vacuum up explosive dusts, flammable liquids, or hot ashes.
WARNING: To reduce the risk of electric shock or injury:
• Do not expose to rain or allow liquid to enter motor compartment. Store
indoors.
• Do not handle plug, switch, or Vac with wet hands.
• Unplug Vac before servicing. If your Vac is not working as it should, has
missing parts, has been dropped, damaged, left outdoors, or dropped into
water, return it to an independent service center or call customer service.
• When using an extension cord, use only outdoor-rated cords that are in
good condition. Do not allow the connection to come into contact with
liquid.
!
!
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 8

9
Operation (continued)
Emptying the Dust Drum
Utility Nozzle - General purpose nozzle for
most vacuuming applications.
Hose - Provides transfer of vacuum or
blowing capability to work site. Provides
the means of attaching accessories.
Hose includes suction relief valve to
reduce hose pull back when the inlet is
blocked.
Vacuuming Dry Materials
1. The filter must always be in correct
position at all times to avoid leaks and
possible damage to Vac.
2. When using your Vac to pick up very
fine dust, it will be necessary for you to
empty the drum and clean the filter at
more frequent intervals to maintain
peak Vac performance.
NOTE: A dry filter is necessary to pick up
dry material. If you use your Vac to pick
up dust when the filter is wet, the filter will
clog quickly and be very difficult to clean.
Vacuuming Liquids
1. When picking up small amounts of
liquid the filter may be left in place.
2. When picking up large amounts of
liquid we recommend that the filter be
removed. If the filter is not removed, it
will become saturated and misting may
appear in the exhaust.
3. When the liquid in the drum reaches a
predetermined level, the float mech-
anism will rise automatically to cut off
suction. You will know that the float has
risen because Vac airflow ceases and
the motor noise will become higher in
pitch, due to increased motor speed.
When this happens, turn off the Vac,
unplug the power cord, and empty the
drum.
4. After using the Vac to pick up liquids,
the filter must be dried to avoid
possible mildew and damage to the
filter.
1. To remove the power head to empty
contents of the dust drum, simply lift
the two drum latches on the front and
rear of the Vac and lift the power head
up and off the dust drum and set to the
side.
Cord Storage
When vacuuming is complete, unplug the
cord and wrap it up as described in the
“Cord, Hose & Accessory Storage”
Section shown on page 7.
Drum Latches (2)
WARNING: Do not operate
without filter cage and float, as they
prevent liquid from entering the
impeller and damaging the motor.
2. Set the power head upright in a clean,
dry area while emptying the drum.
3. Dump the drum contents into the proper
waste disposal container.
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before emptying
the drum.
!
!
IMPORTANT: To avoid damage to the
Vac, do not run motor with float in raised
position.
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 9

10
NOTE: The filter is made of high quality
paper designed to stop very small
particles of dust. The filter can be used
for dry pick up or small amounts of liquid.
Handle the filter carefully when removing
to clean or installing it. Creases in the
filter pleats may occur from installation
but will not affect the performance of the
filter.
Maintenance
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before changing
or cleaning filter.
Cleaning Vac Filter
Be sure to dry the filter before storing or
picking up dry debris.
IMPORTANT: After cleaning, check the
filter for tears or small holes. Do not use
a filter with holes or tears in it. Even a
small hole can cause a lot of dust to
come out of your Vac. Replace the filter
immediately.
Blowing Feature
Your wet/dry Vac has the capability to be
used as a blower for yard work, patio
cleanup and workshop applications to
blow sawdust and other debris. Raise the
right cover and install the locking end of
the hose into the blower port.
Operation (continued)
Right
Cover
Blowing
Port
Locking
End of
Hose
Removal
Refer to page 6 "Filter Removal and
Installation" Section of this manual.
IMPORTANT: To avoid damage to the
blower wheel and motor, always reinstall
the filter before using the Vac for dry
material pickup.
WARNING: Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
using as a blower.
CAUTION: Wear a dust mask if
blowing creates dust which might
be inhaled.
CAUTION: To reduce the risk of
hearing damage, wear ear protectors
when using the Vac/Blower for
extended time or in a noisy area.
WARNING: To reduce the risk of
injury to bystanders, keep them
clear of blowing debris.
!
!
!
!
!
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 10

11
WARNING: To assure product
SAFETY and RELIABILITY, any other
maintenance, repairs or adjustments
should be performed by Authorized
service centers, always using RIDGID
replacement parts.
Cleaning A Dry Filter
NOTE: For best cleaning results due to
accumulated dust, clean the filter in an
open area. Cleaning SHOULD be done
outdoors and not in the living quarters.
1. Remove filter from Vac. Gently tap the
filter against the inside wall of your dust
drum and the debris will loosen and
fall.
2. For thorough cleaning of a dry filter
with fine dust (no debris) you may run
water through it as described in the
“Cleaning A Wet Filter” Section.
Cleaning A Wet Filter
After filter is removed, run water through
the filter from a hose or spigot. Take care
that water pressure from the hose is not
strong enough to damage filter.
IMPORTANT: After cleaning, check the
filter for tears or small holes. Do not use
a filter with holes or tears in it. Even a
small hole can cause a lot of dust to
come out of your Vac. If your filter is
damaged or worn, Replace the filter
immediately.
Allow the filter to dry before reinstalling
and storing the Vac.
Cleaning and Disinfecting the
Wet/Dry Vac
To keep your Wet/Dry Vac looking its
best, clean the outside with a cloth
dampened with warm water and mild
soap.
To clean the drum:
1. Dump debris out.
2. Wash drum thoroughly with warm water
and mild soap.
3. Wipe out with dry cloth.
Before prolonged storage or as needed
(i.e., waste water pick up) the drum
should be disinfected.
!
To disinfect the drum:
1. Pour 1 gallon of water and 1 teaspoon
chlorine bleach into the drum.
2. Let solution stand for 20 minutes,
carefully swishing every few minutes,
making sure to wet all inside surfaces
of the drum.
3. Empty drum after 20 minutes. Rinse
with water until bleach smell is gone.
Allow drum to dry completely before
sealing the motor on the drum.
Cord Maintenance
When vacuuming is complete, unplug the
cord and store it properly under the left
cover (see "Cord, Hoses and Accessory
Storage" section on page 7). If the power
cord is damaged, it must be replaced by
the manufacturer or their service agent or
by similarly qualified personnel to reduce
the risk of accident.
Storage
Before storing your Vac, the drum should
be emptied and cleaned. The cord should
be stored properly inside the unit and the
hose should be stored as described in
this manual. Accessories should be kept
in the same area as the Vac so they can
be readily available. The Vac should be
stored indoors.
Maintenance (continued)
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 11

Key
No. Part No. Description
1 510158 Filter Cage Assembly
2 VF3500 Filter, Fine Dust
3 831327 Hose Assembly
4 VT1702 Crevice Tool
5 VT1701 Dusting Brush
6 VT1709 Utility Nozzle
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) may also be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
Repair Parts
RIDGID 4.5 Gallon PRO PACK Wet/Dry Vac
Model Number 4500RV0
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
Key
No. Part No. Description
7 831095 Right Cover
8 831094 Left Cover
9 831096 Handle
10 VT1708 Extension Wand
11 832199 Wand Clip (Left)
12 832200 Wand Clip (Right)
13 SP6951 Owner’s Manual
† These replacement parts may be available where you purchased your Vac.
†
†
†
†
†
12
!
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 12

Repair Parts (continued)
RIDGID 4.5 Gallon PRO PACK Wet/Dry Vac
Model Number 4500RV0
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
3
12
11
4
9
8
7
10
13
5
1
2
6
13
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:49 AM Page 13

Part No. SP6951 Form No. SP6951 Printed in Mexico 01/15
QUESTIONS OR COMMENTS? CALL
1-800-4-RIDGID (1-800-474-3443)
www.ridgidvacs.com
Please have your Model Number and Serial Number on hand when calling.
Stock No. 4500RV
Model No. 4500RV0
Serial Number
Model and serial numbers may be found on the handle. You should record both
model and serial numbers in a safe place for future use.
c 2015 Emerson
• What is covered
RIDGID®Wet/Dry Vacs are warranted to be free of defects in workmanship and material.
• How long coverage lasts
This warranty lasts for the lifetime of the RIDGID®Wet/Dry Vac.
• How to obtain service
To obtain the benefit of this warranty, deliver via prepaid transportation the complete product to
RIDGE TOOL COMPANY, Elyria, Ohio, or any authorized RIDGID®INDEPENDENT SERVICE
CENTER. Pipe wrenches and other hand tools should be returned to the place of purchase.
• What we will do to correct problems
Warranted Wet/Dry Vacs will be repaired or replaced, at Ridge Tool Company's option, and returned
at no charge; or, if after three attempts to repair or replace during the warranty period the Wet/Dry
Vac is still defective, you can elect to receive a full refund of your purchase price.
• What is not covered
Failures due to misuse, abuse or normal wear and tear are not covered by this warranty. RIDGE
TOOL COMPANY SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
• How local laws relate to the warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific rights, and you
may also have other rights which vary from state to state, province to province, or country to
country.
• No other express warranty applies
This FULL LIFETIME WARRANTY is the sole and exclusive warranty for RIDGID®Wet/Dry Vacs.
No employee, agent, dealer, or other person is authorized to alter this warranty or make any other
warranty on behalf of Ridge Tool Company.
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:50 AM Page 14

4500RV0
ASPIRADORA PARA MOJADO/SECO
PRO PACK
DE 4,5 GALONES EE.UU./15 LITROS
SI TIENE PREGUNTAS O DESEA INFORMACIÓN, CONTÁCTENOS LLAMANDO AL
1-800-4-RIDGID (1-800-474-3443) O
CONECTÁNDOSE A www.ridgidvacs.com
No. de pieza SP6951 Impreso en México
MANUAL DEL USUARIO
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
Gracias por comprar un producto RIDGID.
ADVERTENCIA:
Para reducir el riesgo de lesiones, el usuario debe leer y entender el manual del usuario antes
de utilizar este producto.
!
• Français - page 29
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:50 AM Page 15

16
Sección Página
Instrucciones de seguridad importantes . . . . . . . 16
Introducción . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Desempaquetado y comprobación del
contenido de la caja de cartón . . . . . . . . . . . . 18
Familiarización con la aspiradora . . . . . . . . . . . . 19
Instalación de las abrazaderas para
tubos extensores . . . . . . . . . . . . . . . . . . . . . . 20
Remoción e instalación del filtro . . . . . . . . . . . . . 20
Almacenamiento del cordón,
la manguera y los accesorios . . . . . . . . . . . . . 21
Funcionamiento . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Recogida de materiales secos con la aspiradora . 23
Recogida de líquidos con la aspiradora . . . . . . 23
Sección Página
Vaciado del tambor para polvo . . . . . . . . . . . . . 23
Almacenamiento del cordón . . . . . . . . . . . . . . . 23
Dispositivo de soplado . . . . . . . . . . . . . . . . . . . 24
Mantenimiento . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Filtro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Limpieza y desinfección de la aspiradora
para mojado/seco . . . . . . . . . . . . . . . . . . . . . . 25
Mantenimiento del cordón. . . . . . . . . . . . . . . . . 25
Almacenamiento . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Piezas de repuesto . . . . . . . . . . . . . . . . . . . . . . . . 26
Servicio de ajustes y reparaciones de
la aspiradora para mojado/seco
con aislamiento doble. . . . . . . . . . . . . . . . . . . 26
Garantía . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
La seguridad es una combinación de sentido común,
permanecer alerta y saber cómo funciona la
aspiradora para mojado/seco (“la aspiradora”).
Palabras de señal de seguridad
PELIGRO: indica una situación peligrosa que,
si no se evita, causará la muerte o lesiones graves.
ADVERTENCIA: indica una situación peligrosa
que, si no se evita, podría causar la muerte o lesiones
graves.
PRECAUCIÓN: indica una situación peligrosa que,
si no se evita, pudiera causar lesiones leves o
moderadas.
Cuando utilice la aspiradora, siga siempre las
precauciones básicas de seguridad, incluyendo
las siguientes:
ADVERTENCIA– Para
reducir el riesgo de incendio, sacudidas
eléctricas o lesiones:
• Lea y entienda este manual y todas las etiquetas
que están colocadas en la aspiradora antes de
utilizarla
• Utilice la aspiradora únicamente de la manera que
se describe en este manual.
• No deje la aspiradora en marcha mientras esté
desatendida. Usted podría no notar señales
importantes que indiquen un funcionamiento
anormal, tal como pérdida de succión, residuos o
líquido que salen por el escape o ruidos anormales
del motor. Deje de usar la aspiradora
inmediatamente si observa estas señales.
• No abandone la aspiradora cuando esté enchufada.
Desenchúfela del tomacorriente cuando no la esté
utilizando y antes de realizar servicio de revisión.
• Las chispas que se producen en el interior del
motor pueden incendiar los vapores inflamables o
el polvo. Para reducir el riesgo de incendio o
!
!
!
!
explosión: No use la aspiradora cerca de líquidos,
gases, o polvos combustibles como gasolina u
otros combustibles, líquido encendedor,
limpiadores, pinturas a base de aceite, gas natural,
polvo de carbón, polvo de magnesio, polvo de
aluminio, polvo de granos de cereal o pólvora.
• No recoja con la aspiradora nada que esté ardiendo
o humeando, como cigarrillos, fósforos o cenizas
calientes.
• No recoja con la aspiradora polvo de pared de tipo
seco ni hollín frío o ceniza fría de chimenea con un
filtro estándar. Este material es un polvo muy fino
que puede ser expulsado de vuelta al aire. Utilice un
filtro para polvo fino en lugar de un filtro estándar.
• Para reducir el riesgo de inhalar vapores tóxicos,
no recoja con la aspiradora materiales tóxicos o
peligrosos ni la use cerca de dichos materiales.
• Para reducir el riesgo de descargas eléctricas, no
exponga la aspiradora a la lluvia ni deje que entren
líquidos en el compartimiento del motor. Guarde la
aspiradora en un lugar interior.
• No permita que la aspiradora se utilice como un
juguete. Se necesita prestar máxima atención
cuando sea utilizada por niños o cerca de éstos.
• No use la aspiradora con un filtro desgarrado o sin
tener el filtro instalado, excepto cuando recoja con
ella líquidos de la manera que se describe en este
manual. Los residuos secos absorbidos por el
impulsor podrían dañar el motor o ser expulsados
de vuelta al aire.
• Apague la aspiradora antes de desenchufarla.
• Para reducir el riesgo de lesiones debidas a un
arranque accidental, desenchufe el cordón de
energía antes de cambiar o limpiar el filtro.
• No desenchufe la aspiradora tirando del cordón.
Para desenchufarla, agarre el enchufe y no el
cordón.
• No use la aspiradora con el cordón dañado, el
enchufe dañado u otras piezas dañadas. Si la
aspiradora no funciona como debe, le faltan piezas,
Indice
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:50 AM Page 16

• Para reducir el riesgo de lesiones en los ojos, use
protección ocular de seguridad. La utilización de
cualquier aspiradora utilitaria o soplador utilitario
puede hacer que se soplen objetos extraños hacia
los ojos, lo cual puede causar daños graves en
los ojos.
• No almacene ni apile artículos sobre la aspiradora.
se ha caído, ha sido dañada, se ha dejado a la
intemperie o se ha caído al agua, llame a servicio
al cliente.
• No tire de la aspiradora usando el cordón ni la lleve
por el cordón, ni use el cordón como asa, ni cierre
una puerta sobre el cordón, ni tire del cordón alre-
dedor de bordes o esquinas afilados. Mantenga el
cordón alejado de las superficies calientes.
• No maneje el enchufe, el interruptor o la aspiradora
con las manos mojadas.
• Utilice únicamente cordones de extensión que
tengan capacidad nominal para uso a la intemperie.
Los cordones de extensión que estén en malas
condiciones o tengan un tamaño de alambre
demasiado pequeño pueden crear peligros de
incendio y descargas eléctricas. Para reducir el
riesgo de estos peligros, asegúrese de que el
cordón esté en buenas condiciones y que el líquido
no entre en contacto con la conexión. No utilice un
cordón de extensión que tenga conductores con un
diámetro menor al calibre 16 (AWG). Para reducir la
pérdida de potencia, utilice un cordón de extensión
de calibre 14 si la longitud es de 25 a 50 pies, y de
calibre 12 si la longitud es de 50 pies o más.
• Esta aspiradora tiene aislamiento doble, lo cual
elimina la necesidad de un sistema independiente
de conexión a tierra. Utilice únicamente piezas de
repuesto idénticas. Lea las instrucciones de servicio
de revisión de las aspiradoras para mojado/seco
con aislamiento doble.
• No ponga ningún objeto en las aberturas de venti-
lación. No recoja nada con la aspiradora cuando
cualquiera de las aberturas de ventilación esté
bloqueada; mantenga dichas aberturas libres de
polvo, pelusa, pelo o cualquier cosa que pueda
reducir el flujo de aire.
• Mantenga el pelo, la ropa holgada, los dedos y
todas las partes del cuerpo alejados de las aber-
turas y de las piezas móviles.
• Para reducir el riesgo de caídas, tenga cuidado
adicional al limpiar en escaleras.
• Para reducir el riesgo de lesiones corporales o
daños a la aspiradora, utilice únicamente
accesorios recomendados por Ridgid.
• Cuando utilice la aspiradora como soplador :
- Dirija la descarga de aire solamente hacia el área
de trabajo.
- No dirija el aire hacia las personas que estén
presentes.
- Mantenga alejados a los niños durante la
operación de soplado.
- No utilice el soplador para trabajos que no sean
soplar suciedad y residuos.
- No use la aspiradora como rociador.
GUARDE ESTE MANUAL
PRECAUCIÓN:
• Para reducir el riesgo de daños a la audición, use
protectores de oídos cuando utilice la
aspiradora durante muchas horas seguidas o
cuando la emplee en un área ruidosa.
• Para operaciones que generan polvo, use una
máscara antipolvo.
• Las descargas de estática son comunes cuando
la humedad relativa del aire es baja. Si recoge
residuos finos con la aspiradora, se puede
depositar carga estática en la manguera o en la
aspiradora. El mejor remedio para reducir la
frecuencia de las descargas de estática en su casa
o cuando use esta aspiradora es añadir humedad
al aire con un humidificador.
!
Siga las siguientes advertencias que aparecen en la
caja del motor de la aspiradora.
AISLAMIENTO DOBLE. NO SE REQUIERE
CONEXION A TIERRA.
CUANDO HAGA SERVICIO DE REVISIÓN DE
LA ASPIRADORA, UTILICE ÚNICAMENTE PIEZAS DE
REPUESTO IDÉNTICAS.
ADVERTENCIA: Para reducir el riesgo de
sacudidas eléctricas, no exponga la aspiradora a
la lluvia y guárdela en interiores.
ADVERTENCIA: No pise la aspiradora, no se
pare sobre ella ni se siente en ella. El uso
inapropiado puede causar lesiones.
ADVERTENCIA: Para reducir el riesgo de
incendio, no almacene objetos extraños en este
compartimiento. Almacene únicamente los
accesorios de la aspiradora.
ADVERTENCIA: Para su propia seguridad, lea
y entienda el manual del operador. No tenga en
marcha la aspiradora desatendida. No recoja
cenizas calientes, carbón caliente, materiales
tóxicos ni inflamables ni otros materiales
peligrosos. No use la aspiradora alrededor de
líquidos o vapores explosivos.
!
!
!
!
17
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:50 AM Page 17

18
A
E
F
G
C
I
D
H
B
Saque todo el contenido de la caja de cartón. Asegú-
rese de que no falte ningún artículo utilizando la lista
del contenido de la caja. Llame al 1-800-4-RIDGID
(1-800-474-3443) (www.ridgidvacs.com) si alguna
pieza está dañada o falta.
Lista del contenido de la caja de cartón
Clave Descripción Cant.
A Aspiradora PRO PACK de 4,5 galones ......1
B Abrazadera para tubos extensores
(izquierda)..................................................1
C Abrazadera para tubos extensores
(derecha)....................................................1
D Tubos extensores .......................................2
E Boquilla rinconera ......................................1
F Cepillo para polvo.......................................1
G Boquilla de uso general ...............................1
H Manguera Superflex ...................................1
I Manual del usuario......................................1
Desempaquetado y comprobación del contenido
de la caja de cartón
Introducción
Esta aspiradora para mojado/seco PRO PACK está
diseñada solamente para uso doméstico. Se puede
utilizar para recoger materiales mojados o secos y se
puede usar como soplador.
Lea este manual del usuario para familiarizarse con las
características del producto y para entender la
utilización específica de su nueva aspiradora.
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:50 AM Page 18

Drum Latch (2)
Drum
Left
Cover Right
Cover
Accessory
Storage Area
Blowing
Port
Handle
Cord & Hose
Storage Area
Vacuum
Port Inlet
Power Switch
Hose
Storage
Crevice
Tool
Storage
Power Cord
Storage
Dusting
Brush
Storage
Utility
Nozzle
Storage
Blowing
Port
Left
Extension
Wand Clip
Right
Extension
Wand Clip
Extension
Wand
BACK VIEW OF UNIT
Familiarización con la aspiradora
1. Familiarícese con los controles y las características de la aspiradora para mojado/seco antes de
utilizarla.
Almacenamiento
de la manguera
Almacena-
miento de
la boquilla
rinconera
Almacenamiento del
cordón de energía
Orificio
de soplado
Almacenamiento de
la boquilla utilitaria
Almacenamiento
del cepillo para
polvo
Cubierta
izquierda Mango Cubierta
derecha
Interruptor
de encendido
Tambor
Área de
almacenamiento
del cordón y
la manguera
Pestillos del tambor (2)
Orificio
de soplado
Área de
almacenamiento
de accesorios
Entrada del orificio
de aspiración
VISTA TRASERA DE LA UNIDAD
Tubos
extensores
Abrazadera derecha
para tubos
extensores
Abrazadera
izquierda para
tubos extensores
19
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:50 AM Page 19

20
R
L
Left
Extension
Wand Clip
Right Extension
Wand Clip
Slot
Rotate
Hook
Remoción del filtro:
1. Sostenga las lengüetas del filtro Qwik Lock™ en
cada mano.
2. Con un dedo pulgar en el vástago Qwik Lock™,
que sobresale a través de la placa del filtro
integrada, levante las lengüetas del filtro a la vez
que empuja hacia abajo sobre el vástago.
3. Esta acción hará que el filtro se suelte de la jaula
del filtro. Deslice el filtro hasta retirarlo de la
jaula.
Instalación del filtro:
1. Deslice cuidadosamente el filtro Qwik Lock™
sobre la jaula del filtro y presione hacia abajo
sobre el borde exterior del filtro hasta que el
empaque de goma ubicado en la parte inferior
del filtro se asiente firmemente alrededor de la
base de la jaula del filtro y contra la tapa.
2. Alinee el agujero central pequeño ubicado en la
parte superior del filtro sobre el vástago Qwik
Lock™ ubicado en la jaula del filtro. Presione
firmemente sobre la parte de arriba del filtro
cerca del vástago, para permitir que el filtro se
acople a presión sobre la bola ubicada en el
extremo del vástago. Una vez hecho esto, el
filtro estará instalado.
Integrated Filter
Plate with Center
Hole
PULL
Filter
Cage
Rubber
Gasket at
Bottom of
Filter
(cutaway
i)
PUSH
DOWN
NOTA: Si no se asienta apropiadamente el
empaque inferior, el resultado podría ser que los
residuos rodeen el filtro.
Instalación de las abrazaderas para tubos extensores
NOTA: Los abrazaderas para tubos extensores
están marcadas con las letras “L” (LEFT, izquierda)
y “R” (RIGHT, derecha), y se deben instalar en la
parte trasera de la unidad PRO PACK.
NOTA: Mientras ve la unidad desde detrás, la
abrazadera marcada con la letra “L” va en el lado
izquierdo, y la abrazadera marcada con la letra “R”
va en el lado derecho.
Enganche la lengüeta ubicada en la parte inferior de
la abrazadera para tubos extensores en la
depresión ubicada en la parte inferior del tambor.
Gire la abrazadera hacia arriba hasta que la
abrazadera para tubos extensores se acople a
presión en las ranuras del tambor, de la manera
que se muestra en la ilustración.
Abrazadera
izquierda
para tubos
extensores
Ranura
Girar
Enganchar debajo
de la aspiradora
Abrazadera derecha
para tubos extensores
Remoción e instalación del filtro
EMPUJE
HACIA
ABAJO
JALE
Jaula
del
filtro
Empaque de
goma en la
parte inferior
del filtro
(vista en corte)
Placa de filtro
integrada con agujero
central
SP6951 RIDGID 4.5 Gallon-ESF_SP6609 1/16/15 8:50 AM Page 20
