Riello 370T1 Series Quick start guide

2903193 (5) - 12/2006
Installation, use and maintenance instructions
Montage und Bedienungsanleitung
Light oil burners
Öl-Gebläsebrenner
CODE MODEL
MODELL
TYPE
TYP
3737005 BGK1 370T1
3737405 BGK2 374T1
GB
D
One stage operation
Einstufiger Betrieb

DECLARATION OF CONFORMITY Royal Decree (A.R.) 8/1/2004 -
Belgium
Producer: RIELLO S.p.A.
Via Pilade Riello, 7
37045 LEGNAGO (VR) Italy
Tel. ++39.0442630111
Fax ++39.044221980
Distributed by: RIELLO NV
Ninovesteenweg 198
9320 Erembodegem
Tel. [phone]
Fax. [phone]
e-mail. [e-mail]
URL. www.riello.be
This is to certify that the series of units specified below conforms to the model of the type
described in the EC declaration of conformity, and is produced and distributed in conformity with
the requirements laid down in Belgian Royal Decree (A.R.) dated 8 January 2004.
Product type: Light oil burner
Model: BGK1 – 370T1
BGK2 – 374T1
Standard applied: EN 267 and A.R. of 8 January 2004
Control body: TÜV Industrie Service GmbH
TÜV SÜD Gruppe
Ridlerstrase, 65
80339 Munchen DEUTSCHLAND
Measured value: NOx max: 120 mg/kWh
CO max: 8 mg/kWh
Date: 30/11/2005 RIELLO S.p.A.

3193 1GB
INDEX
1. BURNER DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 Burner equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Overall dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.3 Firing rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 Working position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2 Boiler fixing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3 Hydraulic systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.4 Electrical wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. BURNER OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1 Combustion adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Recommended nozzles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3 Pump pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.4 Maintenance position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.5 Combustion head setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.6 Air damper setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.7 Electrode positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.8 Flame detector adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.9 Fuel heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.10 Operating programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6. FAULTS / SOLUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7. SAFETY WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.1 Burner identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.2 Basic safety rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3193 2GB
1. BURNER DESCRIPTION
One stage light oil burner with low pollutant emissions (Nitric Oxide NOx, Carbon monoxide CO and unburnt
Hydrocarbons).
1.1 BURNER EQUIPMENT
Flange with insulating gasket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .No. 1
Screw and nuts for flange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
7 pin plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .No. 1
Recirculating pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Screw and nuts for flange to be fixed to boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 4
Flexible oil pipes with nipples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .No. 2
1–Oilpump
2– Air damper adjustment assembly
3– Nozzle holder assembly
4– Flange with insulating gasket
5– Control box
6– Reset button with lock-out lamp
7– Flame detector
8– Combustion head
9– Recirculation pipe
10 –Motor
³Burner with CE marking in conformity with EEC directives: EMC 89/336/EEC, Low Voltage 73/23/EEC,
Machines 98/37/EEC and Efficiency 92/42/EEC.
³CE Certification No.: 0036 0232/98 (370T1) – 0036 0233/98 (374T1), as 92/42/CEE.
³The burner meets protection level of IP X0D (IP 40) as EN 60529.
³The burner is approved for intermittent operation as per Directive EN 267.
D7290
Fig. 1 2
7
6
1
3
10
5
9
4
8

3193 3GB
2. TECHNICAL DATA
2.1 TECHNICAL DATA
2.2 OVERALL DIMENSIONS
2.3 FIRING RATES, (as EN 267)
TYPE 370T1 374T1
Output 1.5 −3.0 kg/h 2.7 −5.0 kg/h
Thermal power 17.8 −35.6 kW 32 −59.3 kW
Fuel Light oil, viscosity 4 – 6 mm2/s at 20 °C
Electrical supply Single phase, 230V ±10% ~50Hz
Motor Run current 0.8A – 2750 rpm – 288 rad/s
Capacitor 4 µF
Ignition transformer Secondary 8 kV – 16 mA
Pump Pressure 8 – 15 bar
Absorbed electrical power 0.25 kW
TYPEABCDEØ FØ GHIL
370T1 255 280 202 230 192 87 89 10 28 107
374T1 255 280 202 230 197 90 89 10 28 115
C
11
45°
45°
Ø G
EA
189
106
140
168
H
83
83
D
B
Ø F
L
D7217
I
Pressure in combustion
chamber – mbar
Light oil output – kg/h
Thermal power – kW
12
15 20 25 30
3
35 40 45 50 55
45
60
D7637
0,2
0
0,8
0,6
0,4
370T1 374T1

3193 4GB
3. INSTALLATION
THE BURNER MUST BE INSTALLED IN CONFORMITY WITH LEGISLATION AND LOCAL STANDARDS.
3.1 WORKING POSITION
The burner is designed for operation in positions 1and 2only. Installation 1is the preferred option as it is the
only one that enables maintenance to be performed as described later on in this manual.
Operation is possible with installation option 2though maintenance cannot be performed with the burner con-
nected to the boiler. Note that any other installation position is likely to hinder the unit’s proper operation. Instal-
lations 3, 4 and 5are prohibited as safety is compromised.
3.2 BOILER FIXING
Important: with some boilers it is possible that the CO values exceed those declared in this manual.
To reduce these emissions, the recirculation pipe supplied must be used.
To fit the burner to the boiler it is necessary to carry out the following:
³If necessary insert the recirculating pipe (1) on the burner blast tube (2) and fix it with the screw (3), (see
fig. 2).
Attention: respect the dimensions, as described in chapter “2.2 OVERALL DIMENSIONS“ at page 3.
³Put on the flange (4) the screw and two nuts, (see fig. 4).
³Widen, if necessary, the insulating gasket holes (5, fig. 5).
³Fix the flange (4) to the boiler door (6) using screws (7) and (if necessary) the nuts (8) interposing the
insulating gasket (5), (see fig. 3).
D7088
1 2 3 4 5
S7709
Boiler door must have a max. thickness of 80 mm, refractory linig included.
ATTENTION
S7708
E9163
D5012
Fig. 2 3
1 2
8
4
6
4
Fig. 4
Fig. 5
5
7
75
Fig. 3

3193 5GB
3.3 HYDRAULIC SYSTEMS
*ONLY FOR ITALY: Automatic shut-off device as per Ministry of Internal Affairs’ regulation no. 73 dated 7/29/71.
H= difference of level; L= max. length of the suction line; I. D. = internal diameter.
PRIMING PUMP:
On the system in fig. 6 it is sufficient to loosen the suction gauge connec-
tion (6, fig. 7) and wait until oil flows out.
On the systems in fig. 8 and 9 start the burner and wait for the priming.
Should lock-out occur prior to the arrival of the fuel, await at least 20 sec-
onds before repeating the operation.
The pump suction should not exceed a maximum of 0.4 bar (30 cm Hg).
Beyond this limit gas is released from the oil. Oil pipes must be completely
tight.
In the vacuum systems (fig. 9) the return line should terminate within the oil
tank at the same level as the suction line. In this case a non-return valve is
not required. Should however the return line arrive over the fuel level, a
non-return valve is required. This solution however is less safe than previ-
ous one, due to the possibility of leakage of the valve.
H
meters
L meters
øi
8 mm
øi
10 mm
0,5
1
1,5
2
10
20
40
60
20
40
80
100
³
The burner is designed to accommodate the installation of
light oil supply pipes on either side.
³
It is necessary to install a filter on the fuel supply line.
³
The pump is designed to allow working with two pipes. In
order to obtain one pipe working it is necessary to unscrew
the return plug (2), remove the by-pass screw (3) and then
screw again the plug (2). (See fig. 7).
³
Before starting the burner make sure that the return pipe-
line is not clogged. An excessive back pressure would
cause the damage of the pump seal.
WARNING:
H
meters
L meters
øi
8 mm
øi
10 mm
0
0,5
1
1,5
2
3
3,5
35
30
25
20
15
8
6
100
100
100
90
70
30
20
SYSTEM
NOT PERMITTED 1- Suction line
2- Return line
3- By-pass screw
4 - Gauge connection
5- Pressure adjuster
6- Suction gauge connection
7- Valve
8- Auxiliary pressure gauge
1
324
8
76
Fig. 7
D5487
5
H
max. 4 m
max. 4 m
H
H
H
D6329
Fig. 8 Fig. 9
**
H
max. 4 m
*
D6328
Fig. 6
IN GERMANY

3193 6GB
3.4 ELECTRICAL WIRING
CARRIED-OUT IN THE FACTORY
7 pin plug
7 pole socket
h
T
L1 B4S3T2T1N
Black
White
Blue
Capacitor
Burner-earth
Main switch
T6A
Neutral
CONTROL BOX
550SMD
230V ~50Hz
L
1231231234
DO NOT EXCHANGE NEUTRAL WITH PHASE
WARNING
Motor
D5521 Heater with start
thermostat
12
Flame detector
Safety
thermostat T
Black
Blue
Oil valve
Hour counter
(230V - 0.1A max.)
Limit
thermostat Remote lock-out signal
(230V - 0.5A max.)
Ignition
electrodes
Brown
M
N
Blue
Brown
Black
S7145
NOTES:
– Wires of min. 1 mm2section. (Unless requested oth-
erwise by local standards and legislation).
– The electrical wiring carried out by the installer must
be in compliance with the rules in force in the Country.
*(See page 5). Connect the automatic shut-off de-
vice (230V - 0.5A max.) to the clamps N - T2 of the
7 pin plug.
CONTROL BOX
■To remove the control-box from the burner, loosen screw (A, fig. 10)
after removing all components, the 7 pin plug and earth wire.
During the re-assembly of the control box, retighten the screw
(A) with a torque wrench setting of 1 – 1.2 Nm.
■For burners installed on air generators, remove the bridge (B, fig. 10)
from the control box.
M
~
TESTING:
Check the shut-down of the
burner by opening the thermo-
stats and the lock-out by
darkening the flame detector.
Fig. 10
E9070
B
A
Green led (Fan)
Yellow led (Heater)
Red led (Lock-out signalling due to failure to shut-down)

3193 7GB
4. BURNER OPERATION
4.1 COMBUSTION ADJUSTMENT
In conformity with Efficiency Directive 92/42/EEC the application of the burner on the boiler, adjustment and
testing must be carried out observing the instruction manual of the boiler, including verification of the CO and
CO2concentration in the flue gases, their temperatures and the average temperature of the water in the boiler.
To suit the required appliance output, choose the proper nozzle and adjust the pump pressure, the setting of
the combustion head, and the air damper opening in accordance with the following schedule.
The values shown in the table are measured on a CEN boiler (as per EN 267), and they refer to 12.5% CO2
at sea level (1013 hPA) and with light oil and room temperature of 20 °C, with a combustion chamber pres-
sure of 0 mbar.
4.2 RECOMMENDED NOZZLES
Steinen type 60° H;
Danfoss type 60° H;
Delavan type 60° W.
4.3 PUMP PRESSURE
The pump leaves the factory set at 12 bar.
To change it act on pump pressure adjust screw (5, fig. 7, page 5).
TYPE
Nozzle Pump
pressure
Burner
output
Combustion head
adjustment
Air damper
adjustment
GPH Angle bar kg/h ± 4% Set-point Set-point
370T1
0.40 60° W 13 1.5 11.4
0.50 60° W 12 1.7 1.5 1
0.60 60° W 12 2.1 22.2
0.65 60° W 12 2.3 2.5 2
0.75 60° W 12 2.7 3 3
0.75 60° W 14 3.0 3.5 3.2
374T1
0.75 60° W 12 2.7 1.5 1.2
0.85 60° W 12 3.0 1.5 1.8
1.00 60° W 12 3.7 2 2
1.10 60° W 12 4.1 2.5 2.2
1.25 60° W 12 4.6 3.5 2.8
1.25 60° W 14 5.0 4 3
QUALIFIED PERSONNEL WITH THE RIGHT INSTRUMENTS MUST HANDLE THE BURNER'S FIRST
START-UP
!
WARNING
NOTE:
to achieve CLASS 3 (EN267:1999) emissions, hollow-cone
nozzles have been used.

3193 8GB
4.4 MAINTENANCE POSITION, (fig. 11)
Before performing maintenance on the burner, it is
best to disconnect the system’s power supply.
³Unscrew and remove the screw fastening it to the
flange to take the burner off the boiler.
³Hook the burner onto flange (7), loosen screws (5)
and pull off the blast tube assembly (4).
³Loosen screw (3, fig. 14 page 9) to remove the dif-
fuser disc support assembly (3) from nozzle-holder
assembly (1).
³Pull wires (2) out from electrodes.
³Replace nozzle (6) and screw the new one on prop-
erly, holding it as illustrated in figure 11.
³Refit following the above procedure in the reverse
order.
4.5 COMBUSTION HEAD SETTING, (fig. 13)
Combustion head adjustment varies depending on
burner delivery. To adjust, proceed as follows:
³Turn adjusting screw (2) clockwise or anticlockwise
until the notch on the regulating rod (3) is lined up with
the outer surface of the nozzle-holder assembly (1).
³In the example, the regulating rod (3) is set to setpoint
3. This means the burner is adjusted for an output of
2.7 kg/h with a pump pressure of 12 bar using a 0.75
GPH nozzle, as indicated in the reference table relat-
ing to burner type 370T1.
4.6 AIR DAMPER ADJUSTMENT
To adjust the air damper proceed as follows:
³Loosen nut (5, fig. 13) and set the valve by adjusting
the screw (4).
³When the adjustment is complete screw down nut (5).
Type 370T1 - BGK1
When the burner stops, the air damper closes automati-
cally until maximum negative flue pressure is 0.5 mbar.
Type 374T1 - BGK2
When the burner stops, the air damper stays open.
4
3
2
5
6 7
E9286
1
Fig. 11
D7291
Fig. 13 2
1
3
1
4 5
WARNING
In the event of maintenance
made to the diffuser disc-hold-
er assembly, screw the nut (A)
as shown in the figure 12.
A
TIGHTEN WITHOUT MOVING
BACKWARDS TO THE END
D5684
Fig. 12

3193 9GB
4.7 ELECTRODES ADJUSTMENT, (see fig. 14)
To reach the electrodes, proceed as
described on page 8.
³Lean the diffuser disc-holder
assembly (1) on the nozzle-holder
(2) and lock it by screw (3).
³For prospective adjustments
loosen screw (4) and move the
electrodes assembly (5).
WARNING:
MEASURES MUST BE RESPECTED
4.8 FLAME DETECTOR ADJUSTMENT, (fig. 15)
The flame detector comes with a factory setting of 4.
It comprises:
- Potentiometer (3) for adjusting sensitivity.
- Led (1) indicating sensitivity.
- Led (2) indicating operation.
³During pre-purging, the led (1 and 2) are unlit.
³Stable operation is reported by both Leds lighting.
To adjust, proceed as follows:
³Using the potentiometer (3), turn the indicator anticlockwise
until led (1) lights, thus determining the minimum setpoint
value.
³Using the potentiometer (3), turn the indicator clockwise until
led (1) is steadily lit. Consider the final setting as the minimum
value determined, increasing by 1 or 2 notches.
³Check after at least a 5-minute stop that the resulting adjust-
ment produces a correct burner start-up programme.
4.9 FUEL HEATING
In order to assure regular ignition and operation even at low temperatures, the burner has an oil heater fitted in
the combustion head. The heater starts when the thermostats close.
When the required temperature for ignition is reached, a thermostat fitted on the nozzle holder enables burner
start-up.
Heating stays on during operation and switches off when the burner shuts down.
D5843
5
4
3 1
4.5 - 0.5 mm
0
3 ± 0.3 mm
5.5 ± 0.3 mm
2
Fig. 14
Fig. 15
Blue
Brown
Black
S7903
1
2
3
ATTENTION

3193 10 GB
4.10OPERATING PROGRAMME
Lock out is indicated by a lamp on the control box (5, fig. 1, page 2).
In this case the burner will not reset because there is a serious fault.
CALL THE SERVICE AGENT
The authorized service agent must:
■Restore the working by moving backward the control box, keeping
it supplied and acting on the reset tongue (see fig. 16).
■Check the efficiency of:
Flame detector (7, fig. 1, page 2).
Pump:interception valve (7), or pressure adjuster piston (5), see fig. 7,
page 5.
5. MAINTENANCE
Disconnect the electric supply to the burner by switching off the main power switch and close the
light oil shut-off valve before maintaining or checking the system.
The burner requires scheduled maintenance that must be carried out by qualified personnel and in compli-
ance with local legislation.
Scheduled maintenance is vital for the smooth operation of the burner; it avoids waste of fuel and reduces
harmful emissions into the atmosphere.
THE FUNDAMENTAL OPERATIONS TO CARRY OUT ARE AS FOLLOWS:
³Check there are no occlusions or obstructions in the inlet or return pipes, in the air suction areas and in
the combustion product waste pipe.
³Check that the positioning of the combustion head is correct and that it is properly fixed to the boiler.
³Clean the combustion head at the fuel outlet.
³Clean the fuel suction line filter and the pump filter.
³Check that the burner electrical connections are correct.
³Clean the flame detector.
³Check for correct fuel consumption.
³Check the combustion head (fig. 13, page 8) and the air damper are set correctly (fig. 13, page 8).
³Replace the nozzle if necessary (fig. 11, page 8) and check the correct position of electrodes (fig. 14,
page 9).
³Clean the fan.
Leave the burner working without interruptions for 10 min. and check the right settings at 1st and 2nd stage
of all components stated in this manual. Then carry out the analysis of the combustion by checking:
- Smoke index as per the Bacharach scale; - CO2percentage (%); - CO content (ppm);
- NOx content (ppm); - Smoke temperature at the chimney
D5197
~12s
Thermostat
Motor
Ignition transformer
Valve
Flame
Lock-out lamp
Lock-out due to
failure to light
ALock-out due to
failure to shut-down
B
Normal
Lock-out due to
failure to shut-down
Heating
0–150s 0–150s0–150s ~12s ~12s 20–60s
5s
A
B
Fig. 16
E9071

3193 11 GB
6. FAULTS / SOLUTIONS
Here below you can find some causes and the possible solutions for problems that could cause a failure to
start or a bad working of the burner.
A fault usually makes the lock-out lamp light which is situated inside the reset button of the control box
(5, fig. 1, page 2).
When lock out lamp lights the burner will attempt to light only after pushing the reset button. After this if the
burner functions correctly, the lock-out can be attributed to a temporary fault.
If however the lock out continues the cause must be determined and the solution found.
WARNING
6.1 The manufacturer cannot accept responsibility for any damage to persons, animals or property due to
error in installation or in the burner adjustment, or due to improper or unreasonable use or non observance
of the technical instruction enclosed with the burner, or due to the intervention of unqualified personnel.
FAULTS POSSIBLE CAUSES SOLUTION
The burner doesn’t
start when the limit
thermostat closes.
Lack of electrical supply.
Check presence of voltage in the
L1 - N clamps of the 7 pin plug.
Check the conditions of the fuses.
Check that safety thermostat is not
lock out.
Heating and start thermostats are
faulty. Replace them.
The connections in the control box
are wrongly inserted.
Check and connect completely all the
plugs.
Lock-out because of a failure to turn
off (event B page 10).Call technical assistance.
The burner remains
in the pre-purge
phase.
The flame detector sees strange light
(Led 1 is switched on). Eliminate the light.
Burner runs normal-
ly in the prepurge
and ignition cycle
and locks out after 5
seconds ca.
The flame detector is dirty. Clear it.
The flame detector is defective Change it.
Flame moves away or fails.
Check pressure and output of the fuel.
Check air output.
Change nozzle.
Check the coil of solenoid valve.
Yellow flame.
Nozzle dirty or worn. Replace it.
Defect in the air output. Adjust the air output.
Pump pressure is not correctly set.
Verify the pressure and the output of
the fuel and adjust them according to
the instructions of this manual.
Air suction inlet is clogged. Clear it.
Obstruction in the exhaust circuit. Clear it.
Burner starts with an
ignition delay.
The ignition electrodes are wrongly
positioned.
Adjust them according to the
instructions of this manual.
Air output is too high. Set the air output according to the
instructions of this manual.
Nozzle dirty or worn. Replace it.

3193 12 GB
7. SAFETY WARNINGS
The dimension of the boiler’s combustion chamber must respond to specific values, in order to guarantee a
combustion with the lowest polluting emissions rate.
The Technical Service Personnel will be glad to give you all the imformation for a correct matching of this
burner to the boiler.
This burner must only be used for the application it was designed for.
The manufacturer accepts no liability within or without the contract for any damage caused to people, ani-
mals and property due to installation, adjustment and maintenance errors or to improper use.
7.1 BURNER IDENTIFICATION
The Identification Plate on the product gives the serial number, model and main technical and performance
data. If the Identification Plate is tampered with, removed or missing, the product cannot be clearly identi-
fied thus making any installation or maintenance work potentially dangerous.
7.2 BASIC SAFETY RULES
³Children or inexpert persons must not use the appliance.
³Under no circumstances must the intake grids, dissipation grids and ventilation vents in the installation
room be covered up with cloths, paper or any other material.
³Unauthorised persons must not attempt to repair the appliance.
³It is dangerous to pull or twist the electric leads.
³Cleaning operations must not be performed if the appliance is not disconnected from the main power supply.
³Do not clean the burner or its parts with inflammable substances (e.g. petrol, alcohol, etc.). The cover
must be cleaned with soapy water.
³Do not place anything on the burner.
³Do not block or reduce the size of the ventilation vents in the installation room.
³Do not leave containers and inflammable products in the installation room.

KONFORMITÄTSERKLÄRUNG K.E. 8.1.2004 - Belgium
Hergestellt von: RIELLO S.p.A.
Via Pilade Riello, 7
37045 LEGNAGO (VR) Italy
Tel. ++39.0442630111
Fax ++39.044221980
In den Verkehr gebracht durch: RIELLO NV
Ninovesteenweg 198
9320 Erembodegem
Tel. [phone]
Fax. [phone]
e-mail. [e-mail]
URL. www.riello.be
Wir bestätigen hiermit, dass die nachstehende Geräteserie dem in der CE-Konformitätser-
klärung beschriebenen Baumuster entspricht und dass sie im Einklang mit den Anforderun-
gen des K.E. vom 8. Januar 2004 hergestellt und in den Verkehr gebracht wird.
Produktart: Öl-Gebläsebrenner
Modell: BGK1 – 370T1
BGK2 – 374T1
Angewandte Norm: EN 267 und K.E. vom 8. Januar 2004
Kontrollorganismus: TÜV Industrie Service GmbH
TÜV SÜD Gruppe
Ridlerstrase, 65
80339 Munchen DEUTSCHLAND
Meßwerte: NOx max: 120 mg/kWh
CO max: 8 mg/kWh
Datum: 30/11/2005 RIELLO S.p.A.

3193 1D
INHAL
1. BESCHREIBUNG DES BRENNERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 Mitgeliefertes Zubehör . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. TECHNISCHE MERKMALE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Technische Daten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Abmessungen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.3 Betriebsbereich . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 Betriebsposition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2 Brennermontage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3 Ölversorgungsanlage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.4 Elektrisches Verdrahtungsschema . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. BETRIEB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1 Einstellung der Brennerleistung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Empfohlene Düsen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3 Pumpendruck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.4 Wartungsposition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.5 Flammkopfeinstellung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.6 Einstellung der Luftklappe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.7 Elektrodeneinstellung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.8 Flammendetektoreinstellung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.9 Vorwärmung des Heizöls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.10 Betriebsprogramm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5. WARTUNG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6. STÖRUNGEN / ABHILFE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7. HINWEISE UND SICHERHEIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.1 Kennzeichnung des Brenners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.2 Grundlegende Sicherheitsregeln . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3193 2D
1. BESCHREIBUNG DES BRENNERS
Einstufiger Ölbrenner mit niedrigem Schadstoffausstoß (Stickoxyde NOx, Kohlenmonoxyd CO und unver-
brannte Kohlenwasserstoffe CmHn).
1.1 MITGELIEFERTES ZUBEHÖR
Kesselflansch mit Isolierdichtung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 St.
Schraube und Muttern für Brennerflansch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 St.
7 - poliger Stecker. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 St.
Rezirkulationsrohr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 St.
Schrauben und Muttern für Kesselflansch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 St.
Ölschläuche mit Anschlußnippel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 St.
1– Ölpumpe
2– Luftklappenregulierung
3– Düsenstock
4– Kesselflansch mit Isolierdichtung
5– Steuergerät
6– Entstörtaste mit Störanzeige
7– Flammendetektor
8–Brennkopf
9– Rezirkulationsrohr
10 –Motor
³Brenner mit CE-Kennzeichnung gemäß der EWG-Richtlinien: EMV 89/336/EWG, Niederspannungsrichtlinie
73/23/EWG, Maschinenrichtlinie 98/37/EWG und Wirkungsgradrichtlinie 92/42/EWG.
³CE - Reg. - Nr.: 0036 0232/98 (370T1) - 0036 0233/98 (374T1), nach 92/42/EWG.
³Der Brenner entspricht der Schutzart IP X0D (IP 40) gemäß EN 60529.
³Der Brenner ist gemäß der Norm EN 267 für intermittierenden Betrieb typgenehmigt.
D7290
Fig. 1
2
7
6
1
3
10
5
9
4
8

3193 3D
2. TECHNISCHE MERKMALE
2.1 TECHNISCHE DATEN
2.2 ABMESSUNGEN
2.3 ARBEITSFELDER, (nach EN 267)
TYP 370T1 374T1
Durchsatz 1,5 ÷3,0 kg/h 2,7 ÷5,0 kg/h
Brennerleistung 17,8 ÷35,6 kW 32 ÷59,3 kW
Brennstoff Heizöl-EL, Viskosität 4 ÷ 6 mm2/s bei 20°C
Stromversorgung Einphasig, 230V ±10% ~50Hz
Motor Stromaufnahme 0,8A – 2750 U/min – 288 rad/s
Kondensator 4 µF
Zündtransformator Sekundärspannung 8 kV – 16 mA
Pumpe Druck: 8 ÷15 bar
Leistungsaufnahme 0,25 kW
TYPABCDEØ FØ GHIL
370T1 255 280 202 230 192 87 89 10 28 107
374T1 255 280 202 230 197 90 89 10 28 115
C
11
45°
45°
Ø G
EA
189
106
140
168
H
83
83
D
B
Ø F
L
D7217
I
12
15 20 25 30
3
35 40 45 50 55
45
60
D7637
0,2
0
0,8
0,6
0,4
370T1 374T1
Druck im Feuerraum
mbar
Heizöldurchsatz – kg/h
Brennerleistung – kW

3193 4D
3. INSTALLATION
DIE INSTALLATION DES BRENNERS MUSS IN ÜBEREINSTIMMUNG MIT DEN ÖRTLICHEN GESETZEN
UND VORSCHRIFTEN AUSGEFÜHRT WERDEN.
3.1 BETRIEBSPOSITION
Der Brenner ist ausschließlich für den Betrieb in den Positionen 1und 2vorbereitet.
Die Position 1ist vorzuziehen, da sie die einzige ist, die eine Durchführung der Wartung wie hier folgend in die-
ser Anleitung beschrieben ermöglicht. Die Position 2ermöglicht den Betrieb, aber nicht die Wartung mit dem
Einhängen am Heizkessel. Jede andere Position kann den korrekten Betrieb des Geräts beeinträchtigen.
Die Positionen 3, 4und 5sind aus Sicherheitsgründen verboten.
3.2 BRENNERMONTAGE
Achtung: Bei manchen Heizkesseln können die CO-Werte die in diesem Handbuch angegebenen über-
schreiten. Um diese Emissionen zu verringern muss das mit der Ausstattung gelieferte Rezirkulations-
rohr benutzt werden.
Zur Installation des Brenners am Heizkessel sind folgende Vorgänge auszuführen:
³Falls notwendig das Rezirkulationsrohr (1) an dem Brennerrohr (2) montieren und mit der Schraube (3)
befestigen, (siehe Abb. 2). Achtung: die im Kapitel “2.2 ABMESSUNGEN“ auf Seite 3 beschriebene Ab-
messungen befolgen.
³Die Schraube und die beiden Muttern am Flansch (4) montieren, (siehe Abb. 4).
³Falls erforderlich, die Bohrungen der Isolierdichtung (5, Abb. 5) erweitern.
³Mit den Schrauben (7) und (falls erforderlich) den Muttern (8) den Flansch (4) an der Kesseltür (6) mit
Isolerdichtung (5) montieren, (siehe Abb. 3).
D7088
1 2 3 4 5
Die Kesseltür darf mit Isolierung höchstens 80 mm dick sein.
WICHTIGER HINWEIS
S7708
D5012
8
4
6
Abb. 5
5
7
75
Abb. 3
E9163
Abb. 2 3
1 2
S7709
4
Abb. 4

3193 5D
3.3 ÖLVERSORGUNGSANLAGE
*NUR FÜR ITALIEN: automatische Absperrung gemäß Rundschreiben des Innenministeriums Nr. 73 vom 29.7.71.
H = Höhenunterschied; L = max. Länge der Saugleitung; øi = Innendurchmesser der Leitung.
AUFFÜLLEN DER PUMPE MIT HEIZÖL:
Bei der in Abb. 6 dargestellten Anlage ist es ausreichend, wenn man den
Vakuummeteranschluß (6, Abb. 7) lockert und das Austreten des Brennstoffes
abwartet.
Bei den in Abb. 8 und in Abb. 9 dargestellten Anlagen den Brenner starten und das
Auffüllen abwarten. Sollte vor Eintritt des Brennstoffes eine Störabschaltung erfolgen,
mindestens 20 Sekunden warten und danach den Vorgang wiederholen.
Der max. Unterdruck in der Saugleitung von 0,4 bar (30 cm Hg) darf nicht unter-
schritten werden. Unter diesem Wert bilden sich im Brennstoff Gase. Sich
unbedingt vergewissern, daß die Leitungen absolut dicht sind.
Bei den Anlagen nach Abb. 9, empfehlen wir, die Ölrücklauf-Leitung in gleicher
Höhe wie die Saugleitung im Tank enden zu lassen. Es kann auf ein Fußventil in
der Saugleitung verzichtet werden. Endet die Rücklauf-Leitung über dem Ölniveau
wird auf der Saugseite zwingend ein Fußventil benötigt, wobei dieses dann bei
Verschmutzung Probleme verursachen kann.
H
Meter
L Meter
øi
8 mm
øi
10 mm
0,5
1
1,5
2
10
20
40
60
20
40
80
100
³
Der Brenner ist für den Einbau der Heizölversorgungsrohre
auf beiden Seiten vorgerüstet.
³
In der Brennstoff–Ansaugleitung muß ein Filter eingebaut
werden.
³
Die Pumpe ist werksseitig für den Zweirohr-Betrieb einge-
richtet. Wird ein Pumpen-Einrohrbetrieb für notwendig
erachtet, so ist der Rücklauf-Schlauchleitungsstopfen (2) zu
lösen und die By-Pass Schraube (3) zu entfernen. Danach
ist der Rücklauf-Schlauchleitungsstopfen wieder einzu-
schrauben. (Siehe Abb. 7).
³
Es muß sichergestellt werden, daß die Ölrücklauf-Leitung
ohne Verengung und Verstopfung frei in den Tank zurückge-
führt wird. Durch Druckerhöhung von mehr als 0,5 bar im
Rücklauf wird die Ölpumpe undicht.
WICHTIGER HINWEIS:
H
Meter
L Meter
øi
8 mm
øi
10 mm
0
0,5
1
1,5
2
3
3,5
35
30
25
20
15
8
6
100
100
100
90
70
30
20
IN DEUTSCHLAND
NICHT ZULÄSSIGE
1– Saugleitung
2– Rücklaufleitung
3– By-pass schraube
4– Manometeranschluß
5– Druckregler
6– Vakuummeteranschluß
7– Ölmagnetventil
8 – Hilfsdruckanschluß
1
324
8
76
Abb. 7
D5487
5
H
max. 4 m
max. 4 m
H
H
H
D6329
Abb. 8 Abb. 9
**
H
max. 4 m
*
D6328
Abb. 6
ANLAGE
