Riftek RF096-30/75-120 User manual

Certified according to ISO 9001:2015
LEAF SPRING HOLE INNER DIAMETER
MEASUREMENT MACHINE
22, Logoisky tract, Minsk
220090, Republic of Belarus
tel/fax: [phone]
[e-mail]
User's manual
www.riftek.com
RF096-30/75-120 Model

2
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Contents
.............................................................................................................................................31. Safety precautions
.............................................................................................................................................32. CE сompliance
.............................................................................................................................................33. Laser safety
.............................................................................................................................................34. General information
.............................................................................................................................................45. Basic technical data
.............................................................................................................................................46. Example of item designation when ordering
.............................................................................................................................................57. Structure and operating principle
.............................................................................................................................................68. Connection
.............................................................................................................................................69. Network setting
.............................................................................................................................................610. Intended use
........................................................................................................................................... 610.1. Preparation for use
........................................................................................................................................... 610.2. How to install a leaf spring
.............................................................................................................................................711. Service program
........................................................................................................................................... 711.1. System requirements
........................................................................................................................................... 711.2. Running the program
........................................................................................................................................... 711.3. Authorization
........................................................................................................................................... 811.4. Main window
........................................................................................................................................... 911.5. Settings ................................................................................................................. 911.5.1. "Settings" window
.............................................................................................................. 911.5.1.1. "SCAN" tab
.............................................................................................................. 1011.5.1.2. "HARDWARE" tab
.............................................................................................................. 1111.5.1.3. "REPORT" tab
.............................................................................................................. 1211.5.1.4. "ABOUT" tab
................................................................................................................. 1211.5.2. "User Management" window
.............................................................................................................. 1211.5.2.1. "My Account" tab
.............................................................................................................. 1311.5.2.2. "Account Management" tab
................................................................................................................. 1411.5.3. "Connection" window
........................................................................................................................................... 1411.6. Calibration
........................................................................................................................................... 1611.7. Measurement ................................................................................................................. 1611.7.1. Scan session
................................................................................................................. 1611.7.2. Scanning .............................................................................................................. 1611.7.2.1. Creating the scan program and starting the scanning process
.............................................................................................................. 1711.7.2.2. Ignore area
.............................................................................................................. 1811.7.2.3. 3D view .............................................................................................................. 1911.7.2.4. Profile view
.............................................................................................................. 2011.7.2.5. Zoom ................................................................................................................. 2011.7.3. Browsing the results
................................................................................................................. 2011.7.4. History ................................................................................................................. 2011.7.5. Scan report
................................................................................................................. 2011.7.6. Export / Import data
........................................................................................................................................... 2111.8. Hot keys
.............................................................................................................................................2112. Technical support
.............................................................................................................................................2113. Warranty policy
.............................................................................................................................................2114. List of changes
.............................................................................................................................................2115. Distributors

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
3
1. Safety precautions
· Use supplyvoltage and interfaces indicated in the machine specifications.
· In connection/disconnection of cables, the system power must be switched off.
· Do not use the system in locations close to powerful light sources.
2. CE сompliance
The machine has been developed for use in industry and meets the requirements of
the following Directives:
· EU directive 2014/30/EU. Electromagnetic compatibility (EMC).
· EU directive 2011/65/EU, “RoHS“ category 9.
3. Laser safety
The machine makes use of a c.w. 660 nm wavelength semiconductor laser.
Maximum output power is 1 mW. The system belongs to the 2 laser safety class according
to IEC/EN 60825-1:2014. The following warning label is placed on the housing:
The following safety measures should be taken while operating the machine:
· Do not target laser beam to humans.
· Do not disassemble the laser sensor.
· Avoid staring into the laser beam.
4. General information
The machine is intended for non-contact scanning and inner diameter measurement
of leaf springs holes.

4
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
5. Basic technical data
Parameter
Value
Measured ID range, mm
30...75
ID measurement accuracy, mm
±0.04
Angle scan resolution, points for turnover
3200
Hole depth measurement range, mm
120
Linear translation accuracy, mm
±0.05
Linear translation resolution, mm
programmable, from 0.02
Laser sensor linearity, µm
±20
Laser sensor resolution, µm
5
Laser sensor sample frequency, kHz
10
Light source
red semiconductor laser,
660 nm wavelength
Laser sensor output power, mW
1
Laser safety class
2 (IEC60825-1)
Interface
Ethernet
Power supply, V
220
Measurement speed, parts/s
programmable,
depending on depth
Environmental resistance
Vibration
20 g / 10…1000 Hz, 6 hours for
each of XYZ axes
Shock
30 g / 6 ms
Permissible ambient light, lx
30000
Relative humidity, %
5-95 (no condensation)
Operating ambient temperature, °С
0…+45
Storage temperature, °С
-20…+70
Housing material
aluminum
Weight (without cables), gram
13000
Note: Machine parameters can be changed for a specific task.
6. Example of item designation when ordering
RF096-Dmin/Dmax-L
Symbol
Description
Dmin/Dmax
ID measurement range, mm.
L
Hole depth, mm.

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
5
7. Structure and operating principle
Operation of the machine is based on the scanning of the item inner hole surface by
rotating point triangulation laser sensor.
The machine contains a base on which installed a table with the V-block and fixing
screw (for placing the measured spring), linear translation mechanism, controller. The linear
translation mechanism carries the rotation module on which the laser sensor installed. On
the back side of the machine there are two connectors for power and interface.
Figure 1. Front view
Figure 2. Side view
Figure 3. View from above
The machine operates as follows:
A leaf spring must be installed onto the table and fixed in the V-block by the fixing
screw. On the operator's command, a laser sensor moves into the control hole. Rotating
laser sensor scans the inner surface of a leaf spring, and the system transmits polar
coordinates of the surface (distance from the rotation axis measured by the sensor and a
corresponding angle of rotation) to the PC for calculating the required geometric
parameters. The depth of control and number of measured cross sections are defined by
the software.

6
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
8. Connection
· Connect the machine to your PC by means of two cables (Ethernet cable and
RS485 cable).
· Connect the power cable to the rotation module (this power cable is mounted on
the machine housing).
· Connect the machine to 220V AC by using the special power cable.
All cables are shipped with the machine.
9. Network setting
The machine is shipped with the following default network configuration:
· IP address: 192.168.0.3.
It is imperative to configure the network card of the PC in the following address
space: 192.168.0.Х.
10. Intended use
10.1. Preparation for use
· Check the condition of output window of laser sensor and, if necessary, wipe it
with a soft cloth.
· Rotate a laser sensor by hand and check smooth progress.
· Check the cables and power supply.
· Make sure that the network settings are correct.
· Switch on the machine.
· Run a service program.
· Perform the calibration procedure (for the first use).
When you have done all the steps listed above, you can start the measurement
procedure. How to install the springs properly, see in the next topic.
10.2. How to install a leaf spring
Depending on the spring size, there are four ways to install it on the table.
To install a leaf spring 1, it is necessary to place it on the table tight to the V-block,
and to fix it by the fixing screw (Figure 4).
To install the smaller leaf springs (# 2, 3, 4), you need to use special liners as shown
on Figures 5, 6, 7. Liners are supplied with the machine.
Figure 4. Leaf spring 1
Figure 5. Leaf spring 2

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
7
Figure 6. Leaf spring 3
Figure 7. Leaf spring 4
11. Service program
11.1. System requirements
· Operating system Windows 7 and later.
· Microsoft Visual C++ Runtime Redistributable for Windows 64-bit. Shipped with
the package (you need to run vcredist_x64.exe).
11.2. Running the program
To run the program, you need to double-click on the executable file - idm.exe.
11.3. Authorization
After you run the program, you need to log in:
· Enter the user name (by default - Admin).
· Enter the password (by default - Admin).
· Click the Log In button.
How to create a new account, or how to edit a current account, see p. 11.5.2.

8
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
11.4. Main window
Main control tabs:
Tab
Description
Measure
Calculated parameters for selected profile / whole scan.
Scan
Scan settings and scan process control.
Calibration
System calibration.
Log
Program log.
Toolbar:
Element
Description
DEFECT VIEW
Toggle the profile / defect view. The defect view mode is intended to show the
profile deviations in depth.
SHOW:
CLOUD
Switch on / off the display of point cloud.
MESH
Switch on / off the view of triangle mesh built from a point cloud (press Ctrl key
to rebuild mesh).
BOX
Draw a scale box.
PT SIZE
Change a point size for a point cloud.
History of measurements.
Session window.
Open the report in Excel.
Import a point cloud / mesh from an external file.
Export a current cloud / mesh / profile to an external file.
Scan and hardware settings, information about the program.
Account management window.
Connection window.

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
9
11.5. Settings
11.5.1. "Settings" window
11.5.1.1. "SCAN" tab
Click in the toolbar. The SCAN tab:
VERTICAL MOTION:
Parameter
Description
Scan Step, mm
Scan step for Continuous Mode.
Table Level, mm
Height where a top of table surface located.
Upper Limit, mm
Upper limit of the vertical motion of the linear translation mechanism. The
maximum value is 116.55.
Lower Limit, mm
Lower limit of the vertical motion of the linear translation mechanism.
Continuous Mode
Default and recommended mode of scanning. Uncheck to switch to turn-per-step
mode in case of troubleshooting. In addition, turn-per-step mode may be
preferable in case of discrete scan.
Measures per Turn
Number of points per single profile. Maximum and default value is 3200. Change
to lower value in order to lower memory consumption. In addition, it makes
sense to use lower values on bigger scan step to make a point cloud uniform.
FILTERING:
Parameter
Description
Remove Noise
General noise removal filter (recommended to always be turned on).
Auto-remove Peak
Program guesses the peak location to remove it from scan. It is experimental
feature that works fair on a clear surface only. Manual peak set is
recommended.
Peak Extension, pt
Enable a filter to remove extra points from both sides (number of points).

10
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Parameter
Description
Profile Smoothing
Apply a smooth filter on each profile. Recommended to use only on discrete
scans (it's not good on whole point cloud).
Model Smoothing
Apply parameters of model smoothing (UPRc and Lc).
UPRc
The maximum allowable number of undulations per one revolution. The range of
values: 0...3200 (number of points). The default value is "50". The less the value,
the more smoothed the profile will be. If the value is "0", the profile will be
completely smoothed.
Lc, mm
The size of the surface roughness to be smoothed (in vertical direction). The
default value is "4". If the value is "0", the profile will not be smoothed.
CALIBRATION:
Parameter
Description
Calibration Method
Calibration method:
Sample - calibration using the calibration unit;
Embedded - calibration using the embedded calibration detail.
To save the changes, click OK.
11.5.1.2. "HARDWARE" tab
Hardware settings must remain unchanged and may be overridden only in case of firmware
upgrade.
Click in the toolbar and go to the HARDWARE tab:
RF096 SETTINGS:
Parameter
Description
TCP/IP Address
TCP/IP address of RF096 (IP address of your PC must be in the same subnet).
Destination Port
Ports used for communication with RF096.
Source Port

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
11
MOTOR SETTINGS:
Parameter
Description
Serial Port
Serial port of the motor (COM on Windows).
Baud Rate
Baud rate of the motor.
Network ID
Network ID of the motor.
Motor Step, mm
Motor step in millimeters.
To save the changes, click OK.
11.5.1.3. "REPORT" tab
Click in the toolbar and go to the REPORT tab:
Click Browse and specifya path to the directory where the reports will be stored.
To generate the reports automatically after each scan, select Generate report
automatically after each scan.
To save the changes, click OK.

12
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
11.5.1.4. "ABOUT" tab
Click in the toolbar and go to the ABOUT tab:
In this tab, you can find a software version, website of the device manufacturer, and
a list of hot keys.
For more information about hot keys, refer to p. 11.8.
11.5.2. "User Management" window
11.5.2.1. "My Account" tab
Click in the toolbar. The My Account tab:

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
13
The My Account tab displays a name of the current account and a full name of the
user. To change a password, you need to follow the steps below:
· Enter the current password in the Current password field.
· Enter the new password in the New password field.
· Retype the new password in the Retype password field.
To save the changes, click Apply changes.
11.5.2.2. "Account Management" tab
Click in the toolbar and go to the Account Management tab:
In the Account Management tab, you can add, edit, or delete the accounts.
To add a new account:
· Click Add.
· Enter the account name in the User name field (this name will be used to log in).
· Select a group from the Group list: Administrator or Operator.
· Enter a full name of the user in the Full name field.
· Click Apply.
· In the emerged dialog box, set the password for the new account: enter the
password in the Password field, then retype it in the Retype password field,
and click Ok.
To edit the account:
· Edit the account (NOTE: only the group and the full name can be changed).
· Click Apply.
To delete the account:
· Place the cursor in the Full name field.
· Click Delete.

14
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
11.5.3. "Connection" window
Click in the toolbar. The Connection window:
By default, a local database is selected (SQLite).
If you select MySQL, you need to perform the setting procedure:
11.6. Calibration
The calibration procedure must be done once before you start to use the machine. You may
recalibrate it in case of significant changes to the environment.
The calibration is performed using the embedded calibration detail.
The calibration parameters are preset in the program and must not be changed:
Buttons assignment:
Button
Description
Start the calibration process.
Stop the calibration process.
Lift up the sensor.

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
15
To perform the calibration procedure, follow the steps below:
· Click in the toolbar.
· In the SCAN tab, select Embedded for the Calibration Method parameter, and
click OK.
· Close the Settings window.
· Click .
Upon successful calibration, you will see the following:

16
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
11.7. Measurement
11.7.1. Scan session
The Session window appears immediately after authorization.
The Session window can be opened by clicking in the toolbar.
In this window, the user should:
· Create the session description by populating the fields in the left side;
· Customize a list of measurements:
oTick the parameters you need to measure;
oSet the nominal values and tolerances.
To save the changes, click Save and Proceed.
After typing the value in the field, you need to press the Enter key, otherwise this value will not be
saved.
11.7.2. Scanning
11.7.2.1. Creating the scan program and starting the scanning process
When you have created the scan session, it is necessary to create the scan
program. Each program step must be entered to the table:
Position – height to move to in millimeters (relative to the table surface). To add the
scan position, click . To remove the scan position, put the cursor in the empty field to the
right of the selected position, press the left mouse key, and then click .

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
17
Continuous Scan – trigger to take a series of profiles from this position to the next
one. The step can be customized in the "Settings" window, the "SCAN" tab (see p.
11.5.1.1.). When it is unchecked, a single profile will be taken and then a sensor will be
moved to the next position.
Buttons assignment:
Button
Description
Start the scanning process.
Stop the scanning process.
Lift up the sensor.
When you have created the scan program, install a leaf spring onto the table as
described in p. 10.2. and click in order to start the scanning process.
11.7.2.2. Ignore area
During the scan process or right after it, you may select the defective area to
exclude it from calculation (hereinafter - the ignore area). You may select only one such
area. In order to select the ignore area, hold the Ctrl key pressed and click the left mouse
key on the profile in two different positions to cover the defective area (see the screen shot
below). To reset the ignore area, press the Esc key.
The ignore area of the selected profile will be green (in Profile View).

18
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
11.7.2.3. 3D view
When you run the scanning process, the software starts to construct the 3D model of
the object.
To select a profile to view in the Profile View mode, hold the Ctrl key pressed and
click the left mouse key on the profile. In the 3D View mode, the selected profile will be
highlighted.
To construct the mesh model, tick the MESH box in the toolbar:
To browse the measured values, go to the MEASURE tab.

RF096-30/75-120 [Revision 2.0.0] 27.06.2018
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
19
11.7.2.4. Profile view
Profile View is the detailed view of selected profile in a point cloud model. How to
select a profile, see in the previous topic.
To view the profile deviations in depth, tick the DEFECT VIEW box in the toolbar.
Profile View
Defect View
Blue - average diameter of selected profile
Green - ignore area
Red - profile
Purple - maximum error value
Green - minimum error value
Red - error values
To view the radius, hold the Ctrl key pressed and put the cursor on the profile.
To view the measured values for selected profile, go to the MEASURE tab.
You can exchange the Profile View and 3D View by pressing Ctrl +Tab.

20
Leaf Spring Hole Inner Diameter Measurement Machine. RF096-30/75-120 Model
RF096-30/75-120 [Revision 2.0.0] 27.06.2018
11.7.2.5. Zoom
You may zoom profiles (both in 3D View and Profile View) by rotating the mouse
wheel, and you may move them by pressing the left mouse key. To reset these actions, you
need to double-click on the area (Profile View or 3D View).
11.7.3. Browsing the results
To browse the measured values for the selected profile, go to the MEASURE tab.
The measured value will be displayed in the Value field. The deviation from the
normal value will be displayed in the Error field. If the error value doesn't exceed the
tolerances, it will be displayed in green color, otherwise - in red color.
To select a profile, hold the Ctrl key pressed and click the left mouse key on the
profile in the 3D View area.
11.7.4. History
To browse the history of measurements, click in the toolbar:
You can filter the data: type the word or number in the Filter field and press Enter.
11.7.5. Scan report
To open the scan report, click in the toolbar. For more information, refer to p.
11.5.1.3.
11.7.6. Export / Import data
To export data to external file, click in the toolbar.
Supported file formats: ASC, STL, IDM, CSV.
To import data from external file, click in the toolbar.
Supported file formats: ASC, STL, IDM.
