Rigaku 4364F501 User manual

Cat. No. 4364F501
DIRECT DRIVE TYPE
ROTOR TARGET
(FXRT)
INSTRUCTION MANUAL
Manual No. ME14003C01

This manual describes the correct use of the product as well the usage precautions to be observed. To
obtain full-expected performance from the product, thoroughly read this manual.
Also, store this manual at an easily accessible place so that you can promptly refer to it whenever
it is necessary.
The contents of this manual are subject to change without prior notice.
This manual described in it may not be disclosed to a third party or copied, in whole or in part, without
the written consent of Rigaku Corporation.
In no event will Rigaku Corporation be responsible for the results of the use of this manual.
As a rule, one set of the instruction manual has to be purchased for each product.
If there are any missing or incorrectly collated pages in the delivered instruction manual, please
contact the sales representative who you purchased the instrument from for instruction manual
replacement.
Microsoft, Windows, Windows XP, Windows Vista, Windows 7, Microsoft Internet Explorer, Microsoft Excel, and
Microsoft Word Operating System are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. The ™ and ® marks have been omitted.
Adobe, the Adobe logo, and Reader are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries. The ™ and ® marks have been omitted.
The names of actual companies and products mentioned herein may be the registered trademarks or
trademarks of their respective owners.

ME14003C -i
Contents
1. GENERAL .............................................................................................................................................1
2. SPECIFICATIONS ...............................................................................................................................2
3. LIST OF SUPPLIED ITEMS...............................................................................................................3
3.1 Standard Items ....................................................................................................................................................... 3
4. INSTALLING THE ROTOR TARGET IN AN X-RAY TUBE .......................................................4
4.1 Unpacking.............................................................................................................................................................. 4
4.2 Mounting the Rotor Target in an X-ray Tube ........................................................................................................ 4
5. MAINTENANCE ..................................................................................................................................5
5.1 Cleaning the Surface of a Target............................................................................................................................ 5
5.2 Inspecting and Servicing the Cooling-Water Seal ................................................................................................. 5
5.3 Failures: Insufficient Vacuum, Rotational Noise, or Heavier Vibrations............................................................ 5
5.4 Notes on Water Quality ......................................................................................................................................... 5
5.5 Example of a Maintenance Record ........................................................................................................................ 6
5.6 Other Precautions................................................................................................................................................... 6
5.7 Typical Problems and Remedies............................................................................................................................ 7
5.8 About Repair and Service for the Rotor Target ..................................................................................................... 8
First Edition:June 25, 2004

-1-
ME14003C
1. GENERAL
This instruction manual describes the installation and maintenance procedures for the Rotor Target,
which is to be mounted in the high-intensity X-ray generators. For the X-ray generators in which the
Rotor Target can be mounted and the other related equipment, refer to their respective manuals.
It is also well to remember that the Rotor Target needs to be repaired or serviced in our factory to
secure the performance it possesses at shipment.

-2-
ME14003C
2. SPECIFICATIONS
(1) Target diameter : 99 mm (drum OD)
(2) Rotational speed : 150 s-1 (9000 rpm)
(3) Weight : About 5 kg
(4) Drive system : Direct drive by built-in motor
(5) Kind of target
Target material Catalog number
Cu
Cr
Mo
4364F501
4364B501
4364G501
Table 1
(6) Maximum permissible load
Target material
Maximum
permissible
voltage (kV)
Focus size
(mm2)
Maximum permissible
load (kW)
The values in the
parentheses are optimum
loads.
Cu 60
0.07 ×0.7 1.2 (40kV-30mA)
Cr 40
0.07 ×0.7 1.0 (35kV-28mA)
Mo 60
0.07 ×0.7 1.2 (50kV-24mA)
Table 2

-3-
ME14003C
3. LIST OF SUPPLIED ITEMS
3.1 Standard Items
(1) Body of the Rotor Target ×1
The body is supplied with the water leakage prevention plug installed over the cooling hose
fitting.
(2) Spare parts
The following spare parts are contained with the body in a storage box:
①Carbon ring ×1 (for water sealing)
②O-ring ×2 (S30 silicone)
③Key ×1 (for target shaft)

-4-
ME14003C
4. INSTALLING THE ROTOR TARGET IN AN X-RAY TUBE
4.1 Unpacking
(1) Check the packing for breakage and other abnormality.
(2) After unpacking, check all supplied items with a LIST OF SUPPLIED ITEMS (section 3).
(3) Check for no flaw on the surface of the Rotor Target. Stripes on the surface of the Rotor Target
are the traces of electronic beams and do not constitute any problem.
4.2 Mounting the Rotor Target in an X-ray Tube
(1) Carry the Rotor Target by securely holding the body of it.
Never carry the Rotor Target by holding its cable or target drum. In addition, do not give any
shock to the target drum.
(2) Wipe the part of the Rotor Target body to be inserted into the X-ray tube with a cloth or paper
moistened with hexane or like solvent. Use care so that the solvent does not flow into the body.
Do not directly touch the said part by your hand.
(3) Wipe the O-ring to be attached to the flange of the Rotor Target with a clean cloth or paper.
Also, thoroughly wipe off any dirt from the O-ring groove of the body and the part of the X-ray
tube at which the O-ring is engaged.
(4) Firmly hold the body, and slowly insert into position while aligning it with the X-ray tube
mounting port. Use extreme care so that the circumferential surface of the body does not bump
against anything.
(5) Make sure that the flange on the Rotor Target body is in proper contact with the X-ray tube, and
then tentatively tighten the four mounting screws by degrees and in turn.
(6) Properly connect the two connectors of the body.
(7) If a plug is attached to the cooling-water hose fitting, pull it out pushing the ring on the fitting.
(8) Properly connect the cooling-water hose to the body, aligning the label on the hose with the label
on the body (by strongly pushing the tip of the hose into the fitting).
(9) Insert the leakage sensor to the fitting on a side of the body.
(10) Turn ON the circuit breaker and the main power. After it starts emitting exhaust, firmly tighten
the four mounting screws by degrees and in turn.
Note: Before attaching or removing the Rotor Target, be sure to turn OFF the X-ray
generator power, wait for at least 30 minutes after it stops to emit exhaust and
until the TMP revolutions fully drop to a speed safe to handle.

-5-
ME14003C
5. MAINTENANCE
5.1 Cleaning the Surface of a Target
(1) Remove any burnt material buildup on the central part using fine sandpaper.
Except Cu, be sure to polish the surface of a target along the circumference. Polishing the target
surface toward the axis may cause dust scraped off from Cu, which is the cup's main material,
and improperly enter an area other than the central section of Cu, thereby causing an adverse
effect on measurements. To prevent scraped Cu dust from improperly entering, first tape the
central section of Cu, then polish the target surface. After polishing the target surface, wipe it
thoroughly clean.
The limit you can polish the surface of a target is 0.1 mm (0.2 mm in diameter).
(2) Wipe clean any oil or dust on the target surface with a cloth or paper moistened with hexane or
similar solvent.
5.2 Inspecting and Servicing the Cooling-Water Seal
The TARGET WATER LEAK ALARM the X-ray generator issues indicates that the carbon ring
on the water seal unit needs to be replaced.
It is recommended to replace the carbon ring at intervals of 3000 hours. The warranty is good for
a period of 3000 hours or one year after delivery, whichever occurs first.
5.3 Failures: Insufficient Vacuum, Rotational Noise, or Heavier Vibrations
The Rotor Target is equipped with a magnetic fluid seal to produce a vacuum. The VACCUM
ALARM the X-ray generator issues indicates that the magnetic fluid seal may possibly need to be
replaced.
If the Rotor Target has louder rotational noise or heavier vibrations, the bearings supporting the
rotational axis need to be replaced.
It is recommended to replace the bearings at intervals of 3000 hours. The warranty is good for a
period of 3000 hours or one year after delivery, whichever occurs first.
Note that, however, replacement and adjustment must be done in our factory.
5.4 Notes on Water Quality
(1) Use cooling water for the Rotor Target which satisfies the requirements stated in the
specifications and the instruction manual of the X-ray generator you use.
(2) Using polluted cooling water causes precipitation of foreign substances and corrosion in the
Rotor Target which may lead to critical malfunction. If you observe the cooling water getting
polluted, replace it immediately.

-6-
ME14003C
5.5 Example of a Maintenance Record
To prevent accidents and assure smooth servicing in the event of an accident, you should record the
contents of servicing and repairing tasks performed.
A typical maintenance record example is presented below (the hour meter indicates a reading on
the hour meter of the X-ray generator):
No. Date Hour meter/Target Description Serviced by
1
2
3
2004.10.20
2005.5.30
2005.9.30
42 Cu No.1
3100 Cu No.2
5500 Cu No.2
Delivered, and Installed.
Target replaced.
Strange noise from the
target; repaired
Table 3 Example of a maintenance record
5.6 Other Precautions
(1) Store the Rotor Target in a place where there is neither high temperature nor high humidity to
prevent it from deteriorating.
(2) In replacement of a target, use care so that water drops remaining within the cooling water hoses
do not come into contact with the target surface or the inside of the body of the Rotor Target.
(3) It is recommended that the environmental conditions of the room be properly maintained so as to
avoid moisture condensation during equipment use. Using the Rotor Target in an unfavorable
environment (e.g., high temperature or humidity) may influence the parts in it and deteriorate the
performance it can really provide.
(4) When removing the body of the Rotor Target from the equipment (i.e., to change the target
material), be sure to turn OFF the X-ray generator power, wait for at least 30 minutes after it
stops to emit exhaust and until the TMP revolutions fully drop to a reasonable speed.
(5) For use of any solvent to wipe clean the Rotor Target, exercise utmost care to provide adequate
ventilation and keep fire away at the work site.

-7-
ME14003C
5.7 Typical Problems and Remedies
Problem Probable cause Remedy
Water leakage occurs. There is foreign dust on the
surface of the seal, or
the water seal unit has
reached the end of its useful
life.
Replace the water seal unit.
The connector connection is
not properly made.
Check for the proper connector
connection or the retaining screws
whether properly tightened.
There is an alarm issued for
the target driver.
Solve the cause of the alarm, then turn
the power OFF on the operation panel
and turn it ON again.
The target does not rotate.
There is water in the
connector (e.g., the cooling
water in a hose might have
entered during target
replacement).
Immediately turn OFF the X-ray
generator power, disconnect the
connector, and thoroughly dry the
inside of the connector.
Abnormal noise is
generated.
Vibration is increasing.
The bearings are faulty. Replace the bearings.

-8-
ME14003C
5.8 About Repair and Service for the Rotor Target
The Rotor Target needs to be repaired or serviced in our factory to secure the performance it
possesses at shipment.
Thus, if the Rotor Target is in need of repair or service, contact our service department.
See the following figure and list of the Rotor Target parts below just for reference.

-9-
ME14003C
Direct-Drive Rotor Target (FXRT) Parts List (First Edition)
Cat.No.4364*501
No. Parts Number Name Qty. Requirements Remarks
1 C048-314 Nut 1
φ21.5
2 C048-3-17 O-ring 1 P16 (nitrile)
3 C048-3-01 Washer-attached screw 3 HB3 ×10 washer
attached
4 C048-303 Water-cooling
connector base
1 φ81.5
5 C048-3-5 Spring 6
φ2.9 × L4.7
6 5661-4862 Spacer 1 φ30
7 C048-3-18 O-ring 2 S30 (silicone) Two pieces
supplied
8 A347-3-2D SiC ring 1 φ30
9 5661-48-3D Carbon ring 1 φ30 One piece
supplied
10 5661-4865 Sheet cushion 1 φ30×t1
11 C048-304 Seal case 1 φ61
12 C048-3-12 O-ring 1 S15 (Viton)
13 4555-307 Key 1 L5.8 One piece
supplied
14 C048-003-2 Target housing 1
15 O-ring 1 S28 (Viton)
16 4555-609 Pin 1 φ2×L13
17 C048-002-2 Target drum 1
18 C048-3-21 Cooling water hose
fitting
2 PL6-01M
19 C048-3-24 Plug 3 PP6
20 C048-3-22 Cooling water hose
fitting
1 PC6-02
21 C048-3-23 Cooling water hose
fitting
1 PC12-02
22 C048-3-25 Plug 1 PP12
The parts No. 7, and No. 9 through 12 compose the water seal unit.

LINE OF BUSINESS
X-ray Equipment for Science and Industry
X-ray Diffractometer and Attachments
X-ray Generators
X-ray Diffraction Cameras
X-ray Spectrometers
Piezo Goniometers
X-ray Stress Analyzers
Industrial X-ray Radiographic Equipment
Vacuum Rotary Feedthrough
Thermal Analysis Equipment
Differential Thermal Analyzers
Thermobalance Equipment
Thermomechanical Analyzers
Differential Scanning Calorimeters
Specifications Subject to Change without Notice
Rigaku Corporation Tokyo Branch
4-14-4, Sendagaya, Shibuya-ku, Tokyo 151-0051, Japan
Phone: [phone] Fax: [phone] e-mail: [e-mail] www.rigaku.com
Rigaku Corporation Rigaku Americas Corporation Rigaku Europe SE
Head Office
3
-9-12, Matsubara-cho, Akishima-shi,
Tokyo 196-8666, Japan
Phone: [phone]
Fax: [phone]
e-mail: [e-mail]
9009 New Trails Drive,
The Woodlands, Texas 77381-5209, USA
Phone: [phone]
Fax: [phone]
e-mail: [e-mail]
Gross-Berliner Damm 151,
12487 Berlin, Germany
Phone: [phone]
Fax: [phone]
e-mail: [e-mail]
Rigaku Corporation Rigaku Beijing Corporation
Worldwide Rigaku Representatives
Osaka Factory
14-8, Akaoji-cho, Takatsuki-shi,
Osaka 569-1146, Japan
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
Rm2601A, Tengda Plaza, No.168, Xizhimenwai
Avenue, Haidian District, 100044 Beijing,
China
Phone: [phone]
Fax: [phone]
e-mail: [e-mail]
URL:http://www.rigaku.com/contact/world.html
2012.02
