RIGOL
IV User Guide for PVA7000 Series Active Probe
Contents
Guaranty and Declaration .................................................................... I
Safety Notices and Symbols ............................................................... II
Document Overview .......................................................................... III
PVA7000 Series Overview ....................................................................1
Probe Introduction.............................................................................2
General Inspection.............................................................................3
Probe Dimensions ..............................................................................4
Accessories and Options .....................................................................5
Active Probe Amplifier ........................................................................5
Probe Head .......................................................................................6
To Use PVA7000 Series Active Probe ...................................................9
To Connect to the Oscilloscope.......................................................... 10
To Use the Probe Head..................................................................... 12
To Replace Probe Accessories ........................................................... 15
To Adjust Offset Voltage ................................................................... 16
To Calibrate the Probe...................................................................... 17
Care and Cleaning.............................................................................. 18
Warranty............................................................................................ 19
Specifications .................................................................................... 20
