Rigol DG1062Z Use and care manual

RIGOL
Calibration Guide
DG1000Z Series
Function/Arbitrary Waveform Generator
Feb. 2014
RIGOL Technologies, Inc.

RIGOL
DG1000Z Calibration Guide
I
Guaranty and Declaration
Copyright
© 2014 RIGOL Technologies, Inc. All Rights Reserved.
Trademark Information
RIGOL is a registered trademark of RIGOL Technologies, Inc.
Publication Number
CGB09100-1110
Notices
RIGOL products are protected by patent law in and outside of P.R.C.
RIGOL reserves the right to modify or change parts of or all the specifications
and pricing policies at company’s sole decision.
Information in this publication replaces all previously corresponding material.
RIGOL shall not be liable for losses caused by either incidental or consequential
in connection with the furnishing, use or performance of this manual as well as
any information contained.
Any part of this document is forbidden to be copied or photocopied or
rearranged without prior written approval of RIGOL.
Product Certification
RIGOL guarantees this product conforms to the national and industrial standards in
China as well as the ISO9001:2008 standard and the ISO14001:2004 standard.
Other international standard conformance certification is in progress.
Contact Us
If you have any problem or requirement when using our products or this manual,
please contact RIGOL.
E-mail: [e-mail]
Websites: www.rigol.com

RIGOL
II DG1000Z Calibration Guide
Document Overview
This manual gives a detailed introduction of the calibration notices and calibration
process of DG1000Z.
Subjects in this Manual:
Chapter 1 Calibration Notices
This chapter gives a detailed introduction of the recommended calibration interval,
calibration safety, the method to stop the calibration and the related information, the
method to acquire the calibration service, the recommended test devices and the
notices during the test.
Chapter 2 Calibration Process
This chapter gives a detailed introduction of the calibration interface and the
calibration process of each calibration item of DG1000Z.
Format Conventions in this Manual:
1. Button
The front-panel key is denoted by the format of “Text Box + Button Name
(Bold)” in the manual, for example, Utility denotes the “Utility” key.
2. Menu
The menu is denoted by the format of “Character Shading + Menu Word (Bold)”
in the manual, for example, System denotes the “System” menu item under
Utility.
3. Operation Step
The next step of the operation is denoted by an arrow “” in the manual. For
example, Utility System denotes pressing Utility at the front panel and
then pressing System.
Content Conventions in this Manual:
DG1000Z series function/arbitrary waveform generator includes the following models.
Unless otherwise noted in this manual, DG1062Z is taken as an example to introduce
the calibration notices and calibration process of DG1000Z series.
Model Number of Channels Max. Output Frequency
DG1062Z 2 60MHz
DG1032Z 2 30MHz

Contents RIGOL
DG1000Z Calibration Guide
III
Contents
Guaranty and Declaration.........................................................................I
Document Overview................................................................................II
Chapter 1 Calibration Notices.............................................................1-1
Calibration Interval................................................................................ 1-1
Calibration Safety.................................................................................. 1-1
To Stop the Calibration........................................................................... 1-1
To Acquire the Calibration Service........................................................... 1-2
Recommended Test Devices ................................................................... 1-2
Test Notices.......................................................................................... 1-2
Chapter 2 Calibration Process ............................................................2-1
Frequency Accuracy Calibration............................................................... 2-3
Amplitude (AC Amplitude) Calibration...................................................... 2-4
Low-frequency Flatness Calibration ......................................................... 2-5
Offset (Output Offset) Calibration............................................................ 2-6
Inner Load Calibration ........................................................................... 2-7
High-frequency Flatness Calibration......................................................... 2-9

Chapter 1 Calibration Notices RIGOL
DG1000Z Calibration Guide
1-1
Chapter 1 Calibration Notices
Calibration Interval
Regular calibration can ensure the performance specifications of DG1000Z. You are
recommended to calibrate the instrument at a one-year calibration interval. You can
select a proper calibration interval according to your requirement of performance
accuracy. However, the calibration interval cannot exceed 2 years; otherwise, the
specifications cannot be guaranteed.
You are recommended to perform a complete calibration at the selected calibration
interval to ensure that the instrument will remain within specifications before the
next calibration.
Calibration Safety
You need to input the correct password before calibration each time you want to
calibrate the instrument. The password is used to prevent accidental or unauthorized
calibration of the instrument.
Press Utility Test/Cal Manual Cal, input the correct password using the
numeric keyboard. Then, press OK to enter the calibration interface.
The calibration password is “123456”. The password is stored in the non-volatile
memory and will not change at power-off or remote interface reset.
You are allowed to modify the calibration password. Press Utility Test Cal 
Password Modify, press Old, New and Confirm in turn, input the corresponding
password and then press OK to finish the password modification.
To Stop the Calibration
You can power off the instrument to stop the calibration at any time during the
calibration. The calibration data stored will not be cleared when the calibration is
stopped and you do not need to calibrate the items already calibrated again in the
next calibration.
CAUTION
If the calibration is stopped when the instrument is writing the new
calibration constants into the Flash, you may lose all the calibration
constants and you need to perform the calibration again.

RIGOL Chapter 1 Calibration Notices
1-2 DG1000Z Calibration Guide
To Acquire the Calibration Service
Improper calibration may result in output accuracy reduction and even output error.
RIGOL does not recommend manual calibration by users. If calibration is required,
please contact RIGOL customer service department or the local distributor.
Recommended Test Devices
It is recommended that you use the test devices listed in the table below or other test
devices whose performance specifications satisfy the “Performance Requirement”
listed in the table below for calibration.
Table 1-1 Recommended Test Devices
Device
Performance Requirement
Recommended
Digital Multimeter
61/
2
digits
RIGOL DM3068
Frequency Counter >10MHz
Accuracy: 0.1ppm Agilent 53131A
Power Meter -30dBm to +20dBm Accuracy: ±0.02dB
Resolution: 0.01dB Agilent E4418B
Connecting Wire
BNC (m) - Dual banana plug (m)
--
Connecting Wire
BNC (m) - BNC (m)
--
Power Sensor -30dBm to +20dBm Agilent N8482A
Power Sensor
Connecting Wire
Used to connect the power meter and
power sensor
--
50Ω Load 50Ω/1W --
Test Notices
For optimum performance, all procedures should comply with the following
recommendations.
1) Make sure the environment temperature is stable and between 18℃and 28℃.
Ideally, the calibration should be performed at 23℃±1℃.
2) Make sure the environment relative humidity is less than 80%.
3) Make sure that the instrument has been warmed up for at least 30 minutes
before the calibration.
4) Keep the test cables as short as possible and make sure that the impedance of
the cable is consistent with the requirement.

Chapter 2 Calibration Process RIGOL
DG1000Z Calibration Guide 2-1
Chapter 2 Calibration Process
Warm DG1000Z up for at least 30 minutes. Press Utility Test/Cal Manual
Cal and input the correct password using the numeric keyboard. Then, press OK to
enter the calibration interface as shown in the figure below.
Figure 2-1 Calibration Interface
1. Cal Item
Press this softkey to select the desired calibration item. The calibration items of
DG1000Z manual calibration are listed in the table below. You can select one or
more calibration items, but it is recommended to perform a complete calibration.
Table 2-1 Calibration Items
No.
Item
1
Amplitude (AC amplitude)
2 Low-frequency Flatness
3 High-frequency Flatness
4
Inner Load
5 Offset (output offset)
6 Frequency Accuracy
Note: To acquire higher calibration accuracy, pay attention to the following
points during the calibration process.
Perform the frequency accuracy calibration before performing the
amplitude calibration.
Perform the frequency accuracy calibration and amplitude calibration before
performing the flatness calibrations (include the low-frequency flatness and
high-frequency flatness).

RIGOL Chapter 2 Calibration Process
2-2 DG1000Z Calibration Guide
Perform the amplitude calibration before performing the inner load
calibration or offset calibration.
Perform the inner load calibration before performing the high-frequency
flatness calibration.
2. Cal Point
Press this softkey and the specified calibration point in the ID column is
highlighted (not applicable to the “Freq Accuracy” calibration item). At this point,
you can rotate the knob to select the current calibration point.
Note: Users cannot set the current calibration point for the inner load
calibration at will. For the detailed calibration method, refer to “Inner Load
Calibration”.
3. Meas Val
Press this softkey after selecting a calibration point (not applicable to the “Freq
Accuracy” calibration item). The MeasValue column of the corresponding point
becomes editable. At this point, use the numeric keyboard or the knob and
direction keys to input the measurement value.
4. Input Val
After selecting a calibration point and inputting the measurement value (not
applicable to the “Freq Accuracy” calibration item), press this softkey to write
the measurement value into the system and finish the calibration of the point
selected.
5. Save
Press this softkey to save the current calibration data.
6. Default
Press this softkey to restore the calibration values to the factory calibration
values.
The calibration method of each calibration item is introduced in detail in the following
part of this chapter.
CAUTION
You are recommended to calibrate each item following the sequence
below.

Chapter 2 Calibration Process RIGOL
DG1000Z Calibration Guide 2-3
Frequency Accuracy Calibration
1. Make sure that DG1000Z has been warmed up for at least 30 minutes. Use a
dual-BNC connecting wire to connect the channel output terminal of DG1000Z
(take CH1 as an example, the calibration method is also applicable to CH2) and
the signal input terminal of the frequency counter, as shown in the figure below.
DG1000Z Series Frequency Counter
Figure 2-2 Connect DG1000Z and the Frequency Counter
2. Press Output1corresponding to CH1 on the front panel of DG1000Z to turn on
the channel output.
3. Set the input impedance of the frequency counter to HighZ.
4. Enter the DG1000Z calibration interface and press Cal Item to select Freq
Accuracy.
5. Press Start according to the prompt message on the calibration interface to
start the frequency accuracy calibration (the calibration frequency is 10MHz).
6. Observe the measurement value of the frequency counter. If the current
measurement value is less than 10MHz, press UpWard Adjust to increase the
DG1000Z output frequency and if the current measurement value is greater
than 10MHz, press DnWard Adjust to reduce the DG1000Z output frequency
until the absolute value of the difference between the measurement value of the
frequency counter and 10MHz is less than 1Hz.
7. Press Save and the frequency accuracy calibration is finished.
◎

RIGOL Chapter 2 Calibration Process
2-4 DG1000Z Calibration Guide
Amplitude (AC Amplitude) Calibration
1. Make sure that DG1000Z has been warmed up for at least 30 minutes. Connect
the channel output terminal of DG1000Z (take CH1 as an example, the
calibration method is also applicable to CH2) and the voltage input terminals of
the digital mutlimeter using a BNC-Dual banana plug connecting wire, as shown
in the figure below.
DG1000Z Series Digital Multimeter
Figure 2-3 Connect DG1000Z and the Digital Multimeter
2. Press Output1corresponding to CH1 on the front panel of DG1000Z to turn on
the channel output.
3. Turn on the digital multimeter, select the ACV measurement function and set the
range to “Auto”.
4. Enter the DG1000Z calibration interface and press Cal Item to select Ampl (the
default calibration item).
5. Press Cal Point and the cursor switches to the first calibration point in the ID
column.
6. Press Meas Val and the MeasValue column of the point selected becomes
editable. At this point, use the numeric keyboard or the knob and direction keys
to input the current measurement value of the digital multimeter.
7. Press Input Val to write the measurement value into the system and finish the
calibration of the point selected. The cursor switches to the ID column.
8. Use the knob to select the next calibration point. Repeat steps 6 and 7 to
measure the amplitude (AC amplitude) of this calibration point until finishing the
calibration of all the calibration points.
9. Press Save and the amplitude (AC amplitude) calibration is finished.
◎◎
◎◎
◎

Chapter 2 Calibration Process RIGOL
DG1000Z Calibration Guide 2-5
Low-frequency Flatness Calibration
1. Make sure that DG1000Z has been warmed up for at least 30 minutes. Connect
the channel output terminal of DG1000Z (take CH1 as an example, the
calibration method is also applicable to CH2) and the voltage input terminals of
the digital mutlimeter using a BNC-Dual banana plug connecting wire, as shown
in Figure 2-3.
2. Press Output1corresponding to CH1 on the front panel of DG1000Z to turn on
the channel output.
3. Turn on the digital multimeter, select the ACV measurement function and set the
range to “Auto”.
4. Enter the DG1000Z calibration interface and press Cal Item to select Low Freq
Flat.
5. Press Cal Point and the cursor switches to the first calibration point in the ID
column.
6. Press Meas Val and the MeasValue column of the point selected becomes
editable. At this point, use the numeric keyboard or the knob and direction keys
to input the current measurement value of the digital multimeter.
7. Press Input Val to write the measurement value into the system and finish the
calibration of the point selected. The cursor switches to the ID column.
8. Use the knob to select the next calibration point. Repeat steps 6 and 7 to
measure the low-frequency flatness of this calibration point until finishing the
calibration of all the calibration points.
9. Press Save and the low-frequency flatness calibration is finished.

RIGOL Chapter 2 Calibration Process
2-6 DG1000Z Calibration Guide
Offset (Output Offset) Calibration
1. Make sure that DG1000Z has been warmed up for at least 30 minutes. Connect
the channel output terminal of DG1000Z (take CH1 as an example, the
calibration method is also applicable to CH2) and the voltage input terminals of
the digital mutlimeter using a BNC-Dual banana plug connecting wire, as shown
in Figure 2-3.
2. Press Output1corresponding to CH1 on the front panel of DG1000Z to turn on
the channel output.
3. Turn on the digital multimeter, select the DCV measurement function and set the
range to “Auto”.
4. Enter the DG1000Z calibration interface and press Cal Item to select Offset.
5. Press Cal Point and the cursor switches to the first calibration point in the ID
column.
6. Press Meas Val and the MeasValue column of the point selected becomes
editable. At this point, use the numeric keyboard or the knob and direction keys
to input the current measurement value of the digital multimeter.
7. Press Input Val to write the measurement value into the system and finish the
calibration of the point selected. The cursor switches to the ID column.
8. Use the knob to select the next calibration point. Repeat steps 6 and 7 to
measure the offset of this calibration point until finishing the calibration of all the
calibration points.
9. Press Save and the offset (output offset) calibration is finished.

Chapter 2 Calibration Process RIGOL
DG1000Z Calibration Guide 2-7
Inner Load Calibration
1. Make sure that DG1000Z has been warmed up for at least 30 minutes. Connect
the channel output terminal of DG1000Z (take CH1 as an example, the
calibration method is also applicable to CH2) and the voltage input terminals of
the digital mutlimeter using a BNC-Dual banana plug connecting wire, as shown
in Figure 2-3.
2. Press Output1corresponding to CH1 on the front panel of DG1000Z to turn on
the channel output.
3. Turn on the digital multimeter, select the ACV measurement function and set the
range to “Auto”.
4. Enter the DG1000Z calibration interface and press Cal Item to select Inner
Load.
5. Press Cal Point and the cursor switches to the first calibration point in the ID
column.
6. You need to calibrate each calibration point twice (otherwise, you cannot select
the next calibration point).
a) Calibration without 50Ω load:
Press Meas Val and the MeasValue column of the point selected becomes
editable. At this point, use the numeric keyboard or the knob and direction
keys to input the current measurement value of the digital multimeter. Press
Input Val to write the measurement value into the system. At this point,
“Please connect 50 ohm load.” is displayed on the instrument screen and
the cursor switches to the ID column. Please connect a 50Ωload between
DG1000Z and the digital multimeter, as shown in the figure below.
DG1000Z Series Digital Multimeter
50Ω Load
Figure 2-4 Connect DG1000Z and the Digital Multimeter via a 50Ω Load
◎◎
◎◎
◎

RIGOL Chapter 2 Calibration Process
2-8 DG1000Z Calibration Guide
b) Calibration with 50Ω load:
Press Meas Val and the MeasValue column of the point selected becomes
editable. At this point, use the numeric keyboard or the knob and direction
keys to input the current measurement value of the digital multimeter. Press
Input Val to write the measurement value into the system. At this point,
“Please remove the 50 ohm load.” is displayed on the instrument screen and
the cursor switches to the ID column. Please remove the 50Ωload between
DG1000Z and the digital multimeter and connect DG1000Z and the digital
multimeter according to Figure 2-3.
7. Use the knob to select the next calibration point. Repeat step 6 to measure the
inner load of this calibration point until finishing the calibration of all the
calibration points.
8. Press Save and the inner load calibration is finished.

Chapter 2 Calibration Process RIGOL
DG1000Z Calibration Guide 2-9
High-frequency Flatness Calibration
1. Make sure that DG1000Z has been warmed up for at least 30 minutes. Connect
the power meter and power sensor; then connect the power sensor to the
output terminal of DG1000Z (take CH1 as an example, the calibration method is
also applicable to CH2), as shown in the figure below.
DG1000Z Series Power Meter
Power Sensor
Figure 2-5 Connect G1000Z and the Power Meter
2. Press Output1corresponding to CH1 on the front panel of DG1000Z to turn on
the channel output.
3. Turn on the power meter.
4. Enter the DG1000Z calibration interface and press Cal Item to select High
Freq Flat.
5. Press Cal Point and the cursor switches to the first calibration point in the ID
column.
6. The frequency of the first calibration point is 100kHz. Please set a proper
frequency calibration factor on the power meter according to the ratio of the
power sensor.
7. Press Meas Val and the MeasValue column of the point selected becomes
editable. At this point, use the numeric keyboard or the knob and direction keys
to input the current measurement value of the power meter.
8. Press Input Val to write the measurement value into the system and finish the
calibration of the point selected. The cursor switches to the ID column.
◎

RIGOL Chapter 2 Calibration Process
2-10 DG1000Z Calibration Guide
9. Use the knob to select the next calibration point (for each calibration point, set a
proper frequency calibration factor on the power meter). Repeat steps 7 and 8
to measure the high-frequency flatness of this calibration point until finishing
the calibration of all the calibration points.
10. Press Save and the high-frequency flatness calibration is finished.
