Service Guide
DSG800 Series RF Signal Generator
Sept. 2018
RIGOL (SUZHOU) TECHNOLOGIES, INC.

RIGOL
DSG800 Service Guide I
Guaranty and Declaration
Copyright
© 2015 RIGOL (SUZHOU) TECHNOLOGIES, INC. All Rights Reserved.
Trademark Information
RIGOL is a registered trademark of RIGOL (SUZHOU) TECHNOLOGIES, INC.
Publication Number
SGG02104-1110
Notices
RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
RIGOL reserves the right to modify or change parts of or all the specifications and pricing
policies at the company’s sole decision.
Information in this publication replaces all previously released materials.
Information in this publication is subject to change without notice.
RIGOL shall not be liable for either incidental or consequential losses in connection with the
furnishing, use or performance of this manual as well as any information contained.
Any part of this document is forbidden to be copied, photocopied or rearranged without prior
written approval of RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial standards in China as well
as the ISO9001:2015 standard and the ISO14001:2015 standard. Other international standard
conformance certifications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual, please contact
RIGOL.
E-mail: [e-mail]
Website: www.rigol.com

RIGOL
II DSG800 Service Guide
Safety Requirement
General Safety Summary
Please review the following safety precautions carefully before putting the instrument into operation
so as to avoid any personal injury or damage to the instrument and any product connected to it. To
prevent potential hazards, please follow the instructions specified in this manual to use the instrument
properly.
Use Proper Power Cord.
Only the exclusive power cord designed for the instrument and authorized for use within the local
country could be used.
Ground the Instrument.
The instrument is grounded through the Protective Earth lead of the power cord. To avoid electric
shock, connect the earth terminal of the power cord to the Protective Earth terminal before connecting
any input or output terminals.
Connect the Probe Correctly.
If a probe is used, do not connect the ground lead to high voltage since it has isobaric electric potential
as the ground.
Observe All Terminal Ratings.
To avoid fire or shock hazard, observe all ratings and markers on the instrument and check your
manual for more information about ratings before connecting the instrument.
Use Proper Overvoltage Protection.
Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the product.
Otherwise, the operator might be exposed to the danger of an electric shock.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Do Not Insert Anything Into the Air Outlet.
Do not insert anything into the air outlet to avoid damage to the instrument.
Use Proper Fuse.
Please use the specified fuses.
Avoid Circuit or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered on.
Do Not Operate With Suspected Failures.
If you suspect damage occurs to the instrument, have it inspected by RIGOL authorized personnel
before further operations. Any maintenance, adjustment or replacement especially to circuits or
accessories must be performed by RIGOL authorized personnel.
Provide Adequate Ventilation.
Inadequate ventilation may cause an increase of temperature in the instrument, which would cause
damage to the instrument. So please keep the instrument well ventilated and inspect the air outlet and
the fan regularly.

RIGOL
DSG800 Service Guide III
Do Not Operate in Wet Conditions.
To avoid short circuit inside the instrument or electric shock, never operate the instrument in a humid
environment.
Do Not Operate in an Explosive Atmosphere.
To avoid personal injuries or damage to the instrument, never operate the instrument in an explosive
atmosphere.
Keep Instrument Surfaces Clean and Dry.
To avoid dust or moisture from affecting the performance of the instrument, keep the surfaces of the
instrument clean and dry.
Prevent Electrostatic Impact.
Operate the instrument in an electrostatic discharge protective environment to avoid damage induced
by static discharges. Always ground both the internal and external conductors of cables to release
static before making connections.
Use the Battery Properly.
Do not expose the battery (if available) to high temperature or fire. Keep it out of the reach of children.
Improper change of a battery (lithium battery) may cause an explosion. Use the RIGOL specified
battery only.
Handle with Caution.
Please handle with care during transportation to avoid damage to keys, knobs, interfaces and other
parts on the panels.

RIGOL
IV DSG800 Service Guide
Safety Notices and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation or practice which, if not avoided, will result in
serious injury or death.
CAUTION
Indicates a potentially hazardous situation or practice which, if not avoided, could result
in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
It calls attention to an operation, if not correctly performed, could result in injury or
hazard immediately.
WARNING
It calls attention to an operation, if not correctly performed, could result in
potential
injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could result in
damage to
the product or other devices connected to the product.
Safety Symbols on the Product:
Hazardous
Voltage
Safety
Warning
Protective
Earth
Terminal
Chassis
Ground
Test
Ground

RIGOL
DSG800 Service Guide V
Allgemeine Sicherheits Informationen
Überprüfen Sie diefolgenden Sicherheitshinweise sorgfältigumPersonenschädenoderSchäden am
Gerätundan damit verbundenen weiteren Gerätenzu vermeiden. Zur Vermeidung vonGefahren, nutzen
Sie bitte das Gerät nur so, wiein diesem Handbuchangegeben.
Um Feuer oder Verletzungen zu vermeiden, verwenden Sie ein ordnungsgemäßes
Netzkabel.
Verwenden Sie für dieses Gerät nur das für ihr Land zugelassene und genehmigte Netzkabel.
Erden des Gerätes.
Das Gerät ist durch den Schutzleiter im Netzkabel geerdet. Um Gefahren durch elektrischen Schlag zu
vermeiden, ist es unerlässlich, die Erdung durchzuführen. Erst dann dürfen weitere Ein- oder
Ausgänge verbunden werden.
Anschluss einesTastkopfes.
Die Erdungsklemmen der Sonden sindauf dem gleichen Spannungspegel des Instruments geerdet.
SchließenSie die Erdungsklemmen an keine hohe Spannung an.
Beachten Sie alle Anschlüsse.
Zur Vermeidung von Feuer oder Stromschlag, beachten Sie alle Bemerkungen und Markierungen auf
dem Instrument. Befolgen Sie die Bedienungsanleitung für weitere Informationen, bevor Sie weitere
Anschlüsse an das Instrument legen.
Verwenden Sie einen geeigneten Überspannungsschutz.
Stellen Sie sicher, daß keinerlei Überspannung (wie z.B. durch Gewitter verursacht) das Gerät
erreichen kann. Andernfallsbestehtfür den Anwender die GefahreinesStromschlages.
Nicht ohne Abdeckung einschalten.
Betreiben Sie das Gerät nicht mit entfernten Gehäuse-Abdeckungen.
Betreiben Sie das Gerät nicht geöffnet.
Der Betrieb mit offenen oder entfernten Gehäuseteilen ist nicht zulässig. Nichts in entsprechende
Öffnungen stecken (Lüfter z.B.)
Passende Sicherung verwenden.
Setzen Sie nur die spezifikationsgemäßen Sicherungen ein.
Vermeiden Sie ungeschützte Verbindungen.
Berühren Sie keine unisolierten Verbindungen oder Baugruppen, während das Gerät in Betrieb ist.
Betreiben Sie das Gerät nicht im Fehlerfall.
Wenn Sie am Gerät einen Defekt vermuten, sorgen Sie dafür, bevor Sie das Gerät wieder betreiben,
dass eine Untersuchung durch RIGOL autorisiertem Personal durchgeführt wird. Jedwede Wartung,
Einstellarbeiten oder Austausch von Teilen am Gerät, sowie am Zubehör dürfen nur von RIGOL
autorisiertem Personal durchgeführt werden.
Belüftung sicherstellen.
Unzureichende Belüftung kann zu Temperaturanstiegen und somit zu thermischen Schäden am Gerät
führen. Stellen Sie deswegen die Belüftung sicher und kontrollieren regelmäßig Lüfter und
Belüftungsöffnungen.
Nicht in feuchter Umgebung betreiben.
Zur Vermeidung von Kurzschluß im Geräteinneren und Stromschlag betreiben Sie das Gerät bitte

RIGOL
VI DSG800 Service Guide
niemals in feuchter Umgebung.
Nicht in explosiver Atmosphäre betreiben.
Zur Vermeidung von Personen- und Sachschäden ist es unumgänglich, das Gerät ausschließlich fernab
jedweder explosiven Atmosphäre zu betreiben.
Geräteoberflächen sauber und trocken halten.
Um den Einfluß von Staub und Feuchtigkeit aus der Luft auszuschließen, halten Sie bitte die
Geräteoberflächen sauber und trocken.
Schutz gegen elektrostatische Entladung (ESD).
Sorgen Sie für eine elektrostatisch geschützte Umgebung, um somit Schäden und Funktionsstörungen
durch ESD zu vermeiden. Erden Sie vor dem Anschluß immer Innen- und Außenleiter der
Verbindungsleitung, um statische Aufladung zu entladen.
Die richtige Verwendung desAkku.
Wenneine Batterieverwendet wird, vermeiden Sie hohe Temperaturen bzw. Feuer ausgesetzt werden.
Bewahren Sie es außerhalbder Reichweitevon Kindern auf. UnsachgemäßeÄnderung derBatterie
(Anmerkung: Lithium-Batterie) kann zu einer Explosion führen. VerwendenSie nur von RIGOL
angegebenenAkkus.
Sicherer Transport.
Transportieren Sie das Gerät sorgfältig (Verpackung!), um Schäden an Bedienelementen, Anschlüssen
und anderen Teilen zu vermeiden.

RIGOL
DSG800 Service Guide VII
Sicherheits Begriffe und Symbole
Begriffe in diesem Guide:
WARNING
Die Kennzeichnung WARNING beschreibt Gefahrenquellen die leibliche Schäden oder
den Tod von Personen zur Folge haben können.
CAUTION
Die Kennzeichnung Caution (Vorsicht) beschreibt Gefahrenquellen die Schäden am Gerät
hervorrufen können.
Begriffe auf dem Produkt:
DANGER
weist auf eine Verletzung oder Gefährdung hin, die sofort geschehen kann.
WARNING
weist auf eine Verletzung oder Gefährdung hin, die möglicherweise nicht sofort
geschehen.
CAUTION
weist auf eine Verletzung oder Gefährdung hin und bedeutet, dass eine mögliche
Beschädigung des Instruments oder anderer Gegenstände auftreten kann.
Symbole auf dem Produkt:
Gefährliche
Spannung Sicherheits- Hinweis Schutz-erde Gehäusemasse Erde

RIGOL
VIII DSG800 Service Guide
Document Overview
Format Conventions in this Manual
1. Key:
The key at the front panel is denoted by the format of "Text Box + Key Name (Bold)" in the
manual. For example, FREQ denotes the FREQ key.
2. Menu:
The menu is denoted by the format of "Character Shading + Menu Word (Bold)" in the manual.
For example, LF denotes the submenu low frequency under FREQ.
3. Connector:
The connector on the front or rear panel is denoted by the format of "Square Brackets +
Connector Name (Bold)" in the manual. For example, [RF OUTPUT 50Ω].
4. Operation Step:
The operation for the next step is denoted by an arrow "" in the manual. For example, FREQ 
LF denotes that you first press FREQ on the front panel and then press LF.
Manuals of this Product
The manuals of this product include Quick Guide, User’s Guide, Programming Guide, Data Sheet,
Service Guide, etc. The latest versions of the manuals can be downloaded from www.rigol.com.

Contents RIGOL
DSG800 Service Guide IX
Contents
Guaranty and Declaration................................................................................................ I
Safety Requirement........................................................................................................II
General Safety Summary...................................................................................................II
Safety Notices and Symbols.............................................................................................. IV
Allgemeine Sicherheits Informationen..................................................................................V
Sicherheits Begriffe und Symbole..................................................................................... VII
Document Overview....................................................................................................VIII
Chapter 1 Disassembly and Assembly........................................................................ 1-1
Notices to Disassembly and Assembly...............................................................................1-1
Exploded View Drawing of the Instrument ........................................................................1-2
Disassemble the Handle..................................................................................................1-4
Disassemble Rear Support Legs.......................................................................................1-5
Disassemble the Metal Enclosure .....................................................................................1-6
Disassemble BNC-MCX Feedthroughs................................................................................1-7
Disassemble the Power Module........................................................................................1-8
To Disassemble the IQ Module.........................................................................................1-9
Disassemble Front Protective Covers ..............................................................................1-10
Disassemble the Front Panel Assembly ...........................................................................1-11
Disassemble the Control Board ......................................................................................1-12
Disassemble the Front Panel Cover, Keypads and the Knob...............................................1-13
Disassemble the LCD....................................................................................................1-14
Disassemble the Keypad Boards.....................................................................................1-15
Disassemble the OCXO Module......................................................................................1-16
Disassemble the RF Module...........................................................................................1-17
Disassemble the Fan.....................................................................................................1-18
Assembly Procedures....................................................................................................1-19
Chapter 2 Troubleshooting&Maintenance ................................................................. 2-1
Troubleshooting .............................................................................................................2-1
Maintenance..................................................................................................................2-4
System Maintenance ................................................................................................2-4
Warranty.................................................................................................................2-4
Care and Cleaning....................................................................................................2-5
Environmental Considerations ...................................................................................2-5
Chapter 3 Appendix................................................................................................... 3-1
Appendix A: Error Codes and Explanations........................................................................3-1
Command Errors......................................................................................................3-1
Execution Errors ......................................................................................................3-3
Device-specific Errors...............................................................................................3-5
Query Errors............................................................................................................3-7
Appendix B: Software Update..........................................................................................3-8

Chapter 1 Disassembly and AssemblyRIGOL
DSG800 Service Guide 1-1
Chapter 1 Disassembly and Assembly
Notices to Disassembly and Assembly
Notices:
Do not disassemble the instrument unless for working requirement.
Only authorized personnel are allowed to disassemble the instrument.
Cut off the power supply before disassembling the instrument.
Please wear anti-static wrist strap or make other anti-static precaution when disassembling the
instrument.
Please use proper tools and follow the correct steps.
Take care not to deform the metal structure or get hurt when disassembling the metal structures.
To avoid causing damage to the instrument due to improper operation and to save your time, we
recommend you to follow the disassembly steps and methods in this guide manual.
Required Tools:
Phillips screwdriver T20/T10
BNC socket wrench
WARNING
Ensure that the power supply is cut off before disassembling the instrument. Only
well-trained professional personnel or qualified personnel are allowed to disassemble
the instrument.

RIGOL Chapter 1 Disassembly and Assembly
1-2 DSG800 Service Guide
Exploded View Drawing of the Instrument
You need to get a basic understanding of the main parts of the instrument before disassembling and
assembling the instrument. When disassembling or assembling the instrument, please follow the
procedures and avoid scratching the part surface. This manual mainly introduces the disassembly and
assembly methods of DSG800 series RF signal generator. The exploded view drawing for DSG800
(with the IQ and OCXO modules) is as shown in Figure 1-1.
Figure 1-1 DSG800 Exploded View Drawing

Chapter 1 Disassembly and AssemblyRIGOL
DSG800 Service Guide 1-3
Table 1-1 Replacement Parts List
No.
Part No.
Qty.
Name/Description
1
2010002859
1
Front Panel
2
1020003311
1
Side Keypad
3
2010003560
1
LCD
4
2010003245
1
Side Keypad Board
5
2010001542
1
Knob
6
1020003319
1
Screen Bezel Mounting Frame
7
1020003310
1
Main Keypad
8
2010003244
1
Main Keypad Board
9
1020003315
1
Front Metal Cover
10
1020000552
4
M4*6 Torx Pan Head Screw
11
2010003243
1
Control Board
12
1020003320
1
Shielding Cover
13
2010001561
1
Front Protective Cover (Bottom Left)
14
2010001563
1
Front Protective Cover (Top Left)
15
1020000569
8
M4*10 Torx Pan Head Screw
16
2010001564
1
Front Protective Cover (Bottom Right)
17
2010001562
1
Front Protective Cover (Top Right)
18
2010003648
1
RF Module
19
1010004911
4
BNC-MCX Feedthrough
20
1020001048
4
M4*14 Torx Pan Head Screw
21
1020000579
12
M3*6 Torx Flat Countersunk Head Screw
22
2010001566
2
Rear Support Leg (Bottom)
23
2010001560
2
Rear Support Leg (Top)
24
1020003317
1
Metal Enclosure
25
1020000571
19
M3*6 Torx Pan Head Combination Screw
26
1020001834
1
OCXO Plate
27
1020000550
4
M3*10 Torx Pan Head Screw
28
1020000648
4
BNC Washer
29
2010003300
1
OCXO Module
30
1020002124
10
M3*25 Torx Pan Head Combination
Screw
31
2010000346
1
Handle
32
2010003649
1
Power Box
33
2010003396
1
IQ Module
34
1020003307
1
Fan
35
1020003198
4
PTF5*10 Torx Flat Countersunk Head
Self-tapping Screw
36
1020003316
1
Metal Chassis
The recommended disassembly procedures are as follows:
Disassemble the Handle Disassemble Rear Support Legs Disassemble the Metal Enclosure 
Disassemble BNC-MCX Feedthroughs Disassemble the Power Module To Disassemble the IQ
Module Disassemble Front Protective Covers Disassemble the Front Panel Assembly 
Disassemble the Control Board Disassemble the Front Panel Cover, Keypads and the Knob 
Disassemble the LCD Disassemble the Keypad Boards Disassemble the OCXO Module 
Disassemble the RF Module Disassemble the Fan.

RIGOL Chapter 1 Disassembly and Assembly
1-4 DSG800 Service Guide
Disassemble the Handle
Figure 1-2 Disassemble the Handle
Part Description:
①1 handle.
Disassembly Step:
Rotate the handle upright and pull out from the sides of the instrument to remove the handle.
Note: Before assembling the handle, check whether the metal enclosure is correctly installed.
Handle

Chapter 1 Disassembly and AssemblyRIGOL
DSG800 Service Guide 1-5
Disassemble Rear Support Legs
Figure 1-3 Disassemble Rear Support Legs
Part Description:
①4 screws (M4*14 torx pan head screw, used for securing rear support legs).
Disassembly Steps:
1. Use the T20 screwdriver to remove 4 screws (①) that secure rear support legs.
2. Take off rear support legs gently.
Note: When assembling rear support legs, pay attention to the mounting position of rear support legs.
The rear support leg with 2 ribs on it should be mounted at the top; whereas the rear support leg with
three ribs on it should be mounted at the bottom.
①
①
①
①

RIGOL Chapter 1 Disassembly and Assembly
1-6 DSG800 Service Guide
Disassemble the Metal Enclosure
Figure 1-4 Disassemble the Metal Enclosure
Part Description:
①2 screws (M3*6 torx flat countersunk head screw, used for fastening the metal enclosure to the
metal chassis).
②1 metal enclosure.
Disassembly Steps:
1. Use the T10 screwdriver to remove 2 screws (①) that secure the metal enclosure.
2. Take off the metal enclosure gently in the arrow direction (as shown in the figure above).
Note: When assembling the metal enclosure, the side of the metal enclosure with a binding seam
should be placed downward.
①
①
Metal Enclosure
Binding Seam

Chapter 1 Disassembly and AssemblyRIGOL
DSG800 Service Guide 1-7
Disassemble BNC-MCX Feedthroughs
Figure 1-5 Disassemble BNC-MCX Feedthroughs
Part Description:
①4 BNC nuts for fastening BNC-MCX feedthroughs.
②4 BNC washers for fastening BNC-MCX feedthroughs.
Disassembly Steps:
1. Use the BNC socket wrench to remove 4 BNC nuts (①) and 4 BNC washers (②) that fasten
BNC-MCX feedthroughs.
2. Remove BNC-MCX feedthroughs gently.
Tip:
Before disassembling BNC-MCX feedthroughs, pay attention to the mounting position of each
feedthrough to avoid incorrect mounting or incomplete mounting when assembling the
feedthroughs.
BNC-MCX Feedthroughs
BNC Washers
BNC Nuts

RIGOL Chapter 1 Disassembly and Assembly
1-8 DSG800 Service Guide
Disassemble the Power Module
Figure 1-6 Disassemble the Power Module
Part Description:
①2 screws (M3*10 torx pan head screw, used for fastening the power cord connector).
②2 screws (M3*10 torx pan head screw, used for fastening the power module).
③1 screw (M4*8 torx pan head screw, used for fastening the power module).
Disassembly Steps:
1. Use the T10 screwdriver to remove 2 screws (①) that fasten the power cord connector.
2. Remove the cables that connect the power module.
3. Use the T10 screwdriver to remove 2 screws (②) that fasten the power module.
4. Use the T10 screwdriver to remove the screw (③) that fastens the power module.
5. Take out the power module gently.
Tip:
1. Before disassembling the cables on the power module, please pay attention to the connecting
positions of the cables to avoid incorrect connection or incomplete connection when assembling
the cables.
2. When assembling the instrument, the three screws that fasten the power module should be
well grounded.
①
③
①
②
②
