Rigol DG1062Z User manual

RIGOL
User’s Guide
DG1000Z Series Function/Arbitrary
Waveform Generator
Oct. 2016
RIGOL TECHNOLOGIES, INC.

RIGOL
DG1000Z User’s Guide I
Guaranty and Declaration
Copyright
© 2013 RIGOL TECHNOLOGIES, INC. All Rights Reserved.
Trademark Information
RIGOLis a registered trademark of RIGOL TECHNOLOGIES, INC.
Publication Number
UGB09109-1110
Notices
RIGOL products are covered by P.R.C. and foreign patents, issued and pending.
RIGOL reserves the right to modify or change parts of or all the specifications
and pricing policies at the company’s sole decision.
Information in this publication replaces all previously released materials.
Information in this publication is subject to change without notice.
RIGOL shall not be liable for either incidental or consequential losses in
connection with the furnishing, use, or performance of this manual, as well as
any information contained.
Any part of this document is forbidden to be copied, photocopied, or rearranged
without prior written approval of RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial
standards in China as well as the ISO9001:2008 standard and the ISO14001:2004
standard. Other international standard conformance certifications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual,
please contact RIGOL.
E-mail: [e-mail]
Websites: www.rigol.com

RIGOL
II DG1000Z User’s Guide
Safety Requirement
General Safety Summary
Please review the following safety precautions carefully before putting the
instrument into operation so as to avoid any personal injury or damage to the
instrument and any product connected to it. To prevent potential hazards, please
follow the instructions specified in this manual to use the instrument properly.
Use Proper Power Cord.
Only the exclusive power cord designed for the instrument and authorized for use
within the local country could be used.
Ground the Instrument.
The instrument is grounded through the Protective Earth lead of the power cord. To
avoid electric shock, connect the earth terminal of the power cord to the Protective
Earth terminal before connecting any input or output terminals.
Connect the Probe Correctly.
If a probe is used, do not connect the ground lead to high voltage since it has
isobaric electric potential as the ground.
Observe All Terminal Ratings.
To avoid fire or shock hazard, observe all ratings and markers on the instrument and
check your manual for more information about ratings before connecting the
instrument.
Use Proper Overvoltage Protection.
Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the
product. Otherwise, the operator might be exposed to the danger of an electric
shock.
Do Not Operate Without Covers.
Do not operate the instrument with covers or panels removed.
Do Not Insert Anything Into the Air Outlet.
Do not insert anything into the air outlet to avoid damage to the instrument.
Use Proper Fuse.
Please use the specified fuses.
Avoid Circuit or Wire Exposure.
Do not touch exposed junctions and components when the unit is powered on.

RIGOL
DG1000Z User’s Guide III
Do Not Operate With Suspected Failures.
If you suspect that any damage may occur to the instrument, have it inspected by
RIGOL authorized personnel before further operations. Any maintenance,
adjustment or replacement especially to circuits or accessories must be performed by
RIGOL authorized personnel.
Provide Adequate Ventilation.
Inadequate ventilation may cause an increase of temperature in the instrument,
which would cause damage to the instrument. So please keep the instrument well
ventilated and inspect the air outlet and the fan regularly.
Do Not Operate in Wet Conditions.
To avoid short circuit inside the instrument or electric shock, never operate the
instrument in a humid environment.
Do Not Operate in an Explosive Atmosphere.
To avoid personal injuries or damage to the instrument, never operate the
instrument in an explosive atmosphere.
Keep Instrument Surfaces Clean and Dry.
To avoid dust or moisture from affecting the performance of the instrument, keep the
surfaces of the instrument clean and dry.
Prevent Electrostatic Impact.
Operate the instrument in an electrostatic discharge protective environment to avoid
damage induced by static discharges. Always ground both the internal and external
conductors of cables to release static before making connections.
Use the Battery Properly.
Do not expose the battery (if available) to high temperature or fire.
Keep it out of the reach of children. Improper change of a battery (lithium battery)
may cause an explosion. Use the RIGOL specified battery only.
Handle with Caution.
Please handle with care during transportation to avoid damage to keys, knobs,
interfaces, and other parts on the panels.

RIGOL
IV DG1000Z User’s Guide
Safety Notices and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation or practice which, if not
avoided, will result in serious injury or death.
CAUTION
Indicates a potentially hazardous situation or practice which, if not
avoided, could result in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
It calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.
WARNING It calls attention to an operation, if not correctly performed, could
result in potential injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could
result in damage to the product or other devices connected to the
product.
Safety Symbols on the Product:
Hazardous
Voltage
Safety
Warning
Protective
Earth
Terminal
Chassis
Ground
Test
Ground

RIGOL
DG1000Z User’s Guide V
Allgemeine Sicherheits Informationen
Überprüfen Sie diefolgenden Sicherheitshinweise
sorgfältigumPersonenschädenoderSchäden am Gerätundan damit verbundenen
weiteren Gerätenzu vermeiden. Zur Vermeidung vonGefahren, nutzen Sie bitte das
Gerät nur so, wiein diesem Handbuchangegeben.
Um Feuer oder Verletzungen zu vermeiden, verwenden Sie ein
ordnungsgemäßes Netzkabel.
Verwenden Sie für dieses Gerät nur das für ihr Land zugelassene und genehmigte
Netzkabel.
Erden des Gerätes.
Das Gerät ist durch den Schutzleiter im Netzkabel geerdet. Um Gefahren durch
elektrischen Schlag zu vermeiden, ist es unerlässlich, die Erdung durchzuführen. Erst
dann dürfen weitere Ein- oder Ausgänge verbunden werden.
Anschluss einesTastkopfes.
Die Erdungsklemmen der Sonden sindauf dem gleichen Spannungspegel des
Instruments geerdet. SchließenSie die Erdungsklemmen an keine hohe Spannung
an.
Beachten Sie alle Anschlüsse.
Zur Vermeidung von Feuer oder Stromschlag, beachten Sie alle Bemerkungen und
Markierungen auf dem Instrument. Befolgen Sie die Bedienungsanleitung für weitere
Informationen, bevor Sie weitere Anschlüsse an das Instrument legen.
Verwenden Sie einen geeigneten Überspannungsschutz.
Stellen Sie sicher, daß keinerlei Überspannung (wie z.B. durch Gewitter verursacht)
das Gerät erreichen kann. Andernfallsbestehtfür den Anwender die
GefahreinesStromschlages.
Nicht ohne Abdeckung einschalten.
Betreiben Sie das Gerät nicht mit entfernten Gehäuse-Abdeckungen.
Betreiben Sie das Gerät nicht geöffnet.
Der Betrieb mit offenen oder entfernten Gehäuseteilen ist nicht zulässig. Nichts in
entsprechende Öffnungen stecken (Lüfter z.B.)
Passende Sicherung verwenden.
Setzen Sie nur die spezifikationsgemäßen Sicherungen ein.
Vermeiden Sie ungeschützte Verbindungen.
Berühren Sie keine unisolierten Verbindungen oder Baugruppen, während das Gerät
in Betrieb ist.

RIGOL
VI DG1000Z User’s Guide
Betreiben Sie das Gerät nicht im Fehlerfall.
Wenn Sie am Gerät einen Defekt vermuten, sorgen Sie dafür, bevor Sie das Gerät
wieder betreiben, dass eine Untersuchung durch RIGOL autorisiertem Personal
durchgeführt wird. Jedwede Wartung, Einstellarbeiten oder Austausch von Teilen am
Gerät, sowie am Zubehör dürfen nur von RIGOL autorisiertem Personal
durchgeführt werden.
Belüftung sicherstellen.
Unzureichende Belüftung kann zu Temperaturanstiegen und somit zu thermischen
Schäden am Gerät führen. Stellen Sie deswegen die Belüftung sicher und
kontrollieren regelmäßig Lüfter und Belüftungsöffnungen.
Nicht in feuchter Umgebung betreiben.
Zur Vermeidung von Kurzschluß im Geräteinneren und Stromschlag betreiben Sie das
Gerät bitte niemals in feuchter Umgebung.
Nicht in explosiver Atmosphäre betreiben.
Zur Vermeidung von Personen- und Sachschäden ist es unumgänglich, das Gerät
ausschließlich fernab jedweder explosiven Atmosphäre zu betreiben.
Geräteoberflächen sauber und trocken halten.
Um den Einfluß von Staub und Feuchtigkeit aus der Luft auszuschließen, halten Sie
bitte die Geräteoberflächen sauber und trocken.
Schutz gegen elektrostatische Entladung (ESD).
Sorgen Sie für eine elektrostatisch geschützte Umgebung, um somit Schäden und
Funktionsstörungen durch ESD zu vermeiden. Erden Sie vor dem Anschluß immer
Innen- und Außenleiter der Verbindungsleitung, um statische Aufladung zu entladen.
Die richtige Verwendung desAkku.
Wenneine Batterieverwendet wird, vermeiden Sie hohe Temperaturen bzw. Feuer
ausgesetzt werden. Bewahren Sie es außerhalbder Reichweitevon Kindern auf.
UnsachgemäßeÄnderung derBatterie (Anmerkung: Lithium-Batterie) kann zu einer
Explosion führen. VerwendenSie nur von RIGOLangegebenenAkkus.
Sicherer Transport.
Transportieren Sie das Gerät sorgfältig (Verpackung!), um Schäden an
Bedienelementen, Anschlüssen und anderen Teilen zu vermeiden.

RIGOL
DG1000Z User’s Guide VII
Sicherheits Begriffe und Symbole
Begriffe in diesem Guide:
WARNING
Die Kennzeichnung WARNING beschreibt Gefahrenquellen die leibliche
Schäden oder den Tod von Personen zur Folge haben können.
CAUTION
Die Kennzeichnung Caution (Vorsicht) beschreibt Gefahrenquellen die
Schäden am Gerät hervorrufen können.
Begriffe auf dem Produkt:
DANGER
weist auf eine Verletzung oder Gefährdung hin, die sofort
geschehen kann.
WARNING
weist auf eine Verletzung oder Gefährdung hin, die möglicherweise
nicht sofort geschehen.
CAUTION
weist auf eine Verletzung oder Gefährdung hin und bedeutet, dass
eine mögliche Beschädigung des Instruments oder anderer
Gegenstände auftreten kann.
Symbole auf dem Produkt:
Gefährliche
Spannung Sicherheits- Hinweis Schutz-erde Gehäusemasse Erde

RIGOL
VIII DG1000Z User’s Guide
Care and Cleaning
Care
Do not store or leave the instrument where it may be exposed to direct sunlight for
long periods of time.
Cleaning
Clean the instrument regularly according to its operating conditions.
1. Disconnect the instrument from all power sources.
2. Clean the external surfaces of the instrument with a soft cloth dampened with
mild detergent or water. When cleaning the LCD, take care to avoid scarifying it.
CAUTION
To avoid damage to the instrument, do not expose it to caustic liquids.
WARNING
To avoid short-circuit resulting from moisture or personal injuries,
ensure that the instrument is completely dry before connecting it to the
power supply.

RIGOL
DG1000Z User’s Guide IX
Environmental Considerations
The following symbol indicates that this product complies with the WEEE Directive
2002/96/EC.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or
human health. To avoid the release of such substances into the environment and
avoid harm to human health, we recommend you to recycle this product
appropriately to ensure that most materials are reused or recycled properly. Please
contact your local authorities for disposal or recycling information.

RIGOL
X DG1000Z User’s Guide

RIGOL
DG1000Z User’s Guide XI
DG1000Z Series Overview
DG1000Z Series is a multifunctional generator that combines many functions in one,
including Function Generator, Arbitrary Waveform Generator, Noise Generator, Pulse
Generator, Harmonics Generator, Analog/Digital Modulator and Counter. As a
multi-functional, high performance, high cost-effective and portable generator, it will
be a new selection in education, R&D, production, test, etc.
Main Features:
Maximum output frequency (Sine): 25MHz, 30MHz and 60MHz
Innovative SiFi (Signal Fidelity): generate the arbitrary waveform point by point,
undistortedly restore signal, precisely adjustable sample rate and low jitter
(down to 200ps) for all waveforms including Square, Pulse and etc.
Arbitrary waveform memory for each channel: 2Mpts (standard), 8Mpts
(standard), 16Mpts (optional)
Standard dual full functional channels which are equivalent to two independent
generators
±1ppm frequency stability, -125dBc/Hz phase noise
Built-in 8 orders harmonics generator
Built-in 7 digits/s full function frequency counter with 200MHz bandwidth
Up to 160 built-in waveforms encompassing common signals in various fields
including Engineering, Medical Electronics, Automotive Electronics, Mathematics
and etc.
200MSa/s sample rate, 14bits vertical resolution
Standard powerful arbitrary waveform editing function. Users can also edit
arbitrary waveform using PC software
Various modulation functions: AM, FM, PM, ASK, FSK, PSK and PWM
Standard waveform summing function. When it is enabled, you can superpose
specified waveform onto basic waveform before output
Standard channel tracking function. When it is enabled, all parameters of dual
channels can be modified synchronously according to user’s requirements
Standard interfaces: USB Host, USB Device, LAN (LXI Core 2011 Device)
3.5 inches (320*240) color display
Portable design, only weight 3.5kg

RIGOL
XII DG1000Z User’s Guide
Document Overview
Subjects in this Manual
Chapter 1 Quick Start
Briefly introduces the appearance and
dimensions, front/rear panel and user interface
of DG1000Z.
Chapter 2 Front Panel Operations
Introduce the main functions and operation
methods of DG1000Z.
Chapter 3 Remote Control Briefly introduce how to control the DG1000Z
remotely.
Chapter 4 Troubleshooting List the possible failures or problems and their
solutions when using DG1000Z.
Chapter 5 Specifications
Provide the specifications of DG1000Z series.
Chapter 6 Appendix Provide the information about the options and
accessories list as well as warranty information
of DG1000Z.
Format Conventions in this Manual
1. Button:
The button at the front panel is denoted by the format of “Text Box + Button
Name (Bold)” in the manual, for example, Sine.
2. Menu:
The menu is denoted by the format of “Character Shading + Menu Word (Bold)”
in the manual, for example, Freq.
3. Connector:
The connector at the front or rear panel is denoted by the format of “Square
Brackets+Connector Name (Bold)” in the manual, for example, [Counter].
4. Operation Steps:
The next step of the operation is denoted by an arrow “” in the manual. For
example, Sine Freq represents pressing Sine at the front panel and then
pressing Freq.

RIGOL
DG1000Z User’s Guide XIII
Content Conventions in this Manual
1. DG1000Z series function/arbitrary waveform generator includes DG1022Z,
DG1032Z and DG1062Z. In this manual, DG1062Z is taken as an example to
introduce the operating method of the generator.
Model
Channels
Max. Frequency
DG1062Z
2
60MHz
DG1032Z 2 30MHz
DG1022Z 2 25MHz
2. Both models of DG1000Z series function/arbitrary waveform generator are
equipped with dual channels (CH1 and CH2). Unless otherwise specified, this
manual takes CH1 as an example to introduce the operation methods which are
also applied to CH2.
Manuals of this Product
The manuals of this product mainly include the quick guide, user’s guide,
programming guide and data sheet. For the newest version of the desired manual,
download it from the RIGOL website (www.rigol.com).

RIGOL Contents
XIV DG1000Z User’s Guide
Contents
Guaranty and Declaration......................................................................... I
Safety Requirement.................................................................................II
General Safety Summary...........................................................................II
Safety Notices and Symbols .....................................................................IV
Allgemeine Sicherheits Informationen ........................................................ V
Sicherheits Begriffe und Symbole.............................................................VII
Care and Cleaning.................................................................................VIII
Environmental Considerations................................................................... IX
DG1000Z Series Overview......................................................................XI
Document Overview............................................................................. XII
Chapter 1 Quick Start ........................................................................ 1-1
General Inspection.................................................................................1-2
To Adjust the Handle..............................................................................1-3
Appearance and Dimensions ...................................................................1-4
Front Panel Overview .............................................................................1-5
Rear Panel Overview ............................................................................1-11
Power On and Inspection......................................................................1-14
To Connect to Power......................................................................1-14
Power-on......................................................................................1-14
To Set the System Language...........................................................1-14
User Interface......................................................................................1-15
Dual Channels Parameters Mode.....................................................1-15
Dual Channels Graph Mode.............................................................1-18
Single Channel View Mode..............................................................1-18
To Use the Built-in Help System.............................................................1-19
Chapter 2 Front Panel Operations...................................................... 2-1
To Output Basic Waveform......................................................................2-2
To Select Output Channel.................................................................2-2
To Select Basic Waveform.................................................................2-3
To Set Frequency/Period...................................................................2-4
To Set Amplitude/High Level.............................................................2-5
To Set Offset/Low Level....................................................................2-7
To Set Start Phase...........................................................................2-8
Align Phase.....................................................................................2-9
To Set Duty Cycle (Square).............................................................2-10
To Set Symmetry (Ramp) ...............................................................2-11
To Set Pulse Width/Duty Cycle (Pulse).............................................2-12
To Set Leading/Trailing Edge Time (Pulse)........................................2-13
To Enable Output...........................................................................2-14
Example: To Output Sine Waveform ................................................2-15

Contents RIGOL
DG1000Z User’s Guide XV
To Output Arbitrary Waveform...............................................................2-17
To Enable Arbitrary Waveform.........................................................2-17
Output Mode and Sample Rate........................................................2-18
To Select Arbitrary Waveform..........................................................2-19
To Edit Arbitrary Waveform.............................................................2-26
To Output Harmonic .............................................................................2-30
Overview ......................................................................................2-30
To Set Fundamental Waveform Parameters.......................................2-31
To Set Harmonic Order...................................................................2-31
To Select Harmonic Type ................................................................2-31
To Set Harmonic Amplitude.............................................................2-32
To Set Harmonic Phase...................................................................2-32
Example: To Output Harmonic.........................................................2-33
Modulation ..........................................................................................2-35
Amplitude Modulation (AM).............................................................2-35
Frequency Modulation (FM).............................................................2-39
Phase Modulation (PM)...................................................................2-42
Amplitude Shift Keying (ASK)..........................................................2-45
Frequency Shift Keying (FSK)..........................................................2-48
Phase Shift Keying (PSK) ................................................................2-51
Pulse Width Modulation (PWM) .......................................................2-54
Sweep.................................................................................................2-57
To Enable Sweep Function..............................................................2-57
Start Frequency and Stop Frequency ...............................................2-57
Center Frequency and Frequency Span ............................................2-58
Sweep Type...................................................................................2-59
Sweep Time..................................................................................2-60
Return Time..................................................................................2-60
Mark Frequency.............................................................................2-61
Start Hold .....................................................................................2-61
Stop Hold......................................................................................2-62
Sweep Trigger Source.....................................................................2-62
Burst...................................................................................................2-65
To Enable Burst Function................................................................2-65
Burst Type.....................................................................................2-65
Burst Period ..................................................................................2-67
Gated Polarity................................................................................2-67
Burst Delay ...................................................................................2-68
Burst Trigger Source.......................................................................2-68
Idle Level......................................................................................2-69
Counter...............................................................................................2-70
To Enable the Counter....................................................................2-70
To Set the Counter.........................................................................2-71
Store and Recall...................................................................................2-74
Storage System .............................................................................2-74
File Type.......................................................................................2-75

RIGOL Contents
XVI DG1000Z User’s Guide
Browser Type................................................................................2-77
File Operation................................................................................2-77
Seamless Interconnection with Oscilloscope.....................................2-81
Utility and System Settings....................................................................2-83
Channel Set ..................................................................................2-84
Coupling Set .................................................................................2-90
Channel Copy................................................................................2-93
Restore Default .............................................................................2-94
To Set System Languege................................................................2-99
System Information .......................................................................2-99
System Set .................................................................................2-100
I/O Configuration ........................................................................2-103
Print Set.....................................................................................2-107
Test/Calibration ...........................................................................2-107
To Use External Power Amplifier (Option).......................................2-108
To Install the Option...........................................................................2-112
To Lock the Keyboard.........................................................................2-114
Chapter 3 Remote Control ................................................................. 3-1
Remote Control via USB..........................................................................3-2
Remote Control via LAN..........................................................................3-5
Remote Control via GPIB (Option)............................................................3-8
Chapter 4 Troubleshooting ................................................................ 4-1
Chapter 5 Specifications .................................................................... 5-1
Chapter 6 Appendix ........................................................................... 6-1
Appendix A: Accessories and Options.......................................................6-1
Appendix B: Specifications of Power Amplifier...........................................6-2
Appendix C: Warranty.............................................................................6-4
Index........................................................................................................1

Chapter 1 Quick Start RIGOL
DG1000Z User’s Guide 1-1
Chapter 1 Quick Start
This chapter briefly introduces the appearance and dimensions, front/rear panel and
user interface of DG1000Z.
Subjects in this chapter:
General Inspection
To Adjust the Handle
Appearance and Dimensions
Front Panel Overview
Rear Panel Overview
Power On and Inspection
User Interface
To Use the Built-in Help System

RIGOL Chapter 1 Quick Start
1-2 DG1000Z User’s Guide
General Inspection
1. Inspect the packaging
If the packaging has been damaged, do not dispose the damaged packaging or
cushioning materials until the shipment has been checked for completeness and
has passed both electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to the instrument
resulting from shipment. RIGOL would not be responsible for free
maintenance/rework or replacement of the instrument.
2. Inspect the instrument
In case of any mechanical damage, missing parts, or failure in passing the
electrical and mechanical tests, contact your RIGOL sales representative.
3. Check the accessories
Please check the accessories according to the packing lists. If the accessories
are damaged or incomplete, please contact your RIGOL sales representative.
