RIKA IMPERA User manual

IMPERA/XL
Operating Manual

2
TABLE OF CONTENT
1. PREFACE 3
Explanations to symbols...........................................................................................................................................................................3
Dimensions ..............................................................................................................................................................................................3
Amount of fuel .........................................................................................................................................................................................3
Technical data...........................................................................................................................................................................................3
Packaging .................................................................................................................................................................................................3
Spare part overview exploded diagram IMPERA ...................................................................................................................................4
Spare part overview exploded diagram IMPERA XL.............................................................................................................................6
Spare part overview article numbers Impera ............................................................................................................................................8
Spare part overview article numbers Impera XL ......................................................................................................................................9
2. IMPORTANT INFORMATION 10
General warning and safety information ................................................................................................................................................10
Safety distances ......................................................................................................................................................................................10
Prior to set up.........................................................................................................................................................................................11
3. BRIEF INFORMATION ON FUEL - LOGS 12
Suitable fuels and fuel amounts ..............................................................................................................................................................12
Wood types.............................................................................................................................................................................................12
Fuel amounts with nominal heat output.................................................................................................................................................12
Clean combustion...................................................................................................................................................................................12
4. INSTALLING THE STOVE 13
General information...............................................................................................................................................................................13
Connection to the chimney ....................................................................................................................................................................13
Connecting to a steel chimney ..............................................................................................................................................................13
Combustion air.......................................................................................................................................................................................13
Feeding in external combustion air.........................................................................................................................................................13
5. OPERATION – MANUAL REAR WALL 14
Correct heating up..................................................................................................................................................................................14
Operating the riddle grate ......................................................................................................................................................................14
Control knob rear wall............................................................................................................................................................................14
6. CLEANING AND MAINTENANCE 15
Basic information ...................................................................................................................................................................................15
Cleaning flue pipes ................................................................................................................................................................................15
Empty the ash drawer.............................................................................................................................................................................16
Cleaning the door glass ..........................................................................................................................................................................16
Cleaning the convection air openings.....................................................................................................................................................16
Combustion air - air intake ....................................................................................................................................................................16
Checking door seal .................................................................................................................................................................................16
Checking chimneay connection..............................................................................................................................................................16
7. ASSEMBLY / DISASSEMBLY 17
Changing to rear connected flue gas.......................................................................................................................................................17
8. PROBLEMS - POSSIBLE SOLUTIONS 18
Problem 1 ...............................................................................................................................................................................................18
Problem 2 ...............................................................................................................................................................................................18
Problem 3 ...............................................................................................................................................................................................18
9. GUARANTEE 19

|3
EN
2
1. PREFACE
Explanations to symbols
...important
note
...useful
tip 4
...allen key #4
(M5 winding) #10
...hex #10
(M6 winding) ...manually
Dimensions
H
B T
RO-T1
RO-H
RO-T2
RO-T3
F-H
F-S
R-H
RO-S
R-S
R-
F-
Dimensions Impera XL
height [mm] 1704 1834
width [mm] 520 570
corpus depth [mm] 451 451
Weight Impera XL
weight without stone [kg] 230 251
weight with stone [kg] 486 541
Flue pipe connection Impera XL
R - Ø flue pipe outlet [mm] 130 150
RO - H original angle pipe connection
height [cm] 180 189
RO - T1 original angle pipe total depth [cm] 47 48
RO - T2 original angle pipe distance to
rear wall [cm] 2 3
RO - T3 deapth from rear wall to middle of
flue pipe [cm] 14 14
RO - S original angle pipe side distance [cm] 26 29
R - H rear connection height [cm] 150 157
R - S rear connection side distance [cm] 26 29
Fresh air connection Impera XL
F - Ø diameter [mm] 125 125
F - H connection height [cm] 26 35
F - S side distance [cm] 18 18
Convection air connection Impera XL
K - Ø diameter [mm] - -
K - H connection height [cm] - -
K - S side distance [cm] - -
Amount of fuel
nominal load part load
Impera ~1,7 kg ~0,9 kg
Impera XL ~2,3 kg ~1,2 kg
*Practical values may vary depending on pellet quality.
Technical data
description measure Impera Impera XL
room heating capacity depending
on house coating [kW] 3 - 6 4 - 8
fuel consumption [m³] 70 - 160 90 - 210
electric supply [kg/h] bis ~1,7 bis ~2,3
average electrical input [%] 88,5 90,2
fuse [%] 9,4 11
efficiency [mg/mN
3] 435 431
CO2[mg/mN
3] 18 19
CO-emission on 13% O [g/s] 7,0 6,9
dust emission [°C] 173,5 163,1
chimney draft requirement [Pa] 12 12
The owner of small firing systems or the person authorised for the small
firing system is to keep the technical documentation and is to submit it to the
authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as local
regulations concerning the installation and operation of firing installations!
Packaging
Your first impression is important to us!!
The packaging of your new stove provides excellent protection against damage.
However damage to the stove and accessories may still occur during transport.
Note
Therefore please check your stove on receipt for damage and completeness!
Report any deficiencies to your dealer immediately! Pay particular attention
during unpacking that the stone panels remain intact. Scratches to the
material can easily occur. Stone panels are excluded from the warranty
The packaging of your new stove is environmentally neutral to a great extent
Tip
The wood used in the packaging has not been surface treated and may
therefore be burnt in your stove. The cardboard and film (PE) can be disposed
of via the municipal waste collection for recycling.

4
1
2
4
5
7
8
6
9
1 1
1 1
1 0
1 0
1 2
1 2
1 3
1 4
1 5
1 6
1 7
1 9
1 8
2 0
2 3
2 2
2 1
2 4
2 5
2 6
2 7
2 8
2 9
3 0
3 1
3 5
3 4
3 3
3 7
3 6
3 2
3
3 8
3 9
40
41
42
43
43
44
45
46
47
48
49
Spare part overview exploded diagram IMPERA

|5
EN
4
5 0
5 1
5 2
5 3
5 4
5 5
5 8
5 9
5 7
5 6
6 0
6 1
6 2
6 3
6 4
6 5
6 6
6 7
6 8
6 9
7 0
7 1
7 1
7 2
7 3
6 9
7 6
7 5
7 7
7 8
7 5
7 4
7 7
7 9
8 0
8 2
8 5
8 3
8 3
8 2
8 4
98
8 3
100
97
8 1
8 8
8 6
8 6
8 7
8 7
93
94
92
91
91
90
96
8 9
8 3
99
95
