Riley RS2 User manual

12

34
Declaration of conformity
Type of device:
This declaration of conformity is issued under the sole responsibility
of the manufacturer.
Object of the declaraton:
Electric scooter
RS2
RILEY SCOOTER RS2
Model NO:
Description:
The object of the declaration described above is in conformity with
the relevant Union harmonisation legislation:
2011/65/EU amended by 2015/863(EU)
2014/30/EU
2014/35/EU
2006/42/EC
2014/53/EU
RoHS directive
EMC Directive
Low Voltage Directive
Machinery Directive
RED DIRECTIVE
References to the relevant harmonize standards used or
references to other technical specification in relation to which
conformity is declared:
Name of manufacturer:
Importer/Distributor contact detail:
RILEY SCOOTERS LIMITED
Address: Kings Lodge, London Road, Sevenoaks, TN16 5AR,
United Kingdom
AUTHORISED SIGNATURE:
Hayden Riley
Founder & CEO
Date: 2022-10-28
www.rileyscooters.com
Riley Scooters Limited: Kings Lodge, London Road, Sevenoaks,
TN15 6AR, United Kingdom
BS EN 17128:2020
EN 17128:2020
EN 60335-1:2012
EN 60335-2-29:2004
EN IEC 55014-1:2021
EN IEC 55014-2:2021
EN 61558-1:2005
EN 61558-2-16:2009
EN 55014-1:2021
EN 55014-2:2015
EN 61000-3-2:2019+A1:2021
EN 61000-3-3:2013+A1:2019

56
15-16
17-19
17
18
19
Charging instructions
20
21
22
9. 24
23
8.
Riley Scooter APP
10-14
10
11
12
13
14
Folding instructions
Assembly instructions
7-8
7
7-9
The manufacturer recommends
riders be 14+ years old.
WARNING!

78

910
Accelerator/Throttle
Handle
Headlight
Folding button
Folding spanner
Anti-slip mat
Motor Stand
Disc brake
Tail lights
Number plate
Fender clip
Fender
Charging port
Battery clip
Detachable battery
Hook
LED Display
Brake lever

11 12
2. Fold clip in
firmly, ensuring it
clicks and button
is tight.
Note: If the
mechanism
becomes loose,
tighten the screw
accordingly.
brake lever to brake. Lightly
2.3 Assembly instructions
3. Attach headset to
the stem, then screw
in 2 screws each side
using the Allen key
provided.
1. Pull up the stem
towards the front
wheel.
Brake lever

13 14
2.4 Folding instructions
1. Push/slide the
button up.
2. Pull the clip firmly
away from the stem,
while pushing the
stem down.
3. Fold the stem
towards the rear
fender.
4. Align the hook
with the fender clip
on the rear fender
and press down till it
clicks.
1. Push Battery
clip in and hold.
2. Push the
battery up, away
from the bottom
of the stem.
1. Insert the battery
horizontally into the
pole, whilepushing
the battery clip in.
2. When in, let go
of the battery clip,
and push battery
down until firmly
secure.

15 16

17 18
The instructions show you how to charge and maintain the battery and
providesome safety notices and the technical specifications. Please
use the battery properly according to theseinstructions to prolong
battery life and performance.
4.1Battery parameters
Name Parameter
TypeLi-ionbattery
Charging timeApprox. 4-5 hours
Voltage 36V
Working temperature 0°C - 35°C
Charging Temperature 0°C - 35°C
Max Charging Voltage 42V
Storage Time (at -10°C – 40°C) 3 months (full charge)
Initial Volume 8.7AH
Max Charging Current 2A

19 20
Product
Unfolded size
Folded size
Height from baseplate to ground 115mm
Net weight 15.7kg
Tyre size 10 inch pneumatic air tyre
withinner tube
Tyre pressure 35 P.S.I (2.41 Bar)
Waterproof level IPX4
Basic Information
Battery Capacity36V/8.7AH
Motor power 350W
Mileage per charge 28 miles (45km)
Max speed 15.5 mph (25km/h)
Max loading 120kg
Climbing angle 15°
Driving modes 3 (beginner, eco, sport)
Input voltage 100-240Vac
Frequency 50-60Hz
Output voltage 42V
Output current 1.5A/2A
Store temperature -10°C-35°C
1131x450x1179mm
1131x450x475mm
Charging
port
Battery
connector
Charging
port
4.3 Charging instructions

21 22
Unable to start up Check to see if the battery is charged.
Does not charge 1. Check whether the plugboard has
electricity.
2. Check the charger to see whether the
AC plug is connected (whether the
light is on).
3. Check the plug of the charger and
the charging port of the e-scooter
have been inserted correctly.
WARNING!
WARNING!

23 24
1x Copy of Manufacturer's Limited Warranty
9. Riley Scooter APP
8. What’s included
Stay on the move with our app which connects directly to your scooter
through Bluetooth. Get directions, view key riding info, and track your
rides effortlessly.
Features:
• Cockpit showing key riding info
• Lock and trace your scooter
• Track your rides
• Shop our range of accessories
Note: When connecting
to your scooter ensure
your Bluetooth is enabled
on your mobile device and
the scooter is turned on.
Scan to download the App. Alternativelly, go to
the Google Play Store (Android) or the Apple
App Store (iOS) and search Riley Scooters to
download and install the App.
Be advised there is a minimum
Android/iOS/Bluetooth version required. See
user materials for additional details.

FCC Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio
or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
FCC Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction
