Rion DMI108 User manual

DMI108
DMI108-Digital Display Inclinometer
SPECIFICATIONS
Item No.：DMI108
Description：Digital Display Inclinometer
Production implementation standard reference
●Enterprise quality system standards: ISO9001: 2008 standard (certification number: 128101)
●Tilt sensor production standards: GB / T 191 SJ 20873-2003 inclinometer general specification of Level
●The Academy of metrology and quality inspection Calibrated in accordance to: JJF1119-2004
Electronic Level calibration Specification
●Software development reference standard: GJB 2786A-2009 military software development General
requirements
●Product environmental testing standards: GJB150
●Electromagnetic anti-interference test standards: GB / T 17626
●Version:Ver.09
●Date:2014.11.21

DMI108
DMI108-Digital Display Inclinometer
Description
DMI108 is a low cost level box of MEMS principle. The measuring range is 90 degree X
4=360 degree, and accuracy is 0.15 degree. The low consumption design ensure the long
time and stable working powered by one 9v battery. The absolute zero is calibrated for
every single item in factory and is stored in the internal storage, so even without battery,
the zero record would not miss. The built-in permanent magnet facilitate the
measurement.
Main feature
●accuracy：±0.15° ●switchover between relative and absolutive angle
●working temperature-0°～+40
●measuring range：90°x 4 ●power supply：9Vbattery ●IP54
Application:
●Building operations ●Vehicle maintenance ●Road grade
●Machinery installation ●Pipe installation ●Industry platform
Technical Data
测量范围 90°x 4 = 360°
Measuring
accuracy
±0.15°
Working
Temperature
0～+40
Power 9Vbattery
Working humidity 85°
Display resolution 0.05°
Dimension L57*W57*H30.5 (mm)
Weight 200g
Ordering information:
Item No. Order Description
DMI108 Standard Digital Display Inclinometer
Parameters DMI108 Unit

DMI108
DMI108-Digital Display Inclinometer
Product Dimension diagram
SIZE:L57*W57*H30.5mm
Measurement Direction

DMI108
DMI108-Digital Display Inclinometer
Product Function Introduction
ON/OFF:Press lightly ON/OFF button to turn on,,press it again to turn off
HOLD/TILT:Short press HOLD button the display will hold the readout data,long press
HOLD button for 2 seconds ,the display change to tilt%
ZERO: set relative to ZERO, gently press the ZERO key, reset do relative measurement;
Absolute measurement mode: after switch on the instrument in any plane, the display data
is the absolute Angle;
Relative measurement mode: boot after put the instrument on the datum, gently press the
ZERO key, set up relative to ZERO, then the inclinometer on the plane need to detect,
measured by the Angle is not only the relative Angle measurement.
Product maintenance
DMI108 powered by AAA battery, if do not use over long-term (three months),
please remove the batteries to avoid damage due to battery leakage on digital
goniometer.
2. If In close distance , the display has dimmed or can not be seen clearly indicates that
the battery
There is a battery cover at the back of the digital display angle instrument, please
follow the instructions to open the lid, then remove the old battery, can put a new battery,
Please note that
the front and back.
Warning:
1. This product has a high-precision sensors and information processing circuit, non-drop
impact or disassemble, or peril.
2. If turn on the power switch then no digital display, replace the batteries immediately.
3. Please do not press the two buttons at the same time, otherwise would undermine the
internal procedures of the product.
4. This product should be placed away from the children to a safe location.
※More information please visit Rion’s company website: www.rion-tech.net
