INSTRUCTION MANUAL
Vibration Meter
VM-63A
3-20-41 Higashimotomachi, Kokubunji, Tokyo 185-8533, Japan
www.64817.com

i
Organization of This Manual
This manual describes the features and operation of the Pocket
Size Vibration Meter VM-63A.
The manual contains the following sections.
Outline
Gives basic information on the unit.
Controls and Features
Briefly identifies and explains all parts of the unit.
Preparations
Describes how to insert the battery and prepare the unit
for measurement.
Display Functions
Explains information appearing on the digital display.
Measurement
Describes the steps for measurement.
Supplied Accessories
Explains how to use the instruction label.
Appendix
Contains a vibration conversion chart and information on
the vibration detector attachments.
Specifications
Lists the technical specifications of the unit.

ii
For Safety
In this manual, important safety instructions are specially
marked as shown below and next page. To prevent the
risk of death or injury to persons and damage to the unit
or peripheral equipment, make sure that all instructions
are fully understood and observed.
WARNING
Disregarding instructions printed
here incurs the risk of death or se-
vere injury to persons.
Disregarding instructions printed
here incurs the risk of injury to per-
sons and/or damage to peripheral
equipment.
CAUTION

iii
Denotes special information that is
helpful in utilizing the capabilities of
the unit but that is not directly related
to safety.
Note

iv
WARNING
When making measurements on exposed
rotating parts or power train parts of machinery,
proceed with utmost care to prevent accidents
due to getting caught in the machinery.

v
Precautions
zOperate the unit only as described in this manual.
zDo not drop the unit. Protect it from shocks and vibra-
tion.
zDo not store or use the unit in locations where the unit
may be subject to
- splashes of water or high levels of dust, or
- air with high salt or sulphur content, or other gases
or chemicals, or
- high temperature or humidity (above 50ºC, 90% RH),
or direct sunlight.
zRemove the battery if the unit is not to be used for an
extended period, to prevent possible damage due to
battery fluid leaks.
zDo not disassemble the unit or attempt internal alter-
ations.
zHave the unit and the accelerometer checked and ser-
viced about once every 18 to 24 months. (Sensitivity
calibration can be performed at the factory for a fee.)
zDo not tap the display with a pen or the like, to prevent
malfunction.
zWhen disconnecting cables, always hold the plug and
do not pull the cable.

vi
zIn case of malfunction, do not attempt any repairs. Note
the condition of the unit clearly and contact the sup-
plier.
zDispose of the battery in accordance with local laws
and regulations.
zThe supplied warranty card and User registration card
is Valid only in Japan.
The Product described in this manual is in conformity with
the following European standards;
EN61000-6-3:2001
EN61000-6-1:2001
Note: CE requirements are met provided that a core
filter is fitted to cable.

vii
Contents
Organization of This Manual .............................................. i
For Safety .......................................................................... ii
Precautions ........................................................................ v
Outline ............................................................................... 1
Controls and Features ........................................................ 2
Front View.................................................................... 2
Top View ...................................................................... 3
Rear View ..................................................................... 4
Bottom View ................................................................ 4
Preparations ....................................................................... 6
Inserting the Battery ..................................................... 6
Measurement Preparations ........................................... 7
Display Functions .............................................................. 9
Measurement ................................................................... 10
Supplied Accessories ....................................................... 12
Instruction Label ........................................................ 12
Appendix ......................................................................... 13
Vibration Conversion Chart ....................................... 13
Vibration Detector Attachments ................................. 14
Specifications................................................................... 17

viii

Outline
1
Outline
The VM-63A is a vibration meter designed for easy mea-
surement of vibrations in rotational machinery or the like.
Measurement is performed simply by holding the tip of
the unit against the measurement object and operating one
button. The unit can measure acceleration, velocity, and
displacement. For acceleration, two measurement ranges
(10 Hz to 1 kHz or 1 kHz to 15 kHz) can be selected.
The unit operates on a single 9-volt battery (6F22). There
is no power switch, because the auto power off function
shuts the unit off automatically.

Controls and Features
2
Controls and Features
Front View
Display
Shows the measurement value, measurement mode, vi-
bration frequency range, and battery replacement indica-
tion.
Vibration detector attachment
Press this section against the measurement object.
MEAS button
Press this button to perform measurement (see page 10).

Controls and Features
3
Top View
High range/low range selector
For acceleration measurement, set the vibration frequency
range to "Lo" (10 Hz to 1000 Hz) or "Hi" (1 kHz to
15 kHz).
Acceleration/velocity/displacement selector
Select the measurement mode with this switch.
H i g h r a n g e / l o w r a n g e s e l e c t o r
A c c e l e r a t i o n / v e l o c i t y /
d i s p l a c e m e n t s e l e c t o r
www.64817.com

Controls and Features
4
Rear View
Battery compartment
A single 9-volt battery (6F22) is inserted here.
Bottom View
Signal output jack
The AC output signal is supplied at this jack. The signal
output is 2-volt peak at full-scale point. It is also possible
to connect the optional earphone VP-37 here.
S i g n a l o u t p u t j a c k
www.64817.com

Controls and Features
5
CAUTION
In case of excessive vibration, the earphone
may produce a very high sound pressure
level that can be harmful to the ear. Use this
function with care.

Preparations
6
Preparations
Inserting the Battery
1. While pressing down the section marked PUSH, lift the
battery compartment lid up to open it.
2. Insert one 9-volt battery (6F22), taking care to observe
correct +/- polarity.
3. Close the battery compartment lid.
On a fresh 9-volt battery (6F22), the unit can operate
continuously for about 25 hours.
L i f t u p
P u s h h e r e
6 F 2 2

Preparations
7
Measurement Preparations
1. Make sure that a 9-volt battery (6F22) is inserted in the
battery compartment.
2. Press the MEAS button.
If the mark shown below ap-
pears on the display, the battery
must be replaced.
3. Use the acceleration/velocity/displacement selector to
set the measurement mode.
M E A S
M E A S b u t t o n

Preparations
8
When acceleration measurement (m/s2) has been se-
lected, the vibration frequency range can be set to "Lo"
(10 Hz to 1000 Hz) or "Hi" (1 kHz to 15 kHz) with the
high range/low range selector.

Display Functions
9
Display Functions
Measurement mode indicator
Shows which measurement mode is currently selected.
High range/low range indicator
When acceleration measurement (m/s2) is selected, this
indicator shows whether the vibration frequency is set to
"Lo" (10 Hz to 1000 Hz) or "Hi" (1 kHz to 15 kHz).
Replace battery mark
When this mark is shown, the remaining battery capacity
is very low. Replace the battery as soon as possible.

Measurement
10
Measurement
1. While keeping the MEAS button depressed, hold the
vibration detector against the measurement object. Use
a pressure of about 500 g to 1 kg.
If the MEAS button is pressed while power is off, the
unit will require about 10 seconds until measurement is
possible.
2. The measured vibration value is shown on the digital
display.
3. Release the MEAS button and read the measurement
value that is being held on the display.
4. When the MEAS button is pressed again, the currently
held value is canceled, and a new measurement can be
performed.
The unit turns itself off automatically about 1 minute
after the MEAS button is released.
HI
1kH z
LO
m / s
2
m m /s
m m
M E A S
