RIOTEC LS6000B series User manual

Laser Barcode Scanner
Model no.
LS6000B,LS6000Z
QUICK GUIDE

2
INTRODUCTION
LS6000B / LS6000Z laser barcode scanners series have incorporated the latest
wireless blue-tooth / Zig-bee technology. The technology provides customer with
the freedom of mobility, with long communication range from the charging
cradle.
The bar code scanner requires establishing communications with its charging
cradle (built-in dongle). After communications have been established between
the scanner and charging cradle, futures bar code scans will be transmitted from
the scanner to the cradle and from the cradle to the host.
For power supply, the charging cradle of LS6000B / LS6000Z also works as a
battery charger for the scanner. Users can plug in 5V DC power adaptor for
power charge of the scanner.
Package of LS6000B / LS6000Z series should contain:
1. LS6000B or LS6000Z Laser Barcode Scanner
(Rechargeable Li-Ion battery pack inside)
2. Charging Cradle with USB cable & DC plug
3. Power Adaptor (5V/1A)
4. User’s Manual
RED BLUE ORANGE
ON Not read Good read
Continual ON
Sleeping mold (If scanner
not in use, will automatic
switch to sleeping mode
after 30 min.)
Low power
Blinking Wireless connection not
linked Charging
Charging Cradle
Buzzer
Exit Window
Trigger
Handle
Charging
3 indicators (LED)
USB dongle
USB Zig-bee dongle

3
INSTALLATION
Insert the plug on the free end of the Communications Cable into the
appropriate connector on the host as below described:
USB Connection (RS232 data format)
1. Install the software “PL-2303 Driver Installer.exe” to the host system
for LS6000B / LS6000Z series.
2. Connect scanner cradle to the USB port on the host system.
3. Go to My Computer ÆOne click right button of mouse ÆAdministrate
ÆDevice Administrator ÆConnect Port (COM and LPT).
4. Choose Prolific USB-to-Serial Com Port, and see identify COM number,
ex. COM 5.
5. Go to START ÆPrograms ÆAccessories ÆCommunications Æ
Hyper Terminal.
Detail set up on the Hyper Terminal, please see at the Figure 1 to Figure 3.
Connec
t
with hos
t

4
Figure 1
Figure 2
Figure 3
N
o need to ke
y
-in
Step 1: key-in the identify
COM number
Step 1: key-in a file name
Step 2: select the first
Step 3: press OK
Step 2: press OK
Row 1: key-in “9600”
Row 2: key-in “8”
Row 3: key-in “none”
Row 4: key-in “1”
Row 5: key-in “none”
Press OK
Step 1: key-in the identify
COM number, ex.
COM 5
Step 2: press OK

5
6. Start to aim the scanner at a bar code, you may see data shown on the hyper
terminal.
Reset Configuration to Defaults
If you are unsure of the scanner configuration or have scanned the incorrect codes,
please scan the “Reset Configuration to Defaults” barcode. This will reset the
scanner to its factory settings.
LS 6000B or LS6000Z
Tip
Do not hold the scanner directly over a barcode at 90˚. Scanning light bounces
directly back into the scanner from the barcode label is known as specular reflection
which will create a "dead zone" where decoding is difficult. Practice a few times to
find what range of angles works best.
Maintenance
Cleaning the scan window is the only maintenance required. A dirty window may
affect scanning accuracy.
Wipe the scanner window gently with a lens tissue or other material suitable for
cleaning optical material.
Do not spray water or other cleaning liquids directly onto the window.

6
