Ritron RRX-450 Installation and operating instructions

Publication 14540001 Rev. D 00-01
Ph:317-846-1201;1-800-USA-1-USA(1-800-872-1872)• Fax:[phone]
WEB: www.ritron.com • E-mail: [email protected]
P.O.Box1998,Carmel,IN46082-1998 • 505West CarmelDrive,Carmel,IN46032 • USA
NOTES:
1. A1KΩresistor installed in RRX J 401 (Pin 4 to Pin 7), turns OFF the RRX internal CTCSS/ QC encoder when
RRX-CGI, pin 12 is connected as shown. DO NOT set R 423 to 0 (zero). (Thisdoes not disable the DQC encoder.)
2. If PJ 404 is left in "A" position, either unplugging the RRX-GCI cable, OR lifting the ORG/BLK wire from GND, will
automatically revert an RRX Repeater to normal (QC) Repeater mode, as programmed. When it is re-connected,
the QC encoder will again be automatically disabled (i.e.: no RESET required).
3. Leave RRX potentiometers at factory settings. Verify/ set R 426 (VOICE DEV pot), reduced to 4.0/ 1.7kHz voice
deviation limiting to allow for 1.0/0.8 kHz of LTRdatadeviation.
RRX REPEATER JUMPER SETTINGS (Same as factory settings)
PJ401
PJ402
PJ403
PJ404
PJ405,PJ406 Not Installed
PJ407
1 1
2
3 3
4
5
6 6
7 7
8
9
10 10
11 11
12 12
13 13
14 14
15 15
RED
N/ C
BLK
N/ C
N/ C
BLU/ BLK
WHT
N/ C
N/ C
N/ C
ORG
ORG/ BLK
BLU
N/ C
GRN
+12 VDC IN (3 AMP PICO FUSE IN RRX)
GND
PTT GND
PTT
EXT "CARRIER DETECT" INPUT (OPTIONAL) *
TX AUDIO OUT
REPEAT DISABLE (GND) [NOTE 1, BELOW.]
DATA OUT
CABLE SHIELD (GND)
RX DISCRIMINATOR AUDIO INPUT
RRX-CGI
CABLE
COLORS
ZETRON INTERNAL JUMPERS
J1 P1
A
B
"HI"
A
A
Set for "INT SQ" *
A = N.O.
TX Polarity = "B - INV"
RX Polarity = "A - TRU"
Not Installed
ZETRON
CONNECTOR
JP1
JP2
JP3
JP4
JP6
JP7
JP8
JP10
JP11
JP5, JP9
ZETRON MODEL 42 -- LEFT SIDE
Follow ZETRON instructions to set all audio levels.
DO NOT ground the Shield/ Drain Wire at the Controller end;
leave it grounded inside RRX only.
1
1
BEEP GENERATOR NORMAL
INTERNAL AUDIO FILTER SELECT (HIGH PASS)
AUDIO PATH TO TONE DECODER
REPEAT DISABLE NOT SELECTED HERE (See Note 2)
"CD" CARRIER DETECT (LO) TO BLU/ WHT WIRE
SHIELD
BLU/ WHT
A
B
A
A
B
APPLICATION NOTE
RRX-450/-452/-460 w/ RRX-ACC and RRX-GCI Cables
Hookup to ZETRON Model 42/ 49 LTR Controllers
NOTE:
Preset all pots to
12 o'clock, a close
approximation of
final setting.
