RIUKOE ML-B0054 User manual

5 Heads Rogue Moving Head Bar Light
ML-B0054
User Manual
Please read this user manual before using this product.

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
INDEX
STATEMENT 3
ACCESSORIES 3
SAFETY INSTRUCTION 3
GENERAL GUIDELINES 4
INSTALLATION 6
TECHNICAL SPECIFICATION 8
CONTROL SYSTEM 9
CONTROL PANEL 9
DISPLAY 9
HOW TO SET THE UNIT 10
CHANNEL DESCRIPTION: 11
CLEANING AND MAINTENANCE 19

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
STATEMENT
The product has well capability and intact packing when leave
factory. All of the user should comply with warning item and manual, any
misuse cause of the damages are not included in our guarantee, and
also cannot be responsible for any malfunction & problem owing to
ignore the manual.
ACCESSORIES
These items are packed together with the product:
Name
Quantity
Unit
Remark
USER MANUAL
1
PCS
DMX CABLE
1
PCS
OMEGA
2
PCS
CLAMP
2
PCS
SATETY ROPE
1
PCS
SAFETY INSTRUCTION
Please keep this User Guide forfuture consultation. If you sell the unit toanother
user, be sure that they also receive this instruction booklet.

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
GENERAL GUIDELINES
NEVER OPEN THIS FIXTURE WHILE IN USE!
During the initial operation of this fixture, a light smoke or smell may emit
from the interior of the fixture. This is a normal process and is caused by
excess paint in the interior of the casing burning off from the heat
associated with the lamp and will decrease gradually over time.
This fixture is a professional lighting effect designed for INDOOR / DRY
LOCATIONS ONLY on stage, in nightclubs, theatres, etc.

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
Please make sure there are NO FLAMMABLE MATERIALS close to the
fixture while operating, to prevent any fire hazard.
The fixture must be installed in a location with adequate ventilation, at least
1.5 feet (.5m) from adjacent surfaces. Be sure no air ventilation slots are
blocked.
DO NOT attempt installation and/or operation without knowledge how to
do so.
DO NOT permit operation by persons who are not qualified to operate this
type of fixture. Most damages are the result of operations by
nonprofessionals. Consistent operational breaks may ensure the fixture will
function properly for many years to come.
DO NOT shake fixture, avoid brute force when installing and/or operating
fixture.
Always install the fixture with an appropriate safety cable. When installing
the fixture in a suspended environment, always use mounting hardware
that is no less than M10 x 25 mm, also be sure the hardware is insert in the
pre-arranged screw holes in the bracket of the fixture.
Use the original packaging and materials to transport the fixture in for
service.
DO NOT TOUCH the housing bare-hand during its operation. Turn OFF
the power and allow approximately 15 minutes for the fixture to cool down
before replacing or serving.

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
INSTALLATION
C A U T I O N S
For added protection, mount the fixture in areas outside walking paths,
seating areas, or in areas were unauthorized personnel might reach the
fixture.
Ambient operating temperature range for this fixture is 5° to 113°F. (-15°
to 45°C) Do not use the fixture under or above this temperature.
Before mounting the fixture to any surface, make sure the installation area
can hold a minimum point load of 10 times the weight of the fixture.
Fixture installation must always be secured with a secondary safety
attachment, such as an appropriate safety cable.
Never stand directly below the device when mounting, removing or
servicing.
The unit should be mounted via its screw holes on the bracket. Always ensure
that the unit is firmly fixed to avoid vibration and slipping while operating. And
make sure that the structure to which you are attaching the unit is secure and is
able to support a weight of 10 times of the unit’s weight. Also always use a

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
safety cable that can hold 12 times of the weight of the unit when installing the
fixture.
The equipment must be fixed by professionals. And it must be fixed at a place
where is out of the touch of people.
Clamp mounting
The moving head provides a unique mounting bracket assembly that
integrates the bottom of the base, the included ‘Omega Bracket’ and the
Safety Cable rigging point in one unit (see the illustration below).When
mounting this fixture to truss be sure to sere to secure an appropriately rated
clamp to the included Omega Bracket using a M10 screw fitted through the
center hole of the ‘omega bracket’. As an added safety measure be sure to
attached at least one properly rated Safety Cable to the fixture using one of
the safety cable rigging point integrated in the base assembly.
DMX-512 control connection:
Connect the provided XLR cable to the female 3-pin XLR output of your controller and the
other side to the male 3-pin XLR input of the moving head. You can chain multiple Moving
head together through serial linking. The cable needed should be two core, screened cable
with XLR input and output connectors. Please refer to the diagram below.

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
DMX-512 connection with DMX terminator:
For installations where the DMX cable has to run a long distance or is in an electrically noisy
environment, such as in a discotheque, it is recommended to use a DMX terminator. This
helps in preventing corruption of the digital control signal by electrical noise. The DMX
terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which
is then plugged into the output XLR socket of the last fixture in the chain. Please see
illustrations below.
TECHNICAL SPECIFICATION
◇ Control: Sound active, Auto, Master/slave and DMX 512 modes
◇DMX Channels: 6CH/18CH/29CH/31CH
◇Electronic dimming:0-100%
◆Voltage: 100V~240V, 50/60Hz
◆Fuse: T6.3A
◆Power consumption: 150W
◆Light source: 5 x 8W RGBW 4IN1 LED
◆Dimension: 212*335*130mm
◆Weight: 3.9kg
◆Pan/Tilt: 540°/360° Infinite
◆Power sockets: IEC IN/OUT
Please Note: Specifications and improvements in the design of this unit and this manual are
subject to change without any prior written notice.

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
CONTROL SYSTEM
Th e D M X512 is w id ely used in intellig ent ligh ti ng con tr ol, with a DMX 512
controller. Connect several lights together dmx in and dmx out,
3 pin XLR connectors : Pin 1: G ND , Pin 2: Nega tive s ign a l (-), Pin 3: P o s itive s i gna l
(+)
CONTROL PANEL
Display
Shows the various menus and selected functions

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
Button
Mains input
Connection to the power supply.
DMX input/output
For DMX 512 linking. Use a 3-pin XLR cables to link to the controller or to other
units.
HOW TO SET THE UNIT
Main Function
To select any of the given functions, press the MENU button up to where the
required function is showing on the display. Select the function by pressing the
ENTER button and the display will blink. Use the DOWN and UP buttons to change
the mode. Once the required mode has been selected, press the ENTER button to
confirm.
The main functions are as below:
DMX address
DMX Address (001-512)
Channel mode
6/18/29/31 CH
Slave mode
Master mode
Slave 1

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
Slave 2
Sound choose
Sh0—sh12
Auto model
Auto 0—16 (speed 0—9)
Show model
Show 0-16
Sound state
On/off
Sound sense
0-100 from slow to fast
Back lights
On/off
Pan Inverse
No/Yes
Tilt Inverse
No/Yes
Test
testing
Hour
Fixture work hours 0---9999
Software version
Ver
Reset
CHANNEL DESCRIPTION:
6 Channel Mode
Channel
DMX Value
Function
1
Dimmer
000 - 255
All dimmer
2
Strobe
000 –7
open
8 –255
From slow to fast 0—100%
3
Tilt
Movement
000-007
No function
008-022
Movement 01
023-037
Movement 02
038-052
Movement 03
053-067
Movement 04
068-082
Movement 05

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
083-097
Movement 06
098-112
Movement 07
113-127
Movement 08
128-142
Movement 09
143-157
Movement 10
158-172
Movement 11
173-187
Movement 12
188-202
Movement 13
203-217
Movement 14
218-232
Movement 15
233-247
Movement 16
248-255
Sound active
4
Movement
Speed
000-255
Movement Speed
5
Color Chase
000-015
No function
016-255
Color Chase
6
Color Chase
000-255
Chase Speed slow to fast
18 Channel Mode
Channel
DMX Value
Function
1
pan
000 - 255
0°~ 540°
2
Pan speed
000 - 255
Speed fast to slow
3
Pan Rotate
000–005
stop
006-126
Movement forward fast to slow
127-128
stop
129-249
Movement forward slow to fast
250-255
stop
4
Tilt1
000-255
Tilt1 0°~ 360°
5
Tilt1 Rotate
000-005
Stop

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
6
Color1
000-255
7
Tilt2
000-255
Tilt2 0°~ 360°
8
Tilt2 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
stop
129-249
Movement forward fast to slow
250-255
stop
9
Color2
000-255
10
Tilt3
000-255
Tilt3 0°~ 360°
11
Tilt3 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
12
Color3
000-255
13
Tilt4
000-255
Tilt4 0°~ 360°
14
Tilt4 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
15
Color4
000-025
16
Tilt5
000-255
Tilt5 0°~ 360
17
Tilt5 Rotate
000-005
Stop
006-126
Movement forward fast to slow

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
18
Color5
000-255
29 Channel Mode
Channel
DMX Value
Function
1
Dimmer
000 - 255
dimmer 0 ~ 100%
2
strobe
000 –007
open
008–255
From slow to fast 0—100%
3
Tilt Movement
000-007
No function
008-022
Movement 01
023-037
Movement 02
038-052
Movement 03
053-067
Movement 04
068-082
Movement 05
083-097
Movement 06
098-112
Movement 07
113-127
Movement 08
128-142
Movement 09
143-157
Movement 10
158-172
Movement 11
173-187
Movement 12
188-202
Movement 13
203-217
Movement 14
218-232
Movement 15
233-247
Movement 16
248-255
Sound active
4
Movement
000-255
Movement Speed

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
Speed
5
Color Chase
000-015
No function
016-255
Color Chase
6
Speed
000-255
Chase Speed slow to fast
7
pan
000 - 255
0°~ 540°
8
Pan speed
000- 255
From Fast to slow
9
Pan Rotate
000–005
stop
006-126
Movement forward fast to slow
127-128
stop
129-249
Movement forward slow to fast
250-255
stop
10
Tilt1
000-255
Tilt1 0°~ 360°
11
Tilt1 speed
000-255
Speed fast to slow
12
Tilt1 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
13
Color1
000-255
14
Tilt2
000-255
Tilt2 0°~ 360°
15
Tilt2 speed
000-255
Speed fast to slow
16
Tilt2 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
17
Color2
000-255
18
Tilt3
000-255
Tilt3 0°~ 360°
19
Tilt3 speed
000-255
Speed fast to slow

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
20
Tilt3
Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
21
Color3
000-255
22
Tilt4
000-255
Tilt4 0°~ 360°
23
Tilt4 speed
000-255
Speed fast to slow
24
Tilt4 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
25
Color4
000-025
26
Tilt5
000-255
Tilt5 0°~ 360
27
Tilt5 speed
000-255
Speed fast to slow
28
Tilt5 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
29
Color5
000-255
31 Channel Mode
Channel
DMX Value
Function
1
Dimmer
000 - 255
dimmer 0 ~ 100%
2
Strobe
000 –007
open
008–255
From slow to fast 0—100%
3
pan
000 - 255
0°~ 540°

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
4
Pan fine
000 - 255
Pan fine
5
Pan speed
000- 255
From Fast to slow
6
Pan Rotate
000–005
stop
006-126
Movement forward fast to slow
127-128
stop
129-249
Movement forward slow to fast
250-255
stop
7
Tilt1
000-255
Tilt1 0°~ 360°
8
Tilt1 Fine
000-255
Tilt1 Fine
9
Tilt1 speed
000-255
Speed fast to slow
10
Tilt1 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
11
Color1
000-255
12
Tilt2
000-255
Tilt2 0°~ 360°
13
Tilt2 Fine
000-255
Tilt2 Fine
14
Tilt2 speed
000-255
Speed fast to slow
15
Tilt2 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
16
Color2
000-255
17
Tilt3
000-255
Tilt3 0°~ 360°
18
Tilt3 Fine
000-255
Tilt3 Fine
19
Tilt3 speed
000-255
Speed fast to slow
20
Tilt3 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
129-249
Movement forward fast to slow
250-255
stop
21
Color3
000-255
22
Tilt4
000-255
Tilt4 0°~ 360°
23
Tilt4 Fine
000-255
Tilt4 Fine
24
Tilt4 speed
000-255
Speed fast to slow
25
Tilt4 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
26
Color4
000-025
27
Tilt5
000-255
Tilt5 0°~ 360
28
Tilt5 Fine
000-255
Tilt5 Fine
29
Tilt5 speed
000-255
Speed fast to slow
30
Tilt5 Rotate
000-005
Stop
006-126
Movement forward fast to slow
127-128
Stop
129-249
Movement forward fast to slow
250-255
stop
31
Color5
000-255

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
CLEANING AND MAINTENANCE
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e
s o m e s ugg es tion s fo r eas y tr ou b leshooting :
CLEANING
Frequent cleaning is recommended to insure proper function, optimized light
output, and an extended life. The frequency of cleaning depends on the
environment in which the fixture operates: damp, smoky or particularly dirty
environments can cause greater accumulation of dirt on the fixture’s optics.
•Clean the external lens surface at least every 20 days with a soft cloth
to avoid dirt/debris accumulation.
•Never use alcohol, solvents, or ammonia based cleaners.
MAINTENANCE
Regular inspections are recommended to insure proper function and extended
life. There are no user serviceable parts inside this fixture, please refer all
other service issues to an authorized service technician. Should you need any
spare parts, please order genuine parts from your local dealer.
Please refer to the following points during routine inspections:

www.riukoe.com ML-B0054 5 Heads Rogue Moving Head Bar User Manual
•A detailed electric check by an approved electrical engineer every
three months, to make sure the circuit contacts are in good condition
and prevent overheating.
•Be sure all screws and fasteners are securely tightened at all times.
Lose screws may fall out during normal operation resulting in damage
or injury as larger parts could fall.
•Check for any deformations on the housing, color lenses, rigging
hardware and rigging points (ceiling, suspension, trussing).
Deformations in the housing could allow for dust to enter into the
fixture. Damaged rigging points or unsecured rigging could cause the
fixture to fall and seriously injure a person(s).
•Electric power supply cables must not show any damage, material
fatigue or sediments. Never remove the ground prong from the power
cable.
