RKI Instruments SDM-2012 User manual

www.rkiinstruments.com
SDM-2012 Docking Station
Standalone Configuration
Operator’s Manual
Part Number: 71-0254RK
Revision: A
Released: 2/27/15

Warranty
Warranty
RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from
defects in materials and workmanship, and performance for a period of one year from
date of shipment from RKI Instruments, Inc. Any parts found defective within that
period will be repaired or replaced, at our option, free of charge. This warranty does
not apply to those items which by their nature are subject to deterioration or
consumption in normal service, and which must be cleaned, repaired, or replaced on
a routine basis. Examples of such items are:
Warranty is voided by abuse including mechanical damage, alteration, rough
handling, or repairs procedures not in accordance with the instruction manual. This
warranty indicates the full extent of our liability, and we are not responsible for
removal or replacement costs, local repair costs, transportation costs, or contingent
expenses incurred without our prior approval.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER
WARRANTIES AND REPRESENTATIONS, EXPRESSED OR IMPLIED, AND
ALL OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF RKI
INSTRUMENTS, INC. INCLUDING BUT NOT LIMITED TO THE WARRANTY
OF MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE. IN
NO EVENT SHALL RKI INSTRUMENTS, INC. BE LIABLE FOR INDIRECT,
INCIDENTAL, OR CONSEQUENTIAL LOSS OR DAMAGE OF ANY KIND
CONNECTED WITH THE USE OF ITS PRODUCTS OR FAILURE OF ITS
PRODUCTS TO FUNCTION OR OPERATE PROPERLY.
This warranty covers instruments and parts sold to users only by authorized
distributors, dealers, and representatives as appointed by RKI Instruments, Inc.
We do not assume indemnification for any accident or damage caused by the
operation of this gas monitor and our warranty is limited to replacement of parts or our
complete goods.
Absorbent cartridges Batteries
Pump diaphragms and valves Filter elements
Fuses

Table of Contents
Table of Contents
Chapter 1: Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
About the SDM-2012. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cautions & Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2: Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
AC Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Single-Port AC Adapter.. . . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . .. . . . . . . .. . . . . . .. 5
3-Port AC Adapter. . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . .. . . . . . .. . . . . . . .. . . .. . . . 5
USB Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Air Filter and Sample Tubing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Instrument Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Power Jack .. . . . . . .. . . . . . .. . . .. . . . . . . .. . . .. . . . . . .. . . . .. . . . . . .. . . . . . .. . . 10
Sample Fittings. . . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . .. . . . . . .. . . . . . . .. . . .. . . 10
PC Connection . . . . . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . . . . .. . . . .. . . . . . . 10
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 3: Preparing to Use the SDM-2012. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Hardware Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the Operational Parameters in Edit Mode. . . . . . . . . . . . . . . . . . . . . . . . 16
Bump Test & Calibration Parameters . . . . . . . . .. . . . . . .. . . . .. . . . . . .. . . . . . .. . . . . 16
Turningon theSDM-2012 with anInstrument. . . . . . . .. . . . . . .. . . .. . . . . . . .. . . .. . . 18
Setting theBump Test Parameters. . . . . . . . .. . . .. . . . . . .. . . . . . .. . . . .. . . . . . .. . . 21
Setting the CalibrationParameters. . . . . . . . .. . . . . . .. . . .. . . . . . .. . . . .. . . . . . .. . . 23

Table of Contents
Setting the Gas Inlet for H2S (GX-2012 Only) . . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . 26
Updating the Tested Sensors Parameter . . . .. . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . 28
Connecting Calibration Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Installing the Single Module Data Viewer Software. . . . . . . . . . . . . . . . . . . . . . . 34
Chapter 4: Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Bump Testing a GX-2012 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Calibrating a GX-2012. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Bump Testing a Gas Tracer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Calibrating a Gas Tracer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Charging an Instrument in a Docking Station . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Recharging a Battery Pack After Performing a Bump Test
or Calibration . . . . . .. . . .. . . . . . .. . . . .. . . . . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . 90
Recharging aBatteryPackWithoutPerforming Any Operations . . . . . . .. . . . .. . . . . . . 91
Battery Pack Too Drained for Standalone Operation . . . . . . . . .. . . . . . .. . . . .. . . . . . . 91
Calibration and Bump Test Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Available Memory in theSDM-2012 . . .. . . . . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . . . 92
Copying Calibration and Bump Test Records. . . . .. . . . . . .. . . . . . .. . . . .. . . . . . .. . . 92
Clearing theSDM-2012’s Memory . . . . . . . . . . .. . . . .. . . . . . .. . . .. . . . . . . .. . . . . . . 94
Bump Test andCalibration Record Files . . . . . .. . . . .. . . . . . .. . . .. . . . . . . .. . . . . . . 94
Bump Testing or Calibrating and Saving Files to a Flash Drive
Multiple Times in OneDay . . . . . . . . . .. . . . . . .. . . . .. . . . . . .. . . . . . .. . . . .. . . . . . . 94
Chapter 5: Single Module Data Viewer Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Launching the Single Module Data Viewer Program . . . . . . . . . . . . . . . . . . . . . 95
Data Viewing Window. . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . . . 96
Using the Single Module Data Viewer Program . . . . . . . . . . . . . . . . . . . . . . . . . 96
Importing Files Into the Database. .. . . . . . . .. . . .. . . . . . .. . . . . . .. . . . .. . . . . . .. . . 97
Organizing the Data . . . . . . . .. . . .. . . . . . . .. . . . . . .. . . .. . . . . . .. . . . .. . . . . . .. . . 98
Viewing the Data. . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . .. . . . . . .. . . . . . . .. . . .. . . 99

Table of Contents
Deleting Data . . . . . . . .. . . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . .. . . . . . . .. . . . . . 103
Changingthe Password . . . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . . . . .. . . . .. . . . . . 104
Exiting the Program . . . . . . . . . .. . . . .. . . . . . .. . . . .. . . . . . .. . . .. . . . . . . .. . . .. . 105
Spare Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
CAUTION: Read and understand this manual before using the SDM-2012. Also
read and understand the GX-2012 Operator’s Manual and/or the Gas
Tracer Operator’s Manual.

1 • Overview
Chapter 1: Introduction
Overview
This chapter briefly describes the SDM-2012 Docking Station and the Single Module
Data Viewer Program. This chapter also describes the SDM-2012 Docking Station
Standalone Operation Operator’s Manual (this document). Table 1 at the end of this
chapter lists the SDM-2012’s specifications.
About the SDM-2012
The SDM-2012 Docking Station is an advanced, reliable system that provides
charging, calibration, bump testing, and calibration and bump test records for both the
GX-2012 and Gas Tracer portable gas monitors. It is designed to save the calibration
and bump test records to a USB flash drive (standalone functionality) or to be
connected directly to a computer (PC controlled functionality). If calibration and bump
test records are stored to a USB flash drive while operating in the standalone
configuration, the Single Module Data Viewer Program can then be used with a
Windows-based personal computer to retrieve calibration and bump test data files
from the USB flash drive or from the computer’s hard drive if the files have been
transferred to the hard drive from the flash drive. If you are using the PC Controller
Program while operating in the PC controlled configuration, you may retrieve
instrument data, bump test, and calibrate up to 10 instruments at once. Instrument
information and data for each instrument can be viewed directly using the PC
Controller Program and can be printed from the PC Controller Program. For
instructions to use the SDM-2012 with the PC Controller Program, see the SDM-2012
Docking Station PC Controlled Configuration Operator’s Manual.
The purpose of this manual is to explain how to set up and use the SDM-2012 in
Standalone configuration. It also explains how to use the Single Module Data Viewer
Program. You will learn how to:
• install and launch the Single Module Data Viewer
• prepare the SDM-2012 for use
• perform a bump test
• perform a calibration
• save calibration and bump test records to a USB flash drive
• view, print, and export calibration and bump test records
• use the SDM-2012 to charge an instrument

System Requirements • 2
CAUTION: The GX-2012 and Gas Tracer detect oxygen deficiency and elevated
levels of oxygen, combustible gases, carbon monoxide, and hydrogen
sulfide (GX-2012 only), all of which can be dangerous or life
threatening. When using the GX-2012 or Gas Tracer, you must follow
the instructions and warnings in the GX-2012 Operator’s Manual and/
or the Gas Tracer Operator’s Manual to assure proper and safe
operation of the instrument and to minimize the risk of personal injury.
CAUTION: The operator of this instrument is advised that if the equipment is used
in a manner not specified in this manual, the protection provided by the
equipment may be impaired.
System Requirements
To use the Single Module Data Viewer Software, your personal computer must meet
the following requirements:
•Operating Systems: Windows®XP, Windows®Vista, Windows® 7.
•Processor: IBM®compatible PC running Pentium®2 processor or equivalent
minimum
•Memory: 32 MB RAM minimum
•Hard Disk Space: 32 MB minimum
• CD-ROM Drive
• Available USB port

3 • Specifications
Specifications
Table 1: SDM-2012 Specifications
Input Power 12 VDC
NOTE: AC Adapter with 100 - 240 VAC, 50/60 Hz,
0.6A input and 12 VDC, 1.2A output provided as
standard.
Environmental Conditions • For Indoor Use Only
• -10° C to 40° C, below 80% Relative Humidity, Non-
Condensing
Applicable Instruments GX-2012 and Gas Tracer
Memory Capacity 64 KB
Maximum Record Size 256 bytes
Maximum Number of
Records Saved 200
Number of Calibration Gas
Cylinders Up to two calibration gas cylinders per bump test or calibration at a time
Standard Accessories • AC Adapter
• USB Flash Drive
• Single Module Data Viewer Software
• SDM Docking Station PC Controller Software
• Inlet Air Filter
• Instruction Manual
• 10 Foot Long Exhaust Tube
• Two 3 Foot Long Tubes for GAS 1 and GAS 2
Fittings
• 3 T-Fittings for PC Controlled Configuration
• USB Cable, Type A to Type B

About this Manual • 4
About this Manual
The SDM-2012 Docking Station Standalone Configuration Operator’s Manual uses
the following conventions for notes, cautions, and warnings.
NOTE: Describes additional or critical information.
CAUTION: Describes potential damage to equipment.
WARNING: Describes potential danger that can result in injury or death.
Cautions & Safety Information
• Use only polyurethane sample tubing with the SDM-2012. Consult RKI
Instruments, Inc. for other materials.
• Do not subject the SDM-2012 to infrared or intense light. This may cause
communication errors.
• Do not expose the SDM-2012 to water.
• Do not subject the SDM-2012 to any hard impact.

5 • Overview
Chapter 2: Description
Overview
This section describes the SDM-2012 docking station. It is designed to be used on a
table top and consists of the AC adaptor, Type A to Type B USB cable, air filter, check
valve, 3 plastic T-fittings, sample tubing, instrument panel, back panel, control panel,
status LEDs, and 2 USB ports.
AC Adapter
Single-Port AC Adapter
The single-port AC adapter is a wall plug style adapter with a 5 foot cable. The end of
the cable has a plug that connects to the power jack on the SDM-2012’s back panel.
The AC adapter is rated 100 - 240 VAC input, 12 VDC 1.2 A output.
3-Port AC Adapter
The 3-port AC adapter is a wall plug style adapter with three 5-foot cables. The end of
each cable has a plug that connects to the power jack on the SDM-2012’s back
panel. The AC adapter is rated 100 - 240 VAC input, 12 VDC 2.0 A output.
To Power Jack
on SDM-2012
Back Panel
Figure 1: Single-Port AC Adapter
To Power Jack
on SDM-2012
Back Panels
Figure 2: 3-Port AC Adapter

USB Cable • 6
USB Cable
A Type A to Type B USB cable is provided with the docking station. It is only for use
with the PC Controlled configuration. It is not used in the Standalone configuration.
Figure 3: USB Cable
Air Filter and Sample Tubing
A cylindrical particle filter with a short length of tubing is supplied with the SDM-2012
for installation to the AIR fitting on the back panel. The filter keeps particulate
contamination out of the docking station.
Two types of sample tubes are included with the docking station. Two 3 foot lengths
of 3/16 inch ID polyurethane tubing are provided to connect the regulator on a
calibration cylinder to the GAS 1 and GAS 2 fittings on the back panel. In addition, a
10 foot length of 5/16 inch ID polyurethane tubing is provided for connection to the
exhaust fitting on the back panel to allow routing of the exhaust to a location such as
an open window where the exhaust can disperse.
WARNING: Do not use an exhaust tube that is longer than 10 feet. The increased flow
restriction caused by a longer tube may affect gas response and cause
inaccurate calibration and bump test results.
Exhaust Tubing, 10 feet
Calibration Gas Sample Tubing, 3 feet,
2 Tubes Included
Particle Filter for Air Inlet
Figure 4: Air Filter & Sample Tubing

7 • Air Filter and Sample Tubing
A check valve is included with the SDM-2012 but is not needed for the Standalone
configuration. It is used for the PC Controlled configuration.
Three T-fittings are included with the SDM-2012. The larger fitting is for the exhaust
tubing. The smaller fittings are for GAS 1 and GAS 2 tubing. None of the T-fittings are
needed for the Standalone configuration. They are used in the PC Controlled
configuration.
Figure 5: Check Valve
For Exhaust
Tubing
For GAS
Tubing
Figure 6: T-Fittings

Instrument Panel • 8
Instrument Panel
The instrument panel is on the top of the SDM-2012 and includes the instrument
cradle, the IR port, the charging contacts, the exhaust line connection fitting, and the
gas out to instrument line. The instrument cradle consists of two recessed areas and
is designed to accept the instrument. The recess at the front of the instrument panel
is for instruments that have a Li-ion battery pack installed. Charging contacts are
located at the back of this recess. The recess behind the Li-ion battery pack cradle is
for instruments that have an alkaline battery pack installed. A plastic flap covers the
recess that is not in use. Insert the instrument into the appropriate instrument cradle
recess when you perform a bump test, calibrate, or charge an instrument. An infrared
(IR) port in the front recess lines up with the instrument’s IR port when it is inserted in
either recess and is used to communicate with the instrument. The exhaust line
connection fitting is in the upper left corner of the instrument panel. The exhaust line
is not factory installed and must be installed by the user. An exhaust line storage
fitting is located along the right side of the instrument panel and accepts the fitting at
the end of the exhaust line for storage. The gas out to instrument line is coiled and
stored in a recess in the upper middle portion of the instrument panel.
Alkaline Battery
Pack Cradle
Gas Out to
Instrument Line
Charging Contacts
IR Port
SDM-2012
BUMP CAL. EDIT
ENTER
Exhaust Line
Storage Fitting
COPY
GX-2012 OFF
1SEC ON
3SEC OFF
POWER
CHARGE
Exhaust Line (Must Be
Installed by User)
Lithium Ion Battery
Pack Cradle
Exhaust Line Connection Fitting
Figure 7: Instrument Panel (Shown Without Recess Cover Flap)

9 • Instrument Panel
SDM-2012
BUMP CAL. EDIT
ENTER
GX-2012 OFF
COPY
CHARGE
POWER
1SEC ON
3SEC OFF
Recess Cover Flap
Figure 8: Instrument Panel with Alkaline Instrument Installed
EDIT
ENTER
CAL.
SDM-2012
BUMP
GX-2012 OFF
COPY
POWER
1SEC ON
3SEC OFF
CHARGE
Recess Cover Flap
Figure 9: Instrument Panel with Lithium Ion Instrument Installed

Back Panel • 10
Back Panel
The back panel includes the power jack, sample fittings, and a USB PC connector.
Power Jack
The power jack is located in the bottom left corner of the back panel. The plug on the
end of the AC adapter cable mates to it.
Sample Fittings
Four sample fittings are located on the back of the SDM-2012. The AIR fitting is in the
upper left corner and draws air into the SDM-2012. The two GAS fittings are in the
center of the back panel and are used to connect the SDM-2012 to calibration gas
cylinders. The GAS 1 fitting is above the GAS 2 fitting. All three fittings accept 3/16
inch ID tubing.
An exhaust fitting is located in the upper right corner. It allows routing of the
exhausted calibration gas to a convenient location. This fitting accepts 5/16 inch ID
tubing. Even though the exhaust gas can be routed to an area to be safely dispersed,
the docking station should still be installed in a well ventilated area.
PC Connection
A type B USB connection is located beneath the exhaust fitting on the SDM-2012’s
back panel. It is only used for the PC Controlled configuration and is not used in the
Standalone configuration.
Gas 2 Fitting
Power Jack
Air Fitting
Gas 1 Fitting
Back Panel USB
Port (Type B),
For Computer
Connection
Exhaust Fitting
Figure 10: Fittings and Connections

11 • Control Panel
Control Panel
The control panel is used to setup and operate the docking station in the Standalone
configuration. It is located at the front of the docking station. It includes the control
buttons, the control button LEDs, and the CHARGE status LED.
Five control buttons are located on the control panel. From left to right they are BUMP
T, CAL S, EDIT ENTER, COPY, and POWER. The BUMP T, CAL S, and COPY
control buttons each have an LED above them thatindicates the status of the function
controlled by that button. The CHARGE LED is located above the POWER button
and functions as a pilot LED, a system failure LED, and a charge indication LED.
Table 2: Control Button Functions
Control
Button Control Button Function(s) Control Button LED Function(s)
BUMP T• Initiates a bump test
• Cancels a bump test
• Moves down a list of parameters
• Decreases an adjustable
parameter
Indicates status of a bump test
in progress
COPY
1SEC ON
3SEC OFF
CHARGE
POWER
GX-2012 OFF
BUMP
SDM-2012
CAL.
Control Buttons
EDIT
ENTER
BUMP LED
CHARGE LED
COPY LED
CAL LED
Figure 11: Control Panel

Control Panel • 12
CAL S• Initiates a calibration
• Cancels a calibration
• Clears data from docking station
memory (when used with COPY
button)
• Moves up a list of parameters
• Increases an adjustable parameter
Indicates status of a calibration
in progress
EDIT
ENTER • Puts docking station into various
edit modes
• Makes a displayed parameter
editable
• Escapes or cancels an operation
• Turns off connected instrument
(when used with POWER button)
n/a
COPY • Copies data to a USB flash drive.
• Clears data from docking station
memory (when used with CAL S
button)
• Indicates amount of docking
station memory used
• Indicates status of copying
function
• Indicates the result of a copy
operation
POWER • Turns on the docking station
• Turns off the docking station
• Turns off connected instrument
(when used with EDIT ENTER
button)
n/a
Table 2: Control Button Functions
Control
Button Control Button Function(s) Control Button LED Function(s)

13 • Front Panel
Front Panel
A type A USB port is located on the front of the docking station. This port can be used
to save calibration and bump test data to a USB flash drive. This USB port is for use
only in the Standalone configuration of the SDM-2012.
NOTE: The SDM-2012 does not support connection of a computer to the front
USB port, only a USB flash drive.
Figure 12: Front Panel

Overview • 14
Chapter 3: Preparing to Use the SDM-2012
Overview
There are four tasks that must be completed before you can begin to use the
SDM-2012: hardware assembly, setting or confirming the bump test and calibration
parameters, connecting calibration gas, and installing the Single Module Data Viewer
Software on your computer. This chapter describes how to assemble the parts that
are shipped with the SDM-2012, how to set or view the bump test and calibration
parameters, and how to install the Single Module Data Viewer Software on a
Windows based personal computer.
Hardware Assembly
The hardware assembly consists of connecting the AC adapter, installing the air filter,
and connecting the sample tubing. Perform the following to complete the hardware
assembly:
1. Place the SDM-2012 on a convenient table top near an AC wall socket in a
well ventilated area. A location near a window that can be opened is best so
that the exhaust can be routed to the window.
2. Connect the AC adapter’s wall plug into a wall AC socket.
3. Insert the round plug on the end of the AC adapter’s cable into the power jack
on the back of the SDM-2012.
NOTE: If you have multiple SDM-2012s and are using a 3-port AC adapter,
plug each of the round plugs on the end of the AC adapter into the
power jack on the back of 3 separate SDM-2012s.
4. Install the exhaust line, a clear 12 inch long tube with a black plastic push-on
fitting, by pushing the open end of the exhaust tube onto the exhaust line
connection fitting located in the upper left corner of the instrument panel. You
may then push the black push on fitting of the exhaust line onto the exhaust
line storage fitting on the other side of the instrument panel.

15 • Hardware Assembly
5. Install the air filter so that the arrow on the filter that indicates direction of flow
is pointing towards the AIR fitting. Push the open end of the flexible tube that is
on one end of the filter onto the AIR fitting on the back of the SDM-2012.
6. Install the 10 foot long 5/16 inch ID flexible tube that is included with the SDM-
2012 onto the exhaust fitting located in the upper left corner of the back panel.
Route the tube to an area where the exhaust can be safely dispersed, such as
an open window.
CAUTION: The maximum recommended length for the exhaust tube is 10 feet. Do
not use more than 10 feet of tubing or tubing with an ID of less than
5/16 inch for the exhaust tube or the bump test and calibration
accuracy may be adversely affected. The tube that is shipped with the
SDM-2012 has an ID of 5/16 inch and is 10 feet long.
7. Install the 3 foot long 3/16 inch ID tubes that are included with the SDM-2012
on the GAS 1 and GAS 2 fittings.
Open End
BUMP
GX-2012 OFF
COPY
1SEC ON
3SEC OFF
SDM-2012
POWER
CAL. EDIT
ENTER
CHARGE
SDM-2012
RKI
Instruments,Inc.
www.rkiinstruments.com
Black Push On Fitting
Step 2:
Black Push
On Fitting
Step 1:
OpenEnd
Figure 13: Installing the Exhaust Line
