Ro-Man Innov8 800 User manual

Wet Room Panel
Instruction Manual
N2VC
IMPORTANT INFORMATION
Be aware toughened glass can shatter if not handled correctly. It should not
be subjected to any sharp impact and it is essential to protect the glass by
resting it on a soft protective surface during installation such as cardboard
or carpeting. It is recommended to wear PPE at all times during installation.
Component Check List: Supplied
Description Quantity
Wall Prole 1
Panel Assembly 1
Screw Cover with Adhesive Tape 1
Dam Mouldings (Left and Right Hand) 1 of each
Bottom Rail 1
Bottom Rail End Cap 1
Bottom Seal 1
Please make sure the purchaser/end user
completes and returns the guarantee card
which is enclosed with this product. Failure
to validate the Guarantee will mean only the 1
Year Statutory Guarantee will apply.
CONSUMER GUARANTEE
PRE-INSTALLATION CHECKS
1. Check you have the correct product. Please look at the labels on the side of the product packaging.
2. Check all the product components are in the box and the xing kits.
3. Unpack your product and handle it with care.
4. Please check the product for defects or damage, once the installation has commenced we cannot accept responsibility for any defects or damage.
5. Please take time to read these instructions prior to installing your product.
6. Before you commence any drilling check there are no hidden electrical cables and/or water pipes.
7. No attempt should be made to re-work the toughened safety glass.
8. The installation of the product should be performed by two persons.
9. It is strongly recommended that the walls the product is going to be installed on are vertical.
10. It is strongly recommended the product is tted on a tiled surface or similar waterproof surface.
11. It is strongly recommended the walls are tiled and grouted before the product is installed.
12. If the walls and/or the tray are not level you will not achieve maximum adjustment of the product.
13. Pictures used are for illustration purposes only, product designs may alter slightly as a result of continuing product development.
14. We do not stipulate where the European Standard Kite Mark should be positioned on the glass when being factory assembled.
15. Please note that some natural misting may occur when you remove this product from its packaging, due to the addition of the glass protection pre-
coating. If this does occur this can easily be removed with a soft, dry cloth.
Ref: N2VC REV3 - SEPT 2020
Equipment Check List: Not Supplied
Description
Electric / Battery Drill
Screwdrivers
Sealant Gun
Bathroom Sealant
Spirit Level
6mm Masonry Drill Bit
Tape Measure
Pencil
Stanley Knife / Snips
Fixing Kit Components
Description Quantity
2.5mm Drill Bit 1
Wall Plugs 3
40mm screws 3
9mm Screws 5
Top Cap 1
3mm Allen Key 1
4mm Allen Key 1
Door Setting Block 2
Branding Badge 1

1. Check the tray is level on all sides (the bubble on the spirit level must be in the centre of the 2 lines).
2. Stand in the tray and check that there is no adverse movement (correct if necessary).
3. The walls should be tiled and grouted up to the tray.
4. The tiles and the tray should be sealed using a good quality bathroom sealant.
• Spray the seal and joints with the shower head and check for leaks when the silicon has cured.
• Check the plumbing for leaks.
• DO NOT plasterboard over the tray.
• DO NOT grout the tiles when the enclosure has been tted, the grout may discolour the aluminium
proles.
• Make sure the tray is installed as per the manufacturer’s instructions.
• When all of the above has been completed please proceed to the Step 2.
Step 1 - Pre-Installation Checks and Tray Sizes

Step 2 - Fitting the Wall Prole
1. Place the Wall Prole 15mm in from the outside of the tray. The longer leg of the Wall Prole must be on
the outside of the enclosure, towards the front of the tray. Make sure the Wall Prole is completely vertical
using a spirit level and mark the wall through the slots with a pencil.
2. Drill the wall with a 6mm Masonry Drill Bit (not supplied) where the Wall Prole is to be positioned. Fit the
Wall Plugs supplied (if going in to a brick or block wall). If going into a plasterboard wall you will need to
purchase appropriate wall xings. Wipe clear all debris from the Tray before referring to the next stage.
3. Where the Wall Prole is to be positioned on the Tray, place a bead of Bathroom Sealant (not supplied)
the width of the Wall Prole along the tiled wall. Screw the Wall Prole to the wall with 40mm Screws
(supplied). Do not over tighten the screws into the Wall Prole as this will misshape the Wall Prole.
Ensure the Wall Prole stays completely vertical throughout this procedure using a Spirit Level.
• Failure to carry out this procedure correctly can result in serious water damage and is not covered by
the Guarantee.
• No sealant to be present between the Wall Proles and the tiled walls vertically prior to screw xing.
4. Seal the gap on the inside between the Tray and Wall Prole with a Bathroom Sealant (not supplied).
• Failure to carry out this procedure correctly can result in serious water damage and is not covered by
the Guarantee.
③
①
IMPORTANT: This product features two di󰀨erent length Wall Proles. See notes below.
①
Short Leg
Long Leg
④

Step 3 - Fixing the Panel to the Wall Prole
1. Place the Setting Blocks onto the bottom of the Panel Glass, ensuring the end marked “A” is on the glass.
2. Carefully lift the Panel Assembly over the Wall Prole and carefully push it until it is fully home, there must
be a minimum of 10mm for xing.
3. On the inside of the enclosure, with the 2.5mm drill bit (supplied), drill a hole into the Vertical Frame and
Wall Prole approximately 100mm from the top and bottom and one in the centre. Drill 2 holes between
these (5 holes in total).
• Ensure the Panel is completely vertical (the bubble on the Spirit Level must be in the centre of the 2 lines).
4. Fasten the Panel to the Wall Prole using the 9mm screws supplied.
5. Seal the Wall Prole vertically top to bottom, both internally and externally where it meets the tiles.
IMPORTANT: Failure to carry out this stage may result in serious water damage and is not covered under
the terms of the guarantee.
• Allow 24 hours for the sealant to fully cure prior to using the shower.
6. Remove the setting blocks from the bottom of the door.
NOTE: 2 people will be required to carry out these operations. Some parts are hidden for clarity reasons.
③10mm ②
Minimum
⑤
①
Ensure the
the block is
tted with
the “A” on
the glass
①

Step 4 - Fitting the Dam and the Bottom Rail
1. Choose the correct Dam for your installation and discard the other.
2. Turn the Dam upside down and add a small amount of sealant on the inside edge (see image).
3. Seal the base of the pivot section to the Tray Top as shown in the image above.
4. Position the Dam against the Vertical Frame at the pivoting side of the door and gently press into the
sealant just applied.
• IMPORTANT: The Dam must be tted before the pre-applied sealant starts to cure.
5. Remove the release paper from the back of the adhesive tape (which is on the underside of the Bottom
Rail) and place the Rail inside the Dam at the pivot side of the door.
6. Press the Rail down onto the top of the tray ensuring that it is kept parallel to the outside edge of the tray
and that the Dam remains in position.
• Make sure the top of the tray is clean and free from any contaminates before applying the Rail.
7. On the Bottom Rail (at the opposite end to the wall) apply a small bead of sealant to the top edge.
Carefully but rmly place the End Cap in place.
• Be careful not to move the Bottom Rail and Dam.
②
⑤
④③
Remove the release paper
↓
↕ ↕
Keep
Parallel
Place the Dam
so that it sits
against the
Vertical Frame
④ ⑥
Dam
⑦
↓
⑦

Step 5 - Fitting Seals and Sealing
1. Seal the base of the enclosure to the top of the tray on the outside only making sure that you seal around
the Dam and End Cap as shown. Seal the Dam vertically where it meets the Vertical Frame.
• IMPORTANT: Failure to carry out stage 1 may result in serious water damage and is not covered under
the terms of the guarantee.
• DO NOT seal the base of the product to the inside, failure to comply may result in the product leaking.
• Allow 24 hours for the sealant to fully cure prior to using the shower.
2. Cut the Bottom Seal in half using snips to get two Seals. Measure between the Pivot Tube and where
the Centre Magnets meet and cut one Bottom Seal to this length. Do the same for the other Bottom Seal,
measuring between the edge of the glass and where the Magnets meet.
• Make sure the rebate end of the seal is kept for the pivot side of the door.
• If the Seal drags over the Bottom Rail, the door may need raising at the magnet side. Unscrew the top
3-4 door xing screws, raise the door, re-drill and re-x.
3. Remove the Magnets from the Door Glass. Fit the Bottom Seals to the Door Glass and put the Magnets
back on the Door Glass. Ensure the Magnets sit on top of the Bottom Seals. Trim the Magnets so they are
level with the top of the glass.
4. Ensure the Magnets locate fully from top to bottom when the door is closed. They can be knocked towards
each other using a wooden batton.
①
③Deector to
face inward
towards the
shower
②
INSIDE
VIEW
INSIDE
VIEW
Angled rebate
at pivot side
Seals to join in the
middle when door closed
Bottom Seal cut in
half to meet here
Centre Magnets to
sit on top of the
Bottom Seals
①

Step 6 - Fitting Screw Cover and Cap
1. Remove the release paper from the Adhesive Tape supplied and place the Tape on the face of the Vertical
Door Frame, ensuring the Tape is positioned to one side of the screw heads.
2. Place one side of the Cover Strip over the leg on the Vertical Frame and press rmly to stick the Cover Strip
to the Frame.
• The Cover Strip should sit on top of the tray.
3. The Top Cap has grooves and can be shortened by cutting along these grooves using scissors or snips
(adding a small amount of sealant will help keep the cap in place).
4. Place the Branding Badge in a prominent position on a none moving part of aluminium.
Cut o󰀨
here
③
①②
Cover Strip
Adhesive Tape
INSIDE
VIEW
Cover Strip to sit on top of the tray

Spare Parts
Part No. Description Qty Part No. Description Qty Part No. Description Qty
1Folding Panel Glass 1 11 Setting Block 2 21
2Magnet Seal 2 12 Bottom Seal 1 22
3Hinge Assembly 213 End Cap 1 23
4Pivoting Panel Assembly 114 Bottom Rail Adhesive Tape 124
5Screw Cover 1 15 Bottom Rail 1 25
6Screw Cover Adhesive Tape 116 Linear Seal 1 26
7Tube Seal 1 17 Dam (Right Hand) 1 27
8Dam (Left Hand) 1 18 Pivot Cap (Right Hand) 1 28
9Top Cap 1 19 Vertical Frame 1 29
10 Pivot Cap (Left Hand) 1 20 Wall Prole 130
If you need to replace any damaged parts please see illustration below for parts list then
call Customer Relations on 01325 328033

TROUBLE SHOOTING GUIDE
Some important information to help you Maintain your product.
The following information is all you need to keep your product looking new.
Clean your product using a mild detergent diluted in water and then polished o󰀨 using a soft cloth.
If you live in a hard water area, periodically clean your product using a 50/50 solution of white vinegar and water. The
solution should be left on the enclosure for approximately 5 minutes then rinsed o󰀨 using warm water. This method of
cleaning should remove lime scale residue.
Simple Maintenance
Our products are generally maintenance free, however it may be necessary to lubricate wheel assemblies and other
moving parts from time to time.
It is strongly recommended that a quality silicone spray is used.
A list of Don’t’s:
1. Don’t use acidic based products which are unsuitable for cleaning enamel surfaces.
2. Don’t use abrasive cleaners or cleaners using bleach or solvents, these products will adversely a󰀨ect the nish of
the aluminium proles.
3. Don’t use scouring pads, powder or any sharp instruments when cleaning the enclosure.
Should you experience any problems during installation please refer to the
Trouble Shooting Guide or contact Customer Relations on:
[phone]
To enable customer relations to provide you with an excellent level of service it is important that you
quote your product Code and Reference Number - these can be found on the Guarantee card.
Problem Solution
Leaking 1. Check that the inside gap between the Tray and Wall Prole has been sealed correctly.
2. Ensure the tray is sealed along the tiled walls prior to installation.
3. Ensure the Wall Prole is sealed vertically inside and outside.
4. Ensure the joint between the enclosure and tray top is sealed.
5. The deector on the Bottom Seals is semi rigid and can be carefully altered to o󰀨er
more deection of the water.
6. Check the Magnet Seals are locating and there are no gaps.
Important: This enclosure should be water tested conforming to BS EN 14428
Enclosure Alignment
on the Tray
1. Is the enclosure tted onto a tiled wall?
2. Is the Wall Prole tted 15mm from the outside edge of the tray?
3. Is the Wall Prole completely vertical?
Panel not operating
correctly
1. Ensure the Wall Prole is completely vertical.
2. Ensure the tray is completely level.

1
14
6
15
8
8
12
7
2
3
13
16
21
10
4
19
17
9
24
18
11
22
5
23
20
Innov8 800 Corner
Bi-fold Panel
N2VC813#
1 BOM R.Morton 15.09.20
ITEM NO. PART NUMBER
COLOUR
DESCRIPTION
LENGTH
QTY.
1 RL8012# Various Wall Profile 1967mm 1
2 RL8014# Various Main Vertical 1957mm 1
3 RL8003# Various 8mm Pivot Tube 1933 1
4 RL8017# Various Cover Plate 1962mm 1
5 RL8010# Various Tray Top Extrusion 709mm 1
6 RMC0403# Various Pivot Cap (Left Hand) 1
7 RMC0402# Various Pivot Cap (Right Hand) 1
8 RMC0398# Various Pivot Tube Clamp 2
9 RMC0404# Various Dual Bathscreen Hinge 2
10 RIM0249# Various Tube Cap (L-Hand) 1
11 RIM0250# Various Tube Cap (R-Hand) 1
12 RIM0459# Various Dam (R-Hand) 1
13 RIM0460# Various Dam (L-Hand) 1
14 RIM0463# Various Pivot Top Cap 1
15 RIM0246# Various End Cap 1
16 RIM0402
Green
Setting Block 2
17 RGT0552
Clear Innov8 Wetroom Pivoting Panel Glass 1933 x 353.50 x 8mm
1
18 RGT0551
Clear
Innov8 Wetroom Hinged Panel Glass
1933 x 327.50 x 8mm
1
19 RG0384
Clear
Tube Seal
1957mm
1
20 RG0419 White Double-Sided Foam Tape 3 x 9mm 1957 1
21 RG0023
Grey
Linear Vertical Seal
1947 1
22 RG0405
Clear
Bottom Seal
1000 1
23 RG0228
White
Adhesive Strip
709mm
1
24 RSMP0007 Clear Innov8 Angled Magnet Pair 1950 1
Rev No.
Description
Sign
Checked
Date
ECR No.
©ROMAN LIMITED
The information contained hereon
may not be copied in whole or part
without prior written consent
A2
General information
Sheet 1 of 1
Scale
Description
Drawing detail
Tel:- [phone] Fax:- [phone]
Whitworth Avenue, Aycliffe Industrial Estate,
Newton Aycliffe, Co. Durham. England.
DL5 6YN
www.roman-showers.com
Part number
Projection
Third Angle
