Robe Anolis ArcSource 4 MC II User manual

1
Version 1.2CE
QR code for user manual

2
ArcSource 4 MC II
The module generates colored light by means of RGBW LED multichip.The product was designed to use with
the ArcPower drivers and for indoor use only.
1.Attention
Do not install the module near high inammable liquids or materials.
Do not allow anything to rest on the module.
Do not use the module near high humidity or water or expose to the rain.
Do not install the module near the naked ames.
Do not install the module in dirty,dusty or badly ventilated location.
Su󰀩cient air accessing to the cooling ribs of the module housing has to be ensured.
Use the standard MR16 ttings to x the modules on a suitable place.
2.Installation
The ArcSource unit should be connected to the ArcPower drivers as stated in technical specications. See the
ArcPower drivers user manuals for full details of mains power requirements and DMX operation.
ArcSource unit is supplied with 1.5 m of cable for direct connection to the ArcPower drivers.
CAUTION!
Avoid looking directly into the LED light beam at close range!
Maximum possible number of LED modules connected to the one ArcPower 36 (or one LED output of the
ArcPower 72/144/360/16x6/RackUnit) is mentioned in the table below.
LED module LED multichips
Max.number
of connected
modules
Compatible LED drivers
ArcSource 4 MC 1 10 ArcPower 36/72/144/360
ArcSource 4 MC 1 2 ArcPower 16x6
ArcSource 4 MC 1 12 ArcPower Rack Unit

3
3.RJ45 pin connection
4.Technical specications:
Max. power consumption: 4.4W
Max input current per colour: 350 mA
Recommended power supplies: ArcPower 36/ 72/ 144/ 360, ArcPower Unit, ArcPower 16x6, DRS
Operating ambient temp.range: -20°C/+40°C
Surface temperature: +44°C@ambient 25°C
Cooling: convection
LED device: 1x multichip (RGBCW, WW)
Projected Lumen Maintenance: L90B10 >90.000 hrs, Ta = 25°C / 77°F
Led life expectancy: minimum 60,000 hours
Optical systems available: 1 10°, 15°, 20°, 30°, 40°, 60°, 90°, 10°x30°, 10°x 60°, 35°x70°, 15°x90
Construction: precision turned alluminium
Weight: 0.25 kg
Ingress protection: IP 2X
Flammability: 94V-0 ame class rating
Power /data plug: RJ45
Power /data cable: 24 AWG x 4P,category 5e or other cable from 8x24AWG to 8x 20AWG
5.Dimensions:
mm [inch]

May 25, 2022
Specications are subject to change without notice
Made in CZECH REPUBLIC by ROBE LIGHTING s.r.o. Palackeho 416/20 CZ 75701 Valasske Mezirici
6. Accessories
1 x Splitter (P/N 13050690)
7. Maintenance
- Keep the module dry.
- Operate only in places where the su󰀩cient airow to cool the module is present
- Periodically clean the front transparent cover.Use a moist, lint-free cloth. Never use alcohol or
solvents!
