ROBOfiber LFC Series User manual

4 www.robofiber.com
LFC series Gigabit Fiber Media Converters
Technical Specifications
Standards
IEEE 802.3, 802.3u, 802.3z, 802.3ab
Connectors
SFP slot, RJ45 UTP port, DC power plug
UTP port
RJ45, Auto MDI/MDI-X, full duplex, 10M,
100M or 1000M modes
SFP slot
Supports 100M or 1000M speed SFPs (up to
2.5G for LFC-1000-SS)
Power Adapter
Adapter with AC 100-240V input, 0.5A
AC frequency: 50-60Hz, Output DC 5V/1A
Power Requirements
DC 5-12V, 4W max. power consumption
Dimensions
90mm x 60mm x 20mm (SFP not included)
Mounting
Wall or shelf (optional bracket needed)
Environmental Conditions
Operating Ambient Temperature: 0 to 50℃
Operating Humidity: Maximum 85%, Non-
condensing
Storage Temperature: -30 to 70℃
Storage Humidity: Maximum 95%, Non-
condensing
Indoor rated operating device
MTBF
65,000 hours
Warning
1. Use only indoors in climate-controlled environment.
2. Avoid looking directly into fibers or lasers while unit is powered.
3. Use only the AC adapter included with the unit (or with the LFC series
chassis available separately)
FCC and CE markings
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
This is a CE class B device, intended to be used in residential, commercial or
industrial applications.
Fiber Media Converters
Gigabit Ethernet and multi-rate LFC series
LFC-1001-SFP
LFC-1002-SFP
LFC-1000-SS
User’s Manual

2 3
LFC series Gigabit Fiber Media Converters
LFC series Gigabit Fiber Media Converters
Gigabit Fiber Media Converters –LFC series
Ordering Information
LFC-1001-SFP Gigabit Media Converter 10/100/1000Base-Tx to
100/1000Base-X SFP slot, DIP sw config., AC adapter included
LFC-1002-SFP Gigabit Media Converter 2x 10/100/1000Base-Tx to
100/1000Base-X SFP slot, DIP sw config., AC adapter included
LFC-1000-SS multi-rate Media Converter SFP slot to SFP slot, DIP sw
config., AC adapter included
Overview
The LFC 1000 series are high performance and reduced size Gigabit Ethernet
fiber media converters. Units have DIP switches for custom speed and flow
settings for strong networking flexibility. Physical dimensions have been
reduced for minimum footprint and highest density attainable in 19” rack
environment: 12 units/RU. Reliability is highly ranked with an MTBF exceeding
65,000 hours.
LFC converters support IEEE802.3u IEEE802.3z 1000Base-TX/FX protocols.
Package includes AC adapter 100-240V to DC 5V and one User Manual.
Features
•10/100/1000Base-T to 100/1000Base-X Conversion (or same rate
transparent for LFC-1000-SS model)
•Auto-Negotiation and Auto MDI/MDIX (LFC-1001/1002-SFP)
•Forward 2048 bytes (Max.) packets in switch mode (copper & fiber
port in different speed)
•Forward 9k bytes in converter mode (fiber & copper port at the same
speed)
•DIP switch settings for fiber speed (100/1000M), LPF and Flow control
•Support for Q in Q double tagged frame transparent
•Support for IEEE 802.1Q Tag VLAN pass thru
•100M to 2.5G transparent O-E-O repeater –both optical ports must
have same rate (model LFC-1000-SS)
•Installs into high density 12 slot/1RU rack mountable chassis, the LFC-
CH12 series (with options of redundant and AC or DC48 power
supplies)
DIP switch settings
Model
LFC-1001-SFP
Model
LFC-1002-SFP
DIP
Function
Settings
Function
Settings
SW 1
LFP
OFF –
Disabled
ON –Enabled
Reserved
Reserved
SW 2
Forwarding
OFF/OFF
Store &
Forward
Jumbo
frame
OFF –
Normal
ON –9K
enabled
mode
OFF/ON
Cut Through
SW 3
(paired
setting 2&3)
ON/OFF
Smart Pass
Through
RJ45 Port
VLAN
OFF -
Disable
ON –Enable
ON/ON
Pass Through
SW 4
FX port
100M mode
OFF –
1000M
ON –100M
FX port
100M
mode
OFF –
1000M
ON –100M
LED Indicators (markings will vary with models)
Function
TP/LNK
Off –No link; On –RJ45 link OK; Blinking –data traffic present
SPD
Off –10M/100M; On –1000M on RJ45 port
FX/LNK SFP1 SFP2
Off –No link; On –Fiber link OK; Blinking –data traffic present
PWR
Off –No power available; On –Power is present
Installation
1. Choose a flat secure surface with room for proper ventilation.
2. Power up the unit using the included AC adapter. Observe PWR LED
status indicating proper power to the unit.
3. Connect RJ45 UTP port using Cat5e or better cable to another Ethernet
device. Make sure the TP LED indicates proper connectivity.
4. Insert a Gigabit or Fast Ethernet rated SFP transceiver into the SFP slot.
Make sure the fiber transceiver used matches the fiber type (MM or SM)
and also matches a similar optical transceiver at the other end of the
fiber. Inspect FX LED for proper fiber link status.
Troubleshooting
1. No TP/LNK light: verify proper UTP cabling/pinout.
2. No FX/LNK light: verify fiber connectivity and fiber type. Consider
cleaning up fiber connectors and SFPs with appropriate tools. Make sure
Tx and RX ports are properly crossed between units. Make sure FX speed
is properly set on DIP sw.
3. No PWR light: Use only the AC adapter included. Make sure AC power is
available
