Z3 Technology Z3-DME-02 User manual

User Instructions
H.264 HD Multimedia System
Digital Media Encoder and Streamer
Model Name: Z3-DME-02
The Power of ZEUS™
DOC-USR-0054-07
Manual Version 2.35a
Software Version 2.35
September 13, 2016
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2016 Z3 Technology, LLC. All rights reserved. ZEUS is a registered trademark of Z3 Technology, LLC.
This document contains proprietary and confidential information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced,
disclosed, or disseminated to anyone without the prior written approval of an authorized representative of Z3.
Z3 Technology, LLC incorporates HDMI® technology. The terms of HDMI and HDMI High-Definition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
2
Revision History
Version
Date
Change Note
Author
2.01.20
05/24/2014
Initial Version
RC
2.01.20a
06/25/2014
Formatting
JF
2.01.20b
10/13/2014
Updated included parts list, video inputs, specifications, HDMI Disclaimer
KA
2.01.54
11/20/2014
Added Section 2.0, updated resolutions (Section 4.0), ZFinder note (Section
6.3) and description of using RTSP (Section 6.6). Other modifications to
Sections 6.9, 6.10, 10.1, 10.3, 10.4, 10.5, 10.6 and Appendix B. Updated
screenshots. Formatting.
RC
2.01.57
01/28/2015
Modifications in Sections: 6.1, 6.2, 6.6, 6.9, 10.1, 10.2, 10.5, 10.6, 10.7,
10.8 and Appendix B. Updated screenshots. Formatting.
RC
2.11
05/13/2015
Added sections on ASI encoding and Closed Caption support. Also added
descriptions of DNS parameters, MPTS parameters, Frame Align,
Authentication, and TSRTP. Updated screenshots for new release. Small
formatting updates.
KA/RC
2.14
06/09/2015
Modifications in Sections 4.0, 6.8, 6.10, 7.3, 7.4, 8.4, 9.4, 11.4. Added note
on Closed Captioning in 6.11. Modified decode description to include
clicking on “Set Display” in Section 9.3. Added AAC-HE in Section 11.5.
Updated screenshots, formatting updates.
RC
2.35
03/31/2016
Added mention of RTP over TS support. Added note about being able to
reboot from GUI in Section 6.10. Added description of 16:9 checkbox,
TSRTP, and Frame Alignment in Section 11.5. Updated screenshots. Updated
HW Warranty information. Formatting updates.
RC/TA
2.35a
09/13/2016
Changed to DCHP default. Added Setting a Static IP Address section.
Updated to registered ZEUS logo. Updated Operation Controls image. Added
TTL information to Appendix B. Formatting and grammar updates.
TA

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
3
TABLE OF CONTENTS
1.0 GENERAL DESCRIPTION.................................................................................................. 7
2.0 QUICK START GUIDE ..................................................................................................... 8
2.1 If You Have Received a System from Z3 with the Software Preloaded ........................................ 8
2.2 If You Already have a System from Z3 and Need to Update the Firmware ................................... 8
3.0 PACKAGE CONTENTS..................................................................................................... 9
4.0 FEATURES ................................................................................................................ 10
4.1 Supported Input Resolutions .......................................................................................10
4.2 Supported Output Resolutions .....................................................................................10
5.0 OPERATING CONTROLS ................................................................................................. 11
6.0 GETTING STARTED WITH THE Z3-DME-02 ............................................................................ 12
6.1 Set up the HD Source................................................................................................12
6.2 Connect and Power up the Z3-DME-02............................................................................12
6.3 Find the Z3-DME-02 on Your Network using ZFinder ............................................................13
6.4 Configure CH1 and Encode .........................................................................................14
6.5 Run VLC to View Stream ............................................................................................16
6.6 Streaming RTP........................................................................................................17
6.7 Changing the Bitrate and Frame Rate Dynamically .............................................................19
6.8 Adjusting the UDP TS Rate..........................................................................................21
6.9 Tuning for Latency...................................................................................................23
6.10 Encoding Closed Caption Data....................................................................................24
6.11 Using the “Aux TS File” Option...................................................................................26
7.0 STREAMING RTMP IN THREE DIFFERENT RESOLUTIONS ............................................................ 27
7.1 Connect the Encoder ................................................................................................27
7.2 Configure the Encoder to “Encode 1 to 3 Ch” Mode............................................................27
7.3 Configure CH1 for RTMP Streaming ...............................................................................28
7.4 Configure CH2 for RTMP Streaming ...............................................................................29
7.5 Configure CH3 for RTMP Streaming ...............................................................................30
7.6 Set Up the Wowza Server...........................................................................................31
7.7 Start the Encode .....................................................................................................31
7.8 View the Content on Wowza .......................................................................................31
8.0 OUTPUTTING ASI ........................................................................................................ 33
8.1 Set up the System ...................................................................................................33
8.2 Connect ASI Out......................................................................................................33
8.3 Initialize CH1 .........................................................................................................33
8.4 Configure MPTS ......................................................................................................35

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
4
8.5 Start Encoding........................................................................................................36
9.0 RUNNING THE DECODER ............................................................................................... 37
9.1 Create a .ts File using the Encoder ...............................................................................37
9.2 Connect the Output .................................................................................................37
9.3 Set Decoder Mode ...................................................................................................37
9.4 Configure the Decoder ..............................................................................................38
10.0 PERFORMING OTHER OPERATIONS WITH THE Z3-DME-02 ........................................................ 39
10.1 Saving Current Settings............................................................................................39
10.2 Using a Static IP Address ..........................................................................................40
10.2.1 Open the User Interfac Using ZFinder................................................................................................................ 42
10.2.2 Open the User Interface Manually..................................................................................................................... 43
10.3 Making a Firmware Update .......................................................................................43
10.4 Using the Password Feature ......................................................................................45
11.0 SUMMARY OF OPTIONS ................................................................................................ 47
11.1 The System Setup Tab .............................................................................................47
11.2 The User Presets Tab...............................................................................................49
11.3 The Status Tab ......................................................................................................49
11.4 The MPTS Tab .......................................................................................................50
11.5 The CH1 Tab (Encode) .............................................................................................51
11.6 The CH1 Tab (Decode) .............................................................................................56
11.7 The CH2/CH3 Tabs .................................................................................................56
11.8 Values Appearing at the Bottom of All Tabs ....................................................................57
APPENDIX A: Configuring the Wowza Server for RTMP ................................................................ 58
APPENDIX B: Troubleshooting ............................................................................................. 60

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
5
LIST OF FIGURES
Figure 1 Package Contents ................................................................................................. 9
Figure 2 Front and Rear Panels of the Z3-DME-02 .....................................................................11
Figure 3 Z3-DME-02 Rear Panel Example Encode Connections .......................................................12
Figure 4 Z3-DME-02 Power Switch and Status Light...................................................................13
Figure 5 ZFinder with Z3-DME-02 Selected .............................................................................13
Figure 6 Z3-DME-02 User Interface System Setup Tab.................................................................14
Figure 7 Channel 1 Configuration Screen - UDP........................................................................15
Figure 8 VLC Open Network Stream Screen for UDP ..................................................................16
Figure 9 Example of Z3 Video Streaming to VLC .......................................................................16
Figure 10 Channel 1 Configuration Screen - RTP.......................................................................17
Figure 11 VLC Open Network Stream Screen for RTP .................................................................18
Figure 12 Example of Z3 Video Streaming to VLC (RTP) ..............................................................18
Figure 13 Viewing Bitrate in VLC.........................................................................................19
Figure 14 Changing the Bitrate Dynamically............................................................................19
Figure 15 Drop in Bitrate after Dynamic Bitrate Change .............................................................20
Figure 16 Status Page Output Showing Lower Bitrate .................................................................20
Figure 17 Changing TS Rate ...............................................................................................21
Figure 18 TS Rate and Lower Bitrate Reflected in VLC ...............................................................22
Figure 19 Tuning for Various Use Cases..................................................................................23
Figure 20 Connections for Closed Caption Extraction .................................................................24
Figure 21 Sample Encoder Settings for Composite Closed Caption Extraction ....................................24
Figure 22 Setting VLC to use the Extracted Closed Caption Data ...................................................25
Figure 23 Using the Aux TS File Enable Option .........................................................................26
Figure 24 Changing to “Encode 1 to 3 Ch” Mode.......................................................................27
Figure 25 Creating Additional Channels .................................................................................27
Figure 26 3-Channel RTMP Encode –Channel 1 Settings ..............................................................28
Figure 27 3-Channel RTMP Encode –Channel 2 Settings ..............................................................29
Figure 28 3-Channel RTMP Encode –Channel 3 Settings ..............................................................30
Figure 29 Getting to the Wowza Test Player............................................................................31
Figure 30 Viewing Z3-DME-02 Content on Wowza......................................................................32
Figure 31 Connecting ASI Out on the Z3-DME-02 .......................................................................33
Figure 32 Z3-DME-02 CH1 Settings for ASI Output .....................................................................34
Figure 33 MPTS Settings ...................................................................................................35
Figure 34 The “Start All” Button .........................................................................................36
Figure 35 The “Status” Tab for an ASI Output ..........................................................................36

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
6
Figure 36 Connecting the Z3-DME-02 for Decode ......................................................................37
Figure 37 Changing to Decoder Mode....................................................................................37
Figure 38 System Setup in Decoder Mode...............................................................................38
Figure 39 Decoder Configuration Settings for Decode Example .....................................................38
Figure 40 The User Presets Tab ...........................................................................................39
Figure 41 Entering a User Preset Name .................................................................................39
Figure 42 Saving New Settings to a User Preset........................................................................40
Figure 43 Setting a Static IP Address within a User Preset ...........................................................41
Figure 44 Saving to a User Preset ........................................................................................41
Figure 45 ZFinder with Z3-DME-02 New IP Address ....................................................................42
Figure 46 User Interface Using DHCP Address ..........................................................................42
Figure 47 Updating the Device Firmware from the Web Interface ..................................................43
Figure 48 Updater Screen .................................................................................................44
Figure 49 File Selection Screen...........................................................................................44
Figure 50 Selecting “Set Password”......................................................................................45
Figure 51 Changing the Password ........................................................................................45
Figure 52 Password Entry Screen.........................................................................................46
Figure 53 Wowza Performance Settings .................................................................................58
Figure 54 Wowza Security Settings.......................................................................................59

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
7
1.0 GENERAL DESCRIPTION
The ZEUSZ3-DME-02 Digital Media Encoder is a cost-optimized, compact 233 x 129 mm system that supports
H.264 High Profile encode and decode up to 1080p at 60 frames per second. This solution works in multiple
applications such as low-cost broadcast encoders, low-bandwidth video security, satellite uplink, remote
monitoring and industrial applications. The Z3-DME-02 provides immediate access to multi-format HD video,
integrated system peripherals and production-qualified codecs.
The Z3-DME-02 features HD performance, compact size, and low latency while still having less power
consumption than a PC-based encoder platform.

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
8
2.0 QUICK START GUIDE
2.1 If You Have Received a System from Z3 with the Software Preloaded
To start working with the encoder, you can go straight to Section 6.0, “GETTING STARTED WITH THE Z3-
DME-02,” on page 12. This section describes how to quickly generate a UDP or RTP stream to VLC, how to
change bitrate dynamically, how to adjust the UDP TS rate, and tuning for latency. Information on RTMP
mode and generating multiple streams from the same input can be found in Section 7.0, “STREAMING
RTMP IN THREE DIFFERENT RESOLUTIONS,” on page 27. Details on performing ASI encode can be found in
8.0, “ OUTPUTTING ASI,” on page 33. Details on running the Decoder can be found in Section 9.0, “
RUNNING THE DECODER”, on page 37.
2.2 If You Already have a System from Z3 and Need to Update the Firmware
You can update the firmware via the user interface by following the instructions in Section 10.3: “Making
a Firmware Update”, on page 39.
Please Note: Actual version numbers for your Z3 product may differ from those pictured in this document.

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
9
3.0 PACKAGE CONTENTS
Z3-DME-02
12V Power Supply
3x BNC to BNC Cable
HDMI Cable
Video Cable
BNC to RCA Adapter
DB-9 Serial Cable
Note: The DB-9 serial cable is included for advanced troubleshooting purposes only and is not needed by
the typical user.
Figure 1 Package Contents

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
10
4.0 FEATURES
The Z3-DME-02 is a high definition, low-cost, network-enabled media encoder with the following features:
HD resolutions up to 1920x1080 including 1080i, 1080p60 and 720p
Standard Definition encoding for ISDB-T, DVB-H, and other standards
Video Inputs: 3G-SDI, Composite, and ASI
Video Outputs: 3G-SDI, HDMI and ASI
On-board video scaler provides full screen with all resolutions
Outputs RTP, RTMP, MPEG-2 TS, or RTP over MPEG-2 TS
Supports fractional resolutions and frame rates
2x USB 2.0 Interfaces for local storage
Supports extraction of closed caption data through composite or SDI
Web-based configuration software for user-friendly configuration and control
RS-232 serial port for technical configuration and control
Operating Temp: 0 to 40 degrees C at 20-80% relative humidity (non-condensing)
Storage Temp: -40 to 70 degrees C at 20-80% relative humidity (non-condensing)
Measurements: 233 x 129 x 35 mm (9.17 x 5.07 x 1.38 in)
Weight: 921g (2.03 lb)
4.1 Supported Input Resolutions
SDI: 1080p60, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94, 720p50, 576p50,
576i25, 480p60, 480i30, and 480i29.97
Composite: 576i25, 480i29.97
4.2 Supported Output Resolutions
SDI: 1080p60, 1080p59.94, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94,
720p50, 480i30, and 576i25
HDMI: 1080p60, 1080p59.94, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94,
720p50

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
11
5.0 OPERATING CONTROLS
1: Power Switch 5: SDI/ASI Input 1 9: RS-232 Serial
2: USB 1 (2.0) 6: SDI/ASI Input 2 10:GigE
3: Status LED’s 7: SDI/ASI Output 11: USB 2 (2.0)
4: Analog Audio Inputs 8: HDMI/DVI Output 12: 12V Power
Figure 2 Front and Rear Panels of the Z3-DME-02
REAR PANEL
FRONT PANEL

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
12
6.0 GETTING STARTED WITH THE Z3-DME-02
This section gives step-by-step instructions on using the Z3-DME-02 to stream 1080p or 1080i video to VLC
media player running on your PC. In addition to the Z3-DME-02, an HD source with SDI output (or HDMI
source with HDMI->SDI converter plus HDMI cable) and a PC with VLC are required as well as a BNC-BNC
cable, an Ethernet cable, and a 12V power supply.
*Note: Actual version numbers for your Z3 product may differ from those pictured in this document.
6.1 Set up the HD Source
(1) Set up the SDI source to output 1080p or 1080i.
If you do not have an SDI source, you can also use an HDMI source along with an HDMI->SDI
converter. It is important that the HDMI source have non-HDCP output (for example, in Z3’s
testing, the Brite-View BV-5005HD is used). To use an HDMI source, do the following:
-Power on the HDMI Source
-Connect an HDMI cable from the HDMI Source to a monitor
-Set the HDMI Source to 1080p30 or 1080i output (1080p60 requires a different mode –see below).
-Select and begin playback of the content
-Take the HDMI cable connected to the monitor and connect it to “HDMI In” of the HDMI to SDI
converter.
6.2 Connect and Power up the Z3-DME-02
(2) Connect the BNC cable from the SDI source to the Z3-DME-02 “SDI 1 Input” port.
(3) Connect an Ethernet cable to “Ethernet” on the back of the Z3-DME-02 to a switch, router or other
DHCP server on the same network as your Windows PC. You will use this PC to control the Z3-DME-
02 and to decode the output stream.
Figure 3 Z3-DME-02 Rear Panel Example Encode Connections
(1) Connect to
SDI source
(2) Connect to
Ethernet
(3) Connect
Power

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
13
(4) Connect the 12V power supply to “+12VDC” and turn on the power switch. It will take 45-60 seconds
to boot. The “Ready” status LED will turn on.
6.3 Find the Z3-DME-02 on Your Network using ZFinder
ZFinder is a PC Utility that allows you to find any Z3 Technology product on your network. If you have
not downloaded this to your computer, you can find it on the USB drive provided with your system.
(5) Verify your Windows PC is is set to DHCP. If it is set to a static IP address, ZFinder will be unable to
discover your encoder, or it will appear in red and you will be unable to proceed further.
(6) Run the “ZFinder” PC Utility on your Windows PC. The ZFinder window appears. ZFinder completes a
scan of the network and lists the location of all Z3 systems that are connected. In this case, the Z3-
DME-02 appears.
(7) Click on the Z3-DME-02 entry in the window to select it. This will cause the “Edit Device”, “Open
Device” and “Flash LEDs” boxes to activate:
Figure 5 ZFinder with Z3-DME-02 Selected
(1) Turn on PWR
(2) “Ready” lights up after around 1 minute
Figure 4 Z3-DME-02 Power Switch and Status Light

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
14
*Note:Selecting “Edit Device” allows for manual changes to network settings. Selecting “Flash
LED’s” is useful when multiple encoders are connected to the same network.
*Note: If the Z3-DME-02 is highlighted in red in ZFinder, this means that the Z3-DME-02 is
currently not accessible from the network. The netmask / IP address of the Z3-DME-02 should be
adjusted using “Edit Device” to conform to the value needed by the network (the netmask should
be the same as the network’s and the IP address should have either the first two or three values
be the same [depending on whether the netmask is 255.255.0.0, or 255.255.255.0]).
(8) Click on “Open Device.” An Internet browser window is opened (for best results, Firefox or Chrome
are recommended) and HTTP-based graphical user interface (GUI) appears at the System Setup tab.
6.4 Configure CH1 and Encode
(9) Click on the “CH1” tab.
(10) In the Channel 1 configuration tab, change Video Resolution to “1920x1080”.
(11) Set Output Format to “UDP,”
(12) You can set the Dest Address to:
(a) the IP address of your PC that will be running the VLC media player(in the pictured
example, 192.168.0.6).
(b) or to a multicast address (An example multicast address would be “225.1.2.3”. If you are
on a shared network, check with your Network Administrator.)
Figure 6 Z3-DME-02 User Interface System Setup Tab

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
15
(13) Make note of the value of “Dest Port” (This will be 5004 by default).
(14) The encoder may have already started (after 20 seconds, the encoder will automatically try to
start). If it has, click on “stop” near the bottom of the screen. Then, click on “start”. Once you do
this, the status will change to “RUNNING.”
*Note: If you want to encode 1080p60, you must first change “Operating Mode” at the bottom right
from “Encode Interlaced/Progressive” to “Encode Single Ch No Scale.” Note that, in “Encode Single
Ch No Scale” mode, only CH1 can be used.
(2) Change
to UDP
(1) Change to
“1920x1080”
or “Follow
input”
(3) Change to IP
Address of your PC
(4) Check value of
“Dest Port”
Figure 7 Channel 1 Configuration Screen - UDP
(5) Click “stop” if
already started
(6) Click “start”

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
16
6.5 Run VLC to View Stream
(15) Run VLC on your PC (version used in testing at Z3: 2.1.5)
(16) Select Media –Open Network Stream. In the box, type “udp://@192.168.0.6:5004”, where
“192.168.0.6” matches the values of the computer IP address or multicast address entered for
“Dest Address” previously, and 5004 is the value of “Dest Port” noted previously.
(17) Press “Enter.”
(18) You will now see video streaming to VLC.
Figure 9 Example of Z3 Video Streaming to VLC
Figure 8 VLC Open Network Stream Screen for UDP

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
17
6.6 Streaming RTP
Once you have UDP streaming, it is relatively simple to change to RTP streaming. All that is needed are a
few parameter changes. To stream using RTP, complete the following steps:
(19) In the CH1 configuration tab, click on “stop” to stop the current encoding session.
(20) Change “Output Format” from “UDP” to “RTP.”
(21) Click on “start” to start the RTP encoding session. At this point your settings should look like the
following:
(22) Open VLC. Select “Media – Open Network Stream”.
Figure 10 Channel 1 Configuration Screen - RTP
Change to “RTP”

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
18
(23) In the “Open Media” box, type “rtsp://{IP Address}/z3-{ch#}{m}.mp4”, where {IP Address} is the IP
address of the Z3-DME-02, {ch #} is 1 for CH1, 2 for CH2, and 3 for CH3, and {m} is added if a
multicast address is being streamed. For example, if the IP address of the Z3-DME-02 is the value of
192.168.81.7, encode is being done from CH1, and unicast streaming is being done, the user would
type in “rtsp://192.168.81.7/z3-1.mp4”:
*Note: VLC version 2.1.5 or later is needed for RTSP support.
(24) Click “Play.” You will then see RTP video streaming on VLC.
Figure 12 Example of Z3 Video Streaming to VLC (RTP)
Figure 11 VLC Open Network Stream Screen for RTP

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
19
6.7 Changing the Bitrate and Frame Rate Dynamically
The Z3-DME-02 includes an “update” button which allows you to change the bitrate or frame rate
without stopping and restarting the encoder. To use it, complete the following steps:
(25) In VLC, click on “Tools” and select “Codec Information”. This brings up a window with four tabs.
Select the “Statistics” tab. In this tab, you can see the current video + audio bitrate:
(26) In the CH1 tab, change the bitrate from “8000K” to “2000K” and click “update”
*Note: If FireFox is used, after entering a value in a text box, it is necessary to click once outside of that
text box for the value to be accepted. The end result is “update” has to be clicked twice after changing
the bit rate.
Figure 13 Viewing Bitrate in VLC
Figure 14 Changing the Bitrate Dynamically
video+audio bitrate
(1) Change bitrate to 2000K
(2) Click “update”

DOC-USR-0054-07
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
20
(27) You should see the video bitrate drop and the quality of the picture in VLC change.
If you click on the status page and click “Refresh,” you will also see the updated bitrate reflected:
You can also use the “update” button to modify the Frame Rate Divider.
Figure 16 Status Page Output Showing Lower Bitrate
Lower bitrate
Figure 15 Drop in Bitrate after Dynamic Bitrate Change
Lower video+audio bitrate
