Roboreel Air User manual

Roboreel®Portable Air Hose Reel 1-888-GR8-STUFF
Quick Start Guide –Page www.roboreel.com
This Quick Start Guide does not replace the User Guide. For complete details and precautions concerning this product, read all instructions in the User Guide provided
CAUTION: The Air Hose System is rated for dry, indoor use only.
DO NOT OPERATE IN WET ENVIRONMENT
IF YOU HAVE ANY QUESTIONS OR DIFFICULTIES CALL OUR CUSTOMER SUPPORT TEAM: 1-888-GR8-STUFF
1. Connect Power
1. Plug Power Entry Cable securely into AC outlet.
* The unit will emit a tune, indicating it is ready to use
1. Connect Air Input Hose to air supply
CAUTION: DO NOT EXCEED 300 PSI PRESSURE
3. Connect Air Tool
1. Connect air tool / device to Quick Coupler
2. Extract hose / tool to desired working length
1. Disconnect tool from Quick Coupler by pulling
down then pushing upward on coupler.
2. Press Remote or Dome Retract Button to reel in
hose
pull
first
then
push
Reel Parts Diagram 2. Connect Air Supply
4. Remove Tool / Retract Hose
1
Doc. No. 070-000139-01, Rev 1

Roboreel®Portable Air Hose Reel 1-888-GR8-STUFF
Quick Start Guide –Page www.roboreel.com
IF YOU HAVE ANY QUESTIONS OR DIFFICULTIES CALL OUR CUSTOMER SUPPORT TEAM: 1-888-GR8-STUFF
6. Program the Slow-Down Point
1. Attach Bench Mount Bracket to work surface using two (2) black wood
screw (included) as shown in Fig 1a
2. Insert leg bar into mount (1) and then pull reel forward to secure it (2)
5. Bench Mount (included) Instructions
2
Wood
Screws
Wall Mount (optional) Instructions
The reel may be wall-mounted using the optional wall mount bracket kit
(purchased separately). Complete mounting instructions are included with
the bracket kit.
This Quick Start Guide does not replace the User Guide. For complete details and precautions concerning this product, read all instructions in the User Guide provided
Wall
Bracket
The reel may be setup to slow down the hose retraction speed at a
desired distance from the unit (the “docking” point) to prevent
whipping action of the hose
To set the slow down (docking) point:
1. Connect the unit to power and air supply (fully retract the hose
into unit)
2. Extract the hose until the Quick Coupler and Remote Retract
Button Module are resting on the floor at the desired slow-down
length.
3. Press and hold either the Remote or Dome Retract Button for
approximately 5 seconds. Once programming is complete, the
unit will begin to reel in (release the button / hose)
4. FULLY extract the hose all the way out and retract the hose to
test slow-down point. Repeat steps 2-4 to change the slow-down
point.
Press and hold Retract
Button at desired location
