Roby RMT1801 User manual

RMT1801
ORIGINAL INSTRUCTIONS
Cordless Multi-Tool

Important!
It is essential that you read the instructions in this manual before assembling,
operating, and maintaining the product.
Subject to technical modification.

Safety
1
Safety, performance, and dependability have been given
top priority in the design of your cordless multi-tool.
INTENDED USE
The product is intended to be used only by adults who
have read and understood the instructions and warnings
in this manual, and can be considered responsible for their
actions.
You may use this product for cutting and sanding purposes.
Do not use the product in any way other than those stated
for intended use.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool’’ in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
WORK AREA SAFETY
■Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
■Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
■Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
■Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
■Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
■Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
■When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
■If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
■Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
■Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce
personal injuries.
■Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
on invites accidents.
■Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
■Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
■Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
■If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
POWER TOOL USE AND CARE
■Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
■Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
■Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
■Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power

Safety
2
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
■Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
■Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
■Use the power tool, accessories and tool bits etc,
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
■When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
■Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
SERVICE
■Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
SPECIAL SAFETY RULES
■Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
■Protect your lungs. Wear a face or dust mask if the
operation is dusty.
■Always wear safety goggles and a dust mask when
sanding, especially sanding overhead.
■A suitable breathing respirator must be worn while
sanding lead paint, some woods and metal to avoid
breathing the harmful/toxic dust or air.
MAINTENANCE
■When servicing, use only identical Ryobi replacement
parts. Use of any other parts may create a hazard or
cause product damage.
■Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their
use. Use clean cloths to remove dirt, dust, oil, grease,
etc.
■Always wear safety goggles or safety glasses with side
shields during power product operation or when blowing
dust. If operation is dusty, also wear a dust mask.
■To avoid serious personal injury, always remove
the battery pack from the product when cleaning or
performing any maintenance.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
of as waste. The machine, accessories
and packaging should be sorted for
environmental-friendly recycling.
SYMBOL
Safety alert
CE conformity
EurAsian Conformity Mark
Ukrainian mark of conformity
Please read the instructions carefully
before starting the machine.
Wear ear protection
Wear eye protection
Recycle

Safety
3
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice.

4
Getting started
1 2
4
B
D
B
D
Bosch
Dremel

5
Getting started
3
65

Operation
6
0˚ 90˚
180˚270˚
0˚ 90˚
180˚270˚
1
2
3
20160810v8

20160810v8
VIBRATION LEVEL
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of
exposure. The declared vibration emission level represents the main applications of the tool. However if the tool is used
for different applications, with different accessories or poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may significantly reduce the exposure level over the total working
period. Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, and organisation of work patterns.
GUARANTEE
In addition to any statutory rights resulting from the purchase, this product is covered by a guarantee as stated below.
1. The guarantee period is 24 months for consumers and commences on the date when the product was purchased.
This date has to be documented by an invoice or other proof of purchase. The product is designed and dedicated to
consumer and private use only. So there is no guarantee provided in case of professional or commercial use.
2. There is, in some cases (i.e. promotion, range of tools), a possibility to extend the warranty period over the period
described above using the registration on the www.ryobitools.eu website. The eligibility of the tool is clearly displayed
in stores and/or on packaging. The end user needs to register his/her newly-acquired tools online within 8 days from
the date of purchase. The end user may register for the extended warranty in his country of residence if listed on the
online registration form where this option is valid. Furthermore, end users must give their consent to the storage of the
data which are required to enter online and they have to accept the terms and conditions. The registration confirmation
receipt, which is sent out by e-mail, and the original invoice showing the date of purchase will serve as proof of the
extended warranty. Your statutory rights remain unaffected.
3. The guarantee covers all defects of the product during the warranty period due to defaults in workmanship or material
at the purchase date. The guarantee is limited to repair and/or replacement and does not include any other obligations
including but not limited to incidental or consequential damages. The warranty is not valid if the product has been
misused, used contrary to the instruction manual, or being incorrectly connected. This guarantee does not apply to
–any damage to the product that is the result of improper maintenance
–any product that has been altered or modified
–any product where original identification (trade mark, serial number) markings have been defaced, altered or
removed
–any damage caused by non-observance of the instruction manual
–any non CE product
–any product which has been attempted to be repaired by an non-qualified professional or without prior authorization
by Techtronic Industries
–any product connected to improper power supply (amps, voltage, frequency)
–any damage caused by external influences (chemical, physical, shocks) or foreign substances
–normal wear and tear of spare parts
–inappropriate use, overloading of the tool
–use of non-approved accessories or parts
–carburettor after 6 months, carburettor adjustments after 6 months
–power tool accessories provided with tool or purchased separately. Such exclusions include but is not limited to
screw driver bits, drill bits, abrasive discs, sand paper and blades, lateral guide
–components (parts and accessories) subject to natural wear and tear, including but not limited to carbon brushes,
chuck, power cord, auxiliary handle, sanding plate, dust bag, dust exhaust tube
4. For servicing, the product must be sent or presented to a RYOBI authorized service station listed for each country in the
following list of service station addresses. In some countries your local RYOBI dealer undertakes to send the product
to the RYOBI service organisation. When sending a product to a RYOBI service station, the product should be safely
packed without any dangerous contents such as petrol, marked with sender’s address and accompanied by a short
description of the fault.
5. A repair/replacement under this guarantee is free of charge. It does not constitute an extension or a new start of the
guarantee period. Exchanged parts or tools become our property. In some countries delivery charges or postage will
have to be paid by the sender.
6. This guarantee is valid in the European Community, Switzerland, Iceland, Norway, Liechtenstein, Turkey and Russia.
Outside these areas, please contact your authorized RYOBI dealer to determine if another warranty applies.

PRODUCT SPECIFICATIONS
Cordless multi-tool
Model RMT1801
Voltage 18 V
Switch Variable speed
No-load speed 0-20,000 min-1
Weight - excluding battery pack 0.95 kg
Oscillation angle 3˚
Measured sound values determined according to EN 60745:
A-weighted sound pressure level
LpA = 85 dB(A)
Uncertainty K 3 dB
A-weighted sound power level
LWA = 96 dB(A)
Uncertainty K 3 dB
Wear ear protectors.
Weighted root mean
The vibration total values (triax vector sum) determined according
to EN 60745:
Vibration emission value
Cutting chipboard (wood) a
h
= 4.2 m/s
2
Uncertainty K 1.5 m/s
2
Cutting chipboard (wood & metal) a
h
= 5.7 m/s
2
Uncertainty K 1.5 m/s
2
Sanding a
h
= 1.4 m/s
2
Uncertainty K 1.5 m/s
2
BATTERY AND CHARGER
Model Compatible battery
pack (not included)
Compatible charger
(not included)
Lithium-ion
RB18L13
RB18L15
RB18L20
RB18L25
RB18L40
RB18L50
BCS618
BCL14181H
BCL14183H
RC18150

DECLARATION OF CONFORMITY
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
Herewith we declare that the product
Cordless Multi-Tool
Brand: Ryobi
Model number: RMT1801
Serial number range: 44405302000001 - 44405302999999
is in conformity with the following European Directives and harmonised standards
2006/42/EC, 2004/108/EC (until 19 April 2016), 2014/30/EU (from 20 April 2016), 2011/65/EU
EN 60745-1:2009+A11:2010, EN 60745-2-4:2009+A11:2011, EN 55014-1:2006+A1:2009+A2:2011,
EN 55014-2:1997+A1:2001+A2:2008
RoHS documentation is compiled according to EN 50581:2012
Andrew John Eyre (BEng, CEng, MIET)
Vice President Regulatory & Safety
Winnenden, Feb. 29, 2016
Authorised to compile the technical file:
Alexander Krug, Managing Director
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
ACD PLANT LTD
145 Southbank Road
Coundon
Coventry, West Midlands
CV6 1FG
Phone: [phone]
Email: [email protected]
Web: www.acdplant.co.uk
CBS Power Tools Limited
Unit 4, V P Square
Storeys Bar Rd, Fengate
Peterborough, Cambridgeshire
PE1 5YS
Phone: [phone]
Email: [email protected]
Web: www.cbspowertools.com
C D Powertools
76 Old Road
Churwell Morley, Leeds
LS27 7TH
Phone: [phone]
Email: [email protected]
Web : www.cdpowertools.co.uk
C J Sinclair Limited
44 Victoria Road
St Peters
Broadstairs, Kent
CT10 2UG
Phone: [phone]
Email: [email protected]
Web: www.cjsinclairltd.co.uk
Powertech Ind Ltd
Unit 2C, Ellison Road
Norwood Ind, Killamarsh
Sheffield, South Yorkshire
S21 2JG
Phone: [phone]
Email: [email protected]
Web: www.powertech-industrial.co.uk
RYCKO Technical Services LTD
104 Green Lane
St Albans, Herts
AL3 6EX
Phone: [phone]
Email: [email protected]
Web: www.ryckotechnical.com
ToolTech Industrial Equipment
227 E Dunhill Road, Macosquin
Coleraine, Co Londonderry
BT514LQ
Phone: [phone]
Email: [email protected]
AUTHORISED SERVICE CENTRES
For an updated list of authorised service centres, visit http://uk.ryobitools.eu/header/service-and-support/service-agents.

961152078-04
Techtronic Industries GmbH
Max-Eyth-Straße 10,
71364 Winnenden, Germany
