Roche cobas c User manual

cobas c pack opener
Operator’s Manual

Roche Diagnostics
Operator’s Manual · Version 1.2 3
cobas c pack opener
Table of contents
Document information ........................................................................................................5
Contact address .....................................................................................................................6
Conventions used in this manual ........................................................................................7
Other symbols ........................................................................................................................8
Unpacking and assembly ......................................................................................................9
Product description .............................................................................................................12
Operator qualification ........................................................................................................13
Power on and operation .....................................................................................................14
Disposal of the device .........................................................................................................16
Maintenance .........................................................................................................................17
Troubleshooting ...................................................................................................................19
Technical data and specifications ......................................................................................22

Roche Diagnostics
4Operator’s Manual · Version 1.2
cobas c pack opener

Roche Diagnostics
Operator’s Manual · Version 1.2 5
cobas c pack opener Document information
Document information
Revision history
Edition notice Operator’s Manual for users of the cobas c pack opener.
Every effort has been made to ensure that all the information contained in this
manual is correct at the time of printing. However, Roche Diagnostics GmbH
reserves the right to make any changes necessary without notice as a part of ongoing
product development. Any customer modification to the instrument will render the
warranty or service agreement null and void.
Intended use The cobas c pack opener is a semiautomatic device designed for use with
cobas ®8000 modular analyzer series and cobas c513 analyzer. It is intended for
opening the cobas c pack large.
Copyright © 2009-2018, Roche Diagnostics GmbH. All rights reserved.
Trademarks The following trademarks are acknowledged:
cobas, cobas c , and LIFE NEEDS ANSWERS are trademarks of Roche.
Instrument approvals The cobas c pack opener meets the protection requirements laid down in
IVD Directive 98/79/EC. Furthermore, the device is manufactured and tested
according to the following international standards:
oIEC/EN 61010-1
oIEC 61010-2-101
oIEC 61326-2-6
The Operator's Manual meets the requirements of European Standard EN ISO
18113-3:2011.
Compliance is demonstrated by the following marks:
Manual version Revision date Changes
1.0 August 2009 Initial version
1.1 August 2015 cobas c 513 analyzer was added to
the section Intended use.
1.2 August 2018 Removed cobas c 711 analyzer,
updated intended use, updated
symbols list, updated
Maintenance and
Troubleshooting sections, minor
editorial revisions.
Complies with the IVD directive 98/79/EC.
Issued by Underwriters Laboratories, Inc. (UL) for Canada
and the US.

Roche Diagnostics
6Operator’s Manual · Version 1.2
Contact address cobas c pack opener
Contact address
Manufacturer Roche Diagnostics GmbH
Sandhofer Strasse 116
D-68305 Mannheim
Germany

Roche Diagnostics
Operator’s Manual · Version 1.2 7
cobas c pack opener Conventions used in this manual
Conventions used in this manual
Visual cues are used to help quickly locate and interpret information in this manual.
This section explains the formatting conventions used in this manual.
The safety precautions and important user notes are classified according to the
ANSI Z535.6 standard. Familiarize yourself with the following meanings and icons:
The following symbols and signal words are used for specific hazards:
Important information that is not safety relevant is indicated by the following
symbol:
The following symbols are also used:
The safety alert symbol (without a signal word) is used to promote awareness of generic
hazards or to direct the reader to safety information provided elsewhere in the document.
WARNING
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.
NOTICE NOTICE
Indicates a hazardous situation which, if not avoided, may result in property damage.
Tip
Indicates additional information on correct use of the device or useful tips.
Symbol Used for
aStart of procedure
• List item
eCross-reference

Roche Diagnostics
8Operator’s Manual · Version 1.2
Other symbols cobas c pack opener
Other symbols
On the type plate and packaging label of the device you will find the following
additional symbols that have not been explained so far.
Symbol Meaning
Disposal of electronic equipment.
This device is covered by the European Directive WEEE.
Global Trade Item Number.
Quantity contained in the package.
Fragile, handle with care.
Stacking limit by 4.

Roche Diagnostics
Operator’s Manual · Version 1.2 9
cobas c pack opener Unpacking and assembly
Unpacking and assembly
The cobas c pack opener is delivered in a box. If any part was damaged during
transport, inform your supplier or the carrier immediately.
aUnpacking the cobas c pack opener
1 Open the box as indicated.
e Refer to the label on the box.
2 Grasp the unit firmly and remove the unit from the box.
3 Place the unit in an upright position on the bench.
4 Pull off the top foam cushion.
5 Separate the unit from the bottom foam cushion.
6 Pull off the plastic foil and remove the desiccant bag from the unit.
7 Place the unit on a stable, vibration-free surface, for example a bench. Do not
place in direct sunlight. Comply with other environmental requirements.
e Technical data and specifications on page 22
8 Position the unit in a way that its on/off switch and power receptacle can be easily
and quickly accessed whenever needed.
9 Check that the consignment is complete.
CAUTION
Personal injury due to heavy and slippery device
The unit may slip out of your hands.
Always hold the unit firmly.

Roche Diagnostics
10 Operator’s Manual · Version 1.2
Unpacking and assembly cobas c pack opener
If any items are missing, inform your supplier without delay.
A cobas c pack opener
BWaste container
CAdapter for cobas c pack large
Figure 1 cobas c pack opener and components
DPower cord
Figure 2 Optional
A
B
C
B
D
The adapter (C) for using cobas c pack large is part of the standard cobas c pack opener
consignment.
The device is delivered without a power cord (D). A country-specific power cord is
provided separately by Roche.
Keep the original packaging. Transport the cobas c pack opener only in the original
packaging.

Roche Diagnostics
Operator’s Manual · Version 1.2 11
cobas c pack opener Unpacking and assembly
aSetting up the cobas c pack opener
1 Place the adapter for the cobas c pack large.
2 Connect the power cord. The cobas c pack opener will adjust to the local lines
automatically.
Once the power cord is plugged in, the cobas c pack opener is ready for use.
Before using the cobas c pack opener, check that the power cord is connected properly!
AOn/off switch
BFuse holder
CPower receptacle
Figure 3 Rear view of the cobas c pack opener
AC
B

Roche Diagnostics
12 Operator’s Manual · Version 1.2
Product description cobas c pack opener
Product description
The cobas c pack opener is a semiautomatic device, designed to decap integrated
reagent cassettes.
The cobas c pack opener is a tabletop unit that can be operated by users in a standing
or seated position.
Figure 4 A cobas c pack large
APort for cobas c pack large
BWaste container
CAdapter for cobas c pack large
Figure 5 Front view of cobas c pack opener with a standard-size adapter
A
C
B

Roche Diagnostics
Operator’s Manual · Version 1.2 13
cobas c pack opener Operator qualification
General information A cobas c pack large is inserted in the port (A) at the front of the unit. The adapter
(C) is positioned directly at the bottom of the port.
A waste container for the caps (B) is located beneath the port. The waste container is
easy to empty and is dishwasher-safe up to 65°C.
A blue light (LED) is located upside of the waste container. This light indicates that
the unit is ready for use and, additionally, it illuminates the waste container.
Operator qualification
Operators are required to have knowledge of the relevant guidelines and standards as
well as of the information and procedures contained in the Operator’s Manual.
oDo not carry out operation and maintenance unless you have been trained by
Roche Diagnostics.
oCarefully follow the procedures specified in the Operator’s Manual for the
operation and maintenance of the unit.
oLeave maintenance, installation or service that is not described in the Operator’s
Manual to trained Roche service personnel.
oFollow standard laboratory practice, especially when working with biohazard
material.
oDo not use the unit for anything other than its intended use. Otherwise, this may
compromise the safe use of the unit and reduce its effectiveness.

Roche Diagnostics
14 Operator’s Manual · Version 1.2
Power on and operation cobas c pack opener
Power on and operation
aPower on
1 Before powering the unit on, please ensure that no cobas c pack large is inside the
cobas c pack opener.
2 Power on the unit.
3 After a short initialization, the cobas c pack opener will be ready for use. The blue
light shines continuously.
aOpening a cobas c pack large
1 Completely unwrap the packaging foil from a cobas c pack large.
aTo decap a cobas c pack large
1 Fully insert the cobas c pack large by hand into the port until the motor starts and
the light turns off.
2 Wait until the motor stops and the blue light flashes.
3 Remove the opened cobas c pack large.
CAUTION
Skin irritation due to reagent traces
The cobas c pack large caps may be contaminated by reagent splashes.
oWear proper gloves and safety glasses.
oDo not touch your face or your eyes during operation.
Figure 6 Inserting a cobas c pack large by hand.
oThe cap’s orientation must be upwards.
oInsert only one cobas c pack large at a time. Move the cobas c pack large to its
full stop position.
Ensure that no foreign object gets into the cobas c pack large when the caps are off.

Roche Diagnostics
Operator’s Manual · Version 1.2 15
cobas c pack opener Power on and operation
4 To process another cobas c pack large, wait until the light turns on again.
5 Repeat steps 1 to 5.
aChecking the waste container
1 Check the level of the waste container at the end of the day.
2 Empty the container if it is full.
e Maintenance on page 17
NOTICE Always switch off and unplug the unit prior to opening the waste container.
CAUTION
Skin irritation due to reagent traces
When emptying the waste container, follow the normal precautions for handling reagents.
Disposal of all waste material should be in accordance with local guidelines.

Roche Diagnostics
16 Operator’s Manual · Version 1.2
Disposal of the device cobas c pack opener
Disposal of the device
This device is covered by the European Directive WEEE.
The device must be disposed of via designated collection facilities appointed by
government or local authorities.
For more information about disposal of your old product, please contact your city office,
waste disposal service or your local Roche Support personnel.
CAUTION
Personal injury due to sharp-edged parts of the device
Do not attempt to take the device apart for repair or disposal.

Roche Diagnostics
Operator’s Manual · Version 1.2 17
cobas c pack opener Maintenance
Maintenance
The cobas c pack opener is a maintenance-free device.
Users are responsible for cleaning the unit on a regular basis.
aEmpty the waste container and clean the unit
1 Tilt the waste container and pull out.
2 Dispose of the caps in accordance with local specifications and laws.
3 Put the waste container in the dishwasher.
4 Clean surfaces of the unit with a lint-free tissue or a moistened cotton bud if
necessary, using mild detergents or disinfectants, preferably 70% alcohol.
NOTICE Always switch off and unplug the unit prior to opening the waste container.
Always switch off and unplug the unit prior to cleaning.
Do not allow liquids to enter the device.
Do not spray cleaning agents directly onto the device. Use a lint-free tissue or a moistened
cotton bud.
Figure 7 Emptying the waste container
After max. 150 cobas c packs large, empty the waste container.
The waste container is dishwasher-safe up to 65°C (149°F).
Do not put adapters into the dishwasher!

Roche Diagnostics
18 Operator’s Manual · Version 1.2
Maintenance cobas c pack opener
aChanging the fuses
1 Switch off the unit and disconnect the power cord.
If the power cord is still connected, you will not be able to access the fuse holder.
2 Using the tip of a blade screwdriver, lift the fuse holder out of the unit.
3 Replace both fuses.
Make sure you are using the correct types:
(Type 2A/250V AC (5 x 20 mm) - Blow Characteristic -Time Delay).
4 Reconnect the power cord to the unit.
5 Switch on the unit.
Figure 8 Lifting the fuse holder

Roche Diagnostics
Operator’s Manual · Version 1.2 19
cobas c pack opener Troubleshooting
Troubleshooting
This chapter provides information how to troubleshoot the cobas c pack opener.
Removing a jammed c pack large
Main cause Unscrewed cap(s) fall(s) back onto of the cobas c pack large and cause(s) a jam on the
top side of the cobas c pack large. It is not possible to remove the cobas c pack large
manually.
Remedy 1 Pull out the adapter used for cobas c pack large.
2 Pull out the waste container.
3 Pull down the emergency flap.
NOTICE Always switch off and unplug the unit prior to opening the waste container.
Figure 9 A cobas c pack large jammed in a cobas c pack opener
AAdapter cobas c pack large BWaste container
Figure 10 Removing adapter and waste container

Roche Diagnostics
20 Operator’s Manual · Version 1.2
Troubleshooting cobas c pack opener
4 Remove the cobas c pack large, moving it down step by step.
5 Remove the cobas c pack large and all loose caps.
6 Move the emergency flap to its magnetic default position.
7 Reinstall adapter and waste container.
The cobas c pack opener is ready to be used again.
Initialization does not start or is unsuccessful.
Main cause 1 A cobas c pack large is in the port as the cobas c pack opener is switched on.
Remedy Pull out the cobas c pack large. As soon as the cobas c pack large is fully removed
from the port, initialization continues
or
Main cause 2 The cobas c pack opener is defective.
Remedy Call technical support.
After inserting a cobas c pack large: Mechanism starts but stops almost immediately, the blue light fails
to switch on again.
Main cause The cobas c pack large is not inserted correctly.
oThe cobas c pack large was not kept in the correct position for sufficient time.
oThe caps are at the bottom and not at the top.
oThe plastic foil was not removed completely from the cobas c pack large.
Remedies oPull out the cobas c pack large.
oCheck the cobas c pack large.
oInsert it again.
AMoving the cobas c pack large down
Figure 11 Removing the cobas c pack large
NOTICE Before using the affected cobas c pack large - manually unscrew any cap, that has been
left open.
