Rocket Fish RF-700WPS User manual

700 Watt Power Supply
RF-700WPS
User Guide

2
Rocketfish RF-700WPS
700 Watt Power Supply
Contents
Introduction ...................................................................... 2
Features............................................................................... 3
Installing your power supply....................................... 4
Specifications.................................................................... 6
Legal notices ..................................................................... 7
One-Year Limited Warranty.......................................... 9
Introduction
Thank you for choosing this RF-700WPS power supply unit (PSU).
Please read this manual carefully and follow the instructions before
installing the PSU.
The RF-700WPS power supply complies with the newest SSI EPS12V
Version 2.91 and Intel ATX12V version 2.2 specifications. This includes
four +12V output circuits that deliver safer and more reliable output
to your system's components. In addition, this power supply is
energy efficient, reducing power consumption by 80%. It also
includes two PCI-E connectors for SLi. We have also included a variety
of industrial-grade protective circuits, including the following:
• OCP (Over Current Protection)
• OPP (Over Power Protection)
• OVP (Over Voltage Protection)
• SCP (Short Circuit Protection).

3RF-700WPS
Safety information
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS DEVICE TO RAIN OR MOISTURE.
Important Safety Instructions
1Do not place your system near a radiator or other heat source.
2Do not place your system close to a source of strong magnetic fields.
3Do not place you system in a moist or dusty environment, or in an area
subject to strong vibration.
4Do not place your system in direct sunlight.
Features
• Compliant with Intel ATX12V V2.2 and EPS12V V2.91 specifications
• Active Power Factor Correction
•SLiready
• Supports Intel and AMD Dual- and Multi-core processors
• Four +12V output rails
•80%efficiencyperformance
• Higher reliability and built-in protection circuits (OCP, OVP, OLP, and SCP)
and line input fuse protection
• Easily moveable connector
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

4
• FAN speed auto-controlled by a thermal sensor inside the power supply
• 100% Hi-pot and burn-in tested
• Supports 12-16 SCSI hard drives
•Componentsinclude:
Installing your power supply
To make sure you connect your power supply correctly, check your
motherboard and graphics card manuals for compatibility before
connecting RF-700WPS to any of your devices.
To install your power supply:
1Check your local AC voltage before installation (115 VAC voltage is for
USA, Japan, and so on, and 230 VAC voltage is for Europe, South East
Asia, and many other countries).
Caution:
Be sure to connect the PSU (Power Supply Unit) to local input AC voltage only. Setting
the incorrect voltage can damage the power supply and connected equipment, and
may void your warranty. The RF-700WPS is compatible with 115VAC and 230VAC
input voltage.
2Turn off your computer, then unplug the power cord from your old
power supply.
3Open your computer case following the directions provided in your case
manual.
Output cables
3.4 inches
(86.0 mm)
5.9 inches
(150.0 mm)
5.5inches
(140.0 mm)
AC socket
Power switch
Fan
4.7 inches
12 cm

5RF-700WPS
4Disconnect all PSU connectors from the motherboard and the
peripherals devices such as case fans, HDD, FDD, DVD, CD-ROM, and so
on.
5Remove the old power supply from your computer case and install your
new Rocketfish power supply.
6Connect the 24-pin Main Power Connector to your motherboard.
Note:
Use 24-pin to 20-pin adaptor if your motherboard requires 20-pin power connector.
7Connect the Serial ATA connectors to the peripheral devices.
8Connect the peripheral 4-pin power connectors if you are still using an
IDE connector for hard drives or a DVD/CD drive.
9Connect the PCI Express power connector to your PCI Express graphics
cards, as needed.
10 Connect your case fans to the regular 4-pin peripheral connectors if you
are using these fans.
Caution:
Make sure that all connectors are correctly connected. Incorrect connection could
prevent your computer from booting and some components might even be
damaged.
11 Close your computer case and connect the AC power cord to the power
supply.
Booting your system
To boot your system:
1Turn on the power supply by setting the I/O switch on the power supply
to the "I" position.
2Turn on your computer by pushing the power button on the front of
your system.

6
Specifications
Input
Output
DC output power distribution
• Maximum output: 700 Watts
• Combined 3.3 V and 5 V: 170 Watts
• Maximum combined current for the +12V1, +12V2, +12V3, and +12V4 is
41 A.
• Dimensions:
• 5.5 × 3.4 × 5.9 inches (W × H × L)
• 150×86×140mm(W×H×L)
Voltage USA, Japan, and others: 115 Vac
Europe, South East Asia, and others: 230 Vac
Frequency 60 Hz-50 Hz
Current 10 A (max.) at 115 Vac/60 Hz
7 A (max.) at 230 Vac/50 Hz
Parameter Minimum Nominal Maximum Units
Vin (115 VAC) 90 115 132 VRMS
Vin (230 VAC) 180 230 264 VRMS
Vin frequency 47 --- 63 Hz
Voltage Range Min. Nom. Max. Ripple Noise
+12 V1 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+12 V2 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+12 V3 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+12 V4 ±5% +11.4 +12.00 +12.60 120 mV 200 mV
+5 V ±5% +4.75 +5.00 +5.25 50 mV 100 mV
+3.3 V ±5% +3.14 +3.30 +3.47 50 mV 100 mV
-12 V ±10% -10.80 -10.80 -13.20 120 mV 200 mV
+5 Vsb ±5% +4.75 +4.75 +5.25 50 mV 100 mV

7RF-700WPS
Legal notices
FCC compliance
This device complies with Part 15 of FCC rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
FCC warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the user’s
authority to operate this equipment.
Copyright
© 2008 Rocketfish. Rocketfish and the Rocketfish logo are trademarks
of Best Buy Enterprise Services, Inc. Other brands and product names
are trademarks or registered trademarks of their respective holders.
Specifications and features are subject to change without notice or
obligation.
For service and support call 1-800-620-2790.

8

9RF-700WPS
One-Year Limited Warranty
Rocketfish Products (“Rocketfish”) warrants to you, the original purchaser of this new
RF-700WPS (“Product”), that the Product shall be free of defects in the original manufacture of
the material or workmanship for one (1) year from the purchase of the Product (“Warranty
Period”). This Product must be purchased from an authorized dealer of Rocketfish brand
products and packaged with this warranty statement. This warranty does not cover refurbished
Product. If you notify Rocketfish during the Warranty Period of a defect covered by this
warranty that requires service, terms of this warranty apply.
How long does the coverage last?
The Warranty Period lasts for one year (365 days), beginning on the date you purchased the
Product. The purchase date is printed on the receipt you received with the product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of the
Product is determined to be defective by an authorized Rocketfish repair center or store
personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or
(2) replace the Product at no charge with new or rebuilt comparable products or parts. Products
and parts replaced under this warranty become the property of Rocketfish and are not returned
to you. If service of Products and parts are required after the Warranty Period expires, you must
pay all labor and parts charges. This warranty lasts as long as you own your Rocketfish Product
during the Warranty Period. Warranty coverage terminates if you sell or otherwise transfer the
Product.
How to obtain warranty service?
If you purchased the Product at a retail store location, take your original receipt and the Product
to the store you purchased it from. Make sure that you place the Product in its original
packaging or packaging that provides the same amount of protection as the original
packaging. If you purchased the Product from an online web site, mail your original receipt and
the Product to the address listed on the web site. Make sure that you put the Product in its
original packaging or packaging that provides the same amount of protection as the original
packaging.
Where is the warranty valid?
This warranty is valid only to the original purchaser of the Product in the United States, Canada,
and Mexico.
What does the warranty not cover?
This warranty does not cover:
•Customerinstruction
•Installation
•Setupadjustments
•Cosmeticdamage

10
• Damage due to acts of God, such as lightning strikes
•Accident
•Misuse
•Abuse
•Negligence
•Commercialuse
• Modification of any part of the Product, including the antenna
This warranty also does not cover:
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage supply
• Attempted repair by anyone other than a facility authorized by Rocketfish to service the
Product
• Products sold as is or with all faults
• Consumables, such as fuses or batteries
• Products where the factory applied serial number has been altered or removed
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY.
ROCKETFISH SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT
NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST
PROFITS. ROCKETFISH PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO
THE PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD
SET FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER
THE WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Rocketfish:
For customer service please call 1-800-620-2790
www.rocketfishproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645
© 2008 Best Buy Enterprise Services, Inc.
All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in
some countries. All other products and brand names are trademarks of their respective owners.
