Rocket Fish RF-RBWS02 User manual

If this is your rst Rocketboost product and you do not have an existing Rocketboost
network, the devices were joined at the factory. You do not need to join them. If you are
adding these devices to an existing network, change the hub mode switch on the sender
to Disabled and then join BOTH devices to your existing hub.
Use this procedure only if you need to rejoin the transmitter and speaker. This procedure
is not required for normal operation as devices were joined at the factory. To connect
these devices to an existing hub device that you own, follow the same instructions: Join
the sender/receiver to your existing hub, then join the wireless speaker to your existing
hub. Note: You can only join devices to the hub unit (the one with the green LED).
Rocketboost device
ASet the HUB STATUS switch to ENABLE if this is your rst Rocketboost product set.
• The LED lights green when the HUB STATUS switch is set to ENABLE.
• The LED lights blue when the HUB STATUS switch is set to DISABLE.
BPress and hold the button on the sender/receiverfor more than three seconds to
put it into joining mode. The LED starts blinking rapidly and the unit will stay in Join
mode for 30 seconds.
CPress the Power/Join button on the wireless speaker for more than three seconds
so the sender and wireless speaker will enter connection mode.
• The LED lights steadily if the link is activated between both of the units.
• The LED blinks at a slower rate if the communication link is not successful.
DOnce the link is established, if the Source LED on the wireless speaker is not
illuminated, press the Source button to toggle to the next source. If the LED is still
not illuminated, check that your source is powered up.
For further details, see instructions in the user manual for joining new devices to an
existing Rocketboost network.
RF-RBWSO2 Wireless Outdoor Speaker
QUICK SETUP GUIDE
Package contents
Sender
DC adapter
for transmitter User Guide
IR remote
User Guide
Front controls
3.5mm stereo
female to 2-RCA male
cable (6 inches/15.25 cm)
Wireless speaker
DC adapter
for wireless
speaker
3.5 mm
stereo cable
Front Panel
Transmitter
Speaker
1 Getting Started
Connect to an audio source
Connect one end of the audio cable (supplied) to
the AUDIO IN jack on the sender and the other end
to the audio output jack of your device (such as an
A/V receiver, PC, or iPod.)
Note: If you are adding this sender to an existing network,
set the hub switch to Disable and follow the instructions
under Establishing Communication to add the transmitter
and speaker to your existing network. Otherwise, leave it
on Enable as the transmitter and wireless speaker were
pre-congured at the factory and you will not need to go
through the Establish Communication steps. Remember to
turn the volume up on the source device to at least 80%
of its maximum volume.
# Feature
1
2
3
4
5
6
7
Power/Join button
Power/Join indicator (Blue/Green Light)
IR sensor window
Source button
Receiver-mode indicator (Blue Light)
Sender-mode indicator (Blue Light)
OR
To audio
output jack
Supplied
To audio
output jack
Supplied
Connect the AC Adapter
Connect one end of the adapter to the DC IN jack, then
plug the other end into an AC power outlet. The standby
indicator turns red.
Note: Make sure that the power outlet is 100-240V, and do not
connect the AC adapter until all other connections are completed.
Pull up the antennas
Adjust antennas
4 Listening to Music
To listen to music:
ATurn on the sender and the wireless speaker. Make sure that the wireless
speaker is fully charged (if using Batteries) and there is an active link
between the sender and the wireless speaker. An active link will be
indicated by the Power LED showing a solid blue.
BMake sure the volume is turned up to about 80% of maximum volume.
CAdjust the volume level on your wireless speaker. If you have multiple
streams in your Rocketboost network, press the Source button on the
wireless speaker to hear the next stream.
Repeated pressing of the SOURCE button will toggle through available
sources.
ENGLISH 09-0536
Load batteries in wireless speaker
(Installing batteries is optional)
2 Connecting the Transmitter
A Unscrew the bottom cover ( 3 screws).
BInsert eight alkaline or rechargeable NiMH batteries
matching +/- as indicated. This product will only recharge
NiMH batteries. Do not attempt to charge any other
batteries in this product. Note: Your wireless speaker can
operate on batteries or with the DC to AC adapter (provided).
The unit will charge and play simultaneously.
CReplace the cover and fasten the three screws.
x 8
8 rechargeable or alkaline
C batteries (not included)
Charge your wireless speaker
Connect the DC adapter to the wireless speaker and plug into an AC
power outlet. The CHARGE LED blinks green while it is charging. The
light will be solid when charging is complete.
Note: For the rst time,
charge batteries for
16 hours.
Caution: Only use the
supplied power adapter
and make sure your outlet
matches the AC’s input
of 100-240 V.
15VDC
15V DC
BASS
Quick
Setup Guide
QUICK SETUP GUIDE
Wireless speaker
TM
1 5
46 732
TM
Preparing the remote control
To activate the battery:
Remove the tab from the bottom of the remote control to enable the battery.
Please read before setting up your system.
Every Rocketboost network must contain at least one hub device, which directs network data trac and helps devices join the
network. The network can have only one hub, which you can enable using the Hub switch on the back of all Rocketboost
transmitters. See your User Guide for instructions on“joining”devices to the network. If this is your rst Rocketboost product you
should make this unit the hub, if you already have Rocketboost products, you should disable the hub mode on this device.
IMPORTANT: Hub units must always have power for your network to operate. The device may be placed in standby, but the unit
must remain plugged into the wall to operate your network.
For best results, adjust the antennas to
vertical. In some instances, you may
improve range by rotating both
antennas 45 degrees to create a 90°
angle similar to a wide "V".
3 Establishing Communication
CHARGE
BASS
POWER//JOIN
CHANNEL
L - MONO - R
SOURCE
1
7
6
4 4
5 5
8
9
10
VOLVOL
Source
23
TX LED
Front Panel
11
12
TM Standby indicator (Red Light)
1
2
3
4
5
6
7
8
9
10
Volume increase/decrease dial
Power/on standby/Join button
Source
Middle-treble reflex hole
Bass reflex hole
Power/Join indicator (Red/Blue light)
BASS indicator
Charge indicator
Channel MONO (L/R) indicators
Audio source signal indicator
11
12
DC adaptor in
Bass Boost
# Feature
Wireless speaker’s
back panel
