Ladder Assembly
PARTS LIST - LADDER HARDWARE Quantity
17 TrackBracket* Variable
18 TrackEndCap* Variable
19 TrackUnion* Variable
20 #12x11⁄2"PanHeadScrews* Variable
Quantity
21 6'Track*(NotShown) Variable
3. Drill holes and install Hook Bracket Assemblies (9)
to Ladder Rails (1 and 2) using Connector
Bolts (15) and Acorn Nuts (16). Center
components between Aluminum Decorative
Spindle (4). Fig. 3.
4. Dry fit Wheel Assemblies (10) to ladder.
Attach ladder to track and place in the climbing
position (steps parallel to the floor). Adjust
Wheel Assemblies (10) vertical to the floor.
Fig. 4. Drill and attach Connector Bolts (15)
and Acorn Nuts (16) for top of Wheel
Assembly (10). Bottom attaches with a 9/64"
pilot hole and a Pan Head Screw (14).
Note: For added strength and design, install Step
Brackets (42128, sold separately). Install 2 per step.
1. Begin Ladder Assembly. Attach Aluminum
Deocrative Spindle (5) and Cast Steps (6) to
just one rail using Cap Nuts (8) and Connector
Bolts (7). Fit the second rail on to the assembled
side and attach the rung and cast steps using
Cap Nuts and Connector Bolts (7). Fig. 5.
2. Drill holes and install Hook Bracket Assemblies (9)
to Ladder Rails (1 and 2) using Connector Bolts (15)
and Acorn Nuts (16). Center components between
the Aluminum Decorative Spindle (4). Fig. 3.
3. Dry fit Wheel Assemblies (10) to ladder.
Attach ladder to track and place in the climbing
position (steps parallel to the floor). Adjust
Wheel Assemblies (10) vertical to the floor. Fig. 4.
Drill and attach Connector Bolts (15) and Acorn
Nuts (16) for top of Wheel Assembly (10). Bottom
attaches with a 9/64" pilot hole and a Pan Head
Screw (14).
*notincludedinkit
Fig.3
Fig.4
Fig.5
9
5
4
10
7
86
Rail
Rail
Note: Step Rods (11), Cap Nuts (12) and Washer
Head Screws (13) will not be used for Cast
Step Ladders.
Cast Metal Step Ladder Assembly
