UT- 2
COMMUNICATION INTERFACE
v3.1
INSTALLER MANUAL

UT-2 v3.1 EN Rev.C.doc 2007-10-18
-2 -
GENERAL DESCRIPTION
The UT-2 operates as an electrical converter betweenRS232 and RS485 communication
interfaces, it can be used for programming of single PR series access controller or for
management of a networked access system RACS (Roger Access Control System). The
UT-2 is delivered in black plastic case and offers three signalization LEDs. The UT-2 is
equipped with 1.5m cable terminated with DB-9 connector which is dedicated for
connection to PC, connection with an access system or individual controller is carried out
through screw terminals.
RS485 TRANSMISSION CONTROL
Normally, the UT-2 operates in receive mode, it means that all data received by UT-2
through RS485 lines is shifted immediately to RS232 serial interface. With the first byte of
data received from RS232, the UT-2 immediately switches the RS485 interface (lines A
and B) into transmit mode. The RS485 remains in that mode as long as data is received
through RS232. The RS485 returns automatically to receive mode after 1.5 ms time from
the moment when last bit of data has been received from RS232.
Note: The method which is used for RS485 transmission control is developed for PR series
of access controllers from Roger. Optionally, the UT-2 can be used in other application
which require RS232-RS485 conversion but in such cases installer must perform adequate
tests to ensure that UT-2 will operate satisfactory in given applications.
RTS AND CTS LINES
Generally, the RTS and CTS lines are dedicated to improve communication between
managing computer and access systems which are equipped with CPR32-SE. The use of
RTS and CTS lines in such systems is not obligatory and may be omitted. When used both
lines must be connected to adequate input and output of CPR32-SE network controller.
Note: The use of RTS and CTS lines requires PR Master v4.3 and CPR32-SE v30 or
higher.
LED INDICATIONS
The UT-2 is equipped with three LEDs which functions are characterized below.
LED Symbol Color Function
POWER Amber Power supply
TXD Green Data send to RS485 comm. Bus
RXD Red Data received from RS485 comm. bus
INSTALLATION
Locate interface close to PC computer (max. distance is 15m) in a dry area, all electrical
connections must be made with power supply off. UT-2 requires 12VDC supply and up to
150mA current. Interface can be supplied from any device installed in access system
which offer DC supply output or from separate supply source. Note, that supply minus of
UT-2 must have the same potential,in respect to earth,as other devices connected to the
same RS485 bus. This condition can be assured by means of additional wire which will
connect all supply minuses in a system or by adequate grounding arrangements. The UT-2
can be connected to RS485 communication bus in any, arbitrary selected location. The
topology of RS485 communication bus in RACSsystem is free and may incorporate tree,
Notes
No. Fault description
(filled out by the customer) Date of repair (filled out by the
service)
1.
2.
3.
4.
5.

1. Any product returned to ROGER must have an RMA number. ROGER will refuse anypackage
that is returned without a valid RMA number.
2. ROGER products cannot be returned for any reason other than defective
3. Defective products will only be accepted in accordance with the ROGER`s
warranty requirements.
4. All RMA numbers will be valid for a period of not longer than 14 days.
Any package send to ROGER after 14 days of issuance will be refused and shipped back to you
at additional cost.
5. If you purchased Roger product not directly from Roger company, please return it to the place
where you bought it.
6. In order to receive RMA number please fill out the following form.
7. Once the completed form has been received and processed it will be returned to you with a RMA
number appended. This is your authority to return the product.
8. Please ensure that this document accompanies the product when it is returned and that a copy is
retained such that you can refer to it when requesting an update on the progress of a repair.
9. Use one RMA number per one returned product.
10. Put your RMA number on the shipping/address label
11. Please make sure that you always return product in appropriate packaging together with a RMA
formin order to avoid damages during transit, You are advised to get proof of delivery
12. Some repairs may be chargeable and you will receive formal advice if this is the case.
13. If product returned as defective is found not to be defective, it will be returned back to the
customer at his expenses. In that case the customer will be also charged with costs which may
arise after triggering the RMA procedure.
14. If the product is beyond economical repair then the following options will be given:
Scrapped –This will occur automatically if ROGER does not receive a reply to three notices send to
the customer at least in 5 days interval.
(Theremay be some exceptions to this) or if you instruct us during these communications.
Returned – However this will incur shipping charges.
Note: All repairs are dealt with as rapidly as possible although repair time is not guaranteed. Please
contact us and we will try our best to suggest an estimated lead-time.
Please note:
In the unlikely event you experience difficulties with your
ROGER product, please contact ROGER’s Technical
Support Department to resolve the problem.
They may be reached at [phone] or
[e-mail] Monday through Friday 8:00 A.M. to
4:00 P.M. (GMT + 1).
You can also contact the Technical Support Department by
fax at [phone].
If it is determined that you need to return the product, the
followingprocedure must be followed to ensure prompt
service.
UT-2 v3.1 EN Rev.C.doc 2007-10-18
-3 -
star or any combination of them. Also, no terminating resistors are required on the ends of
communication bus.
Note: Some PC computers with Windows operating system may detect the UT-2 unit as
Microsoft BallPoint or similar pointing device. Such a faulty detection leads to problem
with computer mouse and finally corrupts computer operation entirely. In order to fix this
problem installer should enter Windows Device Manager and switch off detection of
mentioned pointing device.
EXTENDING COMMUNICATION DISTANCE
The UT-2 may be used for successful communication on distances up to 1200m. When
longer distance is required a UT-3 interface can be used. The use of two UT-3 interfaces
creates communication link and extends communication distance by next 1200m. For
communication between access networks or controllers located in different buildings or
even cites the UT-4 interface can be used. The UT-4 interface enables communication
with access controller(s) or entire access networks through 100/10BaseT Ethernet network
with TCP/IP communication protocol.
Ordering
UT-2 UT-2 interface with plastic case and 1.5m cable to PC
History
UT-2 v3.0 The RTS and CTS control lines to CPR network controller added.
UT-2 v3.1 The polarity of RTS and CTS line to CPR network controller reversed, low
level on RTS and CTS is now an active state.
Connection terminals assignments
Name Function
GND Supply minus
+12V Supply plus
SHLD RS485 cable shield
A RS485 interface, line A
B RS485 interface, line B
RTS RTS line to CPR32-SE network controller
CTS
RS485
CTS line to CPR32-SE network controller
GND RS232 interface, ground
TXD RS232 interface, line TXD
RTS RS232 interface, line RTS
RXD RS232 interface, line RXD
CTS RS232 interface, line CTS
SHLD
RS232
RS232 cable shield

UT-2 v3.1 EN Rev.C.doc 2007-10-18
-4 -
Technical specification
Power supply 10...15VDC
Average current consumption ~ 60mA
Maximum current consumption ~ 150mA
Operating temp. range 0...+55º C.
Max. communication distance for RS232 15m
Max. communication distance for RS485 1200m
Relative humidity 10 to 95% (without condensation)
Dimensions 100 x 68 x 35 mm
Weight ~80g
The symbol of a crossed-through waste bin on wheels means that the product
must be disposed of at a separate collection point. This also applies to the
product and all accessories marked with this symbol. Products labeled as such
must not be disposed of with normal household waste, but should be taken to
a collection point for recycling electrical and electronic equipment. Recycling
helps to reduce the consumption of raw materials, thus protecting the environment.
RMA Form
Customer information:
Company Name: …………………………………………
Contact Name: …………………………………………..
Street: …………………………………………………….
Code, City: ……………………………………………….
Country: …………………………………………………..
E-mail: …………………………………………………….
Contact phone: …………………………………………..
Fax: ………………………………………………………..
Product information:
Product Name: …………………………………………
Serial Number: ………………………………………..
Date of Purchase: …………………………………….
Reason for return:
Warrantyrepair:
Repair:
Complaint:
Wrong delivery:
Others: …………………………………………….
………………………………………………………
(please specify)
Please note:
In the unlikely event you experience difficulties with your
ROGER product, please contact ROGER’s Technical
Support Department to resolve the problem.
They may be reached at [phone] or
[e-mail] Monday through Friday 8:00 A.M. to
4:00 P.M. (GMT + 1). You can also contact the Technical
Support Department by fax at [phone].
If it is determined that you need to return the product, the
following procedure must be followed to ensure prompt
service.
ROGER Sp.j.
Gosciszewo 59,
82-416 Gosciszewo,
pomorskie, Poland
Tel.: [phone]
Fax: [phone]
Tech. Support: [phone]
http://www.roger.pl
RMA no.
_______________________________
Fault description
:
what does not work, what is the reason for
complaint, what can ROGER do for you ?
……………………………………….…….……..…..
...………………..……………………………..……
……….….………..…………….……..…….…..……
……………….……………..…………………………
……….…………..………….……….……….………
………………..……………..……....………………
…………………..…….……………........................
………………………………………...…….………
…….…………………………..…..…………………
………….…………………………
...
…..……………

UT-2 v3.1 EN Rev.C.doc 2007-10-18
-5 -

UT-2 v3.1 EN Rev.C.doc 2007-10-18
-6 -
