Roger UT-2USB User guide

Communication Interface
UT-2USB v1.0
Installer Manual

UT-2USB v1.0 EN Rev.D.doc 2009-02-19
Strona 2 z 12
General Description
The UT-2USB is a cost-effective module, that allows you to connect your serial RS485
devices (bus) to computer using a USB interface. It features various transmission rates
(half duplex) from 0 kbit/s to 115.2 kbit/s and doesn’t need any power supply. The UT-
2USB is delivered with 1m USB A-B cable required for communication with PC. The
connectivity with RS485 bus is carried out through screw terminals.
Although the UT-2USB converter was designed and tested for Roger Access Control
System (RACS), anyway it can be used with other applications requiring the high speed
(half duplex) serial communications port however in such cases installer must perform
adequate tests to ensure that UT-2USB will operate satisfactory in given application. UT-
2USB interface can be used for programming of a single PR access controller or for
management of a networked access system. Each adapter comes in a black plastic case
intended for wall mounting and has two LEDs which indicate data flow through RS485
and one LED for power supply.
The installation of UT-2USB requires two steps: first to make appropriate electrical
connections, second to install driver on PC. The UT-2USB driver creates a Virtual COM
Port (VSP-Virtual Serial Port or VCP-Virtual Com Port) within the operating system.
Properties
Power supply
The module derives the power from the USB port and doesn’t need any external power
source.
RS485 Transmission Control
The data transfer on RS485 is automatically done by the converter. Normally, the UT-
2USB operates in receive mode, which means that all data received by UT-2USB through
RS485 lines are shifted to PC. With the first byte of data received from PC, the UT-2USB
switches the RS485 interface (lines A and B) into transmit mode. The RS485 remains in
that mode as long as data is transmitted from PC to RS485, once the PC stops
transmission the RS485 lines returns automatically to receive mode.
RTS and CTS Lines
Generally, the RTS and CTS lines are dedicated to improve communication between
managing computer and RACS access systems which operate with CPR32-SE. The use of
RTS and CTS lines in such systems is not obligatory and may be omitted. The RTS and
CTS control lines are mostly used with access networks containing 16 or more
controllers. When used, both lines must be connected to adequate input and output of
the CPR32-SE network controller.
Note: The RTS and CTS control lines are supported by PR Master v4.3 and CPR32-SE
v3.0 or higher.
Electrically, the RTS and CTS lines are adjusted to CPR32-SE v3.0 I/O standards (RTS
active state is represented by ground voltage level, whereas line voltage above ~4,5 V or
line floating keeps line inactive).

UT-2USB v1.0 EN Rev.D.doc 2009-02-19
Strona 3 z 12
LED Indications
LED Symbol Color Function
POWER Amber Power supply
TXD Green Data send to RS485 comm. bus
RXD Red Data received from RS485 comm. bus
Interface Installation
Firstly, a driver installation is required within the operating system to create Virtual COM
Port. The UT-2USB interface should be connected to the PC USB port only after driver
installation (drivers can be download from www.roger.pl ).
The UT-2USB supports Windows 98, Me, XP, VISTA, Windows Server 2003, Linux (kernel
2.4.20 or later), Apple Mac OS 8, 9, Mac OS X.
Install the interface in a dry area, all electrical connections should be carry out while
interface is unplugged from the USB port. For connection with PC use the USB A-B cable
(delivered with package).
Note: Do not modify USB A-B cable, it is not allowed to cut this cable or extend it with
help of others wires inappropriate for USB transmission. It is allowed to use a special
USB extension cord, but the total USB cable length may not be longer than 5 meters.
The UT-2USB can be connected to RS485 communication bus in any, arbitrary selected,
location. The topology of RS485 communication bus in RACS system is free and may
incorporate tree, star or any combination of them. Also, no terminating resistors are
required on the ends of communication bus. Please note, that distance between UT-2USB
and CPR control panel or any controller may not exceed 1200m.
Extending Communication Distance
The UT-2USB may be used for successful communication on distances up to 1200m.
When longer distance is required a UT-3 interface can be used. The use of two UT-3
interfaces creates communication link and extends communication distance by next
1200m. For communication between access networks or controllers located in different
buildings or cities the UT-4 interface can be used. The UT-4 interface enables
communication with access controller(s) or access networks through 100/10BaseT
Ethernet network with TCP/IP communication protocol.
Connection Terminals Assignments
Name Function
CTS
For RACS
CTS line to CPR32-SE network controller (optional for PR Master 4.3)
RTS RTS line to CPR32-SE network controller (optional for PR Master 4.3)
A RS485 interface, line A
B RS485 interface, line B
GND RS485 interface, ground
SHLD RS485 cable shield

UT-2USB v1.0 EN Rev.D.doc 2009-02-19
Strona 4 z 12
Technical Specification
Power supply 5 VDC direct from USB Port
Average current consumption 40 mA
Operating temp. range 0...+55º C.
Communication speed 0-115.2 kbit/s
Max. communication distance for
USB 5 meters
Max. communication distance for
RS485 1200 meters
Relative humidity 10 to 95% (without condensation)
Dimensions 68 x 45 x 23 mm
Weight ~ 35g
Ordering
UT-2USB Interface with black plastic case, 1m USB A-B cable
History
UT-2USB v1.0 Initial product version
Contact
Roger sp. j.
82-416 Gościszewo
Gościszewo 59
Tel.: [phone]
Fax: [phone]
The symbol of a crossed-through waste bin on wheels means that the product
must be disposed of at a separate collection point. This also applies to the
product and all accessories marked with this symbol. Products labeled as such
must not be disposed of with normal household waste, but should be taken to
a collection point for recycling electrical and electronic equipment. Recycling helps to
reduce the consumption of raw materials, thus protecting the environment.

UT-2USB v1.0 EN Rev.D.doc 2009-02-19
Strona 5 z 12

UT-2USB v1.0 EN Rev.D.doc 2009-02-19
Strona 6 z 12

RMA Form
