Rohde & Schwarz EVSG1000 User manual

R&S®EVSG1000
VHF/UHF Airnav/Com
Analyzer
Getting Started
Getting Started
Version 04
1329872102
(=MåE2)

This document describes the following R&S®EVSG1000 models with firmware
version 1.40 or later:
●R&S®EVSG1000 (1329.8009.02)
Furthermore, it covers the following options:
●R&S®EVSG-B1 Second Signal Processing Unit (1329.8809.02)
●R&S®EVSG-B2 Battery Management (1329.8815.02)
●R&S®EVSG-B3 Battery Pack (1329.8821.02)
●R&S®EVSG1-K7 LF-Analysis (1329.9163.02)
●R&S®EVSG-K20 GPS Support (1329.9092.02)
© 2020 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1329.8721.02 | Version 04 | R&S®EVSG1000
The following abbreviations are used throughout this manual: R&S®EVSG1000 is abbreviated as
R&S EVSG1000.

Contents
R&S®EVSG1000
3Getting Started 1329.8721.02 ─ 04
Contents
1 Safety Information................................................................. 7
1.1 Safety Instructions................................................................................7
1.2 Labels on the Product........................................................................ 11
1.3 Warning Messages in the Documentation........................................12
2 Documentation Overview....................................................13
2.1 Getting Started Manual.......................................................................13
2.2 User Manuals and Help...................................................................... 13
2.3 Printed Safety Instructions................................................................ 13
2.4 Data Sheets and Brochures............................................................... 13
2.5 Release Notes and Open-Source Acknowledgment (OSA)............ 14
3 Key Features........................................................................ 15
4 Preparing for Use.................................................................16
4.1 Unpacking and Checking................................................................... 16
4.2 Lifting and Carrying............................................................................16
4.3 Choosing the Operating Site............................................................. 17
4.4 Setting Up the R&S EVSG1000.......................................................... 17
4.4.1 Placing the R&S EVSG1000 on a Bench Top.......................................18
4.4.2 Mounting the R&S EVSG1000 in a Rack..............................................18
4.4.3 Portable Operation................................................................................19
4.5 Connecting to Power.......................................................................... 20
4.5.1 Connecting the Provided AC/DC Power Supply Connector..................20
4.5.2 Connecting an External DC Power Source...........................................21
4.5.3 Using an Optional Battery Pack (R&S EVSG-B3).................................21
4.6 Switching On or Off............................................................................ 22

Contents
R&S®EVSG1000
4Getting Started 1329.8721.02 ─ 04
4.7 Performing an Auto-Calibration........................................................ 24
4.8 Connecting Devices for Signal Input and Output............................ 25
4.9 Connecting to LAN............................................................................. 25
5 Instrument Tour................................................................... 27
5.1 Front Panel.......................................................................................... 27
5.1.1 Power Key.............................................................................................28
5.1.2 Display.................................................................................................. 28
5.1.3 RX1 IN / RX2 IN....................................................................................28
5.1.4 USB.......................................................................................................29
5.1.5 AF Out...................................................................................................29
5.1.6 12 V DC Out..........................................................................................29
5.1.7 System Keys......................................................................................... 29
5.1.8 Softkeys................................................................................................ 30
5.1.9 Function Keys....................................................................................... 30
5.1.10 Keypad..................................................................................................31
5.1.11 Rotary Knob.......................................................................................... 31
5.1.12 Navigation Keys.................................................................................... 32
5.2 Rear Panel........................................................................................... 33
5.2.1 Power Supply........................................................................................34
5.2.2 Li-Ion Battery Pack................................................................................34
5.2.3 LAN (Ethernet)...................................................................................... 34
5.2.4 RS232 GPS.......................................................................................... 35
5.2.5 PPS In...................................................................................................35
5.2.6 Trigger In...............................................................................................35
5.2.7 LF In (Baseband/Low Frequency Input)................................................35
5.2.8 Demod Out............................................................................................35
5.2.9 Loudspeaker......................................................................................... 35

Contents
R&S®EVSG1000
5Getting Started 1329.8721.02 ─ 04
5.2.10 Device ID.............................................................................................. 36
5.3 Accessories.........................................................................................36
6 Operating Basics................................................................. 40
6.1 Understanding the Display Information............................................40
6.2 Manual Operation................................................................................42
6.2.1 Changing Settings and Activating Functions........................................ 43
6.2.2 Entering Data........................................................................................ 43
6.2.3 Getting Help.......................................................................................... 45
6.3 Manual Operation from a VNC Viewer...............................................48
6.4 Remote Control................................................................................... 50
7 Contacting Customer Support........................................... 51
Index..................................................................................... 52

Contents
R&S®EVSG1000
6Getting Started 1329.8721.02 ─ 04

Safety Information
R&S®EVSG1000
7Getting Started 1329.8721.02 ─ 04
1 Safety Information
The product documentation helps you use the product safely and efficiently. Fol-
low the instructions provided here and in the Chapter 1.1, "Safety Instructions",
on page 7.
Intended use
The product is intended for maintenance and servicing of ILS, VOR and marker
beacon ground stations and analyzing ATC COM signals. The portable, robust
design and the integrated battery allow for network-independent measurements
also outdoors. Use the product only for its designated purpose. Observe the oper-
ating conditions and performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you of potential
dangers and gives instructions on how to prevent personal injury or damage
caused by dangerous situations. Safety information is provided as follows:
●In Chapter 1.1, "Safety Instructions", on page 7. The same information is
provided in many languages as printed "Safety Instructions". The printed
"Safety Instructions" are delivered with the product.
●Throughout the documentation, safety instructions are provided when you
need to take care during setup or operation.
1.1 Safety Instructions
Products from the Rohde & Schwarz group of companies are manufactured
according to the highest technical standards. To use the products safely, follow
the instructions provided here and in the product documentation. Keep the prod-
uct documentation nearby and offer it to other users.
Use the product only for its intended use and within its performance limits. Inten-
ded use and limits are described in the product documentation such as the data
sheet, manuals and the printed safety instructions. If you are unsure about the
appropriate use, contact Rohde & Schwarz customer service.
Safety Instructions

Safety Information
R&S®EVSG1000
8Getting Started 1329.8721.02 ─ 04
Using the product requires specialists or specially trained personnel. These users
also need sound knowledge of at least one of the languages in which the user
interfaces and the product documentation are available.
If any part of the product is damaged or broken, stop using the product. Never
open the casing of the product. Only service personnel authorized by
Rohde & Schwarz are allowed to repair the product. Contact Rohde & Schwarz
customer service at http://www.customersupport.rohde-schwarz.com.
Lifting and carrying the product
The maximum weight of the product is provided in the data sheet. To move the
product safely, you can use lifting or transporting equipment such as lift trucks
and forklifts. Follow the instructions provided by the equipment manufacturer.
Choosing the operating site
Only use the product indoors. The product casing is not waterproof. Water that
enters can electrically connect the casing with live parts, which can lead to elec-
tric shock, serious personal injury or death if you touch the casing. If
Rohde & Schwarz provides a carrying bag designed for your product, you can
use the product outdoors.
Unless otherwise specified, you can operate the product up to an altitude of
2000 m above sea level. The product is suitable for pollution degree 2 environ-
ments where nonconductive contamination can occur. For more information on
environmental conditions such as ambient temperature and humidity, see the
data sheet.
Setting up the product
Always place the product on a stable, flat and level surface with the bottom of the
product facing down. If the product is designed for different positions, secure the
product so that it cannot fall over.
If the product has foldable feet, always fold the feet completely in or out to ensure
stability. The feet can collapse if they are not folded out completely or if the prod-
uct is moved without lifting it. The foldable feet are designed to carry the weight of
the product, but not an extra load.
If stacking is possible, keep in mind that a stack of products can fall over and
cause injury.
If you mount products in a rack, ensure that the rack has sufficient load capacity
and stability. Observe the specifications of the rack manufacturer. Always install
Safety Instructions

Safety Information
R&S®EVSG1000
9Getting Started 1329.8721.02 ─ 04
the products from the bottom shelf to the top shelf so that the rack stands
securely. Secure the product so that it cannot fall off the rack.
Connecting to power
The product is an overvoltage category II product and has to be connected to a
fixed installation used to supply energy-consuming equipment such as household
appliances and similar loads. Be aware that electrically powered products have
risks, such as electric shock, fire, personal injury or even death.
Take the following measures for your safety:
●Before switching on the product, ensure that the voltage and frequency indica-
ted on the product match the available power source. If the power adapter
does not adjust automatically, set the correct value and check the rating of the
fuse.
●If a product has an exchangeable fuse, its type and characteristics are indica-
ted next to the fuse holder. Before changing the fuse, switch off the instrument
and disconnect it from the power source. How to change the fuse is described
in the product documentation.
●Only use the power cable delivered with the product. It complies with country-
specific safety requirements. Only insert the plug into an outlet with protective
conductor terminal.
●Only use intact cables and route them carefully so that they cannot be dam-
aged. Check the power cables regularly to ensure that they are undamaged.
Also ensure that nobody can trip over loose cables.
●If the product needs an external power supply, use the power supply that is
delivered with the product or that is recommended in the product documenta-
tion or a power supply that conforms to the country-specific regulations.
●Only connect the product to a power source with a fuse protection of maxi-
mum 20 A.
●Ensure that you can disconnect the product from the power source at any
time. Pull the power plug to disconnect the product. The power plug must be
easily accessible. If the product is integrated into a system that does not meet
these requirements, provide an easily accessible circuit breaker at the system
level.
Cleaning the product
Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that
the casing is not waterproof. Do not use liquid cleaning agents.
Safety Instructions

Safety Information
R&S®EVSG1000
10Getting Started 1329.8721.02 ─ 04
Meaning of safety labels
Safety labels on the product warn against potential hazards.
Potential hazard
Read the product documentation to avoid personal injury or product damage.
Electrical hazard
Indicates live parts. Risk of electric shock, fire, personal injury or even death.
Hot surface
Do not touch. Risk of skin burns. Risk of fire.
Protective conductor terminal
Connect this terminal to a grounded external conductor or to protective ground. This
protects you against electric shock should an electric problem occur.
Handling batteries safely
The product contains lithium polymer or lithium ion cells or batteries. The use of
the word battery in the following always means all types. Only the battery con-
tents are potentially hazardous. As long as a battery is undamaged and the seals
remain intact, there is no danger.
Impact, shock or heat can cause damage such as dents, punctures and other
deformations. A damaged battery poses a risk of personal injury. Handle a dam-
aged or leaking battery with extreme care. Immediately ventilate the area since
the battery releases harmful gases. If you come into contact with the battery fluid,
immediately remove all contaminated clothing. Irritation can occur if the battery
fluid comes in contact with your skin or eyes. Immediately and thoroughly rinse
your skin or eyes with water and seek medical aid.
For safe handling, follow these rules:
●Do not short-circuit the battery.
●Do not mechanically damage the battery. Do not open or disassemble the bat-
tery.
●Do not expose the battery to high temperatures such as open flames, hot sur-
faces and sunlight.
●Only use the battery with the designated Rohde & Schwarz product.
●Only use the appropriate Rohde & Schwarz charger to charge the batteries. If
the batteries are improperly charged, there is a risk of explosion. For charging
and discharging temperature ranges, see the product documentation.
Safety Instructions

Safety Information
R&S®EVSG1000
11Getting Started 1329.8721.02 ─ 04
●Store the battery at room temperature (approximately 20 °C) enclosed in the
original packaging.
●Dispose of batteries separately from normal household waste as specified by
the local waste disposal agency.
If you disregard these rules, you risk serious personal injury or even death due to
explosion, fire or hazardous chemical substances. The product documentation
provides further details.
When replacing a defective battery, only use the same Rohde & Schwarz battery
type. When returning batteries to Rohde & Schwarz subsidiaries, choose a carrier
qualified to transport dangerous goods and follow the carrier’s transport stipula-
tions in line with IATA-DGR, IMDG-Code, ADR or RID. If you need assistance,
contact the carrier or Rohde & Schwarz customer service.
Connecting headphones
Take the following measures to prevent hearing damage. Before using head-
phones, check the volume and reduce it if necessary. If you monitor varying sig-
nal levels, take off the headphones and wait until the signal has settled. Then
adjust the volume.
1.2 Labels on the Product
Labels on the casing inform about:
●Personal safety, see "Meaning of safety labels" on page 10
●Product and environment safety, see Table 1-1
Table 1-1: Labels regarding product and environment safety
Labeling in line with EN 50419 for disposal of electrical and electronic equipment after
the product has come to the end of its service life.
For more information, see the R&S EVSG1000 user manual, chapter "Disposal".
Labeling in line with directive 2006/66/EC for disposal of batteries after they have come
to the end of their service life.
For more information, see the R&S EVSG1000 user manual, chapter "Disposal".
Labels on the Product

Safety Information
R&S®EVSG1000
12Getting Started 1329.8721.02 ─ 04
1.3 Warning Messages in the Documentation
A warning message points out a risk or danger that you need to be aware of. The
signal word indicates the severity of the safety hazard and how likely it will occur
if you do not follow the safety precautions.
CAUTION
Potentially hazardous situation
Could result in minor or moderate injury if not avoided.
NOTICE
Potential risks of damage
Could result in damage to the supported product or to other property.
Warning Messages in the Documentation

Documentation Overview
R&S®EVSG1000
13Getting Started 1329.8721.02 ─ 04
2 Documentation Overview
This section provides an overview of the R&S EVSG1000 user documentation.
You find it on the product page at:
www.rohde-schwarz.com/manual/EVSG1000
2.1 Getting Started Manual
Introduces the R&S EVSG1000 and describes how to set up and start working
with the product. A printed version is delivered with the instrument.
2.2 User Manuals and Help
Contains the description of all instrument modes and functions. It also provides
an introduction to remote control, a complete description of the remote control
commands with programming examples, and information on maintenance, instru-
ment interfaces and error messages. Includes the contents of the getting started
manual.
The contents of the user manual are also available as online help on the
R&S EVSG1000.
2.3 Printed Safety Instructions
Provides safety information in many languages. The printed document is deliv-
ered with the product.
2.4 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S EVSG1000. It
also lists the firmware applications and their order numbers, and optional acces-
sories.
Data Sheets and Brochures

Documentation Overview
R&S®EVSG1000
14Getting Started 1329.8721.02 ─ 04
The brochure provides an overview of the instrument and deals with the specific
characteristics.
See www.rohde-schwarz.com/brochure-datasheet/evsg/
2.5 Release Notes and Open-Source Acknowledg-
ment (OSA)
The release notes list new features, improvements and known issues of the cur-
rent firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of
the used open source software.
See www.rohde-schwarz.com/software/EVSG1000.
Release Notes and Open-Source Acknowledgment (OSA)

Key Features
R&S®EVSG1000
15Getting Started 1329.8721.02 ─ 04
3 Key Features
The R&S EVSG1000 offers the following key features:
●Detailed analysis of ILS, VOR and Marker Beacon ground measurements
(based on ICAO Doc. 8071 and ICAO Annex 10)
●Spectrum preview and detailed signal analysis in frequency and time range
●Dynamic measurements up to 100 measurements per second in high mea-
surement rate modus
●Parallel course and clearance signal analysis in two-frequency systems (ILS)
●Simple remote operation via standard interfaces
●Software options for specific use cases
●Integrated data recording

Preparing for Use
R&S®EVSG1000
16Getting Started 1329.8721.02 ─ 04
4 Preparing for Use
This chapter describes the basic steps to be taken when setting up the product
for the first time.
●Unpacking and Checking................................................................................ 16
●Lifting and Carrying......................................................................................... 16
●Choosing the Operating Site........................................................................... 17
●Setting Up the R&S EVSG1000...................................................................... 17
●Connecting to Power.......................................................................................20
●Switching On or Off......................................................................................... 22
●Performing an Auto-Calibration.......................................................................24
●Connecting Devices for Signal Input and Output............................................ 25
●Connecting to LAN.......................................................................................... 25
4.1 Unpacking and Checking
1. Unpack the R&S EVSG1000 carefully.
2. Retain the original packing material. Use it when transporting or shipping the
product later.
3. Using the delivery notes, check the equipment for completeness.
The instrument comes with the following accessories:
● AC/DC power supply connector with cable
● Printed Getting Started manual
4. Check the equipment for damage.
If the delivery is incomplete or equipment is damaged, contact
Rohde & Schwarz.
4.2 Lifting and Carrying
The carrying handle is designed to lift or carry the instrument. Do not apply
excessive external force to the handle.
Lifting and Carrying

Preparing for Use
R&S®EVSG1000
17Getting Started 1329.8721.02 ─ 04
See "Lifting and carrying the product" on page 8.
4.3 Choosing the Operating Site
The R&S EVSG1000 can be operated in a variety of places without detrimental
effects on its features. Even the movement caused by transportation or mobile
use does not impair its functioning.
Specific operating conditions ensure accurate measurements and avoid damage
to the product and connected devices. For information on environmental condi-
tions such as ambient temperature and humidity, see the data sheet.
See also "Choosing the operating site" on page 8.
Electromagnetic compatibility classes
The electromagnetic compatibility (EMC) class indicates where you can operate
the product. The EMC class of the product is given in the data sheet under "Gen-
eral data".
●Class B equipment is suitable for use in:
– Residential environments
– Environments that are directly connected to a low-voltage supply network
that supplies residential buildings
●Class A equipment is intended for use in industrial environments. It can cause
radio disturbances in residential environments due to possible conducted and
radiated disturbances. It is therefore not suitable for class B environments.
If class A equipment causes radio disturbances, take appropriate measures to
eliminate them.
4.4 Setting Up the R&S EVSG1000
The R&S EVSG1000 is designed for use either on a bench top or in a rack, or as
a portable instrument (with optional battery operation) in a transport bag in the
field.
See also:
●"Setting up the product" on page 8
Setting Up the R&S EVSG1000

Preparing for Use
R&S®EVSG1000
18Getting Started 1329.8721.02 ─ 04
●"Intended use" on page 7
4.4.1 Placing the R&S EVSG1000 on a Bench Top
To place the R&S EVSG1000 on a bench top
1. Place the R&S EVSG1000 on a stable, flat and level surface. Ensure that the
surface can support the weight of the instrument. For information on the
weight, see the data sheet.
2. CAUTION! The instrument can fall over and cause injury. The top surface is
not designed for stacking. Never stack another instrument on top of the
R&S EVSG1000.
As an alternative, you can mount several instruments in a rack.
3. NOTICE! Overheating can damage the product.
Prevent overheating as follows:
● Keep a minimum distance of 10 cm between the fan openings of the
R&S EVSG1000 and any object in the vicinity.
● Do not place the R&S EVSG1000 next to heat-generating equipment such
as radiators or other products.
4.4.2 Mounting the R&S EVSG1000 in a Rack
A 19"-adapter is available as an accessory (R&S EVSG-Z7) to mount the
R&S EVSG1000 in a 19'' rack (e.g. in a measurement vehicle).
To prepare the rack
1. Observe the requirements and instructions in "Setting up the product"
on page 8.
Setting Up the R&S EVSG1000

Preparing for Use
R&S®EVSG1000
19Getting Started 1329.8721.02 ─ 04
2. NOTICE! Insufficient airflow can cause overheating and damage the product.
Design and implement an efficient ventilation concept for the rack.
To mount the R&S EVSG1000 in a rack
1. Use the adapter kit R&S EVSG-Z7 to prepare the R&S EVSG1000 for rack
mounting.
a) Order the rack adapter kit designed for the R&S EVSG1000. For the order
number, see the data sheet.
b) Mount the adapter kit. Follow the assembly instructions provided with the
adapter kit.
2. Lift the R&S EVSG1000 to shelf height.
3. Grab the handles and push the product onto the shelf until the rack brackets
fit closely to the rack.
4. Tighten all screws in the rack brackets with a tightening torque of 1.2 Nm to
secure the R&S EVSG1000 in the rack.
To unmount the R&S EVSG1000 from a rack
1. Loosen the screws at the rack brackets.
2. Remove the R&S EVSG1000 from the rack.
3. If placing the R&S EVSG1000 on a bench top again, unmount the adapter kit
from the R&S EVSG1000. Follow the instructions provided with the adapter
kit.
4.4.3 Portable Operation
The R&S EVSG1000 was designed as a portable, robust instrument that can also
be operated outdoors.
An optional weather protection carrying bag (R&S EVSG-Z1, see Chapter 5.3,
"Accessories", on page 36) designed specifically for the R&S EVSG1000 allows
you to protect the instrument while working in the field. The bag includes ventila-
tion areas at the position of the ventilation outlets in the casing to ensure air circu-
lation. The transparent cover allows you to operate the instrument without remov-
ing it from the bag. Together with the optional battery pack (see Chapter 4.5.3,
"Using an Optional Battery Pack (R&S EVSG-B3)", on page 21), and packed in
Setting Up the R&S EVSG1000

Preparing for Use
R&S®EVSG1000
20Getting Started 1329.8721.02 ─ 04
the dedicated carrying bag, the R&S EVSG1000 is ideally suited for operation
directly in the field, even in rough environments.
See also Chapter 4.2, "Lifting and Carrying", on page 16.
4.5 Connecting to Power
To ensure high mobility and flexibility while using the R&S EVSG1000, it is equip-
ped with a DC power supply connector on the rear panel of the instrument.
There are various options to supply DC power to the R&S EVSG1000:
●Using the AC/DC power supply connector provided with the R&S EVSG1000.
●Using the internal battery, if options R&S EVSG-B2 and R&S EVSG-B3 are
installed.
●Using an external DC power source with a voltage of 10 V DC to 28 V DC and
a current of 3.0 A.
For safety information, see "Connecting to power" on page 9.
●Connecting the Provided AC/DC Power Supply Connector............................20
●Connecting an External DC Power Source..................................................... 21
●Using an Optional Battery Pack (R&S EVSG-B3)...........................................21
4.5.1 Connecting the Provided AC/DC Power Supply Connector
To operate the R&S EVSG1000 on a 230 V AC power supply, use only the provi-
ded AC/DC power supply connector.
1. Connect the DC connector on the provided AC/DC power supply connector to
the Power Supply connector on the back of the R&S EVSG1000 (see Chap-
ter 5.2.1, "Power Supply", on page 34).
2. Plug the AC power cable into the AC/DC power supply connector. Only use
the AC power cable delivered with the R&S EVSG1000.
The required ratings are listed next to the AC power connector and in the data
sheet.
3. Plug the AC power cable into a two-pin power outlet with ground contact.
The green operating LED of the AC/DC power supply connector lights up.
Connecting to Power
