Rohde & Schwarz FPL1000 Series User manual

R&S®FPL1000
Spectrum Analyzer
Getting Started
Getting Started
Version 07
1323160202
(=G@22)

This manual applies to the following R&S®FPL1000 models with firmware version
1.50 and higher:
●R&S®FPL1003 (1304.0004K03) - FPL1000 with maximum frequency 3 GHz
●R&S®FPL1007 (1304.0004K07) - FPL1000 with maximum frequency 7.5 GHz
In addition to the base unit, the following options are described:
●R&S FPL1-B4, OCXO (1323.1902.02)
●R&S FPL1-B5, Additional Interfaces (1323.1883.02)
●R&S FPL1-B9, Internal Generator (1323.1925Kxx)
●R&S FPL1-B10, GPIB interface (1323.1890.02)
●R&S FPL1-B22, preamplifier (1323.1719.02)
●R&S FPL1-B25, electronic attenuator (1323.1990.02)
●R&S FPL1-B30, DC power supply (1323.1877.02)
●R&S FPL1-B31, Li-Ion battery pack and charger (1323.1725.02)
●R&S FPL1-K9, Power Sensor Support (1323.1754.02)
© 2019 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Fax: [phone]
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1323.1602.02 | Version 07 | R&S®FPL1000
The following abbreviations are used throughout this manual: R&S®FPL1000 is abbreviated as
R&S FPL1000.

Contents
R&S®FPL1000
3Getting Started 1323.1602.02 ─ 07
Contents
1 Safety and Regulatory Information...................................... 7
1.1 Safety Instructions................................................................................7
1.2 Labels on R&S FPL1000..................................................................... 11
1.3 Korea Certification Class A................................................................12
2 Documentation-Overview................................................... 13
2.1 Getting Started Manual.......................................................................13
2.2 User Manuals and Help...................................................................... 13
2.3 Service Manual....................................................................................14
2.4 Instrument Security Procedures....................................................... 14
2.5 Basic Safety Instructions................................................................... 14
2.6 Data Sheets and Brochures............................................................... 14
2.7 Release Notes and Open Source Acknowledgment (OSA).............15
2.8 Application Notes, Application Cards, White Papers, etc...............15
2.9 Calibration Certificate.........................................................................15
3 Key Features........................................................................ 16
4 Preparing for Use.................................................................17
4.1 Lifting and Carrying............................................................................17
4.2 Unpacking and Checking................................................................... 17
4.3 Choosing the Operating Site............................................................. 18
4.4 Setting Up the R&S FPL1000............................................................. 18
4.5 Connecting to Power.......................................................................... 21
4.6 Switching On or Off............................................................................ 24
4.7 Connecting to LAN............................................................................. 25
4.8 Connecting a Keyboard......................................................................26

Contents
R&S®FPL1000
4Getting Started 1323.1602.02 ─ 07
4.9 Connecting an External Monitor........................................................27
4.10 Windows Operating System...............................................................29
4.11 Logging On..........................................................................................30
4.12 Checking the Supplied Options.........................................................32
4.13 Performing a Self-Alignment............................................................. 32
4.14 Considerations for Test Setup...........................................................33
5 Instrument Tour................................................................... 34
5.1 Front Panel View................................................................................. 34
5.2 Rear Panel View.................................................................................. 41
6 Trying Out the Instrument...................................................49
6.1 Measuring a Basic Signal...................................................................49
6.2 Displaying a Spectrogram..................................................................51
6.3 Activating Additional Measurement Channels.................................53
6.4 Performing Sequential Measurements............................................. 58
6.5 Setting and Moving a Marker............................................................. 59
6.6 Displaying a Marker Peak List........................................................... 61
6.7 Zooming into the Display................................................................... 62
6.8 Saving Settings................................................................................... 66
6.9 Printing and Saving Results.............................................................. 68
7 Operating the Instrument....................................................70
7.1 Understanding the Display Information - Spectrum Mode............. 70
7.2 Accessing the Functionality.............................................................. 79
7.3 Entering Data.......................................................................................82
7.4 Touchscreen Gestures....................................................................... 84
7.5 Getting Help.........................................................................................87
8 Customer Support............................................................... 89

Contents
R&S®FPL1000
5Getting Started 1323.1602.02 ─ 07
8.1 Collecting Information for Support................................................... 89
8.2 Contacting Customer Support...........................................................91
Index..................................................................................... 93

Contents
R&S®FPL1000
6Getting Started 1323.1602.02 ─ 07

Safety and Regulatory Information
R&S®FPL1000
7Getting Started 1323.1602.02 ─ 07
1 Safety and Regulatory Information
The product documentation helps you use the R&S FPL1000 safely and effi-
ciently. Follow the instructions provided here and in the Chapter 1.1, "Safety
Instructions", on page 7.
Intended use
The R&S FPL1000 is intended for the development, production and verification of
electronic components and devices in industrial, administrative, and laboratory
environments. Use the R&S FPL1000 only for its designated purpose. Observe
the operating conditions and performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you of potential
dangers and gives instructions on how to prevent personal injury or damage
caused by dangerous situations. Safety information is provided as follows:
●In Chapter 1.1, "Safety Instructions", on page 7. The same information is
provided in many languages as printed "Safety Instructions". The printed
"Safety Instructions" are delivered with the R&S FPL1000.
●Throughout the documentation, safety instructions are provided when you
need to take care during setup or operation.
1.1 Safety Instructions
Products from the Rohde & Schwarz group of companies are manufactured
according to the highest technical standards. To use the products safely, follow
the instructions provided here and in the product documentation. Keep the prod-
uct documentation nearby and offer it to other users.
Use the product only for its intended use and within its performance limits. Inten-
ded use and limits are described in the product documentation such as the data
sheet, manuals and the printed safety instructions. If you are unsure about the
appropriate use, contact Rohde & Schwarz customer service.
Using the product requires specialists or specially trained personnel. These users
also need sound knowledge of at least one of the languages in which the user
interfaces and the product documentation are available.
Safety Instructions

Safety and Regulatory Information
R&S®FPL1000
8Getting Started 1323.1602.02 ─ 07
If any part of the product is damaged or broken, stop using the product. Never
open the casing of the product. Only service personnel authorized by
Rohde & Schwarz are allowed to repair the product. Contact Rohde & Schwarz
customer service at http://www.customersupport.rohde-schwarz.com.
Lifting and carrying the product
Some products are heavy. A safety label on the casing indicates if a product
weighs more than 18 kg. To safely move the product, you can use lifting or trans-
porting equipment such as lift trucks, cranes, forklifts and hand trucks. Secure the
product, but not by its handles. Excessive force can break the handles.
Choosing the operating site
Only use the product indoors. The product casing is not waterproof and water that
enters can electrically connect the casing with live parts. This can lead to electric
shock, serious personal injury or death if you touch the casing.
Unless otherwise specified, you can operate the product up to an altitude of
2000 m above sea level. The product is suitable for pollution degree 2 environ-
ments where nonconductive contamination can occur. For more information on
environmental conditions such as ambient temperature and humidity, see the
data sheet.
Setting up the instrument
Always place the instrument on a stable, flat and level surface with the bottom of
the instrument facing down.
To save space, you can mount several instruments in a rack. If you stack instru-
ments, keep in mind that a stack of instruments can tilt over and cause injury.
If the instrument has foldable feet, always fold the feet completely in or out to
ensure stability. The feet can collapse if they are not folded out completely or if
the instrument is moved without lifting it. The foldable feet are designed to carry
the weight of the instrument, but not an extra load.
Connecting to power
The product is an overvoltage category II product and has to be connected to a
fixed installation used to supply energy-consuming equipment such as household
appliances and similar loads. Be aware that electrically powered products have
risks, such as electric shock, fire, personal injury or even death.
Safety Instructions

Safety and Regulatory Information
R&S®FPL1000
9Getting Started 1323.1602.02 ─ 07
Take the following measures for your safety:
●Before switching on the product, ensure that the voltage and frequency indica-
ted on the product match the available power source. If the power adapter
does not adjust automatically, set the correct value and check the rating of the
fuse.
●If a product has an exchangeable fuse, its type and characteristics are indica-
ted next to the fuse holder. Before changing the fuse, switch off the instrument
and disconnect it from the power source. How to change the fuse is described
in the product documentation.
●Only use the power cable delivered with the product. It complies with country-
specific safety requirements. Only insert the plug into an approved grounded
outlet.
●Only use intact cables and route them carefully so that they cannot be dam-
aged. Check the power cables regularly to ensure that they are undamaged.
Also ensure that nobody can trip over loose cables.
●If the product needs an external power supply, use the power supply that is
delivered with the product or that is recommended in the product documenta-
tion or a power supply that conforms to the country-specific regulations.
●Only connect the product to a power source with a fuse protection of maxi-
mum 20 A.
●Ensure that you can disconnect the product from the power source at any
time. Pull the power plug to disconnect the product. The power plug must be
easily accessible. If the product is integrated into a system that does not meet
these requirements, provide an easily accessible circuit breaker at the system
level.
Cleaning the product
Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that
the casing is not waterproof. Do not use liquid cleaning agents.
Meaning of safety labels
Safety labels on the product warn against potential hazards.
Safety Instructions

Safety and Regulatory Information
R&S®FPL1000
10Getting Started 1323.1602.02 ─ 07
Potential hazard
Read the product documentation to avoid personal injury or product damage.
Heavy product
Be careful when lifting, moving or carrying the product. Carrying the product requires
at least two people or transport equipment.
Electrical hazard
Indicates live parts. Risk of electric shock, fire, personal injury or even death.
Hot surface
Do not touch. Risk of skin burns. Risk of fire.
Protective conductor terminal
Connect this terminal to a grounded external conductor or to protective ground. This
protects you against electric shock should an electric problem occur.
Handling batteries safely
The product contains a Lithium ion cell or battery, both referred to as battery in
the following. It is the contents of the battery that is potentially hazardous. As long
as the battery is undamaged and the seals remain intact, there is no danger.
Impact, shock or heat can cause damage such as dents, punctures and other
deformations. A damaged battery poses a risk of personal injury. Handle a dam-
aged or leaking battery with extreme care. Immediately ventilate the area since
the battery releases harmful gases. If you come into contact with the battery fluid,
immediately remove all contaminated clothing. Irritation can occur if the battery
fluid comes in contact with your skin or eyes. Immediately and thoroughly rinse
your skin or eyes with water and seek medical aid.
For safe handling, follow these rules:
●Do not short-circuit the battery.
●Do not mechanically damage the battery. Do not open or disassemble the bat-
tery.
●Do not expose the battery to high temperatures such as open flames, hot sur-
faces and sunlight.
●Only use the battery with the designated Rohde & Schwarz product.
●Only use the appropriate Rohde & Schwarz charger to charge the batteries. If
the batteries are improperly charged, there is a risk of explosion. For charging
and discharging temperature ranges, see the product documentation.
Safety Instructions

Safety and Regulatory Information
R&S®FPL1000
11Getting Started 1323.1602.02 ─ 07
●Store the battery at room temperature (approximately 20 °C) enclosed in the
original packaging.
●Dispose of batteries separately from normal household waste as specified by
the local waste disposal agency.
If you disregard these rules, you risk serious personal injury or even death due to
explosion, fire or hazardous chemical substances. The product documentation
provides further details.
When replacing a defective battery, only use the same Rohde & Schwarz battery
type. When returning batteries to Rohde & Schwarz subsidiaries, choose a carrier
qualified to transport dangerous goods and follow the carrier’s transport stipula-
tions in line with IATA-DGR, IMDG-Code, ADR or RID. If you need assistance,
contact the carrier or Rohde & Schwarz customer service.
Connecting headphones
Take the following measures to avoid hearing damage. Before using headphones,
check the volume and reduce it if necessary. If you monitor varying signal levels,
take off the headphones and wait until the signal has settled. Then adapt the vol-
ume.
1.2 Labels on R&S FPL1000
Labels on the casing inform about:
●Personal safety, see "Meaning of safety labels" on page 9
●Product and environment safety, see Table 1-1
●Identification of the product, see Chapter 5.2.14, "Device ID", on page 47
Table 1-1: Labels regarding R&S FPL1000 and environment safety
Labeling in line with EN 50419 for disposal of electrical and electronic equipment after
the product has come to the end of its service life. For more information, see the prod-
uct user manual, chapter "Disposal".
Labeling in line with directive 2006/66/EC for disposal of batteries after they have come
to the end of their service life. For more information, see the R&S FPL1000 user man-
ual, chapter "Disposal".
Labels on R&S FPL1000

Safety and Regulatory Information
R&S®FPL1000
12Getting Started 1323.1602.02 ─ 07
1.3 Korea Certification Class A
이 기기는 업무용(A급) 전자파 적합기기로서 판매자 또는 사용자는 이 점을 주의하
시기 바라며, 가정외의 지역에서 사용하는 것을 목적으로 합니다.
Korea Certification Class A

Documentation-Overview
R&S®FPL1000
13Getting Started 1323.1602.02 ─ 07
2 Documentation-Overview
This section provides an overview of the R&S FPL1000 user documentation.
Unless specified otherwise, you find the documents on the R&S FPL1000 product
page at:
www.rohde-schwarz.com/manual/FPL1000
2.1 Getting Started Manual
Introduces the R&S FPL1000 and describes how to set up and start working with
the product. Includes basic operations, typical measurement examples, and gen-
eral information, e.g. safety instructions, etc.
A printed version is delivered with the instrument. A PDF version is available for
download on the Internet.
2.2 User Manuals and Help
Separate user manuals are provided for the base unit and the firmware applica-
tions:
●Base unit manual
Contains the description of all instrument modes and functions. It also pro-
vides an introduction to remote control, a complete description of the remote
control commands with programming examples, and information on mainte-
nance, instrument interfaces and error messages. Includes the contents of the
getting started manual.
●Firmware application manual
Contains the description of the specific functions of a firmware application,
including remote control commands. Basic information on operating the
R&S FPL1000 is not included.
The contents of the user manuals are available as help in the R&S FPL1000. The
help offers quick, context-sensitive access to the complete information for the
base unit and the firmware applications.
User Manuals and Help

Documentation-Overview
R&S®FPL1000
14Getting Started 1323.1602.02 ─ 07
All user manuals are also available for download or for immediate display on the
Internet.
2.3 Service Manual
Describes the performance test for checking the rated specifications, module
replacement and repair, firmware update, troubleshooting and fault elimination,
and contains mechanical drawings and spare part lists.
The service manual is available for registered users on the global
Rohde & Schwarz information system (GLORIS):
https://gloris.rohde-schwarz.com
2.4 Instrument Security Procedures
Deals with security issues when working with the R&S FPL1000 in secure areas.
It is available for download on the Internet.
2.5 Basic Safety Instructions
Contains safety instructions, operating conditions and further important informa-
tion. The printed document is delivered with the instrument.
2.6 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S FPL1000. It also
lists the firmware applications and their order numbers, and optional accessories.
The brochure provides an overview of the instrument and deals with the specific
characteristics.
See www.rohde-schwarz.com/brochure-datasheet/FPL1000
Data Sheets and Brochures

Documentation-Overview
R&S®FPL1000
15Getting Started 1323.1602.02 ─ 07
2.7 Release Notes and Open Source Acknowledg-
ment (OSA)
The release notes list new features, improvements and known issues of the cur-
rent firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of
the used open source software.
See www.rohde-schwarz.com/firmware/FPL1000
2.8 Application Notes, Application Cards, White
Papers, etc.
These documents deal with special applications or background information on
particular topics.
See www.rohde-schwarz.com/application/FPL1000
2.9 Calibration Certificate
The document is available on https://gloris.rohde-schwarz.com/calcert. You need
the device ID of your instrument, which you can find on a label on the rear panel.
Calibration Certificate

Key Features
R&S®FPL1000
16Getting Started 1323.1602.02 ─ 07
3 Key Features
The R&S FPL1000 sets standards in RF performance and usability. Outstanding
key features are:
One instrument for multiple applications
●Spectrum analysis
●Signal analysis of analog and digitally modulated signals
●Power measurements with power sensors
●Noise figure and gain measurements
Solid RF performance
●Low spurious response
●Low displayed average noise level (DANL)
●40 MHz signal analysis bandwidth
●Low level measurement uncertainty
●Precise spectral measurements due to low phase noise
Intuitive user interface
●High-resolution display
●Multipoint touchscreen
●Flexible arrangement of results and MultiView
●Toolbar
●Quiet operation
Fully portable
●Battery pack and 12 V/24 V power supply
●Carrying bag and shoulder harness
●Low power consumption

Preparing for Use
R&S®FPL1000
17Getting Started 1323.1602.02 ─ 07
4 Preparing for Use
This chapter describes the basic steps to be taken when setting up the
R&S FPL1000 for the first time.
●Lifting and Carrying......................................................................................... 17
●Unpacking and Checking................................................................................ 17
●Choosing the Operating Site........................................................................... 18
●Setting Up the R&S FPL1000......................................................................... 18
●Connecting to Power.......................................................................................21
●Switching On or Off......................................................................................... 24
●Connecting to LAN.......................................................................................... 25
●Connecting a Keyboard...................................................................................26
●Connecting an External Monitor......................................................................27
●Windows Operating System............................................................................29
●Logging On......................................................................................................30
●Checking the Supplied Options.......................................................................32
●Performing a Self-Alignment........................................................................... 32
●Considerations for Test Setup......................................................................... 33
4.1 Lifting and Carrying
The carrying handles are designed to lift or carry the instrument. Do not apply
excessive external force to the handles.
See "Lifting and carrying the product" on page 8.
4.2 Unpacking and Checking
1. Unpack the R&S FPL1000 carefully.
2. Retain the original packing material. Use it when transporting or shipping the
R&S FPL1000 later.
3. Using the delivery notes, check the equipment for completeness.
Unpacking and Checking

Preparing for Use
R&S®FPL1000
18Getting Started 1323.1602.02 ─ 07
4. Check the equipment for damage.
If the delivery is incomplete or equipment is damaged, contact
Rohde & Schwarz.
4.3 Choosing the Operating Site
Specific operating conditions ensure accurate measurements and avoid damage
to the R&S FPL1000 and connected devices. For information on environmental
conditions such as ambient temperature and humidity, see the data sheet.
See also "Choosing the operating site" on page 8.
Electromagnetic compatibility classes
The electromagnetic compatibility (EMC) class indicates where you can operate
the R&S FPL1000. The EMC class of the R&S FPL1000 is given in the data sheet
under "General data".
●Class B equipment is suitable for use in:
– Residential environments
– Environments that are directly connected to a low-voltage supply network
that supplies residential buildings
●Class A equipment is intended for use in industrial environments. It can cause
radio disturbances in residential environments due to possible conducted and
radiated disturbances. It is therefore not suitable for class B environments.
If class A equipment causes radio disturbances, take appropriate measures to
eliminate them.
4.4 Setting Up the R&S FPL1000
The R&S FPL1000 is designed for use either on a bench top or in a rack, or as a
portable instrument (with optional battery operation) in a transport bag in the field.
See also:
●"Setting up the instrument" on page 8
●"Intended use" on page 7
Setting Up the R&S FPL1000

Preparing for Use
R&S®FPL1000
19Getting Started 1323.1602.02 ─ 07
4.4.1 Placing the R&S FPL1000 on a Bench Top
To place the R&S FPL1000 on a bench top
1. Place the R&S FPL1000 on a stable, flat and level surface. Ensure that the
surface can support the weight of the R&S FPL1000. For information on the
weight, see the data sheet.
2. CAUTION! Foldable feet can collapse. See "Setting up the instrument"
on page 8.
Always fold the feet completely in or out. If they are folded out, do not place
anything on top or underneath.
3. CAUTION! R&S FPL1000 can fall over and cause injury. The top surface is
too small for stacking. Never stack another instrument on top of the
R&S FPL1000.
As an alternative, you can mount several instruments in a rack.
4. NOTICE! Overheating can damage the R&S FPL1000.
Prevent overheating as follows:
● Keep a minimum distance of 10 cm between the fan openings of the
R&S FPL1000 and any object in the vicinity.
● Do not place the R&S FPL1000 next to heat-generating equipment such
as radiators or other instruments.
4.4.2 Mounting the R&S FPL1000 in a Rack
To prepare the rack
1. Observe the requirements and instructions in "Setting up the instrument"
on page 8.
Setting Up the R&S FPL1000

Preparing for Use
R&S®FPL1000
20Getting Started 1323.1602.02 ─ 07
2. NOTICE! Insufficient airflow can cause overheating and damage the
R&S FPL1000.
Design and implement an efficient ventilation concept for the rack.
To mount the R&S FPL1000 in a rack
1. Use an adapter kit to prepare the R&S FPL1000 for rack mounting.
a) Order the rack adapter kit designed for the R&S FPL1000. For the order
number, see data sheet.
b) Mount the adapter kit. Follow the assembly instructions provided with the
adapter kit.
2. Lift the R&S FPL1000 to shelf height.
3. Grab the handles and push the R&S FPL1000 onto the shelf until the rack
brackets fit closely to the rack.
4. Tighten all screws in the rack brackets with a tightening torque of 1.2 Nm to
secure the R&S FPL1000 in the rack.
To unmount the R&S FPL1000 from a rack
1. Loosen the screws at the rack brackets.
2. Remove the R&S FPL1000 from the rack.
3. If placing the R&S FPL1000 on a bench top again, unmount the adapter kit
from the R&S FPL1000. Follow the instructions provided with the adapter kit.
4.4.3 Portable Operation
An optional carrying bag designed specifically for the R&S FPL1000 allows you to
protect the instrument while working in the field. The bag includes ventilation
areas at the position of the ventilation outlets in the casing to ensure air circula-
tion. The transparent cover allows you to operate the instrument without removing
it from the bag. With the help of the optional vest holster, you can carry the
R&S FPL1000 in its bag and keep your hands free. Together with the optional
battery pack (see Chapter 4.5.3, "Connecting an Optional Battery Pack
(R&S FPL1-B31)", on page 23), and packed in the dedicated carrying bag, the
R&S FPL1000 is ideally suited for operation directly in the field, even in rough
environments.
Setting Up the R&S FPL1000
