Rohde & Schwarz NGL200 User manual

R&S®NGL200/NGM200
Power Supply Series
User Manual
User Manual
Version 06
1178873602
(;ÜåT2)

This manual describes the following R&S®NGL/NGM models with firmware version 1.00 or higher:
●R&S®NGL201 Single-channel power supply 60W (3638.3376.02)
●R&S®NGL202 Two-channel power supply 120W (3638.3376.03)
●R&S®NGM201 Single-channel power supply 60W (3638.4472.02)
●R&S®NGM202 Two-channel power supply 120W (3638.4472.03)
In addition to the base unit, the following options are described:
●R&S®NGL-B105 Option IEEE-488 (GPIB) Interface (3652.6356.02)
●R&S®NGL-K102 Option Wireless LAN Remote Control (3652.6362.02)
●R&S®NGL-K103 Option Digital I/O (3652.6385.02)
●R&S®NGM-B105 Option IEEE-488 (GPIB) interface (3641.6220.02)
●R&S®NGM-K102 Option Wireless LAN Remote Control (3644.6367.02)
●R&S®NGM-K103 Option Digital I/O (3643.9904.02)
●R&S®NGM-K104 Option Digital Voltmeter (3643.9927.02)
●R&S®NGM-K106 Option Battery Simulation (3636.6626.02)
© 2019 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Fax: [phone]
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1178.8736.02 | Version 06 | R&S®NGL200/NGM200
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g. R&S®NGL200, R&S®NGM200 are
indicated as R&S NGL/NGM.

1171.1307.42 - 05
1
Safety Instructions
Instrucciones de seguridad
Sicherheitshinweise
Consignes de sécurité
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent
electric shock, fire,
personal injury or instrument damage.
●
Do not open the instrument casing.
●
Read and observe the "Basic Safety Instructions" delivered as
printed brochure with the instrument.
●
Read and observe the safety instructions in the following sections.
Note that the data sheet may specify additional operating conditions.
●
Keep the "Basic Safety Instructions" and the product documentation
in a safe place and pass them on to the subsequent users.
Riesgo de lesiones y daños en el instrumento
El instrumento se debe usar de manera adecuada para p
revenir
descargas eléctricas, incendios, lesiones o daños materiales.
●
No abrir la carcasa del instrumento.
●
Lea y cumpla las "Instrucciones de seguridad elementales"
suministradas con el instrumento como folleto impreso.
●
Lea y cumpla las instrucciones de seguridad incluidas en las
siguientes secciones. Se debe tener en cuenta que las
especificaciones técnicas pueden contener condiciones adicionales
para su uso.
●
Guarde bien las instrucciones de seguridad elementales, así como
la documentación del producto, y entréguelas a usuarios
posteriores.

1171.1307.42 - 05
2
Gefahr von Verletzungen und Schäden am Gerät
Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen
Schlag, Brand, Verletzungen von Personen oder Geräteschäden zu
verhindern.
●
Öffnen Sie das Gerätegehäuse nicht.
●
Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise",
die als gedruckte Broschüre dem Gerät beiliegen.
●
Lesen und beachten Sie die Sicherheitshinweise in den folgenden
Abschnitten; möglicherweise enthält das Datenblatt weitere
Hinweise zu speziellen Betriebsbedingungen.
●
Bewahren Sie die "Grundlegenden Sicherheitshinweise" und die
Produktdokumentation gut auf und geben Sie diese an weitere
Benutzer des Produkts weiter.
Risque de blessures et d'endommagement de l'appareil
L'ap
pareil doit être utilisé conformément aux prescriptions afin d'éviter
les électrocutions, incendies, dommages corporels et matériels.
●
N'ouvrez pas le boîtier de l'appareil.
●
Lisez et respectez les "consignes de sécurité fondamentales"
fournies avec l’appareil sous forme de brochure imprimée.
●
Lisez et respectez les instructions de sécurité dans les sections
suivantes. Il ne faut pas oublier que la fiche technique peut indiquer
des conditions d’exploitation supplémentaires.
●
Gardez les consignes de sécurité fondamentales et la
documentation produit dans un lieu sûr et transmettez ces
documents aux autres utilisateurs.

1171.0200.22-06.00
Customer Support
Technical support – where and when you need it
For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer Support
Centers. A team of highly qualified engineers provides telephone support and will work with you to find a
solution to your query on any aspect of the operation, programming or applications of Rohde & Schwarz
equipment.
Up-to-date information and upgrades
To keep your instrument up-to-date and to be informed about new application notes related to your
instrument, please send an e-mail to the Customer Support Center stating your instrument and your wish.
We will take care that you will get the right information.
Europe, Africa, Middle East Phone [phone]
[email protected]
North America Phone 1-888-TEST-RSA(1-888-837-8772)
[email protected]
Latin America Phone [phone]
[email protected]
Asia/Pacific Phone [phone]
[email protected]
China Phone [phone] /
[phone]
[email protected]

Contents
R&S®NGL200/NGM200
3User Manual 1178.8736.02 ─ 06
Contents
1 Documentation Overview......................................................................7
2 Welcome to R&S NGL/NGM.................................................................. 9
3 Important Notes....................................................................................10
3.1 Symbols....................................................................................................................... 10
3.2 Ambient Conditions.................................................................................................... 10
3.3 Measurement Categories............................................................................................11
3.4 Mains Voltage...............................................................................................................11
3.5 Limits............................................................................................................................12
4 Getting Started..................................................................................... 13
4.1 Putting into Operation................................................................................................ 13
4.1.1 Safety............................................................................................................................ 14
4.1.2 Intended Operation....................................................................................................... 15
4.1.3 Unpacking and Checking the Instrument...................................................................... 16
4.1.4 Setting Up the Instrument............................................................................................. 17
4.1.4.1 Bench Operation........................................................................................................... 17
4.1.4.2 Rack Mounting.............................................................................................................. 18
4.2 Instrument Tour...........................................................................................................18
4.2.1 Overview of Controls.....................................................................................................18
4.2.1.1 Front Panel....................................................................................................................18
4.2.1.2 Rear Panel.................................................................................................................... 20
4.2.2 Switching On the Instrument......................................................................................... 22
4.3 Trying Out the Instrument.......................................................................................... 23
4.3.1 Setting the Output Voltage and Current........................................................................ 24
4.3.2 Activating the Channels Output.....................................................................................24
4.4 Maintenance................................................................................................................ 25
5 Operating Basics..................................................................................26
5.1 Display Overview........................................................................................................ 26
5.1.1 Status Bar Information.................................................................................................. 26
5.1.2 Channel Display Area................................................................................................... 29
5.2 Using the Touchscreen...............................................................................................30

Contents
R&S®NGL200/NGM200
4User Manual 1178.8736.02 ─ 06
5.2.1 Using Gestures............................................................................................................. 30
5.2.2 Accessing Functionality in the Home Window.............................................................. 30
5.2.2.1 Settings Button..............................................................................................................31
5.2.2.2 Voltage and Current Inputs........................................................................................... 31
5.2.2.3 Expand/Collapse Button................................................................................................32
5.2.3 Input Data......................................................................................................................33
5.3 Front Panel Keys.........................................................................................................34
5.3.1 Menu Controls...............................................................................................................34
5.3.1.1 Home Key..................................................................................................................... 34
5.3.1.2 Settings Key.................................................................................................................. 34
5.3.1.3 User Key....................................................................................................................... 37
5.3.2 Navigation Controls.......................................................................................................37
5.3.3 Output and Channel Controls........................................................................................38
5.4 Power Derating............................................................................................................38
5.5 Operation Modes.........................................................................................................38
6 Instrument Functions.......................................................................... 40
6.1 Setting the Channels Voltage and Current............................................................... 40
6.2 Activating the Channels Output................................................................................ 41
6.2.1 Set Constant Resistance...............................................................................................42
6.2.2 Fast Transient Response.............................................................................................. 43
6.2.3 Output........................................................................................................................... 44
6.2.3.1 Impedance.................................................................................................................... 44
6.2.3.2 Delay............................................................................................................................. 45
6.2.3.3 Trigger Events............................................................................................................... 46
6.2.3.4 Output Mode................................................................................................................. 47
6.3 Ranges / Digital Voltmeter (DVM)...............................................................................48
6.4 Battery Simulator........................................................................................................ 50
6.5 Protection.................................................................................................................... 54
6.5.1 Over Current Protection (OCP)..................................................................................... 54
6.5.2 Over Voltage Protection (OVP)..................................................................................... 55
6.5.3 Over Power Protection (OPP)....................................................................................... 55
6.5.4 Safety Limits..................................................................................................................56
6.6 Trigger / Digital I/O...................................................................................................... 57

Contents
R&S®NGL200/NGM200
5User Manual 1178.8736.02 ─ 06
6.7 Advanced Features..................................................................................................... 62
6.7.1 Arbitrary.........................................................................................................................62
6.7.2 Ramp.............................................................................................................................65
6.8 User Key.......................................................................................................................66
6.9 Screenshot...................................................................................................................67
6.10 Data Logging............................................................................................................... 68
6.11 FastLog........................................................................................................................ 70
6.12 CSV Settings................................................................................................................71
6.13 File Manager................................................................................................................ 73
6.14 Store and Recall ......................................................................................................... 74
6.15 Interfaces..................................................................................................................... 76
6.15.1 Network Connection......................................................................................................76
6.15.1.1 LAN Connection............................................................................................................ 77
6.15.1.2 Wireless LAN Connection............................................................................................. 79
6.15.2 USB Connection............................................................................................................81
6.15.3 GPIB Address............................................................................................................... 81
6.16 General Instrument Settings...................................................................................... 82
6.16.1 Licenses Management.................................................................................................. 82
6.16.2 Appearance Settings.....................................................................................................84
6.16.3 Sound Settings..............................................................................................................84
6.16.4 Date and Time...............................................................................................................85
6.16.5 Device Information........................................................................................................ 86
6.16.6 Update Device...............................................................................................................86
6.17 Device Documentation............................................................................................... 87
7 Remote Control Commands................................................................88
7.1 Common Setting Commands.....................................................................................88
7.2 System Settings Commands......................................................................................91
7.3 Display Commands.....................................................................................................93
7.4 Trigger Commands..................................................................................................... 93
7.5 Configuration Commands.......................................................................................... 97
7.5.1 Channel Selection......................................................................................................... 97
7.5.2 Safety Limit Setting....................................................................................................... 98
7.5.3 Voltage Setting............................................................................................................ 101

Contents
R&S®NGL200/NGM200
6User Manual 1178.8736.02 ─ 06
7.5.4 Current Setting............................................................................................................ 104
7.5.5 Resistance Setting...................................................................................................... 107
7.5.6 Combined Setting of Voltage and Current Setting...................................................... 109
7.5.7 Output Setting..............................................................................................................110
7.5.8 Range/DVM Setting.....................................................................................................116
7.5.9 OCP Setting.................................................................................................................117
7.5.10 OVP Setting................................................................................................................ 121
7.5.11 OPP Setting................................................................................................................ 124
7.6 Measurement Commands........................................................................................ 127
7.7 Advanced Operating Commands............................................................................ 130
7.7.1 Arbitrary.......................................................................................................................130
7.7.2 Ramp...........................................................................................................................135
7.7.3 Digital I/O.................................................................................................................... 136
7.7.4 Battery Simulation....................................................................................................... 138
7.8 Data and File Management Commands.................................................................. 143
7.9 Status Reporting Commands...................................................................................152
7.9.1 STATus:OPERation Registers.....................................................................................152
7.9.2 STATus:QUEStionable Registers................................................................................ 154
Annex.................................................................................................. 157
A Additional Basics on Remote Control..............................................157
A.1 Messages and Command Structure........................................................................ 157
A.1.1 Messages....................................................................................................................157
A.1.2 SCPI Command Structure...........................................................................................158
A.2 Command Sequence and Synchronization............................................................ 162
A.2.1 Preventing Overlapping Execution..............................................................................162
A.3 Status Reporting System......................................................................................... 162
A.3.1 Structure of a SCPI Status Register............................................................................163
List of Commands..............................................................................168
Index....................................................................................................172

Documentation Overview
R&S®NGL200/NGM200
7User Manual 1178.8736.02 ─ 06
1 Documentation Overview
This section provides an overview of the R&S NGL/NGM user documentation. You can
find it on the product page at:
www.rohde-schwarz.com/product/ngl200
www.rohde-schwarz.com/product/ngm200
Getting Started
Introduces the R&S NGL/NGM power supply series and describes how to set up and
start working with the instrument. The printed document is delivered with the instru-
ment.
User manual
Describes all instrument modes and functions in detail. It also provides an introduction
to remote control and a complete description of the remote control commands with pro-
gramming examples, instrument interfaces, error messages and information on mainte-
nance.
The online version (html format) of the user manual provides the complete contents for
immediate display on the internet.
Basic safety instructions
Contains safety instructions, operating conditions and further important information.
The printed document is delivered with the instrument.
Service manual
Describes the performance test for checking the rated specifications, module replace-
ment and repair, firmware update, troubleshooting and fault elimination, and contains
mechanical drawings and spare part lists. The service manual is available for regis-
tered users on the global Rohde & Schwarz information system (GLORIS, https://
gloris.rohde-schwarz.com).
Datasheet
The datasheet contains the technical specifications of the R&S NGL/NGM power sup-
ply series. It also lists all options with their order numbers and accessories.
See www.rohde-schwarz.com/brochure-datasheet/ngl200
See www.rohde-schwarz.com/brochure-datasheet/ngm200
Release notes and open source acknowledgment
The release notes list new features, improvements and known issues of the current
firmware version, and describe the firmware installation. The open source acknowledg-
ment document provides verbatim license texts of the used open source software.

Documentation Overview
R&S®NGL200/NGM200
8User Manual 1178.8736.02 ─ 06
See www.rohde-schwarz.com/firmware/ngl200. The open source acknowledgment
document can also be read directly on the instrument.
See www.rohde-schwarz.com/firmware/ngm200. The open source acknowledgment
document can also be read directly on the instrument.

Welcome to R&S NGL/NGM
R&S®NGL200/NGM200
9User Manual 1178.8736.02 ─ 06
2 Welcome to R&S NGL/NGM
The one or two-channel power supply series are based on a classical transformer con-
cept with linear regulators. This concept allows the instrument to achieve highest accu-
racy and lowest residual ripple.
The R&S NGL/NGM power supply series feature galvanically isolated, floating over-
load and short-circuit proof outputs. When multiple channels are connected in parallel,
higher currents can be achieved. When connected in serial, higher voltages are ach-
ievable.
Multi-purpose protection functions are available for each channel which you can set
separately, such as overcurrent protection (OCP), overvoltage protection (OVP) and
overpower protection (OPP). If such a limit is reached, the affected output channel is
automatically turned off and an indicator icon ( , , ) blinks on the display. In the
case of two-channel power supply (NGL202, NGM202), the overcurrent protection can
be linked to the other channel. In this case, the linked channel is turned off when the
other channel reaches a limit.
Additionally, the R&S NGL/NGM is protected with overtemperature protection (OTP).
This safety feature protects the R&S NGL/NGM from overheating. When the tempera-
ture in the power supply exceeds the OTP limit, the channel outputs are automatically
cut off.
The Arbitrary function allows a freely definable voltage and current sequences with a
timeframe as short as 1 ms. It allows varying the voltage or current during a test
sequence, for example to simulate different charging conditions of a battery. With
"Ramp" function, the R&S NGL/NGM provides the operating condition to ramp up the
supply voltage within a defined timeframe of 10 ms to 10 s.
All R&S NGL/NGM power supplies are equipped with a color TFT display (800 pixels x
480 pixels) and enhanced with touch input capability. The R&S NGL/NGM comes with
a USB and LAN (LXI) interface. Equipped with a wireless LAN (WLAN) option, you can
establish a network connection wirelessly.
The digital I/O interface installed at the rear panel is activated with an option, it allows a
single trigger-in signal to control multi trigger-out signals on the power supply, providing
many possibilities to control outputs and associated devices in the event when a trigger
occurs.
The user manual contains description of the functionalities that the instrument pro-
vides. The latest version is available for download at the product homepage (http://
www.rohde-schwarz.com/product/ngl200 for R&S NGL and http://www.rohde-
schwarz.com/product/ngm200 for R&S NGM) .

Important Notes
R&S®NGL200/NGM200
10User Manual 1178.8736.02 ─ 06
3 Important Notes
3.1 Symbols
Caution, general danger zone
Ground
PE terminal
ON (supply voltage)
OFF (supply voltage)
Ground terminal
3.2 Ambient Conditions
The allowed operating temperature ranges from +5 °C to +40 °C (pollution category 2).
The maximum relative humidity (without condensation) is at 80 %.
During storage and transport, the temperature must be between -40 °C and +70 °C. In
case of condensation during transportation or storage, the instrument requires approxi-
mately two hours to dry and reach the appropriate temperature prior to operation. The
instrument is designed for use in a clean and dry indoor environment. Do not operate
with high dust and humidity levels, if danger of explosion exists or with aggressive
chemical agents.
Any operating position may be used; however adequate air circulation must be main-
tained. For continuous operation, a horizontal or inclined position (integrated stand) is
preferable.
Specifications with tolerance data apply after a warm up period of at least 30 minutes
at a temperature of 23 °C (tolerance -3 °C / + 7 °C).
The heat produced inside the instrument is guided to the exterior via temperature-con-
trolled fan. Each channel has multiple temperature sensors which check the heat gen-
eration in the instrument and control the fan speed.
It is necessary to ensure that there is sufficient space around the instrument sides for
heat exchange. If the temperature inside the instrument increases to more than
Ambient Conditions

Important Notes
R&S®NGL200/NGM200
11User Manual 1178.8736.02 ─ 06
~72 °C, a channel-specific overheat protection intervenes. Affected outputs will auto-
matically be switched off.
Air circulation
Do not obstruct the ventilation holes!
3.3 Measurement Categories
This instrument is designed for supplying power on circuits that are only indirectly con-
nected to the low voltage mains or not connected at all. The instrument is not intended
for measurements within the measurement categories II, III or IV; the maximum poten-
tial against earth generated by the user must not exceed 250 V peak in this application.
The following information refers solely to user safety. Other aspects, such as the maxi-
mum voltage, are described in the technical data and must also be observed.
The measurement categories refer to transients that are superimposed on the mains
voltage. Transients are short, very fast (steep) current and voltage variations which
may occur periodically and non-periodically. The level of potential transients increases
as the distance to the source of the low voltage installation decreases.
●Measurement CAT IV: Measurements at the source of the low voltage installations
(e.g. meters)
●Measurement CAT III: Measurements in building installations (e.g. power distribu-
tion installations, power switches, firmly installed sockets, firmly installed engines
etc.)
●Measurement CAT II: Measurements on circuits electronically directly connected to
the mains (e.g. household appliances, power tools, etc.)
●0 (instruments without measured measurement category): Other circuits that are
not connected directly to the mains
3.4 Mains Voltage
The instrument uses 50 Hz / 60 Hz mains voltages ranging from 100 VAC, 115 VAC or
230 VAC (tolerance ± 10 %). Mains voltage must be set correctly by removing the fuse
holder and rotating until the correct voltage appears through the window and reinstal-
ling the fuse holder. The input line fuse is accessible externally. Power socket and fuse
holder form a single unit.
You need to first disconnect the power cord from the connector before you can safely
replace the fuse (as long as the fuse holder is undamaged). Next, the fuse holder must
be pried out using a screwdriver. The starting point is a slot next to the contacts. The
fuse can then be forced out of its mounting and must be replaced with an identical fuse
(see information about the fuse type on the rear panel). The fuse holder is inserted
Mains Voltage

Important Notes
R&S®NGL200/NGM200
12User Manual 1178.8736.02 ─ 06
against the spring pressure until it locks into place. The use of mended fuses or short
circuiting the fuse holder is prohibited. Resulting damages are not covered by the war-
ranty.
Safe operation
If the instrument is not in use, it must be switched off at the mains switch for safety rea-
sons.
3.5 Limits
The R&S NGL/NGM is equipped with a protective overload feature. The protective
overload feature prevents damage to the instrument and is intended to protect against
a possible electrical shock. The maximum values for the instrument must not be excee-
ded. The protection limits are listed on the front panel of the R&S NGL/NGM to ensure
the safe operation of the instrument.
These protection limits must be adhered to:
Specification Limits
Maximum output voltage 20.05 VDC
Maximum output current 6.01 A (<= 6 V)
3.01 A (> 6 V)
Maximum voltage against earth 250 V peak
Maximum counter-voltage (same polarity) 22 V
Maximum reverse voltage (opposite polarity) 0.5 V
Maximum reverse current sink current
Maximum reverse Current (through protection diode,
instrument must be operating)
3.01 A
Power supply 100 VAC, 115 VAC or 230 VAC (tolerance ± 10 %)
Frequency 50 Hz / 60 Hz
Maximum power output 120 W (NGL202, NGM202), 60 W (NGL201,
NGM201)
Limits

Getting Started
R&S®NGL200/NGM200
13User Manual 1178.8736.02 ─ 06
4 Getting Started
4.1 Putting into Operation
This chapter describes how to set up the R&S NGL/NGM power supply series for the
first time.
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric shock, fire,
personal injury, or damage.
●Do not open the instrument casing
●Read and observe the "Basic Safety Instructions" delivered as a printed brochure
with the instrument. Note that the basic safety instructions also contain information
on operating conditions that prevent damage to the instrument
In addition, read and observe the safety instructions in the following sections.
Notice that the data sheet may specify additional operating conditions.
Risk of radio interference
This instrument is compliant with Class A of CISPR 32. In a residential environment,
this instrument may cause radio interference.
Risk of instrument damage during operation
An unsuitable operating site or test setup can cause damage to the instrument and the
connected devices. Ensure the following operating conditions before you switch on the
instrument:
●The instrument is dry and shows no sign of condensation
●The instrument is positioned as described in Chapter 4.1.4.1, "Bench Operation",
on page 17
●The ambient temperature does not exceed the range specified in the data sheet
●Signal levels at the input connectors are all within the specified ranges
●Signal outputs are correctly connected and not overloaded
Putting into Operation

Getting Started
R&S®NGL200/NGM200
14User Manual 1178.8736.02 ─ 06
EMI impact on measurement results
Electromagnetic interference (EMI) may affect the measurement results.
To suppress the generated EMI:
●Use suitable shielded cables of high quality, for example, LAN cables
●Note the EMC classification in the data sheet
4.1.1 Safety
This instrument was built in compliance with DIN EN 61010-1, safety regulations for
electrical instruments, control units and Iaboratory equipment.
It has been tested and shipped from the plant in safe condition. It is also in compliance
with the regulations of the European standard EN 61010-1 and the international stan-
dard IEC 61010-1.
To maintain this condition and ensure safe operation, you must observe all instructions
and warnings given in this user manual. Casing, chassis and all measuring ports are
connected to a protective earth conductor. The instrument is designed in compliance
with the regulations of protection class I.
For safety reasons, the instrument may only be operated with authorized safety sock-
ets. The power cable must be plugged in before signal circuits may be connected.
Never use the product if the power cable is damaged. Check regularly if the power
cables are in perfect condition. Choose suitable protective measures and installation
types to ensure that the power cable cannot be damaged and that no harm is caused
by tripping hazards or from electric shock, for instance.
Risk of electric shock
It is prohibited to disconnect the earthed protective connection inside or outside of the
instrument!
If it is assumed that a safe operation is no longer possible, the instrument must be shut
down and secured against any unintended operation.
Safe operation can no longer be assumed when:
●Instrument shows visible damage
●Instrument includes loose parts
●Instrument no longer functions properly
– After an extended period of storage under unfavorable conditions (e.g. out-
doors or in damp rooms)
– After rough handling during transport (e.g. packaging that does not meet the
minimum requirements by post office, railway or forwarding agency)
Putting into Operation

Getting Started
R&S®NGL200/NGM200
15User Manual 1178.8736.02 ─ 06
Exceeding the low voltage protection
Use insulated wires and not bare wires for the terminal connection.
It is assumed that only qualified and trained personnel service the power supplies and
the connected loads.
Before switching on the product, it must be ensured that the nominal voltage setting on
the product matches the nominal voltage of the AC supply network.
4.1.2 Intended Operation
The instrument is intended only for use by personnel familiar with the potential risks of
measuring electrical quantities.
For safety reasons, the instrument may only be connected to properly installed wall
outlets. Separating the ground is prohibited.
The power cable must be inserted before signal circuits may be connected.
Use only the power cable included in the delivery package. See "Delivery package"
on page 17.
Before each measurement, measuring cables must be inspected for damage and
replaced if necessary. Damaged or worn components can damage the instrument or
cause injury.
The instrument may be operated only under the operating conditions and in the posi-
tions specified by the manufacturer, without the product's ventilation being obstructed.
If the manufacturer’s specifications are not observed, this can result in electric shock,
fire and/or serious personal injury, and in some cases, death.
Applicable local or national safety regulations and rules for the prevention of accidents
must be observed in all work performed.
The instrument is designed for use in the following sectors: Industrial, residential, busi-
ness and commercial areas and small businesses.
The instrument is designed for indoor use only. Before each measurement, you need
to verify at a known source if the instrument functions properly.
To disconnect from the mains, unplug the IEC socket on the back panel.
See Table 4-1 for the general data on the instrument specification. For more informa-
tion, see the instrument datasheet (P/N: 5216.1057.32).
Putting into Operation

Getting Started
R&S®NGL200/NGM200
16User Manual 1178.8736.02 ─ 06
Table 4-1: General data on instrument specification
General data
Mains nominal voltage AC 100 V / 115 V / 230 V (±10 %) 50 Hz to 60 Hz
Maximum power consumption 400 W
Mains fuses 2 x IEC T4.0H 250 V
Operating temperature range +5 °C to +40 °C
Storage temperature range -20 °C to +70 °C
Humidity noncondensing 5 % to 95 %
Display TFT 5" 800 pixels x 480 pixels WVGA Touch
Rack installation R&S HZN96 rack adapter 2U (P/N: 3638.7813.02)
Dimensions (W x H x D) 222 mm x 97 mm x 436 mm (8.74" x 3.82" x 17.17")
Weight R&S NGL201
R&S NGM201
7.1 kg (15.65 lb)
7.2 kg (15.87 lb)
R&S NGL202
R&S NGM202
7.3 kg (16.09 lb)
7.4 kg (16.31 lb)
4.1.3 Unpacking and Checking the Instrument
Unpack the R&S NGL/NGM power supply carefully and check the content of the pack-
age.
●Check the equipment for completeness using the delivery note and package con-
tents list for the various items.
●Check the instrument for any damage and loose parts. If there is any damage,
immediately contact the carrier who delivered the instrument.
Packing material
Retain the original packing material. If the instrument needs to be transported or ship-
ped later, you can use the material to protect the control elements and connectors.
Putting into Operation

Getting Started
R&S®NGL200/NGM200
17User Manual 1178.8736.02 ─ 06
Risk of damage during transportation and shipment
Insufficient protection against mechanical and electrostatic effects during transportation
and shipment can damage the instrument.
●Always ensure that sufficient mechanical and electrostatic protections are provided
●When shipping an instrument, the original packaging should be used. If you do not
have the original packaging, use sufficient padding to prevent the instrument from
moving around inside the box. Pack the instrument in antistatic wrap to protect it
from electrostatic charging
●Secure the instrument to prevent any movement and other mechanical effects dur-
ing transportation
Delivery package
The package contents contain the following items:
●R&S NGL power supply or R&S NGM power supply
●Four power cables
●One printed Getting Started manual
●One document folder containing a printed Basic Safety Instructions guide
4.1.4 Setting Up the Instrument
The R&S NGL/NGM is designed for benchtop and rackmount operation.
4.1.4.1 Bench Operation
On a benchtop, the R&S NGL/NGM power supply can either lie flat or stand on its feet.
As shown in Figure 4-1, feet on the bottom can be folded out to set the instrument in
an inclined position.
Figure 4-1: Operating positions
Putting into Operation
