Rohl G1655 Assembly instructions

HOT WATER DISPENSER COLLECTION
FOR USE ONLY WITH PERRIN AND ROWE HOT WATER TANK
SCALDING HAZARD: The tap dispenses water up to
208.4°F (98°C), which can instantly cause scalds or
burns. Use care when operating this appliance.
RECOMMENDED WORKING PRESSURE
Min 1.5bar / 22psi | Max 5bar / 75psi
9.2”
5.5”
1.2/8”
HOLE
1/4”
2MAX
10”
5.5”
1.2/8”
HOLE
1/4”
2MAX
10”
5.5”
1.2/8”
HOLE
1/4”
2MAX
10”
5.5”
1.2/8”
HOLE
1/4”
2MAX
G1445
G7545 MB7945
G1655

The Hot Water Dispenser Collection
Installation & User Guide
Congratulations on the purchace pf your ROHL product. Correctly installed and with sensible care, this product
will give you many years of trouble free service.
IMPORTANT INFORMATION
Before you proceed... We recommend you engage the services of a registered plumber / builder to
install this product.
Ensure you also read and understand the instruction manual that accompanies your Perrin and Rowe
heater tank unit.
To avoid perminent damage to the heater tank it is important not to plug the unit until indicated in
heater tank installation manual. Only operate the tank after it is lled with water.
In addition to the guide below it is essential that the written information is carefully read and
understood.
Preparation Check Box for Installer
Flush the plumbing system before installing
the kitchen product
Once unpacked, remove nut and clamping
plate ready for installation.
1. Unpack the hot water dispenser on a rm
at surface.
2. Carefully straighten the tubing from the
bottom of the dispenser.
3. Ensure the base ring and the O seal are
in place.
Attach to the tank inlet
Attach silicone tube using the clip
Mains water inlet from lter if aplicate

The Hot Water Dispenser Collection
Installation & User Guide
base ring
base seal
work surpace
clamp plate
nut
threaded stud
water inlet
silicone tube
seal
1. Feed the tubes down through the hole.
In the work surface until the base seal
and base ring are at rest.
2. From under the sink, place the semi-
circular clamping plate and xing nuts
onto the threaded stud.
3. Ensure the tap is the desired angle Insert
a screw driver into the hole in the hex
tool (creating a T), and use to tighten
and secure the faucet.
NOTICE
AN ASSISTANT MAY BE NEEDED TO HOLD
THE TAP IN PLACE WHILE SECURING.
TO EASE FEEDING OF THE TUBES THROUGH
THE HOLE, FIRST INSERT THE BLUE TUBE
WITH QUICK-CONNECT ATTACHMENT AND
THEN INSERT THE REMAINING TUBES.
PLEASE ENSURE YOU HAVE READ & UNDERSTOOD THE
PERRIN AND ROWE TANK GUIDE BEFORE USE.
BEFORE USE
• If further building work is to be carried out in the vicinity, cover the faucet to avoid damaging the nish.
• Please ensure that the installation complies with local plumbing codes.
CARE & MAINTENANCE
Wipe down after use to avoid water spotting and mineral build up.
Occasional cleaning with warm soapy water, followed by a polish with a soft cloth is all that is required to keep the plated
nish in good condition.
Don’t use abrasive liquids, powders, or pads to clean the shower. Don’t use any products with ammonia, bleach, or
limescale remover. You will damage the plated nish and void your guarantee.

Electronic Instant Hot Water Appliance
Installaon, Operaon and Care Instrucons
Please read these instrucons fully before commencing the installaon and
operaon of the Electronic Instant Hot Water Appliance

We are delighted that you have chosen the electronic instant hot water appliance to compli-
ment your instant hot water Dispenser. This unique electronic instant hot water appliance
will save you me and eort when requiring near boiling water for making tea and coee
and we are sure you will discover many new uses each day.
Please read and follow our step by step guide to the installaon, operaon and care for the
electronic instant hot water appliance and you will soon be making that rst cup of coee or
tea from your new appliance.
WHAT YOU NEED TO KNOW BEFORE YOU START
For your safety and sasfacon please read all the instrucons, cauons and warnings be-
fore installing or using this electronic instant hot water appliance.
This electronic instant hot water appliance is not intended for commercial use
IMPORTANT NOTICE: This product can cause harm if installed incorrectly and should only be
installed by a competent person, if you feel for any reason unsure about the installation
please contact a qualified plumber or electrician to install the appliance.
Make sure all electrical wiring and connecons conform to local standards.
Make sure all water connecons conform to local standards.
Make sure all electrical wiring and water connecons conform to local codes. Standard 120v
electrical outlet is required under the sink. If possible, use a separate circuit dedicated to
your Hot Tank.
The instant hot water appliance is an open vented system appliance. The water supply
pressure should not exceed 72psi. If it does a pressure reducing valve must be installed.
The required water supply pressure is a minimum of 22psi to maximum of 72psi.
The water lter must be connected to the electronic instant hot water appliance and re-
placed every 6 months or the guarantee will be void.
Equipment Required:
Tape Measure Adjustable Wrench
