Rohnson R-7560 User manual

Kettle R-7560
EN
1
Instruction manual
R-7560
When using your kettle basic safety precautions should always be followed，
including the followings：
1．Read all instruction carefully and thoroughly，before the kettle
operation．
2．Close supervision is necessary when any appliance is used by or near
children.
3．Before connecting the kettle，check whether the voltage indicated on the
appliance (underside of kettle and base unit) corresponds with the
mains voltage in your home．If this is not the case，contact your dealer
and do not use the kettle.
4．Switch off and unplug from the outlet before filling, emptying, cleaning，

Kettle R-7560
EN
2
or using the kettle．
5．Do not overfill, as boiling water may be ejected. Fill with cold water only,
up to the maximum level indicator
6．Do not operated in the presence of explosive and/or flammable fumes,
to avoid fire. Do not operate or place any party of this appliance on or
near gas and electric burner or in a heated oven．
7．Do not let the cord hang over the edge of a table or a counter, nor touch
hot surface．
8．Never yank on the cord as this may damage the cord and eventually
cause a risk of electric shock．
9．If the cord or plug is damaged，or after the appliance malfunctions, is
dropped or damaged in any way, return the appliance immediately to
your nearest authorized service agent for examination, repair or
adjustment．
10．Avoid touching the surface of the hot kettle，use the handle and knobs．
11．To avoid possible steam damage，not face the spout when operating the
kettle．
12．If operated on wood furniture, use a protective pad to prevent damage
on delicate finishes．
13．To avoid scalding, always ensure the lid is correctly positioned before
operation．
14．Scalding may occur if the lid is removed while heating．
15．Remove and replace the lid carefully when hot．
16．Extreme caution must be used when moving the kettle containing hot
water．Never lift the kettle by its lid．Always use the body handle.
17．Do not switch your kettle on if it is empty．
18．To protect from electrical hazard，do not immerse the kettle, its power
base or cord set in any liquid．
19．Use the kettle only with the supplied base unit．Do not use the base unit
for any other purposes．
20．To protect against fire, must not be operated in the presence of
explosive and/or flammable fumes．
21．While the water boiling or in the short time after it does, please be sure
that the cover remains closed for avoiding scalding your hand with the
steam．
22．Please avoid liquid sprinkling in the LCD board and the pressed key
place in the operating process. The water could plunge in the product
and cause malfunction
23．Please do surpass the maximum water volume. This might damage the
product.
24．Please regular clean descale or pot bottom residuum, otherwise the
normal use of the product could be affected.
25．If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or other similarly qualified person in order to avoid
hazard.
26．This appliance should not be used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they are supervised by the person who is

Kettle R-7560
EN
3
Kettle Lid
Power Base
Water Level Gauge
Handle
Lid Release Button
responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
IDENTIFICATION OF PARTS –KNOW YOUR KETTLE
Save these instructions
Instruction for use
Preparatory work before use：
•Before first use，fill the kettle with clean water to maximum capacity and boil．Discard
the water and repeat the process．
•The kettle should always be unplugged when filling or adding water．
•Fill the kettle with water up to desired level．Do not overfill, otherwise there will be a
risk of spillage or spitting．The water level indicator will assist you to measure
the correct amount．You can fill the kettle via the spout or after opening the
lid．Do not forget to close the lid after filling, otherwise the kettle will not
automatically switch off after use．
•Do not fill with less than 0.5 liters of water (to “min”indication) to prevent the kettle
running dry while operating．
•Do not fill with less than 1.7 liters of water (to “max”indication)
•An automatic safety cut-out has been fitted for protection against overheating. It
will operate if the kettle is switched on when containing insufficient
water．Always ensure the water inside the kettle covers the minimum mark on
the water level indicator gauge．If the automatic safety cut-out has operated，
switch the kettle off，disconnect from the power outlet and allow the kettle to
cool down for 5 to 10 minutes. Refill and switch on, the kettle will work as
normal．
Body
Temperature Display

Kettle R-7560
EN
4
•After boiling, the kettle switches off automatically.
−Disconnect the kettle from the electricity supply.
−Do not open the lid when pouring.
−If the kettle is overfilled, boiling water may be ejected.
−The kettle is only to be used with the stand provided.
•This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments.
- farmhouses.
- by clients in hotels, motels and other residential type environments.
- bed and breakfast type environments.
Basal operation：
1. Put the base on a dry, smooth and horizontal surface and insert the plug to the
socket. When the kettle is inserted into the base, the power puts through
automatically, a “DI -DI”sound will be heard and the word “ON” will be displayed,
followed by the present temperature of water.
2. Press the “ ” key shortly. it starts running when the sound “Di’is heard.
3. After the water boils, the indicator turns off and simultaneously
4. The buzzer sends out a “di-”sound.
Advanced operation：
1. Press the “ ” key for two seconds until hearing the sound “Di.”, and the
display shows 100℃. it twinkles two times, and 100℃is appeared. With the
third twinkle, the present temperature of water is shown on the display.
•Quick press key “ ”. The kettle starts running with the function
of keep warm.After the water boils, the LED light changes into
red color and twinkles. The kettle retains the water temperature
for 2 hours. When the temperature arrives at 90℃, it will go on
heating again, doing such a recycle for up to 2 hours.
2. Press the “ ” key for two seconds until hearing the sound “Di.”The display
now shows 100℃. It twinkles two times, and 100℃is shown on the display.
With the third twinkle, the present temperature of water is shown on the display.
•Quick press key “ ”, to start operating with the function of keep
warm.

Kettle R-7560
EN
5
•Press the “ ” key once, and 40℃is showed on the display.
After the third twinkle the present temperature of water is
displayed. When the water reaches 40℃, the LED light twinkles,
and the kettle keeps the water temperature for 2 hours. When the
temperature arrives at 35℃It will go on heating again, doing such
recycles for the following to 2 hours.
•Press the “ ” key two times, and a 50℃is showed on the
display, with the third twinkle, the present temperature of water is
shown on the display. When the water reaches 50℃, the LED
light twinkles. The kettle will keep the water temperature for 2
hours. When the temperature arrives at 45℃, it will go on heating
again, doing such recycles for the following 2 hours.
•Press the “ ” key three times, and 60℃is showed on the
display with the third twinkle, the present temperature of water is
shown on the display. When the water reaches 60℃, the LED
light twinkles. The kettle will keep the water temperature for 2
hours. When the temperature arrives at 55℃, doing such recycles
for the following 2 hours.
•Press the “ ” key four times, and 70℃is showed on the
display with the third twinkle, the present temperature of water is
shown on the display. When the water reaches 70℃, the LED
light twinkles. The kettle will keep the water temperature for 2
hours. The kettle will keep the water temperature for 2 hours.
When the temperature arrives at 65℃, doing such recycles for for
the following 2 hours.
•Press the “ ” key five times, and 80℃is showed on the
display with the third twinkle, the present temperature of water is
shown on the display. When the water reaches 80℃, the LED
light twinkles. The kettle will keep the water temperature for 2
hours. The kettle will keep the water temperature for 2 hours.
When the temperature arrives at 75℃, doing such recycles for for
the following 2 hours.
•Press the “ ” key six times, and 90℃is showed on the
display is showed on the display with the third twinkle, the

Kettle R-7560
EN
6
present temperature of water is shown on the display. When the
water reaches 90℃, the kettle will keep the water temperature for
2 hours. The kettle will keep the water temperature for 2 hours.
When the temperature arrives at 85℃, doing such recycles for for
the following 2 hours.
(Note: The kettle can have the keep warm function only by following above instructions og
operation, and when the body is removed from the base, this function will be disabled and
in need of reset)
3. Press the “ ” key shortly, with the sound “Di”, 100℃is shown on the display. It
twinkles three times and then the present temperature of water is displayed. The
kettle starts running to 100℃.
•Press the “ ” key once, 40℃is showed, twinkles three times and the present
temperature of water is shown on the display. The kettle starts running and
stops when water reaches 40℃.
•Press the “ ” key two times, 50℃is showed, twinkles three times and the
present temperature of water is shown on the display. The kettle starts running
and stops when water reaches 50℃.
•Press the “ ” key three times, 60℃is showed, twinkles three times and the
present temperature of water is shown on the display. The kettle starts running
and stops when water reaches 60℃.
•Press the “ ” key four times, 70℃is showed, it twinkles three times, and the
present temperature of water is shown on the display. The kettle starts running
and stops when water reaches 70℃.
•Press the “ ” key five times, 80℃is showed, it twinkles three times, and the
present temperature of water is shown on the display. The kettle starts running
and stops when water reaches 80℃.
•Press the “ ” key six times,90℃is showed, it twinkles three times, and the
present temperature of water is shown on the display. The kettle starts running
and stops when water reaches 90℃.
NOTE: When kettle under boiling or keep warm condition:
❖The LED light is blue for water temperature in the range of 0-50℃
❖The LED light is light blue for water temperature in the range of 51-60℃
❖The LED light is green for water temperature in the range of 61-70℃
❖The LED light is yellow for water temperature in the range of 71-80℃

Kettle R-7560
EN
7
❖The LED light is purple for water temperature in the range of 81-90℃
❖The LED light is red for water temperature in the range of 91-100℃
4. After using the appliance, put plug off the power socket．
CLEANING & CARE
EXTERIOR CLEANING
Let the kettle cool down before cleaning. Before you clean your kettle, unplug and make
sure all water is poured out from the kettle. Do not immerse the appliance or its base in
water or any other liquid or hold it under a running tap to clean.
Wipe the exterior of the kettle with a soft, damp cloth or sponge. Remove stubborn spots
with a cloth, moistened with mild liquid detergent．Do not use abrasive scouring pads or
powers．
Never immerse the kettle in water or other liquids．
From time to time，depended on the nature of your water supply，a boiled scale deposit is
naturally formed and can be found mostly adhered to the heating element，thus reducing
the heating efficiency．
The amount of boiled scale deposited (and subsequently the need to clean or rescale)
largely depends on the water hardness in your area the frequency with which the kettle is
used．
Boiled scale is not harmful to your health．But if poured into your beverage, can give a
powdery taste to your drink．Therefore，the kettle should be descaled periodically as
indicated below．
INTERIOR CLEANING
Descaling
Descale kettle regularly．With normal use：at least twice a year
1．Fill the kettle up to “max” with a mixture of one-part ordinary vinegar and two parts
water．Switch on and wait for the appliance to switch off automatically．
2．Let the mixture remain inside the kettle overnight．
3．Discard the mixture the next morning．
4．Fill the kettle with clean water up to “max” mark and boil again．
5．Discard the boiled water to remove any remaining scale and vinegar．
6．Rinse the inside of the kettle with clean water．
Technical Characteristics
POWER:AC 220-240V 50-60Hz 1850-2200W

Kettle R-7560
EN
8
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection center or to a
dealer providing this service.
Disposing of a household appliance separately avoids possible negative consequences
for the environment and health, deriving form inappropriate disposal and enables the
constituent materials to be recovered to obtain significant savings in energy and
resources.As a reminder of the need to dispose of household appliances separately, the
product is marked with a crossed-out wheeled dustbin.
