ROHO ADAPTOR PAD User manual

Supplier: This manual must be given to the user of this product.
Operator (Individual or Caregiver): Before using this product, read instructions and save for future reference.
shape fitting technology
®
The ADAPTOR®PAD and
DRY FLOATATION®Special Application Cushioning Devices
Operation Manual

Products:
THE ADAPTOR®PAD (THE ADAPTOR)
ROHO®HEAL PAD®Cushion (HEAL PAD)
ROHO®Lumbar Support Cushion (Lumbar Cushion)
ROHO®MINI-MAX®Cushion (MINI-MAX)
ROHO®PACK-IT® Cushion (PACK-IT)
ROHO®Shower/Commode Cushion (Shower/Commode Cushion)
ROHO®Toilet Seat Cushion (Toilet Seat Cushion)
ROHO®Recliner System (Recliner System)

Table of Contents
Important Safety Information 2-3
Product Specifications 3
THE ADAPTOR
HEAL PAD 4
Lumbar Cushion 5
MINI-MAX
PACK-IT 5-6
Shower/Commode Cushion
Toilet Seat Cushion 6
Recliner System 7
Cleaning and Disinfecting 8
Troubleshooting, Disposal, Limited Warranty 9
Español 10
Français 19
Deutsch 28
Italiano 37
Nederlands 46
Dansk 55
Svenska 64
Norsk 73
Suomi 82
Português 91

2
ROHO Special Application Cushioning Devices Operation Manual
Important Safety Information
ROHO medical products are intended to be part of an overall care regimen. ROHO, Inc.
recommends that a clinician make product recommendations based upon an evaluation of
the individual’s medical and therapeutic needs and overall condition.
Warnings
• Check inflation frequently, at least once a day!
• Check skin frequently, at least once a day. Skin/soft tissue breakdown can occur
due to a number of factors, which vary by individual. Redness, bruising, or darker
areas (when compared to normal skin) may indicate the beginning of soft tissue
breakdown. Consult with a clinician immediately.
• The cushioning device and the cover MUST be compatible sizes and MUST be
used as directed in this manual. IF THEY ARE NOT: 1) The benefits provided by the
cushioning device may be reduced or eliminated, increasing the risk to skin or
to other soft tissue, and 2) the individual may become unstable and vulnerable to
falling.
• DO NOT use your cushioning device on top of, or in conjunction with, any other
products or materials, except as indicated in this manual. Doing so may cause the
individual to become unstable and vulnerable to falling.
• DO NOT use your cushioning device as a water flotation device (e.g., a Life
Preserver). It will NOT support you in water.
• Use caution when skin will contact the seating surface. Tissue damage may result
from increased friction.
• DO NOT use an under-inflated cushioning device or an over-inflated cushioning
device because the product benefits will be reduced or eliminated, resulting in
an increased risk to skin and other soft tissue. If the cushioning device does not
appear to be holding air, or if you are not able to inflate or deflate the cushioning
device, see TROUBLESHOOTING. Immediately contact your clinical caregiver,
distributor, or ROHO, Inc. if the problem persists.
• If you are UNABLE TO PERFORM ANY TASKS described in this manual, seek
assistance.
Cautions
• Keep your cushioning device away from sharp objects.
• DO NOT expose your cushioning device to high heat, open flames or hot ashes.
• DO NOT allow your cushioning device to come into contact with oil-based lotions or lanolin.
They may degrade the material.
• Changes in altitude may require adjustment to a DRY FLOATATION cushioning device.
• Prolonged exposure to ozone may degrade materials used in the cushioning device,
affect the performance of the product, and void the product warranty.
• DO NOT use an inflation valve as a handle for carrying or pulling your DRY FLOATATION
cushioning device. Carry your cushioning device by the cushion base or the carrying
handle on the cover.

3
ROHO Special Application Cushioning Devices Operation Manual
Important Safety Information, Continued
Cautions, Continued
• If a DRY FLOATATION cushioning device has been in temperatures lower than 32°F (0°C),
and exhibits unusual stiffness, allow the cushioning device to warm to room temperature.
• DO NOT use a pump, cover, or repair kit other than those provided by ROHO, Inc. Doing so
may void your product's warranty.
Product Specifications
Package Contents: All products featured in this manual include an operation manual, product
registration card, and Repair Kit. All products except THE ADAPTOR PAD include a ROHO Hand
Pump. The MINI-MAX Cushion, PACK-ITCushion, and Recliner Cushion include a cover.
Sizing Table Height or
Height Range
Width or
Width Range
Depth or
Depth Range Average Weight*
ADAPTOR 1 in.
(2 cm)
9¾ in.
(25 cm)
13½in.
(34 cm)
½lb.
(0.2 kg)
HEAL PAD ½- 1½in.
(1.5 - 4 cm)
11 ½in.
(29.5 cm)
12½in.
(31.5 cm)
¾lb.
(0.3 kg)
MINI-MAX 1¼in.
(3 cm)
15 to 18¼in.
(38.5 - 46.5 cm)
14¾ to 16 in.
(37.5 - 40.5 cm)
2¼lb.
(1.0 kg)
PACK-IT 1¼in.
(3 cm)
16¼in.
(41.5 cm)
9½in.
(24 cm)
1½ lb.
(0.7 kg)
Shower/Commode
Seat
2¼in.
(5.5 cm)
14¾-16 ½in.
(37.5 - 42 cm)
14¾- 18¼in.
(37.5 - 46.5 cm)
2 lbs.
(1 kg)
Toilet Seat 1 - 2¼ in.
(2.5 to 5.5 cm)
7¾ in.
(20.0 cm)
15¾ in.
(40.0 cm)
1¼lbs.
(0.5 kg)
Lumbar Support 4¼ in.
(10.5 cm)
15¼in.
(39.0 cm)
6½in.
(16.0 cm)
1 lb.
(0.5 kg)
Recliner Cushion Contact Customer Care for specifications.
* based on mid-sized cushioning devices.
Cushioning devices: neoprene rubber (made without latex); nickel-plated brass inflation
valves
Components on some cushioning devices: Yellow Rope, buckles, snaps, hook and loop
fastener, foam tab (on HEAL PAD)
Covers: Standard: two-way stretch top, spacer fabric sides. Heavy Duty: two-way stretch,
fluid-resistant top and sides. Standard and Heavy Duty Covers: zipper or snaps and a
non-skid bottom. Refer to the cover care label for material content. The non-skid bottom
of the cover (and the hook and loop fasteners on the covers for Recliner Cushion and
MINI-MAX) help to keep the cushion in place. Elastic strap and metal ring included on the
PACK-IT Cover.
If provided, straps or hook and loop fasteners should be used to secure the
cushioning device to the surface.
Inspect the cover for damage and replace if necessary.

4
ROHO Special Application Cushioning Devices Operation Manual
THE ADAPTOR
Intended Use: THE ADAPTOR®PAD (THE ADAPTOR) is an air-filled,
cellular-design, neoprene surface intended for cushioning and
shock absorption needs and reduction of friction on surfaces such
as a wheelchair side, headrest or footrest to provide skin/soft tissue
protection. There is no weight limit. The ADAPTOR is not intended to
be used as a supporting medium under the buttocks.
Instructions: Use scissors to trim THE ADAPTOR to fit where needed (sides of wheelchairs,
trays, head rests, foot rests). Cut between the sealed air cells when possible. To attach
the product to the surface, use hook and loop fastener strips.
HEAL PAD
Intended Use: The ROHO®HEAL PAD®
Cushion (HEAL PAD) is an adjustable,
air-filled, cellular-design, neoprene
surface and is intended to conform to
an individual’s heel to provide skin/soft
tissue protection and provide an environment to facilitate wound healing. There is no
weight limit.
Inflation Instructions:
1. Place the HEAL PAD flat, with the cells facing up.
2. Slide the rubber nozzle of the hand pump over the inflation valve. Pinch the nozzle and
open the inflation valve.
3. Inflate the HEAL PAD, and then close the inflation valve completely. Remove the hand
pump.
Attachment Instructions:
1. Fasten the snaps.
Air cells that have been cut WILL NOT provide cushioning.
2. Place the
individual's heel
on the cells.
3. Place the foam tab
over the shin, insert
the strap through
the metal ring, and
adjust the strap.
Foam Tab
Strap
CHECK INFLATION! After adjustment, confirm that there is NO CONTACT between the
individual's heel and the base of the HEAL PAD. If there is contact, add air.

5
ROHO Special Application Cushioning Devices Operation Manual
Lumbar Cushion
Intended Use: The ROHO®Lumbar Support Cushion (Lumbar
Cushion) is an adjustable, air-filled, cellular-design,
neoprene surface that utilizes DRY FLOATATION®technology
and is intended to conform to an individual’s lumbar region.
There is no weight limit.
Instructions:
1. Slide the rubber nozzle of the hand pump over the inflation valve. Pinch the nozzle
and open the inflation valve. Inflate the cushion, and then close the inflation valve
completely. Remove the hand pump.
2. Place the cushion on the surface, making sure the air cells face the individual.
Confirm that the individual is in their usual position. Confirm correct placement of the
cushioning device.
3. Adjust the inflation level as required. Close the inflation valve when adjustment is
complete.
MINI-MAX Cushion and PACK-IT Cushion
Intended Use: The ROHO®MINI-MAX®Cushion (MINI-MAX)
is an adjustable, air-filled, cellular-design, neoprene
surface intended as a supplemental seating surface. There
is no weight limit, yet the cushion must be properly sized
to the individual.
Intended Use: The ROHO®PACK-IT® Cushion (PACK-IT) is
an adjustable, air-filled, cellular-design, neoprene surface
intended for short-term cushioning needs. There is no
weight limit, yet the cushion must be properly sized to the
individual.
Atmospheric Adjustment Instructions for MINI-MAX and PACK-IT:
1. Slide the rubber nozzle of the hand pump over the inflation valve. Pinch
the nozzle and open the inflation valve. Inflate until the cushion arches
slightly.
2. Remove the hand pump. Do not close the inflation valve. Allow air to
escape from the inflation valve.
3. Listen (or place your hand in front of the inflation valve) to confirm that
deflation has stopped.
4. Turn the inflation valve clockwise to close.
5. Place the cushion on the surface, making sure the air cells face the individual.
CHECK INFLATION! After adjustment, confirm that there is NO CONTACT between the
individual and the base of the cushioning device. If there is contact, add air.
Open
Close
CHECK INFLATION! After atmospheric adjustment, confirm that there is NO CONTACT
between the individual and the base of the cushioning device. If there is contact, add air.
When possible, use the hook or loop fasteners to further secure the product to the
surface.

6
ROHO Special Application Cushioning Devices Operation Manual
MINI-MAX Cushion and PACK-IT Cushion, Continued
Cover Removal: Unzip the cover and remove the cushion.
MINI-MAX Cover Replacement: Insert the cushion into the cover. Pull the inflation valve
and Yellow Rope through a corner opening.
PACK-IT Cover Replacement: Insert the PACK-IT into the cover. Close the zipper.
Shower/Commode Seat Cushion and Toilet Seat Cushion
Intended Use: The ROHO®Shower/Commode Cushion
(Shower/Commode Cushion) is an adjustable, air-
filled, cellular-design, support surface that utilizes
DRY FLOATATION®technology and is intended for
short-term cushioning needs on bedside commodes
and shower chairs to provide skin/soft tissue
protection. There is no weight limit.
Intended Use: The ROHO®Toilet Seat Cushion (Toilet
Seat Cushion) is an adjustable, air-filled, cellular-design,
neoprene surface intended for short-term cushioning
needs on toilets and portable bedside commodes. There is
no weight limit.
Instructions for Shower/Commode Cushion and Toilet Seat Cushion:
1. Slide the rubber nozzle of the hand pump over the inflation valve(s). Pinch the nozzle
and open the inflation valve(s). Inflate the cushion, and then close the
inflation valve(s) completely. Remove the hand pump.
2. Place the cushion on the surface, making sure the air cells face the
individual. Confirm that the individual is in their usual position. Confirm
correct placement of the cushioning device.
3. Adjust the inflation level as required. Close the inflation valve(s) when
adjustment is complete.
Toilet Seat Cushion Attachment: Use the straps and snaps to secure the
cushion to the surface.
CHECK INFLATION! After adjustment, confirm that there is NO CONTACT between
the individual and the base of the cushion. If there is contact, add air.
Contact between the skin and areas where the toilet seat is NOT covered by the
Toilet Seat Cushion could result in tissue damage.
Open
Close

7
ROHO Special Application Cushioning Devices Operation Manual
Recliner System
Intended Use: The ROHO®Recliner System (Recliner
System) is an adjustable, air-filled, cellular-design,
support surface that utilizes DRY FLOATATION®technology
and is intended to conform to an individual's seated
shape to provide localized skin/soft tissue protection and
an environment to facilitate wound healing. There is no
weight limit, yet the cushion must be properly sized to the
individual.
Instructions:
1. Place the Recliner System on the chair with the
air cells facing up and the non-skid surface of
the cover facing the chair seat and chair back.
When possible, use the hook or loop fasteners to further secure the cover to
the seating surface. On the back cushion, hook and loop fasteners are located
inside the cover and on the back of the cushion.
2. Slide the rubber nozzle of the hand pump over the inflation valve. Pinch
the nozzle and open the inflation valve. Inflate until the cushion begins
to arch slightly. Pinch the rubber nozzle of the hand pump and close
the inflation valve completely. Remove the hand pump. Repeat for all
inflation valves.
3. Confirm that the individual is in their usual position. Confirm correct
placement of the Recliner System.
4. Slide your hand between the each cushion and the individual and feel
for bony prominences. With your hand in place, open the inflation valve,
releasing air as prescribed. Close the inflation valve. Repeat for all inflation valves.
Recliner Cushion Cover Removal: Unsnap and remove the covers from the cushions.
Recliner Cushion Cover Replacement:
1. The zipper on the Back Cushion cover should be closed. For Seat Cushion and Back
Cushion: The non-skid cover material should face up and the snapped opening of the cover
should face you. The air cells should face down: Insert each cushion into its cover, inflation
valve(s) first. Pull the inflation valve(s) and Yellow Rope through the corner opening(s). The
inflation valves will protrude at the front of the Seat Cushion and at the top of the Back
Cushion.
2. Place the two cushions with the snapped openings next to each other. Snap the Back
Cushion to the Seat Cushion. Snap the bottoms of the covers together. Turn the cushions
over so the air cells face up. Snap the tops of the covers together. The cushions should lie
flat inside the covers.
Shown
without
cushion
covers.
CHECK INFLATION! ROHO, Inc. recommends at least ½ in. (1.5 cm) of space
between the cushion base and the individual’s bony prominences. Follow the
prescriber’s recommended inflation levels.
The seated figure shows
standard orientation.
Open
Close

8
ROHO Special Application Cushioning Devices Operation Manual
Cleaning and Disinfecting
Instructions apply to the products featured in this manual.
Cleaning and disinfecting are separate processes. Cleaning must precede
disinfection. Before use by a different individual: clean, disinfect, and check
product for proper functioning.
Cover Care: Remove hook fastener pieces from bottom of cover prior to cleaning and
disinfecting. For the cover on the Recliner System back cushion: Turn the cover
inside out, close the zipper and snaps. Wash with like colors.
To Clean the
Cover:
First remove the cover from the cushioning device. Machine wash in cold water
(30°C) with mild detergent, gentle cycle, or wipe clean with neutral detergent and
warm water. Tumble dry low.
To Disinfect
the Cover:
Hand wash in cold water (30°C) using 1 part household liquid bleach per 9 parts
water, then rinse thoroughly. Or machine wash in hot water (60°C). Tumble dry
low.
Follow the safety guidelines on the bleach container.
Cushion Care
Cautions:
DO NOT allow water or cleaning solution to enter the cushion. DO NOT machine
wash or sanitize the cushion or machine dry the cushion. Use of the following
may cause damage to the cushion: abrasives (steel wool, scouring pads); caustic,
automatic dishwasher detergents; cleaning products that contain petroleum or
organic solvents, including acetone, toluene, Methyl Ethyl Ketone (MEK), naphtha,
dry cleaning fluid, adhesive remover; oil-based lotions, lanolin, or phenolic-based
disinfectants; ozone gas; ultraviolet light cleaning methods.
To Clean the
Cushion:
Remove the cover and close the inflation valve. Hand wash, using mild liquid
hand soap, hand dishwashing liquid, laundry detergent, or a multipurpose
detergent (Follow product label instructions.) Gently scrub all cushion surfaces,
using a soft plastic bristle brush, a sponge or a cloth. Rinse with clean water. Air
dry. DO NOT expose to direct sunlight.
To Disinfect
the Cushion:
Repeat cleaning instructions, using 1 part household liquid bleach per 9 parts
water. Follow the safety guidelines on the bleach product label. Keep the product
wet with the bleach solution for 10 minutes. Rinse thoroughly with clean water.
Air dry.
NOTE: Most germicidal disinfectants are safe if used following the disinfectant
manufacturer’s dilution directions.
NOTE About
Sterilization:
High temperatures accelerate aging and will damage the product assembly. ROHO
products are not packaged in a sterile condition, nor are they intended or required
to be sterilized prior to use. If institution protocol demands sterilization: First, fol-
low the cleaning and disinfecting instructions; then, open the inflation valve and
use the lowest possible sterilizing temperature, but not to exceed 60°C (158°F),
for the shortest time possible. DO NOT autoclave.
30C
1:9
+
30C

9
ROHO Special Application Cushioning Devices Operation Manual
Troubleshooting
For additional assistance, contact your clinical professional, distributor, or ROHO, Inc.
Not Holding Air: Inflate the cushion. Confirm that the inflation valve is completely
closed. Look for holes in the cushion. If very small holes or no holes
are visible, follow the instructions in the Repair Kit provided with
your product. For inflation valve or hose damage, or for large holes or
leaks in the cushion, see the ROHO Limited Warranty supplement, or
contact Customer Care.
Uncomfortable
or Unstable:
Check the inflation level (see the product instructions). Confirm that the
air cells and the top of the cover face the individual. Confirm that the
cushioning device is not too big or too small for the surface. Allow the
individual at least one hour to adjust to the cushioning device.
Cushioning
Device Slides:
Make sure the non-skid bottom of the cover is facing away from
individual. Confirm that the hook and loop fasteners, straps, or snaps
are securely fastened.
Disposal
The components of the products in this manual are associated with no known
environmental hazards when properly used and when disposed of in accordance with all
local/regional regulations. Incineration must be performed by a qualified, licensed waste
management facility.
Limited Warranty
Limited Warranty Term: 24 months from the date the product was originally purchased.
The warranty does not apply to punctures, tears, burns, or misuse, nor does it apply to the
removable cover. See also the ROHO Limited Warranty supplement provided with your product, or
contact Customer Care.
