CHAPTER 1- SUMMARY of USER’S COMMANDS
The Summary of User’s Commands offers installers and users a quick and
convenient way to operate control panel. All can be done under the state of
disarm and so it doesn’t need to enter programming statue. For detailed
information, please go chapter 2.
Function Procedure
Quick arm [ARM]
Arm by code [ARM]+[master code]
Stay Arm [STAY]
Stay Arm by code [STAY]+[master code]
System disarm [user code]
Bypass disarm [duress code]
Free from siren [user code]
Bypass/un-bypass zone [*]+[1]+[user code]+[zone number]
Quick bypass/un-bypass zone [zone ]at least 2 seconds
Display trouble [*]+[3]
Display time [*]+[4]
Set/change main code [*]+[5]+[master code]+[0]+[new code]
Set/change a user code [*]+[5]+master code]+[1-9]+[new code]
Set date [*]+[6]+[1]+[master code]+[MM][DD][YY]
Set time [*]+[6]+[2]+[master code]+[H][H][M][M]
Auto arm time [*]+[6]+[3]+[master code]+[H][H][M][M]
Set follow-me phone no. 1 [*]+[7]+[1]+[master code]+[phone No. 1]+[#]
Set follow-me phone no. 2 [*]+[7]+[2]+[master code]+[phone No. 2]+[#]
Set follow-me phone no. 3 [*]+[7]+[3]+[master code]+[phone No. 3]+[#]
Set follow-me phone no. 4 [*]+[7]+[4]+[master code]+[phone No. 4]+[#]
On/off buzzer [*]+[8]+[master code]+[1]
On/off door chime [*]+[8]+[master code]+[2]
Audible kiss-off [*]+[8]+[master code]+[3]
Display memory [*]+[9]+[master code]+[enevt number]
Test system [*]+[0]+[master code]
keypad panic alarm [1]+[2] at leadt 2 seconds
keypad fire alarm [4]+[5] at least 2 seconds
keypad special emergency [7]+[8] at least 2 seconds
Escape [ESC]
Trouble Table
LCD Trouble
Battery Low The Backup Battery Power is low.
AC Power AC Power is lost.
No Clock Clock have not been set
No Communication The Communication is in trouble.
No Siren The Siren connection is in trouble.

RP208CN User’s and Installer’s Manual Page 4
CHAPTER 2 – ABOUT THE KEYPAD
RP208KCL(LCDKeypad)
The RP208CN can support LCD Keypad. Each control panel can work with four
LCD Keypads at most.
Each keypad in your system reports its status by its LED (lighted) indicators and
LCD display. Through its keys, you can enter commands to Arm and Disarm the
system, bypass intrusion zones, report emergencies, stop the siren, checking the
trouble, programming the system and other handling.
Fig.1 Layout of the RP208KCL
Keypad Instruction
1－Power
2－LCD Display
3－Arm
4－Disarm
5－Bypass
6－Fire
7- Tamper
8－Arm key-press
9－Staykey-press
10－Buzzer
11－Exit/Delete key-press
12－Digit and Function key-press

RP208CN User’s and Installer’s Manual Page 5
LEDIndicationandKeys
1. Power LED
On--The system is operating properly from commercial (AC) power; its
backup battery is in good condition.
Off--The system is inoperative due to the lack of power (from both
commercial AC and backup battery).
Flash-- Indicates a trouble condition.
2. LCD Display
The LCD Display on RP208KCL indicate the status of each of the system,
including zones Triggered, Armed/Disarmed system, Trouble, Time and other
programming information. If there is only “ROISCOK” on the display, which
means all the zones are not triggered. When Z1, Z2, Z3, Z4, Z5, Z6, Z7 or Z8
is/are displayed on the display, which means the zone is triggered:
Statue Explanation
System Disarmed System Armed
ROISCOK All the zones are secured and working normally
Z1 Zone 1 was triggered An alarm has occurred on Zone1
Z2 Zone 2 was triggered An alarm has occurred on Zone2
… … …
Z8 Zone 8 was triggered An alarm has occurred on Zone8
3. ARM LED
The ARM LED indicates whether or not the system is armed. In armed
condition, the ARM LED is on, in case of any violations, there will be an alarm.
The ARM LED is flashing, which means burglar, fire or emergency alarm once
has/have occurred in the corresponding zone(s). The ARM LED is off when the
system is disarmed.
Statue EXPLANATION
On
When the system is armed, in case of any emergency, an
alarm will occur. The Siren will sound, and system will also
dial the follow-me numbers and send alarm report to alarm
center.
Off The system is disarmed.
Flashing Burglar, fire and/or has/have once occurred.

RP208CN User’s and Installer’s Manual Page 6
4. READY LED
The Ready LED indicates whether the system is working normally or not, and
also indicates whether system can be armed or not. When disarm, the LED will
be on; when arm, the LED will be off.
STATUS EXPLANATION
On All the zones are working normally, and then the system can
be armed now.
Off 1. Someone is moving in the zone.
2. The system is armed.
Flashing The system is under the programming status
5. BYPASS LED
The BYPASS LED Indicate that one or more of the system’s intrusion zones
have been bypassed; for more information on bypassing.
6. FIRE LED
When fired the LED flashing rapidly.
7. TAMPER LED
When the detector(s) or the keypad is /are tampered or destroyed, a Tamper
Code report will be sent and the LED will be flashing.
8. System Arming [ARM]
When [ARM] key is depressed, all the zones are armed.
9.Stay Home Arming [STAY]
Home Arming (or Stay Arming) allows individuals to remain inside and move
about the premises even after the system is armed. Home Arming arms the
perimeter detectors (e.g. door and windows), while leaving interior detectors
(e.g. motion detectors) disarmed (bypassed). When [STAY] key is depressed,
the interior zones will not be armed.
10. Exit/Delete [ESC]
Key [ESC] is suitable for correction system operation

RP208CN User’s and Installer’s Manual Page 7
11. Digit Keys
When programming, key in 0-9 digits.
12. Function Key [*] [#]
When programming, key [*] to enter function mode; and [#] for confirmation.
Function and Operation
Keys and Functions
The Keys can support the following functions:
1. Enter digit(s) for Arming, Disarming, Panic Alarm, Programming etc.
2. Enter user’s function mode.
3. Key [ARM] is for Quick Arming and Code Arming. By pressing it, the
system will be fully armed.
4. Key [STAY] is for Quick Stay Arming and Code Stay Arming. By pressing it
to arm, only part of the zone is armed. Each zone can be set as interior
zone or external zone. When use [STAY] for arming, the external zone is
armed while leaves the interior zone disarmed.
5.Under the disarmed status, press [*] to enter user’s function mode.
Reference to CHAPTER 1- SUMMARY of USER’S COMMANDS
1. Setting/Changing and Deleting User’s Code
The default Master Code of RP208CN is 1-2-3-4. Unless your alarm company
has already changed it to suit your preference, it’s best to modify this code to
one which is unique and personalized. RP208CN can set 10 of Codes, one is
Master Code and another 9 are User’s Codes. To change the Master Code,
and /or to set up User Coeds, follow the steps. Make sure the system is
disarmed when setting the code. The User’s Codes are only for Arming and
Disarming the system
Functions of the Master Code:
Adding, changing and deleting User’s Code
Setting Time Clock
Operating and testing
Setting the follow-me numbers

RP208CN User’s and Installer’s Manual Page 8
Setting / Changing the master Codes
Step Operation
1 The system must be disarmed (the ARMED LED will be
OFF). Enter the User Functions Mode [*][5]
2 Enter the current 4-digit Master Code:
For example, Press [ 1][2 ][3 ][4 ]
3 Press [0]
4
Enter the new 4-digit code selected will emit a one-second
confirming tone. The selected User Code is now in effect.
For example, press[5 ][6][7 ][ 8]
5 If successful, the keypad will emit a confirming tone “Beep
－”. The selected User Code is now in effect.
Setting/Changing 1-9 User Codes
At times, it may be desirable to completely delete a User Code. Note that it is
impossible to delete the Master Code (although it can be changed).
Step Operation
1
The system must be disarmed. Enter the User Functions Mode
[*] and choose Codes [5]
Press [*][5]
2 Enter the current 4-digit Master Code:
For example, [5 ][6 ][7 ][8 ]
3
To set/delete the User Code 1, press [1]
To set/delete the User Code 2, press [2]
To set/delete the User Code 3, press [3]
…
The other Codes can be set/deleted in the same way.
4 Enter the new User Code:
For example, [3][3][5][5]
5 If successful, the keypad will emit a confirming tone “Beep－”.
The selected User Code is now in effect.
Deleting User’s Codes
At times, it may be desirable to completely delete a User Code. Note that it is
impossible to delete the Master Code (although it can be changed).
Step Operation
1 The system must be disarmed. Enter the User Functions Mode
[*] and choose Codes [5], Press [*][5]
2 Enter the current 4-digit Master Code: [5 ][ 6][7 ][8 ]

RP208CN User’s and Installer’s Manual Page 9
3
To delete the User Code1, press [1]
To delete the User Code1, press [2]
To delete the User Code1, press [3]
…
The other Codes can be deleted in the same way.
4 Enter the [#]
5 If successful, the keypad will emit a one-second confirming
tone. The selected User Code is now deleted.
2. Setting Date and Time
Set date: [*]+[6]+[1]+[MASTER CODE]+[MM][DD][YY]
Month, Date and Year should all be two digits.
Set time: [*]+[6]+[2]+[MASTER CODE]+[HH][MM]
Use a 24-Hour format. Hour and Minute should be two digits.
For example, if you want to enter 16:28, August 18, 2006, operate as :
[*]+[6]+[1]+[MASTER CODE]+[08][18][06]
[*]+[6]+[2]+[MASTER CODE]+[16] [28]
3. Displaying System Date and Time
Press [*]+[4] to check the system time on LCD keypad. And the format
should be:
MM/DD/YY Hour :Minute
4. Setting Follow-me Number
In case of an alarm event, a phone call can be made to one or more
predefined phone number. There are three different tone types that represent
burglary, fire and special emergency alarms.
The Follow-Me function can support four phone numbers for each system.
Make sure the numbers are all correct; then enter [#]. Operate as:
Set Follow-Me Phone NO.1: [*]+[7]+[1]+[MASTER CODE]+Phone NO.1+[#]
Set Follow-Me Phone NO.2: [*]+[7]+[2]+[MASTER CODE]+Phone NO.2+[#]
Set Follow-Me Phone NO.3: [*]+[7]+[2]+[MASTER CODE]+Phone NO.3+[#]
Set Follow-Me Phone NO.4: [*]+[7]+[2]+[MASTER CODE]+Phone NO.4+[#]

RP208CN User’s and Installer’s Manual Page 10
5. Quick Arming
RP208CN can be divided as interior zone and external zone by programming.
Zone 7 and Zone 8 are defaulted as interior zone.
Press [ARM], and all the zones will be armed.
Press [STAY], then external zone will all be armed while leaves the interior
zones disarmed.
Step Operation
1
Before you arm your system, all of its zones must either be
secured or bypassed .The keypad’s READY LED, if lit,
indicates that all zones are secured. If the READY LED is not
lit, one or more unsecured zone(s) will be display on the LCD.
2
Quick Arming and Code Arming:
Quick Armed：Armed the system just by press [ARM].
Quick Stay Armed：Stay Armed just press [STAY].
3 Three short Beep from the keypad when there are some errors
in entering. Then re-operate it.
4
When arming the system, there will be one confirmation sound,
which means the exit delay begin now. Then leave here before
the exit delay time is over to avoid false alarm. The exit delay
time is defaulted as 30 seconds.
6. Code Arming
Your RP208CN offers two methods of arming, Quick Arming and Code Arming.
It’s defaulted as quick arm. If the user requires code arm, it should be set when
programming in advance.
When RP208CN is set as code arm, it can not support [ARM] and [STAY] for
quick arming. And it should be operated as: [ARM] + [Master Code], or [STAY]
+ [Master Code] to arm or stay arm.
7. Bell Squawk on Arming
If selected, Bell Squawk on Arming will produce a brief confirmation "chirp"
from the system's external sounder(s) once the system is armed and the Exit
Delay expires. To cancel it, refers to Location 30 in Chapter 5.
8. Disarming
RP208CN can set 10 Codes (4 digits), one Master Code and 9 User Codes. In
arming status, simply enter any code of the 10 codes to disarm.
