Roiscok RP208KCL User manual

INDEX
CHAPTER 1- SUMMARY OF USER’S COMMANDS ....................................... 3
CHAPTER 2 – ABOUT THE KEYPAD .............................................................. 5
RP208KCL (LCD KEYPAD) ........................ 5
KEYS AND LED INDICATORS .............................. 5
CHAPTER 3 – SYSTEM FUNCTION AND OPERATION ................................. 9
3.1 DEPRESS KEYS AUDIBLE ........................... 9
3.2 DOOR CHIME .................................. 9
3.3 THE NUMERIC KEYS AND CHARACTER RELATIVE FORM ............... 9
3. DIGIT KEYS AND FUNCTIONS KEYS ..................... 10
3.5 MODIFYING/ SETTING AND DELETING CODE ............. 10
3.6 SET DATE AND TIME ............................. 1
3.7 SET FOLLOW-ME NUMBERS ......................... 1
3.8 ARM AND ARM SOUND ............................ 1
3.9 DISARM AND DISARM SOUND ......................... 15
3.10 DURESS CODE DISARM .............................. 16
3.11 STOP SIREN/BELL AND STOP DIALING A NUMBER ................. 16
3.12 BYPASS AND UN-BYPASS ZONE(S) ........................ 16
3.13 EXIT A ERROR OPERATION ......................... 18
3.1 KEYPAD ALARM ................................. 18
3.15 ENTRY DELAY AND EXIT DELAY .................... 18
3.16 TROUBLE AND DISPLAY ........................ 18
3.17 ZONES CHARACTERS ........................... 19
3.18 SYSTEM PARTITION AND CONTROL .................... 19
CHAPTER 4 SYSTEM INSTALL EXPLAIN .................................................... 22
.1 PREPARATION BEFORE INSTALLATION ................ 22
.2 FQA OF INSTALLATION AND SOLUTION ................ 22
.3 MAIN BROAD LAYOUT AND PORT FUNCTION DESCRIPTION ： ..... 23
.5 CONNECT THE TELEPHONE LINE ...................... 2
.6 CONNECT THE STANDBY BATTERY ...................... 26
`RP2 8CN User’s and Installer’s Manual

.7CONNECT TRANSFORMER ........................... 26
.8 CONNECT SIREN/BELL ......................... 26
.9 CONNECT DETECTOR(S) ........................... 26
.10 CONNECT VOICE MODULE ........................ 26
CHAPTER 5 - FUNCTION AND TECHNICAL DATA ...................................... 2
5.1 FEATURES OF RP2 8KCL ....................... 28
5.2 FEATURES OF RP2 8MB AND EXPANSION MODULES ........ 29
5.3 TECHNICAL DATA ................................ 3
CHAPTER 6 PROGRAMMING DIRECTION .................................................. 36
6.1 PROGRAMMABLE ITEMS ............................ 36
6.2 RESTORE FACTORY DEFAULTS ................... 36
6.3 PROGRAM EXPLAIN .............................. 36
6. CHECK LOCATION DATA ............................ 37
6.5 ENTRY/EXIT PROGRAM STATUS .................. 37
6.5.1 Special Explain ............. 37
6.5.2 System Program .............. 37
6.5.3 Set Zones ............... 41
6.5.4 Programmable Utility O tp t
................................................................................................................ 43
6.5.5 Code Maintenance ........ 45
6.5.6 Dialer ............... 46
6.5.7 Report Code .......... 49
6.5.8 Add Keypad and Mod le . . 50
6.6 COMMUNICATION PROTOCOLS .......................... 50
6.7 RP2 8CN CONTROL PANEL CONTACT ID REPORTING CODES ... 51
ROISCOK’S WARRANT ................................................................................. 53
`RP2 8CN User’s and Installer’s Manual

CHAPTER 1- SUMMARY of USER’S COMMANDS
The Summary of User’s Commands offers installers and users a quick and convenient way to
operate control panel. All can be done under the status of disarm and so it doesn’t need to entry
programming statue. or detailed information, please go chapter 2 and chapter 3.
No Function Procedure
1 Quick arm [ARM]
2 Arm by code [ARM]+[master code]
3 Arm Stay zones [STAY]
4 Arm Stay zones by code [STAY]+[master code]
5 System disarm [user code]+[#]
6 Duress disarm [duress code]+[#]
7 ree from siren [user code]+[#]
Bypass zone [*]+[1] [1]+[user code]+[zone number]
9 Un-bypass zone [*]+[1] [2]+[user code]+[zone number]
10 Utility output [*]+[2][1]
11 Set follow-me phone No. [*]+[2][7]+[ user code]+[ phone No.]
12 Display trouble [*]+[3][1]
13 Display triggered record [*]+[3][2]
14 Display unready zone [*]+[3][3]
15 Display zone status [*]+[3][4]
16 Display memory [*]+[3][5]
17 Test keypad [*]+[4][1]
18 Test Stand-by battery [*]+[4][2]
19 Off door chime [*]+[4][3]
20 On door chime [*]+[4][4]
21 Off partition door chime [*]+[4][5]
22 On partition door chime [*]+[4][6]
23 Off buzzer [*]+[4][7]
24 On buzzer [*]+[4][8]
25 Delete memory [*]+[4][9]
26 Set/change users code [*]+[5]
27 Set time [*]+[6]+[1]
28 Set date [*]+[6]+[2]
29 Next Auto arm time [*]+[6]+[3]
30 Next Auto disarm time [*]+[6]+[4]
31 Auto arm [*]+[6]+[5]
32 Auto disarm [*]+[6]+[6]
33 Auto stay arm [*]+[6]+[7]
34 keypad panic alarm [1]+[2] at least 2 seconds
35 keypad fire alarm [4]+[5] at least 2 seconds
36 keypad special emergency [7]+[8] at least 2 seconds
37 Escape [ESC]
RP2 8CN User’s and Installer’s Manual Page 3

Trouble List
LCD Display Trouble
MAIN：LOW BATT Battery Power low
MAIN：AC TROUBLE AC lost
MAIN：BELL LOOP Siren trouble
LASE CODE P=1 Code error
KITCHEN：IR ire Loop in trouble
KP=03 COMM TRBL The bus in trouble, such as No.3 keypad is in trouble
SYSTEM CLCOK Clock not set
PS= 1 LOW BAT Power Module Battery low. Such as No.1 power Expansion
Module is in trouble
PS=1 AC TRBL Power Module in AC Trouble. Such as No.1 power Expansion
Module is in trouble
PS=1 BELL TRBL Power Module Siren in Trouble. Such as No.1 power
Expansion Module is in trouble
PS=1 AUX TRBL Power Module Stand-by Power is low. Such as No.1 power
Expansion Module is in trouble
PHONE LINE Phone line in trouble
IRE DOOR：DAY Day time zone in trouble.
RP2 8CN User’s and Installer’s Manual Page

CHAPTER 2 – ABOUT THE KEYPAD
RP20 KCL (LCD Keypad)
The control panel RP248CN supports LCD Keypad. Each main board can work with 16 LCD
Keypads at most.
The keypads display system status by its LED indicators and LCD display. Through its keys, can
arm and disarm the system, bypass intrusion zones, report emergencies, stop the siren, stop
calling follow-me number, checking the trouble, program the system etc.
Fig.1 Layout of the RP20 KCL
Keys Instruction
1：Power LED
2：LCD Display
3：Arm LED
4：Disarm LED
5：Bypass LED
6：ire LED
7：Tamper LED
8：Digit and unction key-press
9：Arm key-press
10：Buzzer
11：Stay Arm key-press
Keys and LED indicators
The Keys functions:
1. or Arming, Disarming, Panic Alarm, Programming system etc.
2.Entry user’s function mode.
3.Key [ARM] is for quick arming and code arming. When arm by [ARM], the system will be fully
armed.
RP2 8CN User’s and Installer’s Manual Page 5

.Key [STAY] is for quick stay arming and code stay arming. Any zone or zones can be set as
interior zone(s) or external zone(s). When arming by [STAY], the external zone(s) will be
armed while leaves the interior zone(s) disarmed.
5.Under the disarmed status, depress [*] to entry user’s function mode for setting code, clock,
on/off the buzzer and so on. or detail, go to CHAPTER 1- SUMMARY of USER’S
COMMANDS
1. Power LED
On--the system AC power supply is in normal and the stand-by battery is in good condition.
Off—no AC power supply and stand-by battery is in power lack.
ast flicker—system in trouble.
Slow flicker—system is in users function.
2. LCD Display
The LCD Display on RP248KCL indicates the system status, including zones triggered,
armed/disarmed system, system trouble, time and other programmed information.
Normally the LCD Display indicates partition No., clock, date and weekday as following:
PARTITION 1
10.18 JAN 10 THU
3. ARM LED
On-- system is armed.
Off-- system is disarmed or under the programming status.
licker-- The system is under the delay period status.
4. READY LED
The Ready LED indicates whether the system is under ready or not, and also whether system can
be armed or not.
On-- The system is ready to be armed now.
Off-- The system is not ready to be armed now.
licker-- The system is ready for arming, and at the same time some especial zone(s) with entry
/exit delay is triggered.
RP2 8CN User’s and Installer’s Manual Page 6

5. BYPASS LED
When BYPASS LED on, one or more zone(s) has/have been bypassed or under stay statue.
6. FIRE LED
The LED flicker rapidly when fired.
7. TEMPER LED
When the detector(s), the keypad or the Expansion Module is /are tempered or destroyed, a
Tamper Code report will be sent and the LED will be flicker.
. Digit Keys
When programming, key in 0-9 digits.
Under the status of users function, quick go to the menu.
9. System Arming [ARM]
When depress [ARM] key, all the zones are armed. The LED Display delay time.
Under the user functional status, the key [ARM] is used to set data. or example, when setting the
clock, [ARM] can be used to choice the month, weekday and partition.
10. Keypad Buzzer
The buzzer is used for indicating the entry/exit delay, alarm, door chime and so on.
11. Stay Home Arming [STAY]
When depress [STAY] key, the interior zones will not be armed. During stay arming,
the LCD display the delay time.
Under user function, the [STAY] key is used to set data. or example, when setting the
clock, [STAY] is used to choice month, weekday and partition.
12. Function Key [*]
Depress [*] Key into the function set ting status.
Back t o the anterior menu or return to the normal status.
RP2 8CN User’s and Installer’s Manual Page 7

13. Confirm Key [#]
The Key [#] used for confirm and save input data.
1 . Moving Key [←][→]
Key [←] is used to choice the anterior command, or moving the cursor to left.
Key [→] is used to choice the next command, or moving the cursor to right.
15. Panic Alarm Key [1]＋[2]
Depress [1]+[2] at least 2 seconds, the system will send a panic alarm message to CMS or
following-me numbers.
16. Fire Alarm Key [4]＋[5]
Depress [4]+[5] at least 2 seconds, the system will send a fire alarm message to CMS or following-
me numbers.
17. Special Emergency Key[7]＋[ ]
Depress [7]+[8] at least 2 seconds, the system will send a special emergency message to CMS or
following-me numbers.
RP2 8CN User’s and Installer’s Manual Page 8

CHAPTER 3 – SYSTEM FUNCTION AND OPERATION
3.1 Depress Keys Audible
When depress any keys, keypad will emit a brief deep.
After any successful operation the keypad will emit a long beep to confirm. And after error
operation, the keypad will emit three brief beep warn.
When arming, the keypad(s) will beep until the end of the exit delay time.
When trigger an armed zone, the keypad will beep until end the entry delay time. The
system must be disarmed, if not, it will be triggered.
If zone(s) programmed as door chime function, when triggered the zone(s), keypad will emit
three short beeps.
When use keypad for panic alarm, fire alarm and special emergency, there will be a brief
beep.
When triggered alarm, keypad will emit a beep for confirming.
It will not change the setting for siren/bell after change the buzzer setting on the keypad.
3.2 Door Chime
Each keypad can emit a continuous brief sound, called as DOOR CHIME. If you set the door
chime function, the keypad will emit a door chime sound when the door or window is opened. Turn
on/off the door chime by operation [*]+[4]+[master]+[5] or [6].
3.3 The numeric keys and character relative form
Keys
1 A B C D E G H I J K L M
2 N O P Q R S T U V W X Y Z
3 ! “ & ‘ : - ? . / ( ) [ ]
4 a b c d e f g h i j k l m
5 n o p q r s t u v w x y z
6
7
8
9
0
RP2 8CN User’s and Installer’s Manual Page 9

Program as the following:
1.The Key [←] and [→] are used move the cursor to the left or to the right.
2.Key in the character as the above form, such as depress [1] twice to entry the “A” and depress
[2] four times to entry the “P”.
3.After entry one character, move the cursor to entry other one by Key [←][→].
4. After program, depress [#] to confirm, or depress [*] to cancel.
3.4 Digit Keys and Functions Keys
The Keys can support the following functions:
1.Entry digit(s) for arming, disarming, panic alarm, programming system etc.
2.Entry user’s function mode.
3.Key [ARM] is for quick arming and code Arming.
. Key [STAY] is for quick stay arming and code stay arming. Each zone can be set as interior
zone or external zone. When use [STAY] for arming, the external zone is armed while leaves
the interior zone disarmed.
5.Under the disarmed status, depress [*] to entry user’s function mode. Reference to CHAPTER
1- SUMMARY of USER’S COMMANDS
3.5 Modifying/ Setting and Deleting Code
The Master Code of RP248CN could be set as four or six digit code. The default master code is 1-
2-3-4. Unless your alarm company has already changed it to suit your preference, it’s best to
modify this code to one which is unique and personalized. RP248CN can set a great deal of
codes, one is master code and others are users’ code. The system code can be set under the
disarm status.
Functions of the Master Code:
Change the master code
Distribute, delete and change the system user’s code.
Access to all zones.
RP2 8CN User’s and Installer’s Manual Page 10
