Roland V-Drums Portable TD-4KP User manual

Powerful, Playable, Portable
Surprisingly Compact
Fold and Store
In the Car
Ultra Portable
In Your Room
Intensive Training
At the Gig
Unfold and Play
The compact design of the V-Drums Portable
is perfect for homes, as it greatly minimizes
the space needed for playing as well as storage.
For students practicing at home,
the Coach and Quick Rec functions will
help improve their skills, especially during
private practice sessions with headphones.
With its innovative foldable design,
the V-Drums Portable TD-4KP makes drumming
more convenient and mobile than ever.
It's a drummer's dream for transport and storage.
And, with V-Drums technology at its core,
it provides “no compromise” sound
and playability.
Roland TD-4KP: V-Drums Portable
Kit Configuration
Kick Pad, Snare, Hi-Hat, Hi-Hat Pedal, Tom x 3, Crash, Ride *Kick pedal and drum throne are not included.
Dimensions mm: 1,000 (W) x 1,200 (D) x 1,250 (H), inches: 39-3/8 (W) x 47-1/4 (D) x 49-1/4 (H)
*setting size is adjustable, **including kick pedal, cymbals, and drum throne
Folded Dimensions mm: 300 (W) x 500 (D) x 700 (H), inches: 11-13/16 (W) x 19-11/16 (D) x 27-9/16 (H)
Weight (excluding AC adaptor) 12.5 kg / 27 lbs 9 oz
Accessories Setup Guide x 2, Owner's Manual, AC adaptor, Special connection cable, Wing bolt (M5 x 10) x 2
TD-4: Percussion Sound Module
Instruments Drum Instruments: 125
Drum Kits 25
Instrument Parameters KICK, SNARE, TOM, PERC: Tuning, Muffling
Mixer Parameters Pad Volume, Pan, Kit Volume, Cross Stick Volume
Ambience Types 9
Rhythm Coach Functions Warm Ups, Time Check, Tempo Check, Quiet Count, Auto Up/Down
Quick Rec Resolution: 96 ticks per quarter note, Recording Method: Real-time, Maximum Note Storage: approx. 9,000 Notes
Display Custom (backlit LCD)
Connectors
Trigger Input connector: DB-25 type (Kick, Snare, Tom1, Tom2, Tom3, Hi-Hat, Crash1, Ride, Hi-Hat Control),
OUTPUT (L/MONO, R) jacks: 1/4 inch phone type, PHONES jack: Stereo 1/4 inch phone type,
MIX IN jack: Stereo miniature phone type, MIDI OUT connector
Output Impedance 1 k ohm
Power Supply AC adaptor
Current Draw 500 mA
Dimensions mm: 224.0 (W) x 151.1 (D) x 65.1 (H), inches: 8-7/8 (W) x 6 (D) x 2-9/16 (H)
Weight (excluding AC adaptor) 477 g / 1 lb 1 oz
V-Drums Portable TD-4KP Specications
Visit us online at www.roland.com/V-Drums/
www.Roland.com
Roland and V-Drums are either registered trademarks or trademarks of Roland Corporation in the United States and/or other countries.
All specifications and appearances are subject to change without notice.
Company names and product names appearing in this document are registered trademarks or trademarks of their respective owners.
It is forbidden by law to make an audio recording, video recording, copy or revision of a third party’s copyrighted work (musical work, video work, broadcast,
live performance, or other work), whether in whole or in part, and distribute, sell, lease, perform, or broadcast it without the permission of the copyright owner.
Do not use this product for purposes that could infringe on a copyright held by a third party. We assume no responsibility whatsoever with regard to any
infringements of third-party copyrights arising through your use of this product.
Printed in Japan November, ’12 RAM-4810 ABF-2 GR-UPR-SS
Bring more music into your life.
Roland invites everyone to experience
the joy of making music.

Quick Setup and Breakdown
Space-Saving
Foldable Design
All Pads Stay Attached
Accessories
V-Drums Friend Jam
To set up, simply extend the stand, raise the pipe,
rotate the pads, and power on to play.
To break down, fold the kit with all pads mounted on the stand …
it's incredibly fast and easy!
Innovative Kick Pad
The kick pad and pedal plate are
built in the rack.
To set up, simply rotate them
into the playing position.
Enjoy the comfortable feel
of the kick pad and
the natural beater movement.
Expressive Drum Set Easy Transport Upgrade Options
V-Drums Sound Quality
Improve Your Drumming Technique
Dynamic sounds, cymbal chokes,
delicate hi-hat nuances —
V-Drums Portable provides a natural and
comfortable drumming experience.
The compact 7.5” drum pads are outfitted
with a cushioned-rubber head;
the dual-trigger 10” cymbal pads provide a sensitive,
accurate response and playing feel.
Thanks to the TD-4KP's lightweight and
compact design, it's easy to fold and carry the kit
with all pads mounted on the stand. Bring it
to the gig by yourself, no assistance required.
You can upgrade the snare
with a V-Pad PDX-6/PDX-8 (optional),
which provides a realistic mesh-head feel
as well as rim-shot playability.
The TD-4 sound module (included with the kit) is packed with world-class drum and percussion sounds.
The sounds can be easily edited, as you can quickly and intuitively customize the kits with tuning/
muffling buttons.Ambience effects can also be added to make the sounds more lively and dynamic.
More than just great sounds onboard,
V-Drums Portable is also equipped with built-in
training programs. The Coach function helps you
improve your drumming technique
with five different modes: Warm Up, Time Check,
Tempo Check, Quiet Count, and Auto Up/Down.
Quick REC captures your drumming
and lets you listen to the results — valuable
for self-evaluation and improvement.
Quick and Clean
The V-Drums Portable kit is equipped
with unique features for fast, easy setup.
Quick Release enables instant positioning
and folding of the cymbals
with one-touch operation.
Cable holders neatly bunch the cables
as well as provide storage
for a drum key or cable plug.
Carrying Case
V-Pad
PDX-8 / PDX-6
Pad Mount
MDH-12
CB-TDP
Personal Monitor
PM-03
Features 2.1-channel speaker
Conveniently transport and protect the TD-4KP with the CB-TDP carrying case.
It features a shoulder strap and detachable pouches for the hi-hat and kick pedals,
plus a handy pocket for beaters, sticks, and other accessories.
V-Drums Accessory Package
DAP-3X
The essential accessories for V-Drummers
Contents: Roland kick pedal,
drum throne, and a pair of drumsticks
Monitor Headphones
RH-A7
The essential digital-instrument
accessory
The Science of Mobility
Innovative Mechanics
V-Drums Mat
TDM-1
Secure-Performance Mat
50cm / 19-11/16"
30cm / 11-13/16"
70cm /
27-9/16"
Drum
Throne
120cm /
47-1/4"
60cm /
23-5/8"
100cm / 43-5/16"
V-Drums Friend Jam is a social-networking site where drummers
from over 140 countries and regions can unit and compete.
www.roland.com/FriendJam/V-Drums/
PDX-8
RH-A7-WH
*Kick pedal not included and shown only for photography purposes.
*
The pads included with the TD-4KP do not support rimshots and cross stick.To enable rimshots and cross stick, replace the snare pad with an optional PDX-6 or PDX-8 V-Pad.
*When you mount a PDX-8/6 on the TD-4KP snare pad,
a MDH-12 clamp is required.

Quick Setup and Breakdown
Space-Saving
Foldable Design
All Pads Stay Attached
Accessories
V-Drums Friend Jam
To set up, simply extend the stand, raise the pipe,
rotate the pads, and power on to play.
To break down, fold the kit with all pads mounted on the stand …
it's incredibly fast and easy!
Innovative Kick Pad
The kick pad and pedal plate are
built in the rack.
To set up, simply rotate them
into the playing position.
Enjoy the comfortable feel
of the kick pad and
the natural beater movement.
Expressive Drum Set Easy Transport Upgrade Options
V-Drums Sound Quality
Improve Your Drumming Technique
Dynamic sounds, cymbal chokes,
delicate hi-hat nuances —
V-Drums Portable provides a natural and
comfortable drumming experience.
The compact 7.5” drum pads are outfitted
with a cushioned-rubber head;
the dual-trigger 10” cymbal pads provide a sensitive,
accurate response and playing feel.
Thanks to the TD-4KP's lightweight and
compact design, it's easy to fold and carry the kit
with all pads mounted on the stand. Bring it
to the gig by yourself, no assistance required.
You can upgrade the snare
with a V-Pad PDX-6/PDX-8 (optional),
which provides a realistic mesh-head feel
as well as rim-shot playability.
The TD-4 sound module (included with the kit) is packed with world-class drum and percussion sounds.
The sounds can be easily edited, as you can quickly and intuitively customize the kits with tuning/
muffling buttons.Ambience effects can also be added to make the sounds more lively and dynamic.
More than just great sounds onboard,
V-Drums Portable is also equipped with built-in
training programs. The Coach function helps you
improve your drumming technique
with five different modes: Warm Up, Time Check,
Tempo Check, Quiet Count, and Auto Up/Down.
Quick REC captures your drumming
and lets you listen to the results — valuable
for self-evaluation and improvement.
Quick and Clean
The V-Drums Portable kit is equipped
with unique features for fast, easy setup.
Quick Release enables instant positioning
and folding of the cymbals
with one-touch operation.
Cable holders neatly bunch the cables
as well as provide storage
for a drum key or cable plug.
Carrying Case
V-Pad
PDX-8 / PDX-6
Pad Mount
MDH-12
CB-TDP
Personal Monitor
PM-03
Features 2.1-channel speaker
Conveniently transport and protect the TD-4KP with the CB-TDP carrying case.
It features a shoulder strap and detachable pouches for the hi-hat and kick pedals,
plus a handy pocket for beaters, sticks, and other accessories.
V-Drums Accessory Package
DAP-3X
The essential accessories for V-Drummers
Contents: Roland kick pedal,
drum throne, and a pair of drumsticks
Monitor Headphones
RH-A7
The essential digital-instrument
accessory
The Science of Mobility
Innovative Mechanics
V-Drums Mat
TDM-1
Secure-Performance Mat
50cm / 19-11/16"
30cm / 11-13/16"
70cm /
27-9/16"
Drum
Throne
120cm /
47-1/4"
60cm /
23-5/8"
100cm / 43-5/16"
V-Drums Friend Jam is a social-networking site where drummers
from over 140 countries and regions can unit and compete.
www.roland.com/FriendJam/V-Drums/
PDX-8
RH-A7-WH
*Kick pedal not included and shown only for photography purposes.
*
The pads included with the TD-4KP do not support rimshots and cross stick.To enable rimshots and cross stick, replace the snare pad with an optional PDX-6 or PDX-8 V-Pad.
*When you mount a PDX-8/6 on the TD-4KP snare pad,
a MDH-12 clamp is required.

Powerful, Playable, Portable
Surprisingly Compact
Fold and Store
In the Car
Ultra Portable
In Your Room
Intensive Training
At the Gig
Unfold and Play
The compact design of the V-Drums Portable
is perfect for homes, as it greatly minimizes
the space needed for playing as well as storage.
For students practicing at home,
the Coach and Quick Rec functions will
help improve their skills, especially during
private practice sessions with headphones.
With its innovative foldable design,
the V-Drums Portable TD-4KP makes drumming
more convenient and mobile than ever.
It's a drummer's dream for transport and storage.
And, with V-Drums technology at its core,
it provides “no compromise” sound
and playability.
Roland TD-4KP: V-Drums Portable
Kit Configuration
Kick Pad, Snare, Hi-Hat, Hi-Hat Pedal, Tom x 3, Crash, Ride *Kick pedal and drum throne are not included.
Dimensions mm: 1,000 (W) x 1,200 (D) x 1,250 (H), inches: 39-3/8 (W) x 47-1/4 (D) x 49-1/4 (H)
*setting size is adjustable, **including kick pedal, cymbals, and drum throne
Folded Dimensions mm: 300 (W) x 500 (D) x 700 (H), inches: 11-13/16 (W) x 19-11/16 (D) x 27-9/16 (H)
Weight (excluding AC adaptor) 12.5 kg / 27 lbs 9 oz
Accessories Setup Guide x 2, Owner's Manual, AC adaptor, Special connection cable, Wing bolt (M5 x 10) x 2
TD-4: Percussion Sound Module
Instruments Drum Instruments: 125
Drum Kits 25
Instrument Parameters KICK, SNARE, TOM, PERC: Tuning, Muffling
Mixer Parameters Pad Volume, Pan, Kit Volume, Cross Stick Volume
Ambience Types 9
Rhythm Coach Functions Warm Ups, Time Check, Tempo Check, Quiet Count, Auto Up/Down
Quick Rec Resolution: 96 ticks per quarter note, Recording Method: Real-time, Maximum Note Storage: approx. 9,000 Notes
Display Custom (backlit LCD)
Connectors
Trigger Input connector: DB-25 type (Kick, Snare, Tom1, Tom2, Tom3, Hi-Hat, Crash1, Ride, Hi-Hat Control),
OUTPUT (L/MONO, R) jacks: 1/4 inch phone type, PHONES jack: Stereo 1/4 inch phone type,
MIX IN jack: Stereo miniature phone type, MIDI OUT connector
Output Impedance 1 k ohm
Power Supply AC adaptor
Current Draw 500 mA
Dimensions mm: 224.0 (W) x 151.1 (D) x 65.1 (H), inches: 8-7/8 (W) x 6 (D) x 2-9/16 (H)
Weight (excluding AC adaptor) 477 g / 1 lb 1 oz
V-Drums Portable TD-4KP Specications
Visit us online at www.roland.com/V-Drums/
www.Roland.com
Roland and V-Drums are either registered trademarks or trademarks of Roland Corporation in the United States and/or other countries.
All specifications and appearances are subject to change without notice.
Company names and product names appearing in this document are registered trademarks or trademarks of their respective owners.
It is forbidden by law to make an audio recording, video recording, copy or revision of a third party’s copyrighted work (musical work, video work, broadcast,
live performance, or other work), whether in whole or in part, and distribute, sell, lease, perform, or broadcast it without the permission of the copyright owner.
Do not use this product for purposes that could infringe on a copyright held by a third party. We assume no responsibility whatsoever with regard to any
infringements of third-party copyrights arising through your use of this product.
Printed in Japan November, ’12 RAM-4810 ABF-2 GR-UPR-SS
Bring more music into your life.
Roland invites everyone to experience
the joy of making music.
