Roland HP-1 Operating and maintenance manual
HP-1 RW/MH
HP-2e RW/LA
Roland Digital Piano
SERVICE NOTES
Issued by RES
First edition
SN00060 K6018482 Printed in Italy (E00) (AD)
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
1
Specifications HP-1 HP-2e
Keyboard: 88-keys, hammer action(TP-30 FATAR) 88-keyshammer action(TP-30 FATAR)
Touch sensitivity 4 preset levels 4 preset levels
Keyboard Mode Whole, Dual (adjustable Volume balance) Whole, Dual (adjustable Volume balance), Split (adjustable
split point)
Sound source:
Max polyphony: 64 Voices 64 Voices
Tones: 4 groups:[Piano], [Harpsichord], [Organ], [Strings] 5 groups: [Piano], [E. Piano], [Harpsichord], [Organ], [Strings]
8 Total Tones:Grand Piano1, Grand Piano2, Harpsichord, 20 Total Tones: Grand Piano1, Grand Piano2, Piano + Strings
Electric Piano, Church Organ, Organ, Strings, Choir Piano + Choir, Electric Piano1, Electric Piano2, Vibraphone,
Electric Piano+Choir, Harpsichord, Organ Flute,
Harpsichord + Strings, Harpsichord + Choir, Church Organ,
Rotary Organ, Organ + Strings, Organ + Choir, Strings,
Slow Strings, Strings + Choir, Strings + Brass
Panel controls:
Switch controls Tone (4), Reverb, Demo Tone (5),Variation, Brilliance, Transpose, Split, Reverb, Key Touch,
+/- (up/down), Beat, Metronome, Recorder (4), Song
Rotary pot. Master Volume Master Volume
Key functions:
Master Tuning Keys Tuning (0.1 Hz Steps) 415.3Hz - 466.2 Hz Keys Tuning (0.1 Hz Steps) 415.3Hz - 466.2 Hz
Transpose Key Transpose (-6 / +5 Semitone step) Key Transpose (-6 / +5 Semitone step)
Effects Reverb (8 levels), Chorus (E. Piano), Reverb (8 levels), Chorus (E. Piano),
Sympathetic Resonance (Piano, 8 levels) Sympathetic Resonance (Piano, 8 levels)
Temperament 7 types, selectable tonic 7 types, selectable tonic
Stretched Tuning 2 types 2 types
Pedals:
Right pedal Damper Damper
Central pedal - Sostenuto
Left pedal Soft/Sostenuto (selectable) Soft
Composer:
Tracks - 2
Song - 1
Note Storage - approx. 5000
Tempo - Quarter note = 20 to 250
Resolution - 96 ticks per quarter note
Control - Play/Stop, Rec, Tempo, All Song Play, Track Select
Preset songs 65 (demo songs) 65
Metronome - Beat (2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8)
8 volume levels
Other functions - Panel Lock
Other
Power Output: 20W x 2 20 W x 2
Speakers 12 cm x 2 12 cm x 2
Display - 7 segments, 3-digit LED
Connectors Pedal Connector, Headphones Jack x 2 (Stereo), Pedal Connector, Headphones Jack x 2 (Stereo),
Input Jacks (L/Mono, R) Input Jacks (L/Mono, R),
Output Jacks (L/Mono, R)§ MIDI In / MIDI Out Output Jacks (L/Mono, R), MIDI In / MIDI Out
Power supply AC 117V, AC 230V, AC 240V AC 117V, AC 230V, AC 240V
Power consumption 40 W 40 W
Dimensions (mm)
Piano 1380(W)x443(D)x181(H) 1402(W)x476(D)x244(H)
Stand 1390(W)x390(D)x645(H) 1400(W)x455(D)x643(H)
Total 1390(W)x443(D)x826(H) 1402(W)x476(D)x887(H)
Weight
Piano 34.2 42.7
Stand 11.7 16.4
Total: 45.9 59.1
Supplied accessories Owner's Manual, Power cable Owner's Manual, Power cable, Roland 60 Classical Piano Masterpiece
Cabinet Finish Rosewood (RW)/ Mahogany PVC (MH) Rosewood PVC (RW)/ Light Oak (LA)
Slide Lid No Yes
Stand rear panel Half Semi-Full
Copyright © 2002 by ROLAND CORPORATION
All rights reserved. No parts of this publication may be reproduced in any form whithout the written permission of ROLAND CORPORATION.
TABLE OF CONTENTS Page
SPECIFICATIONS 1
LOCATION OF CONTROLS HP-1 RW/MP2
PARTS LIST OF EXPLODED VIEW HP-1 RW/MP2
EXPLODED VIEW HP-1 RW/MP3
LOCATION OF CONTROLS HP-2e RW/LA4
PARTS LIST OF EXPLODED VIEW HP-2e RW/LA4
EXPLODED VIEW HP-2e RW/LA5
KEYBOARD PARTS LIST6
STAND EXPLODED VIEW KS-1 RW/MP7
2 NOTE PEDAL EXPLODED VIEW & PARTS LIST7
CIRCUIT DIAGRAM 2 NOTE PEDAL7
STAND EXPLODED VIEW KS-2e RW/LA8
3 NOTE PEDAL EXPLODED VIEW & PARTS LIST8
CIRCUIT DIAGRAM 3 NOTE PEDAL8
TEST MODE HP-1 9
HOW TO ENTER TEST MODE, AND HOW TO VISUALIZE THE SYSTEM PROGRAM VERSION 9
TEST MODE HP-2e 10/11
HOW TO ENTER TEST MODE, DEVICE CHECK AND HOW TO VISUALIZE THE SYSTEM PROGRAM VERSION 10
PARTS LIST HP-1 RW/MP 12/13
PARTS LIST KS-2e RW/LA 14/15
BLOCK DIAGRAM 16
PHONES & VOLUME PCB ASSY & CIRCUIT DIAGRAM 17
PRIMARY PCB ASSY & CIRCUIT DIAGRAM 17
MAIN PCB ASSY 18
CIRCUIT DIAGRAM MAIN PCB ASSY 19
POWER & AMP. PCB ASSY 20
CIRCUIT DIAGRAM POWER & AMP. PCB ASSY 21
CONTROL PCB ASSY HP-1 & CIRCUIT DIAGRAM 22
CONTROL PCB ASSY HP-2e & CIRCUIT DIAGRAM 23
HP-1
StringsOrgan1
Harpsi-
chord
Light Medium Heavy Fixed
Piano1
Demo Reverb
Key Touch Piano2 E.Piano Organ2 ChoirFunction
Min Max
Volume
ATTENTION:RISQUE DE CHOC ELECTRIQUE NE PASOUVRIRRISQUE DE CHOC ELECTRIQUENE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOTOPEN
WARNING:
SHOCK,DO NOT EX POSE THIS APPLIANCETO RAIN OR MOISTURE.SHOCK,DO NOT EX POSE THIS APPLIANCETO RAIN OR MOISTURE.
TOREDUCE THE RISK OF FIRE OR ELETRICTOREDUCE THE RISK OF FIRE OR ELETRIC
THIS DEVICE COMPLIESWITH PART 15 OFTHE FCC RULES.
OPERATIONIS SUBJECTTO THE FOLLOWING TWO
CONDITIONS:(1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND(2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDINGINTERFER ENCE
THATMAYCAUSE UNDESIRED OPERATION.
THIS DEVICE COMPLIESWITH PART 15 OFTHE FCC RULES.
OPERATIONIS SUBJECTTO THE FOLLOWING TWO
CONDITIONS:(1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND(2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDINGINTERFER ENCE
THATMAYCAUSE UNDESIRED OPERATION.
N225
N225
"THISCLASS (B) DIGITAL APPARATUS COMPLIES WITH
CANADIANINTERFERENCE- CAUSINGEQUIPMENT REGUL ATIONS"
"THISCLASS (B) DIGITAL APPARATUS COMPLIES WITH
CANADIANINTERFERENCE- CAUSINGEQUIPMENT REGUL ATIONS"
"CETAPPAREILNUMERIQUE DE LACLASSE (B) RESPECTE LE
REGLEMENTSUR LE MATERIEL BROUILLEURDU CANADA"
"CETAPPAREILNUMERIQUE DE LACLASSE (B) RESPECTE LE
REGLEMENTSUR LE MATERIEL BROUILLEURDU CANADA"
AC
MIDI
Out In
Pdle a
Output Input
RR
L (Mono) L (Mono)
Stereo Stereo
AC 100
-
240V~50/60Hz
MODEL
SERIAL NO.
MADE IN ITALYROLAND EUROPE spa
W
E
Rq
BLACK KNOB HP-730/530E
Cod. 22485316
ROT. POT. 10KB 14K12C
Cod. 13289251
5P DIN SOCKET YKF51-5048 (2PCS)
Cod. 13429676
JACK SOCKET HLJ7101-01-3010
Cod. 13449283
REAR VIEW
DIN SOCKET YKF51-5031
Cod. 00340223
UNIVERSAL AC INLET ON PCB
Cod. J3449103
VARN.+SILK. TEMPLATE F/CONTROL BLIND
Cod. 7772912000
VARN.+SILK. CONTROL BLIND HP-1-RW
Cod. 7772913000
2-BUTTON GROUP D. 9.5
Cod. K2478349
SWITCH TP-1101A / EVQ-PAE 05 R
Cod. J3169105
LED DIODE TLHR4401 - RED
Cod. 15029284RI
2
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
LOCATION OF CONTROLS HP-1-RW/MP PARTS LIST OF EXPLODED VIEW HP-1-RW/MP
No. Part No. Description
1 7772916000 MDF MUSIC REST (ROSEWOOD) HP-1-RW
7774404000 MDF MUSIC REST (SATIN MAHOGANY) HP-1-MH
2 J2329105 HINGE F/MUSIC REST
3 K2238113 MUSIC SCORE HOLDER
4 7772915000 MDF BORED TOP CBNT (ROSEWOOD) HP-1-RW
7774405000 MDF TOP CABINET (SATIN MAHOGANY) HP-1-MH
5 K2128134 COUPLING PIN F/TOP CBNT-REAR PANEL
6 K2128135 COUPLING PIN FOR TOP CBNT
7 7772902000 CONTROL PCB ASSY HP-1
8 7772913000 VARN.+SILK. CONTROL BLIND HP-1-RW
9 22485316 BLACK KNOB HP-730/530E
10 K2268121 RED FELT MM 1250X12X1.5
11 K1188132 KEYBOARD SUPPORT R178
12 J2589109 88-KEY KEYBOARD ASSY TP/30 HP-2E RW
13 3249559701 SWITCH CAP
14 K116810602 END-BLOCK POWER ON + LED
15 K116810501 RIGHT END-BLOCK HP-136
16 01453245 AC PUSH SWITCH SDDLB1B2D TV5
17 7699410000 LED ASSY
18 7772903000 PHONES PCB ASSY HP-1/2e/3e
19 7772401000 PRIMARY PCB ASSY KR-777
20 K2458148 TRANSFORMER 100-240 HP-2E-RW
21 02896112 LOUDSPEAKER PD-12355AON
22 7772914000 VARN.+SILK. REAR PANEL HP-1-RW
23 7772911000 CABINET ASSY (ROSEWOOD) HP-1-RW
7774406000 CABINET ASSY (MAHOGANY) HP-1-MH
24 7772912000 VARN.+SILK. TEMPLATE F/CONTROL BLIND
25 7772904000 POWER & AMP. PCB ASSY HP-1
26 7772901000 MAIN PCB ASSY HP-1
27 J2159103 DOUBLE ELASTIC PLATE
28 40016756 NUT M12 HLJ0999-01-360 M12
29 K2248168 LOUDSPEAKER GRILL HP-1-RW
(SCREW)
A J2289212 SCREW 3.5X10 TC TC PR BRUN
B J2289116 SELF TAP.SCREW 3.5X13 TC TC
C J2289227 SCREW 3.9X20 TC PR TFR T.8 BLACK PLATED
D J2289150 SCREW 2.9X16 TC PR TFR H.7
E J2289130 SCREW 2.9X13 TC TC PR TROP
F J2289101 SELF TAP. SCREW 2.9X 6 TC TC
G J2289118 SCREW 2.9X16 TC TC PR BRUN
H J2283213 SCREW 3.9X16 TC TC
I J2289110 SELF LOCK.SCREW M4X20 TCTC H. 9.5
L K2288107 SCREW 3.9X13.5 TC PR TFR H.8
M J2289125 SCREW 2.9X10 TC TC PR TROP
N J2139114 FLAT WASHER I/D 5X14 TH. 1
O K2288110 SCREW M5X20 TC TC TFR H9.5 BRUN
P J2289110 SELF LOCK.SCREW M4X20 TCTC H. 9.5
Q J2289147 SELF LOCK.SCREW M3X12 TCTC H.6
R J2289135 SELF LOCK.SCREW M4X 7 TCTC T.8
3
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
EXPLODED VIEW HP-1-RW/MP
1
B
3
2
A
4
6
6
57
E
10
C
5
5
D
24
9
8
11 12
11
13
16
17
F
14
18
19
25
20
15
M
L
23
P
27
Q
L
28
R
23
O
N
29
I
H
21
21
22 29
26
G
11
4
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
ATTENTION:RISQUE DE CHOC ELECTRIQUE NE PASOUVRIRRISQUEDE C HOC ELECTRIQUENE PAS OUVRIR
CAUTION
RISKOF ELECTRIC SHOCK
DONOT OPEN
WARNING:
SHOCK,DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.SHOCK,DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
TOREDUCE THE RISK OF FIRE OR ELETRICTOREDUCE THE RISK OF FIRE OR ELETRIC
THISDEVICE COMPLIES WITH PART15 OF THE FCC RULES.
OPERATIONIS SUBJECT TO THE FOLLOWING TWO
CONDITIONS:(1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED,INCLUDING INTERFERENCE
THATMAYCAUSE UNDESIRED OPERATION.
THISDEVICE COMPLIES WITH PART15 OF THE FCC RULES.
OPERATIONIS SUBJECT TO THE FOLLOWING TWO
CONDITIONS:(1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED,INCLUDING INTERFERENCE
THATMAYCAUSE UNDESIRED OPERATION.
N225
N225
"THISCLASS (B) DIGITALAPPARATUSCOMPLIES WITH
CANADIANINTERFERENCE- CAUSINGEQUIPMENT REGUL ATIONS"
"THISCLASS (B) DIGITALAPPARATUSCOMPLIES WITH
CANADIANINTERFERENCE- CAUSINGEQUIPMENT REGUL ATIONS"
"CETAPPAREILNUMERIQUE DE LA CLASSE (B) RESPECTE LE
REGLEMENTSUR LE MATERIELBROUILLEURDU CANADA"
"CETAPPAREILNUMERIQUE DE LA CLASSE (B) RESPECTE LE
REGLEMENTSUR LE MATERIELBROUILLEURDU CANADA"
AC
MIDI
Out In
Pdle a
Output Input
RR
L (Mono) L (Mono)
Stereo Stereo
AC100
-
240V~50/60Hz
MODEL
SERIAL NO.
MADEIN ITALYROLAND EUROPE spa
W
E
Rq
5P DIN SOCKET YKF51-5048 (2PCS)
Cod. 13429676
JACK SOCKET HLJ7101-01-3010
Cod. 13449283
LED DIODE TLHR4401 - RED
Cod. 15029284R1
2-BUTTON GROUP W/DIFF. D.9,5
Cod. K2478349
BLACK KNOB
Cod. 22485316
ROT.POT. 10KB14K12C
Cod. 13289251
LED SPR-325MVWT31
Cod. 01121689
2-BUTTON GROUP D.9,5
Cod. K2478350
SILKSCREENED PLEXIGLASS HP-2E-RW
Cod. 7773010000
DISPLAY TYPE LB-603VF - RED
Cod. 00239767
DIN SOCKET YKF51-5031
Cod. 00340223
UNIVERSAL AC INLET ON PCB
Cod. J3449103
2-BUTTON GROUP W/DIFF. D.9,5
Cod. K2478349
LOCATION OF CONTROLS HP-2e-RW/LA
REAR VIEW
PARTS LIST OF EXPLODED VIEW HP-2e-RW/LA
No. Part No. Description
1 7773012000 BORED MUSIC REST HP-2E/3E-RW
7774307000 VARN. MUSIC REST (OAK) HP-2E-LA
2 J2329105 HINGE F/MUSIC REST
3 K2198111 MUSIC SCORE HOLDER HP-2E-RW
7774311000 VARN. MUSIC SCORE HOLDER HP-2E-LA
4 7773011000 BORED MDF TOP CBNT HP-2E-RW
7774308000 MDF TOP CABINET (OAK) HP-2E-LA
5 J2589109 88 KEY KEYBOARD ASSY TP/30
6 K2268127 BLACK ADH. FELT 1320X9X2.5 MM.
7 K2148115 STOP PIN F/MUSIC SCORE HOLDER
K2148116 STOP PIN F/MUSIC SCORE HOLDER
8 00890990 LOGO BADGE ROLAND (GOLDEN)
9 K2128134 COUPLING PIN F/TOP CBNT-REAR PANEL
10 K2128135 COUPLING PIN FOR TOP CBNT
11 K2268149 ADHESIVE BLACK FELT MM540X15X1
12 7773008000 VARN.+SILK. REAR PNEL HP-2E-RW
7774305000 VARN.+ SILK. REAR PANEL HP-2E-LA
13 K2248160 AC SOCKET HOLDER
14 K2268159 CUSHION F/LID BLIND
15 K2128133 LID GEAR
16 7773013000 BORED SLIDE LID HP-2E-RW
7774309000 BORED MDF SLIDE LID (OAK) HP-2E-LA
17 K2128132 SUPPORT F/SHAFT STAY HP-2E-RW
18 K2268121 RED FELT MM 1250X12X1.5
19 22485316 BLACK KNOB HP-730/530E
20 K2478349 2-BUTTON GROUP D. 9.5 W/DIFFUSOR
21 K2478350 2-BUTTON GROUP D.9.5
22 7770025000 VARN. LID BLIND HP-337E
23 7773010000 SILKSCREENED PLEXIGLASS HP-2E-RW
24 7773014000 SHAFT STAY
25 7773015000 TOP CABINET BLIND HP-2E-RW
7774301000 TOP CABINET BLIND (OAK) HP-2E-LA
26 7773009000 VARN.+SILK. CONTROL BLIND HP-2E-RW
7774304000 VARN.+SILK. CONTROL BLIND HP-2E-LA
27 7773007000 VARN.+SILK.TEMPLATE F/TOP CABINET HP-2e
7774306000 VARN.+SILK. CONTROL PANEL BLIND HP-2E-L
A
28 7773006000 CABINET ASSY HP-2E
7774310000 CABINET ASSY (OAK) HP-2E-LA
29 7773002000 CONTROL PCB ASSY HP-2e
30 3249559701 SWITCH CAP
31 K1168114 RIGHT END BLOCK HP-2E RW
7774302000 RIGHT VARN. END-BLOCK HP-2E-LA
32 K1168115 LEFT END BLOCK HP-2E-RW
7774303000 LEFT VARN. END-BLOCK HP-2E-LA
33 K2128131 LEFT GUIDE FOR SLIDE LID
34 K2128130 RIGHT GUIDE FOR SLIDE LID HP-2e-RW
35 K1188132 KEYBOARD SUPPORT R178
36 7695813000 VARNISHED WOOFER NET
37 7773003000 POWER AMP. PCB ASSY HP-2E
38 7699410000 LED ASSY
39 7772401000 PRIMARY PCB ASSY KR-777
40 7772903000 PHONES PCB ASSY HP-1/2e/3e
41 7773001000 MAIN PCB ASSY HP-2e
42 K2268158 REST RUBBER NAIL F/LID
43 00239767 DISPLAY TYPE LB-603VF (RED)
44 13289251 ROT. POT. 10KB 14K12C
45 01453245 AC PUSH SWITCH SDDLB1B2D TV5
46 J2289113 NUT 3MA H.3
47 22415596 LOUDSPEAKER CF160138-01 6 OHM
48 K2458148 TRANSFORMER 100-240 HP-2E-RW
49 40016756 NUT M12 HLJ0999-01-360 M12
(SCREW)
A J2289212 SCREW 3.5X10 TC TC PR BRUN
B J2289116 SELF TAP.SCREW 3.5X13 TC TC
C J2289150 SCREW 2.9X16 TC PR TFR H.7
D J2289227 SCREW 3.9X20 TC PR TFR T.8 BLACK PLATED
E K2288107 SCREW 3.9X13.5 TC PR TFR H.8
F J2289193 SELF LOCK.SCREW M3X6 TC TC H.6
G J2289135 SELF LOCK.SCREW M4X 7 TCTC T.8
H J2289125 SCREW 2.9X10 TC TC PR TROP
I J2289102 SELF TAP.SCREW 2.9X10 TC TC
L J2289115 SCREW 3.5X9.5 TC PR TFR H.8
M J2289130 SCREW 2.9X13 TC TC PR TROP
N J2289213 SELF TAP.SCREW 3.9X16 TC TC
O J2289142 PITCH SCREW M5X25 TC TC
P K2288110 SCREW M5X20 TC TC TFR H9.5 BRUN
Q J2289110 SELF LOCK.SCREW M4X20 TCTC H. 9.5
R J2289221 SELFLOCK. SCREW M4X10 TC TC TFR 9.5
S J2289108 SELF LOCK.SCREW M3X10 TCTC H. 6
T J2289118 SCREW 2.9X16 TC TC PR BRUN
U J2289252 SELF TAP. SCREW 3,9X25 TC TC
V J2289147 SELF LOCK.SCREW M3X12 TCTC H.6
Z J2289101 SELF TAP.SCREW 2.9X 6 TC TC
5
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
EXPLODED VIEW HP-2e-RW/LA
*
*
*
*
1
2
3
4
9D
25 16
6
L
I
34
R
E
E
E
E
E
O
W
P
E
E
38
45
28
28
33
C
N
28
42
I
H
S
Q
V
F
FG
41
37
28
35
Z
F30
26
19
S
23
M
20
21
29
44
5
27
43
R
47 14
L
22
C
7
8
11
10
E
E
12
46
39
48
32
40
36
T
13
N
A
B
24
17
15
F
31
18
6
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
KEYBOARD PARTS LIST
88-KEY KEYBOARD ASSY TP/30 code J2589109
7
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
STAND EXPLODED VIEW HP-1-RW/MP
2
6
C
5
4
B
B
A
A
1
4
7
8
No. Part No. Description
1 7772905000 RIGHT SIDE PANEL (ROSEWOOD) HP-1-RW
7774402000 RIGHT SIDE PANEL (MAHOGANY) HP-1-MH
2 7772907000 LEFT SIDE PANEL (ROSEWOOD) HP-1-RW
7774403000 LEFT SIDE PANEL (MAHOGANY) HP-1-MH
3 7772906000 REAR PANEL (ROSEWOOD) HP-1-RW
7774401000 REAR PANEL (SATIN MAHOGANY) HP-1-MH
4 K235810101 FOOT F/SIDE PANEL KS-136
5 K2028143 COVER FOR PEDAL HP-1-RW
6 J2329107 JOINT BOLT ASSY
7 J3059113 2-NOTE PEDAL KS-137
8 J2329101 SCREW DRIVER TYPE 2
A J2289249 SCREW 4.5X45 TC PR TFR T.9.5
B J2289227 SCREW 3.9X20 TC PR TFR T.8 BLACK PLATED
C K2288107 SCREW 3.9X13.5 TC PR TFR H.8
3
No. Part No. Description
1
4
J3059114 RIGHT PEDAL (GOLD)
2
5
3
6
J2269108
K3418105
7625920000
J2289128
J2289125
RUBBER DAMPER FOR PEDAL
CABLE FOR PEDAL(84)
1P CONDUCTIVE RUBBER LR13/1
SELF.TAP SCREW 3,5x19 TCTCPRBZ
SCREW 2,9x10 TCTC PR TROP
7
8
A
B
K2918155
J2289190
PCB FOR PEDAL
BLACK KNOB M8x14
J3059115
J2179112
LEFT PEDAL (GOLD)
PEDAL SPRING 1,4x14x29
1
4
4
A
B
A
5
6
78
8
3
2
TP1
TP
TP3
TP
TP4
TP
TP5
TP
TP6
TP
WIR1
PEDAL CABLE
4
5
2
13
67
8
10
9
SW3
SW SPST
1 2
SW1
SW SPST
1 2
C1
0.1C
D
OFF
ON ON
OFF
BRWN
ORNG
BLCK
BRWN
RED
ORNG
BLCK
SHLD
SHLD
SOFT DAMPER
PEDAL BOARD 2 PEDALS
X
X
X
X
Circuit Diagram 2-Note Pedal
2-Note Pedal Exploded View & Parts List
ASSY J3059113
8
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
STAND EXPLODED VIEW KS-2e-RW/LA
A
A
C
8
8
A
A
1
3
2
No. Part No. Description
1 K1148151 REAR PANEL (OAK) KS-2E-LA
K1148148 REAR PANEL KS-2E/KS-3E/KS7E
2 7897001000 RIGHT SIDE PANEL ASSY (OAK) KS-2E-LA
7896601000 RIGHT SIDE PANEL ASSY KS-2E
3 7897002000 LEFT SIDE PANEL ASSY (OAK) KS-2E-LA
7896602000 LEFT SIDE PANEL ASSY KS-2E
4 7897004000 BASE F/PEDAL ASSY KE-2E-LA
K1138111 BASE FOR PEDAL (MDF) KS-147E
5 7897003000 FOOT F/SIDE PANEL (STAND) KS-2E-LA
K2358102 SIDE PANEL FOOT
6 J3059116 3-NOTE PEDAL KS-237E/147E
7 J2329107 JOINT BOLT ASSY
8 K2128129 COUPLING BASE KS-237LE
9 K3418105 CABLE F/PEDAL (84) KS137/237/147
A
J2289208 SCREW 3.5X25 TC PR TFR H.8 BRUN
B K2288109 SCREW 3.9X30 TC PR TFR T.8 BRUN
C J2289248 SCREW M6X30 TC PHILIPS TBL (for KS-2E-LA)
J2289247 SCREW M6X30 TC PHILIPS TBL (for KS-2E-RW)
D J2289248 SCREW 4.5X45 TC PR TFR T. 9.5
D
4
6
9
7
5
5
B
D
Circuit Diagram 3-Note Pedal
3-Note Pedal Exploded View & Parts List
ASSY J3059116
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
3. EFFECT CHECK
Press the button DEMO to go on to the next check.
4. PANPOT CHECK
Press the button DEMO to go on to the next check.
5. A/D AND MIDI CHECK
Loop connect the MIDI IN and OUT.
The LED will be off when finished the test.
Press the button DEMO to go on to the next check.
5-1. Pedal test
Bell will be sound when detect Max.
It is OK to detect Min and Max.
* If plural pedals are pressed, it will go to non-checked state (blink).
5-2. MIDI test
✷(blink): non-checked (enterd in test mode without connecting the cable).
●(ON) : Connected MIDI IN and OUT
❍(off) : Not connected.
It is OK, if detected both connected and not connected situation.
6. End
Power Off the HP-1
+------------------------
| +---------------
| | + -----
| | |
T1 T2 T3 T4
Sostenuto Pedal (4-1)
Damper Pedal (4-1)
MIDI Loop (4-2)
+---------------------------------
| +------------------------
sine wave (L)
| | +---------------
| | | + -----
| | | |
T1 T2 T3 T4
sine wave (C)
Rectangle wave (R)
Sound OFF
+---------------------------------
| +------------------------
Dry
| | +---------------
| | | + -----
| | | |
T1 T2 T3 T4
Chorus
Reverb
Resonance
9
TEST MODE HP-1
Notations:
• LED
●= Led ON;
✷= Led blinking
❍= Led off
• BUTTONS
T1: TONE PIANO
T2: TONE HARPSICHORD
T3: TONE ORGAN
T4: TONE STRINGS
1. How to enter Test Mode and how to visualize the System program version
Turn on the power while press the button PIANO
When entering the test mode, "Device Check" is executed.
All the LED will be ON.
If there are any error, the LED will blink according to the part and error number is displayed on the led
When press [Demo] on this situation, the version will be shown.
If there are no errors in device check, the version will be shown immediately.
REV T1 T2 T3 T4
1.00 0 1 0 0 0
1.01 0 1 0 0 1
1.02 0 1 0 1 0
1.03 0 1 0 1 1
Press the button DEMO to go on to the next check.
2. SWITCH / LED CHECK
All the LED will be ON.
Turn off each LED and sounds piano.
When all the LEDs are turned off, proceed to the next.
+--------------------------------- ➔E.01 Flash Memory Error
| +------------------------ ➔E.02 RAM Error
| | +--------------- ➔E.03 Wave ROM Error
| | | + -----
➔E.04 Effect RAM Error
| | | |
✷✷✷✷
T1 T2 T3 T4
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
TEST MODE HP-2e
Items required:
MIDI cable
Oscilloscope
Pedals: SOFT, SOSTENUTO and DAMPER
Notations:
• LED
●= Led ON;
✷= Led blinking
❍= Led off
• BUTTONS
T1: TONE PIANO
T2: TONE E.PIANO
T3: TONE HARPSICHORD
T4: TONE ORGAN
T5: TONE STRINGS
T6: TONE VARIATION
1. How to enter Test Mode, Device Check and how to visualize the System program version
Turn the instrument on.
Press the buttons REC, TRACK 2 and TRANSPOSE contemporarily.
While the system carries out the Device Check, the display visualizes:
Then the display visualizes the system version (i.e.: Ver. 1.01).
In case a problem happens during the Device Check, the display visualizes the error and the LED of the corre-
sponding button keeps blinking, as shown in the table below:
Press the button TRANSPOSE to go on to the next check.
In case you have already selected a test and you want to quit it and go on to the next one, press the button +
and the button TRANSPOSE contemporarily.
+--------------------------------- ➔E.01 Flash Memory Error
| +------------------------ ➔E.02 RAM Error
| | +--------------- ➔E.03 Wave ROM Error
| | | + -----
➔E.04 Effect RAM Error
| | | |
✷✷✷✷
T1 T2 T3 T4
2. SWITCH / LED CHECK
At first, all LEDs are on.
Every time you press a button you hear a piano sound.
When all the buttons have been pressed and all LEDs are off, the system goes on to the following check auto-
matically.
For the buttons BRILLIANCE, VARIATION, METRONOMO, BEAT and KEY TOUCH, orange colour means that
both red and green LEDs work.
The buttons - and + don't have any corresponding LED, but some segments on the display turn off according to
the button pressed, as indicated in the following pictures:
BUTTON - BUTTON +
The system goes on to the following check automatically.
3. EFFECT CHECK
When pressing each button, you hear the sound with the effect indicated.
The display visualizes:
Press the button TRANSPOSE to go on to the next check.
+------------------------------------ ➔ Dry Piano direct sound
| +--------------------------- ➔ Chorus Piano chorus sound
| | +------------------ ➔ Reverb Piano reverb
| | | +--------- ➔ Resonance Piano resonance
| | | |
✷✷✷✷❍❍
T1 T2 T3 T4 T5 T6
10
11
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
4. PANPOT CHECK
When you press the following buttons, you hear the corresponding sound as indicated below.
The display visualizes:
Pressing the buttons as indicated in the following table, you hear the corresponding sounds.
Put the volume potentiometer at max.
Insert a jack connected to the oscilloscope into L/R output and then into the R output.
The oscilloscope shows the wave shape and its value in Volt (Vpp). Namely:
Press the button TONE ORGAN to stop the sound.
Press the button TRANSPOSE to go on to the next check.
Button Wave shape Frequency (Hz) Output Volt (mVpp)
Tone PIANO 220 L Min 850 Max 950
Tone E. PIANO 440 L / R Min 620 Max 680
Tone HARPSI-CHORD 440 R Min 950 Max 1.050
+---------------------- ➔Sine Wave (Left = L) Left output
|
| +------------ ➔Sine Wave (Left/ Right = C) Both output
| |
| | +--- ➔Square Wave (Right = R) Right output
| | |
| | | +--- ➔Sound OFF
| | | |
✷✷✷✷❍❍
T1 T2 T3 T4 T5 T6
5. A/D AND MIDI CHECK
A/D check:
The display visualizes:
Buttons and LEDs are as follows:
Pressing each pedal the corresponding blinking LED goes off, the display shows a value between 0 and 10 and
you hear a sine wave sound. When the value is 0 you don't hear any sound, when the value is 10 you hear a
bell-like sound.
Press the button TRANSPOSE to go on to the next check.
MIDI Check:
Connect MIDI IN and MIDI OUT sockets by a Midi cable:
The LED corresponding to the button T4 is:
●: Connection OK;
❍:Connection failed.
Blinking Led means that the connection has not been tested.
6. End
Once the MIDI check is ended and the MIDI cable is disconnected, the display visualizes:
Press the button TRANSPOSE to enter test mode again.
Turn the power off to exit test mode.
+------------------------------------ ➔
Soft Pedal
| +--------------------------- ➔
Sostenuto Pedal
| | +------------------ ➔
Damper Pedal
| | | +--------- ➔
MIDI Loop
| | | |
✷✷✷✷❍❍
T1 T2 T3 T4 T5 T6
12
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
CASING Q.ty
J2329105 HINGE F/MUSIC REST 2
K2238113 MUSIC SCORE HOLDER 1
# K2028143 COVER FOR PEDAL HP-1-RW 1
K235810101 FOOT F/SIDE PANEL KS-136 2
K116810501 RIGHT END-BLOCK HP-136 1
K116810602 END-BLOCK POWER ON + LED 1
# 7772905000 RIGHT SIDE PANEL (ROSEWOOD) HP-1-RW 1
# 7772907000 LEFT SIDE PANEL (ROSEWOOD) HP-1-RW 1
# 7772906000 REAR PANEL (ROSEWOOD) HP-1-RW 1
J3059113 2-NOTE PEDAL KS-137 1
# 7772911000 CABINET ASSY (ROSEWOOD) HP-1-RW 1
# 7772912000 VARN.+SILK. TEMPLATE F/CONTROL BLIND 1
# 7772913000 VARN.+SILK. CONTROL BLIND HP-1-RW 1
# 7772914000 VARN.+SILK. REAR PANEL HP-1-RW 1
# 7772915000 MDF BORED TOP CBNT (ROSEWOOD) HP-1-RW 1
# 7772916000 MDF MUSIC REST (ROSEWOOD) HP-1-RW 1
ONLY FOR HP-1 MH
# 7774404000 MDF MUSIC REST (SATIN MAHOGANY) HP-1-MH 1
# 7774405000 MDF TOP CABINET (SATIN MAHOGANY) HP-1-MH 1
# 7774406000 CABINET ASSY (MAHOGANY) HP-1-MH 1
# 7774401000 REAR PANEL (SATIN MAHOGANY) HP-1-MH 1
# 7774402000 RIGHT SIDE PANEL (MAHOGANY) HP-1-MH 1
# 7774403000 LEFT SIDE PANEL (MAHOGANY) HP-1-MH 1
KNOB BUTTON
22485316 BLACK KNOB HP-730/530E 1
# K2478349 2-BUTTON GROUP D. 9.5 3
3249559701 SWITCH CAP 1
SWITCH
01453245 AC PUSH SWITCH SDDLB1B2D TV5 1
J3169105 SWITCH TP-1101A / EVQ-PAE 05 R SW1,2,3,4,5,6 on CB 6
JACK, SOCKET
13449252 JACK SOCKET YKB 21-5006 JK101,JK102 on PHB 2
13449283 JACK SOCKET HLJ7101-01-3010 JK1,2,3,4 on PAB 4
00340223 DIN SOCKET YKF51-5031 JK8 on PAB 1
13429676 5P DIN SOCKET YKF51-5048 (2PCS) JK5 on PAB 1
SPEAKER
# 02896112 LOUDSPEAKER PD-12355AON 2
KEYBOARD ASSY
# J2589109 88-KEY KEYBOARD ASSY TP/30 HP-2E RW 1
NOTE: For details, refer to KEYBOARD PARTS LIST (Page 6)
PCB ASSY
# 7772904000 POWER & AMP. PCB ASSY HP-1 1
7699410000 LED ASSY 1
# 7772902000 CONTROL PCB ASSY HP-1 1
7772903000 PHONES PCB ASSY HP-1/2e/3e 1
# 7772901000 MAIN PCB ASSY HP-1 1
7772401000 PRIMARY PCB ASSY KR-777 1
NOTE: The PRIMARY PCB ASSY doesn’t include the fuse. When you replace this assy, please order the fuse, as well, as indicated
on “FUSE, FUSE HOLDER”.
IC
15229718RI I.C. PHOTO-COUPLER 6N 137 IC15 on PAB 1
A02673823 I.C. MASK ROM UPD23C64040ALGY-743-MJH IC11 on MB 1
01786667 I.C. HD6413006F20 FLAT IC6 on MB 1
15249111 I.C. TC7WU04 F FLAT CMOS IC13 on MB 1
00232645 I.C. TC7W14F FLAT IC20 on MB 1
J5259001 I.C. 74 HC 04 FLAT CMOS IC9 on PAB 1
00129278 I.C. SSC1080 FOB (CUSTOM IC) IC16 on MB 1
J5259110 I.C. HM62256LFP-7T FLAT SRAM IC5,7 on MB 2
01126612 I.C. LC324260AJ60/AS4C256K16E050JCT IC14 on MB 1
01679978 I.C. RA09-002 (XP6) CUSTOM IC9 on MB 1
15259884 I.C. TC7S08F MOS CMOS IC19 on MB 1
15189210 I.C. BA 5218F (OP AMP) IC3,5,7 on PAB / IC17 on MB 4
15289105 I.C. UPC 4570G (OP AMP) IC1,2,6,11 on PAB 4
15189189 I.C. UPC 4570HA VERT. (OP.AMP.) IC3 on CB 1
15199937 I.C. M51953 BFP FLAT IC4 on PAB 1
01451578 I.C. AK4324-VF-E2 DAC IC18 on MB 1
J5199102 I.C. UA 7812 CV TO220 IC13 on PAB 1
J5199103 I.C. 7912F TO220 IC14 on PAB 1
01344512 I.C. UPC24A05HF (REGULATOR) IC12 on PAB 1
01458445 I.C. UPC29M33T-T1 FLAT (REGULATOR) IC27 on MB 1
A02780301 I.C. UPC 29L05T REGULATOR FLAT IC15 on MB 1
TRANSISTOR
15129114 TRANSISTOR 2SC-1815GR Q15,16,25,28 on PAB 4
15119113 TRANSISTOR 2SA-1015 GR Q18,22,27 on PAB 3
15129136 TRANSISTOR 2SC-2878-A/B Q3,4,9,10,13,14 on PAB 6
15129602 TRANSISTOR 2SD-667C Q2,8 on PAB 2
15139124 TRANSISTOR 2SK-363 GR FET Q17,21,26,29 on PAB 4
15129164 TRANSISTOR DTC-114ES Q32 on PAB / Q5,6,7,8,9,10 on CB 7
15119163 TRANSISTOR RN2227 Q19,20 on PAB 2
15119615 TRANSISTOR 2SB-647C T2 Q5,11 on PAB 2
00898201 TRANSISTOR RN2421 CHIP Q1 on MB 1
A02126367 TRANSISTOR 2SB-1016 AY Q1,7 on PAB 2
A02126378 TRANSISTOR 2SD-1407 AY Q6,12 on PAB 2
DIODE
15119126 DIODE 1SS-133T REDUCED PITCH D1,2,3,4,5,6,7,8,15,16,17,18 on PAB 12
15339108 DIODE DA-204K D9,11,13,19,21,22 on PAB 6
15039159T0 DIODE RECTIFIER S5688G D14,24,27,28,30,31,33 on PAB 7
15029284RI LED DIODE TLHR4401 - RED LED1,2,3,4,5,6 on CB 6
J5029107 LED DIODE 3 SLR-37VR3F - RED On LEDB 1
15039176 JUMPER DIODE D3SBA20 4A/200V D29 on PAB 1
RESISTOR
J3919108 RESISTOR ARRAY EXB-V8V-103-JV RA3,5,6,8,26 on MB 5
J3919110 RESISTOR ARRAY EXB-V8V-R00-0V RA20,21,22,23,24,25 on MB 6
00126101 RESISTOR ARRAY EXB-V8V-221-JV RA2,7,9,10,11,12 on MB 6
01457145 RESISTOR ARRAY EXB-E10C-103-J RA13 on MB 1
A02019023 RESISTOR ARRAY EXB-E10C-682-J RA16,17,18 on MB 3
13819132RI UNINFL.RES. 100 OHM 0.6W 5% R22,23,24,25 on PHB 4
01783623 RESIST. 2010 10 OHM1/2W 5% R27,30 on MB 2
A01561290 FUSE RESISTOR RF2SL20 8R2 OHM J R137 on PAB 1
A01450978 FUSE RESISTOR RF50S T52 OR1 OHM J R10,47 on PAB 2
POTENTIOMETER
13289251 ROT. POT. 10KB 14K12C VR1 on CB 1
CAPACITOR
01015878 POL.COND. 0805 330P 5% C52,56,57,63,67,68 on PAB 6
15359774 POLYEST.COND. 0805 680P 5% C20,41 on PAB 2
J3629146 ELECTR. COND. 330U 16V P.5 C95,100,105,107 on PAB 4
J3469156 ELECTR. COND. 33U 35V P.5 C1,3,4,6,16,36,37,42,45,48,49,53,55,60,64,66,71,72,73,74,
88,89,91on PAB 23
J3629159 ELECTRL.COND. 1000UF 35V R. C92 on PAB 1
J3629148 ELECTR. COND. 6800U 35V R. C97,102 on PAB 2
J3629132 ELECTRL.COND. 100U 50V P5 C12,19,33,40,77,82 on PAB 6
J3629107 ELECTRL.COND. 1UF 100V P5 C39 on PAB 1
J5369104 ELECTR. COND. RV2 10U 16V (SMD) C11,12,13,45,48,54,78,92,101,104,107,110,115,183 on MB 14
J5369105 ELECTR. COND. RV3 33U 16V (SMD) C16,74,82,117,176 on MB 5
J3629149 ELECTR.COND. 100U 16V H.7 C4 on CB 1
J3629137 ELECTR. COND. 33U 16V H.7 C8,12,16,17 on CB 4
13529104RI CAPACITOR DE1310E472MVA-KH C1 on PB 1
13649103J0 UNPOL.COND. 10U 50 P5 C13,21,84,108,117 on PAB 5
01452189 COND. ECKDBE472 ZF C101 on PAB 1
INDUCTOR, COIL, FILTER
<<EMI>> 12449326 NOISE SUP. SBT-0460 L15 on PAB 1
<<EMI>> 13529187 NOISE SUP. ELKTR391CA FL1,2 on PAB 2
<<EMI>> 12449355 NOISE SUP. FBR07H850TB00 L1,2,3,4on PAB / L18,19,22 on PHB 7
CRYSTAL, RESONATOR
00894034 X-TAL 16 MHZ MA-406 X1 on MB 1
00901912 X-TAL 24.576 MHZ MA-406 X2 on MB 1
FUSE, FUSE HOLDER
J2559123 FUSE 5X20 630MAL/250V SEMKO F1 on PRIMARY B - only for 230V/230VE 1
J2559112 FUSE 5X20 1.25A 250V UL/CSA F1 on PRIMARY B - only for 100V/117V 1
!
!
!
PARTS LIST HP-1-RW/MH (117V, 230V, 230VE, 240VA)
When ordering any parts listed in the parts list,please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
CONSIDERATION ON PARTS ORDERING
NOTE:
#The parts marked " #'' are new (Initial Parts).
AThe parts marked " A'' are new (Initial Parts).for RES but already used by RJA
The parts marked have Safety - Related characteristics.
Use only listed parts for replacement.
<< EMI >> Component for EMC.
NNoottee::Replacement should be made on a unit basis. No replacements available for individual parts.
Replacement only be a unit.
!
!
SAFETY PRECAUTIONS :
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
!
MB = Main Board
PAB = Power Amp. Board
CB = Control Board
PHB = Phones Board
PB = Primary Board
LEDB = Led Board
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
13
J2559104 FUSE 5X20 3.15AL/250V SEMKO F1, F2 on PAB 2
12199597RI FUSE HOLDER T.P1 on PRIMARY B / on PAB 6
CONNECTOR
13369689RI 20P FEM. CONNECTOR AMP 1.27 CN5,6 on MB 2
J3439112 2P MALE CONNECTOR P 2.5 M CN16 on PHB 1
J3439120 4P MALE CONN. P.2 M CN4 on MB 1
J3439122 8P MALE CONNECTOR P.2 M CN1 on PAB 1
J3439141 10P MALE CONNECTOR P.2 M CN3 on MB 1
J3439124 10P MALE CONN. P. 2 M 90°CN3 on CB 1
J3439138 4P MALE CONNECTOR P 3.96 M CN5 on PAB 1
J3439147 14P MALE CONNECTOR P.2 M CN8 on MB / CN4 on PAB 2
J3439148 7P MALE CONNECTOR P.2 M CN15 on PHB / CN2 on MB/ CN6,9 on PAB 4
13369898 2P MALE CONNECTOR B2P3-VH CN1,2 on PB 2
J3439152 5P MALE CONNECTOR P.3.96 M CN11 on PAB 1
J3439171 4P MALE CONNECTOR 90°P.2 M CN1 on CB 1
J3439172 8P MALE CONNECTOR 90°P.2 M CN4 on CB 1
WIRING, CABLE
K3418105 CABLE F/PEDAL (84) KS-137/237/147 1
K3468212 2P CABLE (18) (W/2PC) From CN16 on PHB to CN1 on LEDB 1
K3468153 20P FLAT CABLE (52) -2C From CN6 on MB to Right Contact B. 1
K3468213 20P FLAT CABLE (72) -2C D/R From CN5 on MB to Left Contact B. 1
J3469143 1P CONN. AWG18 (10) - YELLOW On PHB 1
# 7772908000 2+2P COAXIAL CBL ASSY (114) P.2 D/R From CN4 on CB to CN1 on PAB 1
# 7773004000 4P CABLE ASSY (76/40) 1C P3.96 From CN5 on PAB to speakers 1
# 7772909000 4P CABLE ASSY (86) -2C P.2 D/R From CN1 on CB to CN4 on MB 1
7699409000 7P CABLE ASSY (86) -2C P.2 From CN9 on PAB to CN1on PHB 1
7711512000 7P CABLE ASSY (28) -2C P.2 D/R From CN6 on PAB to CN2 on MB 1
# 7772910000 10P CABLE ASSY (86) -2C P.2 D/R HP-1-RW From CN3 on CB to CN3 on MB 1
7700124000 14P CABLE ASSY (28) -2C P.2 From CN4 on PAB to CN8 on MB 1
TRANSFORMER
# K2458148 TRANSFORMER 100-240 HP-2E-RW 1
AC INLET
J3449103 UNIVERSAL AC INLET ON PCB on PB 1
SCREW
J2289101 SELF TAP.SCREW 2.9X 6 TC TC 3
J2289116 SELF TAP.SCREW 3.5X13 TC TC 6
J2289213 SELF TAP.SCREW 3.9X16 TC TC 14
J2289125 SCREW 2.9X10 TC TC PR TROP 10
J2289130 SCREW 2.9X13 TC TC PR TROP 3
J2289118 SCREW 2.9X16 TC TC PR BRUN 3
J2289212 SCREW 3.5X10 TC TC PR BRUN 6
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6 3
J2289147 SELF LOCK.SCREW M3X12 TCTC H.6 5
J2289110 SELF LOCK.SCREW M4X20 TCTC H. 9.5 12
K2288110 SCREW M5X20 TC TC TFR H9.5 BRUN 8
J2289142 PITCH SCREW M5X25 TC TC 3
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6 10
J2289135 SELF LOCK.SCREW M4X 7 TCTC T.8 4
J2289227 SCREW 3.9X20 TC PR TFR T.8 BLACK PLATED 14
J2289150 SCREW 2.9X16 TC PR TFR H.7 7
K2288107 SCREW 3.9X13.5 TC PR TFR H.8 32
# J2289249 SCREW 4.5X45 TC PR TFR T.9.5 6
PACKING
# K2638272 POLYST. END-SIDE HP-1-RW 2
# K2638273 CENTRAL POLYSTERENE END-SIDE HP-1-RW 1
# K2638274 CENTRAL POLYSTERENE END-SIDE HP-1-RW 1
# K2638275 RIGHT SIDE LDPE PROTECTION+BOX HP-1-RW 1
# K2638276 LEFT SIDE LDPE PROTECTION+BOX HP-1-RW 1
# K2638277 CENTRAL LDPE PROTECTION HP-1-RW 2
K2678115 CARTENE ENVELOPE HD 60X80 2
K2678109 CARTENE ENVELOPE HD 150X40 1
K2678116 CARTENE ENVELOPE HD 70X190 1
K2678102 POLYETH. ENVELOPE 25X45 2
K2678106 POLYETH.ENVELOPE 4OX55 1
# K2618277 OUTER CARTON HP-1-RW 1
# K2618278 INNER CARTON HP-1-RW 1
MISCELLANEOUS
40016756 NUT M12 HLJ0999-01-360 M12 2
J2289113 NUT 3MA H.3 2
J2329107 JOINT BOLT ASSY 8
J2139112 FLAT WASHER I.D. 6X18 TH. 1.6 2
J2139114 FLAT WASHER I/D 5X14 TH. 1 8
K2168113 LED SPACER H. 17.1 E.D. 6.7 1
# K2168122 LED SPACER H.4.6 D.E.5.5 6
!
!
J2369106 WIRE HOLDER CLAMPING RN04 2
J2159103 DOUBLE ELASTIC PLATE 2
J2329101 SCREW DRIVER TYPE 2 1
K2268121 RED FELT MM 1250X12X1.5 1
K2268148 ADHESIVE BLACK FELT 25X1X1240 1
K2268149 ADHESIVE BLACK FELT MM540X15X1 2
K1188132 KEYBOARD SUPPORT R178 3
K2248160 AC SOCKET HOLDER 1
K2128135 COUPLING PIN FOR TOP CBNT 2
K2128134 COUPLING PIN F/TOP CBNT-REAR PANEL 3
# K2248168 LOUDSPEAKER GRILL HP-1-RW 2
K253810302 FUSE WARNING LABEL 1
ACCESSORIES
J3439155 CABLE CEE XVIIG-H05VVF2X1-C17W (230V) 1
J3439154 CABLE GB BS89/5 H05VV-F3G1 C13W (230VE) 1
J3439167 CABLE SAA/2-H05VV5 2X1-C17W (240VA) 1
J3439155 CABLE CEE XVIIG-H05VVF2X1-C17W (117V) 1
# K6018476 OWNER'S MANUAL (E-D-F-IT-SP-OL) HP-1-RW 1
# K6018477 MOUNTING SCHEME HP-1-RW 1
!
!
!
!
14
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
CASING
00890990 LOGO BADGE 'ROLAND' (GOLDEN) 1
# K1168114 RIGHT END BLOCK HP-2E RW 1
# K1168115 LEFT END BLOCK HP-2E-RW 1
# K2198111 MUSIC SCORE HOLDER HP-2E-RW 1
# 7773006000 CABINET ASSY HP-2E 1
# 7773007000 VARN.+SILK.TEMPLATE F/TOP CABINET HP-2e 1
7770025000 VARN. LID BLIND HP-337E 1
# 7773008000 VARN.+SILK. REAR PNEL HP-2E-RW 1
# 7773009000 VARN.+SILK. CONTROL BLIND HP-2E-RW 1
# 7773010000 SILKSCREENED PLEXIGLASS HP-2E-RW 1
# 7773011000 BORED MDF TOP CBNT HP-2E-RW 1
# 7773012000 BORED MUSIC REST HP-2E/3E-RW 1
# 7773013000 BORED SLIDE LID HP-2E-RW 1
# 7773014000 SHAFT STAY 1
# 7773015000 KEYBOARD BLIND HP-2E-RW 1
ONLY FOR HP-2e LA
# K2148116 STOP PIN F/MUSIC SCORE HOLDER 2
# 7774310000 CABINET ASSY (OAK) HP-2E-LA 1
# 7774306000 VARN.+SILK. CONTROL PANEL BLIND HP-2E-LA 1
# 7774302000 RIGHT VARN. END-BLOCK HP-2E-LA 1
# 7774303000 LEFT VARN. END-BLOCK HP-2E-LA 1
# 7774311000 VARN. MUSIC SCORE HOLDER HP-2E-LA 1
# 7774305000 VARN.+ SILK. REAR PANEL HP-2E-LA 1
# 7774304000 VARN.+SILK. CONTROL BLIND HP-2E-LA 1
# 7774301000 TOP CABINET BLIND (OAK) HP-2E-LA 1
# 7774308000 MDF TOP CABINET (OAK) HP-2E-LA 1
# 7774307000 VARN. MUSIC REST (OAK) HP-2E-LA 1
# 7774309000 BORED MDF SLIDE LID (OAK) HP-2E-LA 1
KNOB BUTTON
22485316 BLACK KNOB HP-730/530E 1
# K2478349 2-BUTTON GROUP D. 9.5 9
# K2478350 2-BUTTON GROUP D.9.5 1
3249559701 SWITCH CAP 1
SWITCH
01453245 AC PUSH SWITCH SDDLB1B2D TV5 1
J3169105 SWITCH TP-1101A / EVQ-PAE 05 R SW1=>20 on CB 20
JACK, SOCKET
13449252 JACK SOCKET YKB 21-5006 JK101,102 on PHB 2
13449283 JACK SOCKET HLJ7101-01-3010 JK1,2,3,4 on PAB 4
00340223 DIN SOCKET YKF51-5031 JK8 on PAB 1
13429676 5P DIN SOCKET Y KF51-5048 (2PCS) JK5 on PAB 1
DISPLAY UNIT
00239767 DISPLAY TYPE LB-603VF (RED) LED19 on CB 1
SPEAKER
22415596 LOUDSPEAKER CF160138-01 6 OHM 2
KEYBOARD ASSY
# J2589109 88-KEY KEYBOARD ASSY TP/30 1
NOTE: For details, refer to KEYBOARD PARTS LIST (Page 6)
PCB ASSY
# 7773003000 POWER AMP. PCB ASSY HP-2E 1
7699410000 LED ASSY 1
7772401000 PRIMARY PCB ASSY KR-777 1
NOTE: The PRIMARY PCB ASSY doesn’t include the fuse. When you replace this assy, please order the fuse, as well, as indicated
on “FUSE, FUSE HOLDER”.
# 7773002000 CONTROL PCB ASSY HP-2e 1
# 7772903000 PHONES PCB ASSY HP-1/2e/3e 1
# 7773001000 MAIN PCB ASSY HP-2e 1
IC
15229718RI I.C. 6N 137 PHOTO-COUPLER IC15 on PAB 1
A02673823 I.C. MASK ROM UPD23C64040ALGY-743-MJH IC11 on MB 1
01786667 I.C. HD6413006F20 FLAT IC6 on MB 1
15249111 I.C. TC7WU04 F FLAT CMOS IC13 on MB 1
00232645 I.C. TC7W14F FLAT IC20 on MB 1
J5259001 I.C. 74 HC 04 FLAT CMOS IC9 on PAB 1
J5259105 I.C. 74 HC 138 FLAT CMOS IC4 on CB 1
00129278 I.C. SSC1080 FOB (CUSTOM IC) IC16 on MB 1
J5259110 I.C. HM62256LFP-7T FLAT SRAM IC5,7on MB 2
01126612 I.C. LC324260AJ60/AS4C256K16E050JCT IC14 on MB 1
01679978 I.C. RA09-002 (XP6) CUSTOM IC9 on MB 1
15259884 I.C. TC7S08F MOS CMOS IC19 on MB 1
00236845 I.C. TC 74VHC245F IC5 on CB 1
15189210 I.C. BA 5218F (OP AMP) IC3,5,7on PAB/IC17 on MB 4
15289105 I.C. UPC 4570G (OP AMP) IC3 on CB/IC1,2,6,10,11 on PAB 6
15199937 I.C. M51953 BFP FLAT IC4 on PAB 1
01451578 I.C. AK4324-VF-E2 DAC IC18 on MB 1
J5199102 I.C. UA 7812 CV TO220 IC13 on PAB 1
J5199103 I.C. 7912F TO220 IC14 on PAB 1
01344512 I.C. UPC24A05HF (REGULATOR) IC12 on PAB 1
01458445 I.C. UPC29M33T-T1 FLAT (REGULATOR) IC27 on MB 1
A02780301 I.C. UPC 29L05T REGULATOR FLAT IC15 on MB 1
TRANSISTOR
15129114 TRANSISTOR 2SC-1815GR Q15,16,25,28 on PAB 4
15119113 TRANSISTOR 2SA-1015 GR Q12,22,27 on PAB 3
15129136 TRANSISTOR 2SC-2878-A/B Q3,4,9,10,13,14 on PAB 6
15129602 TRANSISTOR 2SD-667C Q2,8 on PAB 2
15139124 TRANSISTOR 2SK-363 GR FET Q17,21,26,29 on PAB 4
15129164 TRANSISTOR DTC-114ES Q32 on PAB 1
15329516 TRANSISTOR DTC-114EK Q8,9,10,11,12,13,14,15 on CB 8
15119163 TRANSISTOR RN2227 Q19,20 on PAB 2
15119615 TRANSISTOR 2SB-647C T2 Q5,11 on PAB 2
00898201 TRANSISTOR RN2421 CHIP Q1 on MB 1
A02126367 TRANSISTOR 2SB-1016 AY Q1,7 on PAB 2
A02126378 TRANSISTOR 2SD-1407 AY Q6,12 on PAB 2
A02451378 TRANSISTOR RN2427 Q1,2,3,4,5,6,7 on CB 7
DIODE
15119126 DIODE 1SS-133T REDUCED PITCH D1,2,3,4,5,6,7,8,15,16,17,18 on PAB 12
15339108 DIODE DA-204K D9,11,13,19,21,22,25 on PAB 7
15339109 DIODE DAP 202K CHIP DA1,2,3,4,5,6,7,8,10,11 on CB 10
15039159T0 DIODE RECTIFIER S5688G D14,24,27,28,30,31,33 on PAB 7
15029284RI LED DIODE TLHR4401 - RED LED5,6,7,9,10,12,13,14,15,20,23,24 on CB 12
J5029107 LED DIODE 3 SLR-37VR3F - RED On LEDB 1
01121689 LED SPR-325MVWT31 LED16,17,18,21,22,25 on CB 6
15039176 JUMPER DIODE D3SBA20 4A/200V D29 on PAB 1
RESISTOR
J3919108 RESISTOR ARRAY EXB-V8V-103-JV RA3,5,6,8,26 on MB 5
J3919110 RESISTOR ARRAY E XB-V8V-R00-0V RA20,21,22,23,24,25 on MB 6
00126101 RESISTOR ARRAY EXB-V8V-221-JV RA2,7,9,10,11,12 on MB 6
01457145 RESISTOR ARRAY EXB-E10C-103-J RA13 on MB 1
A02019023 RESISTOR ARRAY EXB-E10C-682-J RA16,17,18 on MB 3
13819132RI UNINFL.RES. 100 OHM 0.6W 5% R22,23,24,25 on PHB 4
02014945 RESISTOR 0 OHM1/2W 5% 2010 (MCR50) R59 on CB 1
01783623 RESIST. 2010 10 OHM1/2W 5% R27,30 on MB 2
A01561290 FUSE RESISTOR RF2SL20 8R2 OHM J R137 on PAB 1
A01450978 FUSE RESISTOR RF50S T52 OR1 OHM J R10,47 on PAB 2
POTENTIOMETER
13289251 ROT. POT. 10KB 14K12C VR1 on CB 1
CAPACITOR
01015878 POL.COND. 0805 330P 5% C52,56,57,63,67,68 on PAB 6
15359774 POLYEST.COND. 0805 680P 5% C20,41 on PAB 2
J3469156 ELECTR. COND. 33U 35V P.5 C1,3,4,6,16,36,37,42,45,48,49,53,55,60,64,66,71,72,73,74,
88,89,91 on PAB 23
J3629155 CONDENSER 330V 25V P5 ELET PRESAGOM. C95,100,105,107 on PAB 4
# J3629159 ELECTRL.COND. 1000UF 35V R. C92 on PAB 1
J3629148 ELECTR. COND. 6800U 35V R. C97,102 on PAB 2
J3629132 ELECTRL.COND. 100U 50V P5 C12,19,33,40,77,82 on PAB 6
J3629107 ELECTRL.COND. 1UF 100V P5 C39 on PAB 1
J5369104 ELECTR. COND. RV2 10U 16V (SMD) C11,12,13,45,48,54,78,92,101,104,107,110,115,183 on MB 14
J5369105 ELECTR. COND. RV3 33U 16V (SMD) C13,74,82,117,176 on MB 5
J3629137 ELECTR. COND. 33U 16V H.7 C4,5,8,12,16,17 on CB 6
13529104RI CAPACITOR DE1310E472MVA-KH C1 on PB 1
13649103J0 UNPOL.COND. 10U 50 P5 C13,21,84,108,117 on PAB 5
!
PARTS LIST HP-2e-RW/LA (230V/230VE/240VA)
When ordering any parts listed in the parts list,please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
CONSIDERATION ON PARTS ORDERING
MB = Main Board
PAB = Power Amp. Board
CB = Control Board
PHB = Phones Board
PB = Primary Board
LEDB = Led Board
NOTE:
#The parts marked " #'' are new (Initial Parts).
AThe parts marked " A'' are new (Initial Parts).for RES but already used by RJA
The parts marked have Safety - Related characteristics.
Use only listed parts for replacement.
<< EMI >> Component for EMC.
NNoottee::Replacement should be made on a unit basis. No replacements available for individual parts.
Replacement only be a unit.
!
!
SAFETY PRECAUTIONS :
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
!
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
15
01452189 COND. ECKDBE472 ZF C101on PAB 1
INDUCTOR, COIL, FILTER
<<EMI>> 12449326 NOISE SUP. SBT-0460 L15 on PAB 1
<<EMI>> 13529187 NOISE SUP. ELKTR391CA FL1,2,3 on PAB 3
<<EMI>> 12449355 NOISE SUP. FBR07H850TB00 L1,2,3,4 on PAB/L18,19,22 on PHB 7
CRYSTAL, RESONATOR
00894034 X-TAL 16 MHZ MA-406 X1 on MB 1
00901912 X-TAL 24.576 MHZ MA-406 X2 on MB 1
FUSE, FUSE HOLDER
J2559123 FUSE 5X20 630MAL/250V SEMKO F1 on PRIMARY B - only for 230V/230VE 1
J2559104 FUSE 5X20 3.15AL/250V SEMKO F1, F2 on PAB 2
12199597RI FUSE HOLDER T.P1 on PRIMARY B / on PAB 6
CONNECTOR
13369689RI 20P FEM. CONNECTOR AMP 1.27 CN5,6 on MB 2
J3439112 2P MALE CONNECTOR P 2.5 M CN16 on PHB 1
J3439120 4P MALE CONN. P.2 M CN4 on MB 1
J3439122 8P MALE CONNECTOR P.2 M CN16 on PAB 1
J3439141 10P MALE CONNECTOR P.2 M CN3 on MB 1
J3439124 10P MALE CONN. P. 2 M 90°CN3 on CB 1
J3439138 4P MALE CONNECTOR P 3.96 M CN5 on PAB 1
J3439147 14P MALE CONNECTOR P.2 M CN4 on PAB/CN8 on MB 2
J3439148 7P MALE CONNECTOR P.2 M CN2 on MB/CN6,9 on PAB/CN15 on PHB 4
13369898 2P MALE CONNECTOR B2P3-VH CN1,2 on PB 2
J3439152 5P MALE CONNECTOR P.3.96 M CN5 on PAB 1
J3439171 4P MALE CONNECTOR 90°P.2 M CN1 on CB 1
J3439172 8P MALE CONNECTOR 90°P.2 M CN4 on CB 1
WIRING, CABLE
K3468212 2P CABLE (18) (W/2PC) From CN16 on PHB to CN1 on LEDB. 1
K3468153 20P FLAT CABLE (52) -2C From CN6 on MB to CN KEY DX 1
K3468213 20P FLAT CABLE (72) -2C D/R From CN5 on MB to CN KEY SX 1
J3469143 1P CONN. AWG18 (10) -GREEN On PHB 1
7770122000 4P CABLE ASSY (32) 2C P.2 D/R From CN1 on CB to CN4 on MB 1
# 7773004000 4P CABLE ASSY (76/40) 1C P3.96 From CN5 on PAB to SPEAKERS 1
7699409000 7P CABLE ASSY (86) -2C P.2 From CN9 on PAB to CN15 on PHB 1
7711512000 7P CABLE ASSY (28) -2C P.2 D/R From CN6 on PAB to CN2 on MB 1
# 7773005000 8P CABLE ASSY (86) -2C P.2 D/R From CN4 on CB to CN1 on PAB 1
7699418000 10P CABLE ASSY (38) -2C P.2 From CN3 on CB to CN3 on MB 1
7700124000 14P CABLE ASSY (28) -2C P.2 From CN4 on PAB to CN8 on MB 1
TRANSFORMER
# K2458148 TRANSFORMER 100-240 HP-2E-RW 1
AC INLET
J3449103 UNIVERSAL AC INLET ON PCB on PB 1
SCREW
J2289101 SELF TAP.SCREW 2.9X 6 TC TC 2
J2289102 SELF TAP.SCREW 2.9X10 TC TC 8
J2289116 SELF TAP.SCREW 3.5X13 TC TC 6
J2289213 SELF TAP.SCREW 3.9X16 TC TC 12
J2289125 SCREW 2.9X10 TC TC PR TROP 4
J2289130 SCREW 2.9X13 TC TC PR TROP 7
J2289118 SCREW 2.9X16 TC TC PR BRUN 3
J2289212 SCREW 3.5X10 TC TC PR BRUN 6
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6 3
J2289147 SELF LOCK.SCREW M3X12 TCTC H.6 5
J2289221 SELFLOCK. SCREW M4X10 TC TC TFR 9.5 6
J2289110 SELF LOCK.SCREW M4X20 TCTC H. 9.5 10
K2288110 SCREW M5X20 TC TC TFR H9.5 BRUN 8
J2289142 PITCH SCREW M5X25 TC TC 3
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6 12
J2289135 SELF LOCK.SCREW M4X 7 TCTC T.8 4
J2289115 SCREW 3.5X9.5 TC PR TFR H.8 18
J2289227 SCREW 3.9X20 TC PR TFR T.8 BLACK PLATED 10
J2289150 SCREW 2.9X16 TC PR TFR H.7 17
K2288107 SCREW 3.9X13.5 TC PR TFR H.8 44
PACKING
# K2638266 RIGHT LDPE END SIDE + BOX HP-2E-RW 1
# K2638267 LEFT LDPE END SIDE + BOX HP-2E-RW 1
# K2638268 CENTRAL LDPE PROTECTION HP-2E-RW 2
K2678121 CARTENE HD ENVELOPE CM 80X200 1
K2678106 POLYETH.ENVELOPE 4OX55 1
# K2618266 OUTER CARTON HP-2E-RW 1
!
!
!
MISCELLANEOUS
40016756 NUT M12 HLJ0999-01-360 M12 2
J2289113 NUT 3MA H.3 2
J2329105 HINGE F/MUSIC REST 2
J2139114 FLAT WASHER I/D 5X14 TH. 1 8
K2168113 LED SPACER H. 17.1 E.D. 6.7 1
# K2168121 LED SPACER H. 3.6 D.E.9 6
# K2168122 LED SPACER H.4.6 D.E.5.5 12
K2268158 REST RUBBER NAIL F/LID 1
J2369106 WIRE HOLDER CLAMPING RN04 5
K2248160 AC SOCKET HOLDER 1
K2268121 RED FELT MM 1250X12X1.5 1
K2268127 BLACK ADH. FELT 1320X9X2.5 MM. 1
K2268149 ADHESIVE BLACK FELT MM540X15X1 2
K2268159 CUSHION F/LID BLIND 2
7695813000 VARNISHED WOOFER NET 2
K1188132 KEYBOARD SUPPORT R178 3
K253810302 FUSE WARNING LABEL 1
# K2128130 RIGHT GUIDE FOR SLIDE LID HP-2e-RW 1
# K2128131 LEFT GUIDE FOR SLIDE LID 1
# K2128132 SUPPORT F/SHAFT STAY HP-2E-RW 3
# K2128133 LID GEAR 2
# K2128134 COUPLING PIN F/TOP CBNT-REAR PANEL 3
# K2128135 COUPLING PIN FOR TOP CBNT 2
# K2148115 STOP PIN F/MUSIC SCORE HOLDER 2
ACCESSORIES
J3439155 CABLE CEE XVIIG-H05VVF2X1-C17W (230V) 1
J3439154 CABLE GB BS89/5 H05VV-F3G1 C13W (230VE) 1
J3439167 CABLE SAA/2-H05VV5 2X1-C17W (240VA) 1
# K6018467 OWNER'S MANUAL (E-D-F-IT-SP-OL) HP-2E 1
A02892389 SONG BOOK 60 PCN 1
PARTS LIST STAND KS-2e-RW/LA
K3418105 CABLE F/PEDAL (84) KS-137/237/147 1
K2288109 SCREW 3.9X30 TC PR TFR T.8 BRUN 4
J2289208 SCREW 3.5X25 TC PR TFR H.8 BRUN 7
J2289247 SCREW M6X30 TC PHILIPS TBL 2
# J2289249 SCREW 4.5X45 TC PR TFR T.9.5 6
J2329107 JOINT BOLT ASSY 6
J2329101 SCREW DRIVER TYPE 2 1
K2358102 SIDE PANEL FOOT 2
K2128128 COUPLING BASE KS-237PE 2
K2638142 MID POLYST. END-SIDE 1
K2638143 POLYST. SHEET 500X1510X20 1
K2678115 CARTENE ENVELOPE HD 60X80 2
K2678116 CARTENE ENVELOPE HD 70X190 1
K2678102 POLYETH. ENVELOPE 25X45 1
K2678105 CARTENE ENVELOPE HD 140X57 1
# 7896601000 RIGHT SIDE PANEL ASSY KS-2E 1
# 7896602000 LEFT SIDE PANEL ASSY KS-2E 1
K1138111 BASE FOR PEDAL (MDF) KS-147E 1
# K1148148 REAR PANEL KS-2E/KS-3E/KS7E 1
# K2618267 OUTER CARTON KS-2E 1
J3059116 3-NOTE PEDAL KS-237E/147E 1
# K6018468 MOUNTING SCHEME KS-2E 1
ONLY FOR KS-2e LA
J2289248 SCREW M6X30 TC PHILIPS TBL 2
K2128129 COUPLING BASE KS-237LE 2
# 7897001000 RIGHT SIDE PANEL ASSY (OAK) KS-2E-LA 1
# 7897002000 LEFT SIDE PANEL ASSY (OAK) KS-2E-LA 1
# K1148151 REAR PANEL (OAK) KS-2E-LA 1
# 7897004000 BASE F/PEDAL ASSY KE-2E-LA 1
# 7897003000 FOOT F/SIDE PANEL (STAND) KS-2E-LA 2
NOTE: The “3-NOTE PEDAL KS-237”includes the parts shown in the Pedal Exploded view, on page 8..
!
!
!
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
16
11
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
BLOCK DIAGRAM
MIDI IN
BUFFER
IC9 IC15
KEYBOARD
POWER
SUPPLY
LEFT/MONO RIGHT
AA
ADDRESS BUS
EA
IC14
UCAS
A
D
IC5,IC7
D
LOUT
CPU
D
XP
KEY SCAN
IC17
WA A
T
IC12
RAS
ED
IC6
RAS
R
D
ALPF
DATA BUS
DATA
IC18
EWE
IC9
WE
D
MAIN BOARD
IC22
L
WD
WAVE ROM
ROUT
SRAM
D/A
D
A
A
ED
MK BK
IC16
CAS
MIDI OUT
Q12
Q13
Q14
SOFT
SOST/DAMP
SOFT
SOST
DAMPER
TX
RX
XRES
AC
FILTER
POWER & AMP. BOARD
XRES
88 KEYS TP-30
IC15 IC27
PEDAL UNIT FOR HP-2e
PEDAL JACK
D RAM
IN IN
OUT OUT
SOFT SOST DAMPER
PHONES BOARD
IP OP
LED+SW
MATRIX
PANEL BOARD
MASTER
VOLUME
SOST
DAMPER
8M-FLASH
SOFT
INPUT
LEFT/MONO RIGHT
OUTPUT
TRANSFORMER
POWER
SWITCH
AC INLET
D29
IC12
IC13
IC14
RESET
IC4
MIXER
IC5
BUFFER
IC6
EQU
AMPL.
EQU
AMPL.
Q1,Q2,Q5,Q6
Q7,Q8,Q11,Q12
IC1
IC2
EQU
IC3
BUFFER
IC7
Q17
Q26
Q3
Q9 Q4
Q10
Q13
Q14
MUTE
CONTROL
Q20,Q32,Q22,Q28
OUT
MUTE
PHONES
MUTE
POWER
MUTE
Q21
SPEAKERS
DAMPERSOFT
PEDAL UNIT FOR HP-1
+5VD+VCC
A
A
D
A+5VAVCC +3.3VD+5VD
-VCC
A
A
A
2
4
3
7
8
1
5
1
4
2
5
3 1
4
2
5
3
2
4
3
7
8
1
5
3
1
2
3
1
2
3
1
2
3
1
2
4 5
2
1 3
6 7
8
10
9
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
17
11
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
SIG_L
AGND
SIG_R
MUTE_SEND
MUTE_RET
LED_K
LED_A
L18=L19=L22=EXCELDR25V
3
4
2
1
5
6
7
CN15
53014-0710
L19
L22
L18
2
4
3
7
8
1
5
JK101
YKB21-5006
2
4
3
7
8
1
5
JK102
YKB21-5006
R22 100 I
R23 100 I
R24 100 I
R25 100 I
P
H
O
N
E
S
C123
100nFC
2
1
CN16
5045-02A
12
D1
From JACK BOARD
To LED BOARD
(Cn1)
PHONES BOARD
LED BOARD
LED DIODE
3 SLR-37VR3F-RED
View from component side
PHONES PCB ASSY & CIRCUIT DIAGRAM
ASSY 7772903000
View from component side
BLK
SAFETY PRECAUTIONS:
The parts marked have safety-related characteristics.
Use only listed parts for replacement.
COM
INLET BOARD
TO PAB-M Board
(CN11)
GMD 1.25A/250V
230V/240V T630mAL250V
F1 LABEL
100V/117V OMEGA-ALERT GMD 1.25A/250V
OMEGA-ALERT S504 T630mAL250V
N
L
MAINS
BLKBLK
POWER SW1
SDDLB1B2D-TV5
WHT
240V
230V
120V
100V
BLK
WHT
TRANSFORMER
N
L
INLET1
K+B 42R65.1114
2
1
C1
DE1310E472M-KH
F1
CN2
B2P3-VH
2
1
CN1
B2P3-VH
2
1
PRIMARY PCB ASSY & CIRCUIT DIAGRAM
ASSY 7772401000
NOTE: The PRIMARY PCB ASSY doesn’t include the fuse. When you replace this assy, please order the fuse, as well, as indicated on PARTS
LIST “FUSE, FUSE HOLDER”.
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
18
11
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
MAIN PCB ASSY
for HP-1 ASSY 7772901000
for HP-2e ASSY 7773001000
View from component side View from solder side
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
19
11
HP-1 MH/RW, HP-2e RW/LA
Mar, 2002
CIRCUIT DIAGRAM (MAIN PCB ASSY)
TO
PHONES L
Serial I/F
TO CONTROL BOARD
(CN1)
TO POWER & AMP. BOARD
(CN4)
TO CONTROL BOARD
(CN3)
TO O POWER & AMP. BOARD
(CN6)
8Mbit Flash
256kbit SRAM
256kbit SRAM
TO KEYBOARD
(LEFT)
TP-30
TO KEYBOARD
(RIGHT)
TP-30
LEFT
RIGHT
For RES Contact Board
(88 Keys)
For RES Contact Board
(88 Keys)
T7
T6
T5
T4
T3
T2
T1
T0
T7
T6
T5
T4
T3
XRES
XHWR
XRES
FLASH-CT1
XHWR
XRAM
PORT6
PORT5
PORT4
PORT4
PORT5
PORT6
DATA-5--AN-3
PORT3
PB5
PB5
PB6
PB6
PB7
PB7
XKEY
KEYINT
XROM
XRES
XRES
FLASH-CT1
PORT7
SW-1
SW-2
SW-3
XMUTE
LRCK
BCK
256/384FS
XPD
XRES
XMUTE
WD4
WD12
XWCS1
XXPINT
XLWR
WD3
EA[0..8]
XRD
WD11
WD8
WD14
WD5
WD7
WD12
WD3
EA2
WD11
WD13
WD2
XRD
WD4WD2
XWCS0
WD15
WD10
WD12
EA1
EA0
EA8
XRD
EA8
XRD
WD11
WD13
EA0
WD14
WD2
EA1
WD0
EA2
WD15
EA3
WD13
WD5
WD3
XRD
WD10
WD8
WD15
WD4XRD
EA3
WD10
EA4
XWOE
WD7
EA7
WD0
WD8
EA4
EA5
XW3-CS1
WD7
EA6
WD0
WD14
WD5
EA5
EA7
EA6
A13
A13
A9
A9
A4
A4
A8
A5
A2
A12
A12
A7
A15
A1
A3
A0
A11
A6
A6
A5
A10
A10
A16
A12
A11
A3
A8
A5
A5
A12
A1
A15
A3
A14
A2
A2
A13
A0
A10
A2
A13
A7
A7
A1
A17
A11
A6
A6
A7
A14
A9
A4
A10
A15
A1
A3
A8
A1
A14
A18
A0
A8
A9
A4
ED1
ED2
ED6
ED4
ED5
ED7
ED3
ED5
ED1
ED0
ED3
ED6
ED4
ED2
ED7
ED0
ED[0..7]
FLASH-CT0
AN-0
MODEL SELECT
XHWR
SD
XXP
PHAI
XRES
AN-4
AN-3
AN-3
PB4
PB4
CTS
DATA-6--AN-4
PORT0
PORT1
PORT2
XLWR
XLWR
E-WR
MIDI-IN
RXD1
MIDI-OUT
TXD1
MK10
MK9
MK8
MK7
MK8
MK9
MK10
AN-2
AN-1
XW3-OE
MK7
A[0..1]
A19
WD9
WD9
WD6
WD9
WD1
WD1
WD1
WD6
WD6
WD8
WD7
WD12
WD3
WD11
WD2
WD10
WD13
WD14
WD15
WD5
WD4
WD0
WD6
WD9
WD1
XW3-OE
XW3-CS0
WD[0:15]
XWCS0
XWCS1
XW3-CS0
XW3-CS1
XRAM
XRAM
L 4.5V
T1
SCAN-B
DATA0
AN-4
SCAN-C
DATA1
SCAN-A
DATA3
DATA2
LED-EN
PORT7
DATA-4--AD-VREF
DATA-7--AD-GND
XWE-FLASH0
VSS-FLASH0
XWE-FLASH1
VSS-FLASH1
XWE-FLASH1
VSS-FLASH1
XWE-FLASH0
VSS-FLASH0
A18
A17
A16
A15
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
XHWR
A19
VPP
A[0:19]
WA3-12
WA3-11
WA3-6
WA3-7
WA3-8
WA3-5
WA3-9
WA3-10
WA3-18
WA3-23
WA3-21
WA3-19
WA3-22
WA3-20
WA3-17
WA3-16
WA3-13
WA3-14
WA3-15
WA8
WA6
WA5
WA7
WA22
WA21
WA17
WA23
WA19
WA20
WA18
WA16
WA14
WA13
WA15
WA10
WA12
WA9
WA11
XW3-CS0
XW3-CS1XWCS1
XWCS0
WA3-4
WA3
WA3-1WA1
WA3-3
WA3-2WA2
WA4
RES
MUTE-CTL
MIDI-Select
SW-1
CTS
RTS
FLASH-CT0
RES
XPD
A-
A+
AGND
RightCh-Signal
LeftCh-Signal
SOSTENUTE
SOFT
DAMPER
AN-1
PHONE-SENSE
MIDI-IN
E-CAS
E-RAS
D7
D7
D6
D5
D14
D12
D4
D7
D10
D14
D13
D1
D[0..15]
D2
D10
D11
D15
D9
D0
D9
D11
D12
D1
D0
D8
D9
D0
D8
D2
D6
D9
D11
D15
D[0..15]
D3
D2
D14
D15
D0
D13
D13
D15
D14
D4
D10
D10
D6
D3
D8
D5
D5
D14
D13
D12
D3
D8
D6
D13
D12
D4
D4
D3
D8
D7
D5
D9
D1
D11
D1
D15
D2
D10
D12
D11
A11
XWOE XW3-OE
WA3-15
WA3-9
WA11
WA3-16
WA3-16
WA3-8
WA3-13
WA15
WA4
WA3-23
WA8
WA3-22
WA15
WA3-19
WA3-10
WA3-12
WA9 WA3-16
WA2
WA13 WA13
WA3-22
WA18
WA3-11
WA3-20
WA3-23
WA3-21
WA3-17
WA3-6
WA3-21
WA3-15
WA19
WA3-3
WA1
WA3-7
WA3-6
WA3-18
XW3-OE
WA8
WA3-21
WA3-4
WA9
WA3-8
WA3-5
WA16
WA3-19
WA3
WA[1:23]
WA3-11
WA3-20
WA3-10
WA3-10
WA18
WA3-[1:23]
WA22
WA23
WA3-5
WA3-1
WA3-14
WA3-14
WA10
WA3-13
WA3-7
WA17
WA6
WA20
WA20
WA3-18
WA3-22
WA19
WA3-12
WA3-3
WA3-23
WA17
WA21
WA22
WA23
WA14 WA14
WA5
WA3-4
WA3-4
WA3-6WA6
WA3-17
WA3-2
WA3-9
WA3-11
WA10
WA3-3
WA3-18
WA3
WA3-19
WA3-1
WA12
WA21
WA3-13
WA1
WA16
WA3-20
WA3-14
WA12
WA11
WA2
WA3-7
WA3-5
XWOE
WA3-15
WA3-2 WA3-2
WA3-12
WA3-9
WA3-1
WA7
WA7
WA3-8
WA4
WA3-17
WA5
L 4.5V
R 4.5V
MODEL SELECT
RAM-POWER
KEYINT
XXP
XXPINT
XROM
SW-3
VPP
RAM-POWER
SW-2
RAM-POWER
XKEY
R 4.5V
MIDI-Select
FLASH-CT0
XCS7
XCS7
MIDI-OUT
RTS
RXD1
TXD1
RES
MUTE-CTL
AN-2
1MHz
PHAI
1MHz
AVCC
MK2
MK3
MK4
MK5
MK6
MK7
MK8
MK9
MK10
MK1
MK0
BR10
BR9
BR8
BR7
BR6
BR5
BR4
BR2
BR1
BR0
BR3
BR5
BR4
MK3
BR2
MK0
MK6
MK2
BR6
MK4
BR1
MK5
BR3
MK1
BR0
T0
MK10
BR8
MK8
BR7
MK7
MK9
BR9
BR10
T2
MK0 T0
BR0 T1
MK1 T2
BR1 T3
MK2 T4
BR2 T5
MK3 T6
BR3 T7
MK4 MK10
BR4 BR10
T0
T1
T2
T3
T4
T5
T6
T7
BR10
MK10
MK5
BR5
MK6
BR6
MK7
BR7
MK8
BR8
MK9
BR9
BR0
MK1
BR1
MK2
BR2
MK3
BR3
MK10
BR10
MK0
T5
BR6
BR9
T2
T0
T4
MK5
T5
MK7
BR8
T7
T3
MK4
MK9
BR7
MK4
T7
T3
T6
BR5
T1
MK8
T6
BR4
MK6
BR4
T4
T1
T2
T0
AN-4
AN-0
+
D3.
3
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
DD
D
D
A
A
+5
A
A
D
D D
D
D
DD
D
A
D
D
+5
A
D
+5
D
D
D
D
DD
D
D
D
D
D
D
A
+5
A
D
+
D
+
+
+
D3.
3
+
D3.
3
+
D3.
3
+
D
+
D
D
+
D3.
3
A
A
D
D
D
D
D
+5
D
+
D
+
D
+
D3.
3
D
+
D3.
3
D
+
D3.
3
D
D
D
D
D
D
+
+5
D
+
+
D3.
3
D
+
A9
+
A9
+
A9
+
A9
-9A
D
D
+
A9
+5
D
A
A
D
+
D3.
3+
D3.3
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D+5D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
+5
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
+5
D
C32 0.1
C39 0.1
C35 0.1
C40 0.1
C4
1000p
R63 100
R95 NIU
C175
NIU
C65
0.01
IC2B
TC7W00F
NIU 5
6
3
R46
68k
C119
220p
C100
220p
R93 NIU
CN5
AMPC1.2720P
3
4
5
6
7
8
2
1
9
20
19
18
17
16
15
14
13
12
1110
C75
0.1
R15
10k
R19 NIU
R71 NIU
R70
NIU
R41
68k
IC7
TC55257DFL-55L
1
26
2
23
21
24
25
3
4
5
6
7
8
9
10
20
27
22
19
18
17
16
15
13
12
11
28
14
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A0
CE
R/W
OE
I/O8
I/O7
I/O6
I/O5
I/O4
I/O3
I/O2
I/O1
VDD
GND
C3
EECS5R5T473
NIU
IC18
AK4324
1 2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
DVSS DVDD
CKS
MCLK
PD
BICK
SDATA
LRCK
SMUTE
DFS
DEM0
DEM1
DIF0
DIF1
DIF2
AOUTR-
AOUTR+
AOUTL-
AOUTL+
AVSS
VREF
AVDD
DZFR
DZFL
C19
560p
C18
560p
C66
15p
C51100p
R83 100
R84 100
R85
100
R2
MCR50J@
NIU
R79
470
IC20A
TC7W14F
17
C130
0.01
C155
22p
IC20C
TC7W14F
62
R103 NIU
R64
100
C163
22p
C156
22p
C164
22p
C165
22p
C157
22p
C166
22p
C158
22p
C167
NIU
C159
NIU
CN6
AMPC1.2720P
3
4
5
6
7
8
2
1
9
20
19
18
17
16
15
14
13
12
1110
IC13C
TC7WU04F
6 2
C168
NIU
C160
NIU
C169
NIU
C161
NIU
C170
NIU
C162
NIU
RA11
EXBV8V@JV
220
1 8
2 7
3 6
4 5
C171
220p
R69
NIU
C57
220p
C58
220p
C59
220p
RA12 220
1 8
2 7
3 6
4 5
IC5
TC55257DFL-55L
1
26
2
23
21
24
25
3
4
5
6
7
8
9
10
20
27
22
19
18
17
16
15
13
12
11
28
14
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A0
CE
R/W
OE
I/O8
I/O7
I/O6
I/O5
I/O4
I/O3
I/O2
I/O1
VDD
GND
R29 100
R31 100
R34 100
R32 100
L7
N1608ZA@T01
NIU
R28
NIU
R6
10K NIU
C11
ECEV-A@SR
10/16
C81
0.1
C64
NIU R24
0
RA2
EXBV8V@JV
220
1 8
2 7
3 6
4 5
C2
NIU
R23
0
R76
100K
R109
10K
C70
220p
C69
220p
C68
220p
Q1
RN2421
1
3 2
C84
0.1
C12
ECEV-A@SR
10/16
R7
1.5k
R30
MCR50J@
10
IC20B
TC7W14F
35
R110
100
R45
47k
R107 NIU
R106 0
C53 NIU
R27
MCR50J@
10
C9
0.1
R49
0
RA20
0
18
27
36
45
RA22 0
18
27
36
45
RA24 0
18
27
36
45
R94 0
C117
ECEV-A@SR
33/16
C54
ECEV-A@SR
10/16
C15
0.1
C16
ECEV-A@WR
33/16
IC12
UPD2 3C12 8000LGY@MJH
NIU
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
2627
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
WORD/BYTE
A16
A15
A14
A13
A12
A11
A10
A9
A8
A19
A21
A20
A18
A17
A7
A6
A5
A4
A3
A2
A1
A0
CE
GND
GND
OE/OE/DC
O0
O8
O1
O9
O2
O10
O3
O11
A22
VCC
VCC
O4
O12
O5
O13
O6
O14
O7
O15/A-1
GND
GND
C179
0.1
C26
0.1
C45
ECEV-A@SR
10/16
IC25
TC74VHCT245AFT
NIU
9
8
7
6
5
4
3
2
19
1
11
12
13
14
15
16
17
18
2010
A8
A7
A6
A5
A4
A3
A2
A1
G
DIR
B8
B7
B6
B5
B4
B3
B2
B1
VCCGND
IC23
TC74VHCT245AFT
NIU
NIU
9
8
7
6
5
4
3
2
19
1
11
12
13
14
15
16
17
18
2010
A8
A7
A6
A5
A4
A3
A2
A1
G
DIR
B8
B7
B6
B5
B4
B3
B2
B1
VCCGND
IC26B
TC7WH32FU
NIU
5
6
3
IC26A
TC7WH32FU
NIU
1
2
7
IC24
TC74VHCT245AFT
NIU
9
8
7
6
5
4
3
2
19
1
11
12
13
14
15
16
17
18
2010
A8
A7
A6
A5
A4
A3
A2
A1
G
DIR
B8
B7
B6
B5
B4
B3
B2
B1
VCCGND
C46
12p
RA21 0
18
27
36
45
RA23 0
18
27
36
45
RA25 0
18
27
36
45
R113
10K
RA26
EXBV8V@JV
10K
18
27
36
45
IC16
SSC1080
7
33
20
46
24
23
22
21
19
18
17
16
15
14
13
12
11
10
9
8
6
5
4
3
2
1
31
30
29
28
27
26
25
32
49
48
47
44
43
42
41
40
39
38
37
34
36
35
45
50
51
52
VDD
VDD
VSS
VSS
SC10
PR10
SC9
PR9
SC8
PR8
SC7
PR7
SC6
PR6
SC5
PR5
SC4
PR4
SC3
PR3
SC2
PR2
SC1
PR1
SC0
PR0
T7
T6
T5
T4
T3
T2
T1
T0
CLK
A1
A0
D7
D6
D5
D4
D3
D2
D1
D0
INT
RD
WR
CS
RESET
TEST1
TEST2
C154
22p
C25
0.1
C180
0.1
C20
NIU
C21
NIU
R77
100K
RA10
EXBV8V@JV
220
1 8
2 7
3 6
4 5
RA16
EXBE10C@J
6.8K
12
3
4
5
6
7
8
910
C182
0.1
R74
10k
IC13A
TC7WU04F
1 7
IC13B
TC7WU04F
3 5
C77
0.1
R25
1M
X2
MA-406@
24.576MHz
14
C177
0.1
C183
ECEV-A@SR
10/16
IC6
HD6413006
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
VCC
CS7/TMO0/PB0/*
CS6/DREQ0/PB1/*
CS5/TMO2/PB2/*
CS4/DREQ1/PB3/*
UCAS/TP12/PB4
SCK2/LCAS/PB5/*
TXD2/TP14/PB6
RXD2/TP15/PB7
RESO
VSS
TXD0/P90
TXD1/P91
RXD0/P92
RXD1/P93
IRQ4/SCK0/P94
IRQ5/SCK1/P95
D0/P40
D1/P41
D2/P42
D3/P43
VSS
D4/P44
D5/P45
D6/P46
D7/P47
D8
D9
D10
D11
D12
D13
D14
D15
VCC
A0
A1
A2
A3
A4
A5
A6
A7
VSS
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
VSS
P60/WAIT
P61/BREQ
P62/BACK
P67/FAI
STBY
RES
NMI
VSS
EXTAL
XTAL
VCC
AS
RD
HWR
LWR
MD0
MD1
MD2
AVCC
VREF
P70/AN0
P71/AN1
P72/AN2
P73/AN3
P74/AN4
P75/AN5
P76/AN6/DA0
P77/AN7/DA1
AVSS
P80/IRQ0/RFSH
P81/IRQ1/CS3
P82/IRQ2/CS2
P83/IRQ3/CS1/AD
P84/CS0
VSS
PA0/TEND0/TCLK*
PA1/TEND1/TCLK*
PA2/TCLKC/TIOC*
PA3/TCLKD/TIOC*
PA4/A23/TIOCA1*
PA5/A22/TIOCB1*
PA6/A21/TIOCA2*
PA7/A20/TIOCB2*
IC27
UPC29M33T
1
2
3
IN
GND
OUT
C152
22p
R9
10K
R104
10k
R73
10k
C105
0.1
C30
0.1
R10
10k
C50
0.1
IC9
TC203C180AF(XP6)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
VDD5
SDIB
BCKB
WCKB
SDOC
VSS
SDOD
BCKC
WCKC
OUTP1
VDD5
VDD3
OUTP2
OUTP0
VSS
SYO
VSS
SYI
RW
DS
CA10
CA9
CA11
CA8
CA12
CA7
CA13
CA6
CA5
CA4
CA3
CA2
VDD5
CA1
CA0
CD15
CD0
CD7
VSS
CD8
CD14
CD1
CD6
VDD5
VDD5
CD9
CD13
CD2
CD5
CD10
VSS
CD12
CD3
CD4
CD11
VDD3
WAIT
CS
RESET
AS
VSS
INT
VSS
CK
TEST
VDD5
WA23
WA22
WA20
WA21
WA19
VSS
WA18
WA9
WA8
WA10
VDD5
WA7
WA11
WA6
WA12
WA5
VSS
WA13
WA4
WA14
WA3
VDD5
VDD5
WA15
WA2
WA16
WA0
WA1
WA17
VSS
WOE1
WOE0
WD15
VDD3
WD0
WD7
WD8
WD14
VSS
WD1
WD6
WD9
WD13
WD2
WD5
WD10
WD12
WD3
WD4
WD11
VSS
WCS0
WCS1
WCS2
VDD5
WCS3
WCS4
WCS5
WCS6
WCS7
VSS
WREQ
WACK
ED7
VSS
VDD5
VDD5
VSS
ED6
ED5
ED4
ED3
ED2
VSS
ED1
ED0
EWE
VDD3
RAS
CAS
EA8
EA0
VSS
EA7
EA1
EA6
EA2
EA5
EA3
EA4
VSS
SDOA5
SDOA4
SDOA3
SDOA2
SDOA1
SDOA0
VSS
VDD5
SDIA5
SDIA4
SDIA3
SDIA2
SDIA1
VSS
SDIA0
BCKA
WCKA
SDOB
VDD5
IC21
PQ05DZ1U
NIU
1
2
3
4
5
IN
OFF
OUT
NC
GND
C370.1
R112
10K
R11
10K
C78
ECEV-A@SR
10/16
R13
NIU
C113
0.1
CN8
53014-1410
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
C116
0.1
C8 0.1
RA18
EXBE10C@J
6.8K
12
3
4
5
6
7
8
910
C17
0.1
IC13D
TC7WU04F
84
R105
10k
CN4
53014-0410
1
2
3
4
1
2
3
4
C36
0.1
R26
0
0
C72
0.1
IC8
PQ3DZ53
NIU
1
2
3
4
5
IN
OFF
OUT
NC
GND
R78
100K
C149
22p
RA13
EXBE10C@J
10K
1 2
3
4
5
6
7
8
910
X1
MA-406@
16.000MHz
14
R108 0
C55
0.1
IC14
M11B416256A-35J
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
VCC
DQ0
DQ1
DQ2
DQ3
VCC
DQ4
DQ5
DQ6
DQ7
NC
NC
WE
RAS
NC
A0
A1
A2
A3
VCC
VSS
A4
A5
A6
A7
A8
OE
UCAS
LCAS
NC
DQ8
DQ9
DQ10
DQ11
VSS
DQ12
DQ13
DQ14
DQ15
VSS
C82
ECEV-A@WR
33/16 C43
0.1
C151
22p
C174
NIU
CN2
53014-0710
1
2
3
4
5
6
7
1
2
3
4
5
6
7
R4 0
C1
NIU
C42
0.1
CN1
AMPC1_2720P NIU
3
4
5
6
7
8
2
1
9
20
19
18
17
16
15
14
13
12
1110
C67
15p
C33
0.1
C140
0.1
RA17
EXBE10C@J
6.8K
12
3
4
5
6
7
8
910
C79
0.1
R22
NIU
C14
0.1
C47
NIU
C13
ECEV-A@WR
10/16
CN7
AMPC1_2720P NIU
3
4
5
6
7
8
2
1
9
20
19
18
17
16
15
14
13
12
1110
R97 NIU
R99 0
C7 0.1
IC19
TC7S08F
1
2
4
53
R1
0
C6 0.1
RA19
EXBE10C@J
NIU
12
3
4
5
6
7
8
910
C73
0.1
IC20D
TC7W14F
84
IC26C
TC7WH32FU
NIU
84
C5
0.1
0.1
C108
0.1
C184 0.1
RA7 220
1 8
2 7
3 6
4 5
C141
22p
C142
22p
C143
22p
C144
22p
C145
22p
C173
NIU
R21 0
R20 0
C146
22p
C147
22p
IC11
uPD23C64040ALGY-743-MJH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
2627
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
WORD/BYTE
A16
A15
A14
A13
A12
A11
A10
A9
A8
A19
A21
A20
A18
A17
A7
A6
A5
A4
A3
A2
A1
A0
CE
GND
GND
OE/OE/DC
O0
O8
O1
O9
O2
O10
O3
O11
A22
VCC
VCC
O4
O12
O5
O13
O6
O14
O7
O15/A-1
GND
GND
C172
NIU
C41
C74
ECEV-A@WR
33/16
C107
10/16
C110 10/16
C101 10/16
C104 10/16
C153
22p
C181
0.1
C44
15p
C62
220p C52 0.01
C29
NIU
C49
0.1
C48
ECEV-A@SR
10/16
C63
220p
R72
NIU
C111
100p
C61
220p
R114 10K
R116
10K
C115
ECEV-A@SR
10/16
C38
0.1
C28
NIU
C27
NIU
C80
0.1
R115
10K
C92
ECEV-A@SR
10/16
L1
N1608ZA@T01
0
L2
N1608ZA@T01
0
C148
22p
C10
0.1
R75
10k
D1
RB420D
NIU
13
C340.1
C150
22p
C31
0.1
C24
0.1
C22
NIU
C60
220p
IC22
LH28F800BVE-BV85@
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
A15
A14
A13
A12
A11
A10
A9
A8
NC
NC
WE
RP
VPP
WP
RY/BY
A18
A17
A7
A6
A5
A4
A3
A2
A1
A0
CE
GND
OE
DQ0
DQ8
DQ1
DQ9
DQ2
DQ10
DQ3
DQ11
VCC
DQ4
DQ12
DQ5
DQ13
DQ6
DQ14
DQ7
A-1/DQ15
GND
BYTE
A16
C176
ECEV-A@WR
33/16
C76
0.1
+
-
IC17A
M5218AFP
2
3
1
CN12
53014-1110
NIU
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
6
7
8
9
10
11
R3
0
IC2C
TC7W00F
NIU
84
R44 0
RA9
EXBV8V@JV
220
1 8
2 7
3 6
4 5
C102
0.1
C106
0.01
+
-
IC17C
M5218AFP
84
R5
10K
+
-
IC17B
M5218AFP
6
5
7
C178
0.1
C56
220p
IC15
uPC29L05T
3 1
2
IN OUT
COM
R57 6.8k
IC2A
TC7W00F
NIU
1
2
7
R37
10K
R40
15K
R35
10K
R33
15K
C83 220p
R36
6.8k
R38
6.8k
C91
220p
R17
10k
C131
100p
C118
0.1
L5
N1608ZA@T01
NIU
L6
N1608ZA@T01
NIU
C129
0.1
R101 NIU
C23
NIU
R111
NIU
RA3
EXBV8V@JV
10k
1 8
2 7
3 6
4 5
RA5
EXBV8V@JV
10k
1 8
2 7
3 6
4 5
RA6
EXBV8V@JV
10k
1 8
2 7
3 6
4 5
RA8
EXBV8V@JV
10k
1 8
2 7
3 6
4 5
C71
NIU
L4
N1608ZA@T01
0
L3
N1608ZA@T01
0
R14
NIU
R56
10K
R62
15K
R50
10K
R48
15K
C112 220p
R51 6.8k
C114
220p
R98 NIU
R100 NIU
R96 NIU
R102 NIU
CN3
53014-1010
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
20
11
HP-1 MH/RW, HP-2e RW/LA Mar, 2002
POWER & AMP. PCB ASSY
for HP-1 ASSY 7772904000
for HP-2e ASSY 7773003000
View from component side
Other manuals for HP-1
1
This manual suits for next models
1
Table of contents
Other Roland Musical Instrument manuals
Roland
Roland F-110 User manual
Roland
Roland FP-7F User manual
Roland
Roland RD-88 User manual
Roland
Roland VS-1680 V-XPANDED User manual
Roland
Roland RD-300NX User manual
Roland
Roland V-Accordion FR-1x User manual
Roland
Roland Atelier AT90 User manual
Roland
Roland KR-33 User manual
Roland
Roland E-60 User manual
Roland
Roland KR-107 User manual
Roland
Roland HPi-7 User manual
Roland
Roland RD-700 Quick start guide
Roland
Roland GO:PIANO with Alexa Built-in User manual
Roland
Roland RG-3M User manual
Roland
Roland VS-880EX User manual
Roland
Roland LX-15e User manual
Roland
Roland HP-147Re User manual
Roland
Roland E-50, E-60 Operating and maintenance manual
Roland
Roland G-70 Operating and maintenance manual
Roland
Roland RD-300GX User manual
