Compact cabinet with an exquisite, stately look.
Approximately 30cm deep (approx. 12") in depth, the DP-990R is
streamlined and stylish, and has an eye-catching, reflective polished ebony
finish. The classy exterior is a perfect match for the Ivory Feel keyboard
— a first for the DP series. With the control panel and
lid hinges in the same black finish, and with silver
pedals, the DP-990R is in a class of its own. When
the keyboard lid is closed, the DP-990R transforms
into an uncluttered, elegant piece of furniture. With its
refined, elegant presence, the DP-990R is a perfect
match for any room.
Elegance meets ease of use.
Has a large music rest and headphone hook for easy storage.
Designed for safety, the keyboard lid closes slowly and smoothly. The DP-
990R provides friendly features for players of all skill levels.
Visit us online at www.Roland.com All specifications and appearances are subject to change without notice.
All trademarks used in this catalog are the property of their respective companies.
Printed in Japan Apr. 2009 RAM-4459 GR-UPR-SS EAE1
Keyboard
<Keyboard>88 keys (PHA II Ivory Feel Keyboard with Escapement) <Touch Sensitivity>Touch: 5
levels/Fixed Touch, Hammer Response: Off/1–10 <Keyboard Mode>Whole, Dual (volume balance
adjustable), Split (split point adjustable), Twin piano
Sound Generator
Conforms to
GM2/GS/XG lite
<Max. Polyphony>128 voices <Tones>306 tones (including 8 drum sets, SFX set) <Temperament>8
types, selectable tonic <Stretched Tuning>On/Off <Master Tuning>415.3–466.2 Hz (adjustable in
increments of 0.1 Hz) <Transpose>Key Transpose: -6–+5 (in semitones) Playback Transpose (with
Audio CD/Audio File): -6–+5 (in semitones) <Effects>3D (4 Levels), Dynamics (3 types), Reverb
(Off/1–10), Key Off Resonance (only for piano tones, Off/1–10), String Resonance (only for piano
tones, Off/1–10), Damper Resonance (only for piano tones, Off/1–10)
Recorder
<Tracks>3 tracks <Songs>Recorder Section: 1 song, Internal Memory: Max. 99 songs <Note
Storage>Approx. 30,000 notes <Control>Song Select, Play/Stop, Rec, Previous/Rewinding, Next/
Fast-forwarding, Track Mute (Mute Level adjustable), Tempo, Tempo Mute, All Song Play, Count-in,
Count-down, Song Volume, Center Cancel (only for audio playback) <Tempo>Quarter note = 10 to
500 <Resolution>120 ticks per quarter note <Metronome>Beat: 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4,
3/8, 6/8, 9/8, 12/8 , Volume: 0–10 Metronome Sound: 8 types
Internal Memory <Songs>Max. 99 songs <Save Song>Standard MIDI Files (Format 0)
External Memory
<External
Storage>USB
Memory
,
Floppy
Disk
(when
using
an
optional
oppy
disk
drive)
<Playable
Software>Standard MIDI Files (Format 0/1), Roland Original Format (i-Format), Audio File (WAV
44.1kHz / 16-bit Linear Format), Audio CDs (CD-DA) (when using an optional CD drive)
Others
<Internal Songs>65 songs + 7 Tone Demo Songs <Rated Power Output>12 W x 2 <Speakers>12 cm
x 2 (with speaker box) <Display>7 segments, 3 characters LED, Beat LED <Control>Volume, Brilliance
(
-10–10)
<Pedal>Damper
(half-pedal
recognition),
Soft
(half-pedal
recognition,
function
assignable),
Sostenuto (function assignable) <Other Function>Panel Lock, V-LINK <Connectors>DC inlet, Pedal
connector, Input jacks (L/Mono, R), Output jacks (L/Mono, R), MIDI connectors (IN, OUT), Phones
jack
(Stereo)
x
2,
External
Memory
port
(USB)
<Power
Supply>DC
12
V
<Power
Consumption>48
W <Dimensions*>1,398 (W) x 344 (D) x 781 (H) mm / 55-1/16 (W) x 13-9/16 (D) x 30-3/4 (H) inches
(With lid closed) 1,398 (W) x 339 (D) x 974 (H) mm / 55-1/16 (W) x 13-3/8 (D) x 38-3/8 (H) inches (With
lid open)(*measurements include stabilizer components attached) <Weight>48 kg/105 lbs 14 oz
<Accessories>Owner’s manual, AC Adaptor, Power Cord (for connecting AC Adaptor), Headphone Hook
Options
Specications
USB Flash Memory
M-UF1G
USB Flash Memory
M-UF2G
Floppy Disk Drive
FD-01A
USB CD Drive
CD-01A
SD/CD Recorder
CD-2e
DESIGN SOUND
TOUCH LESSONS & ENTERTAINMENT
88-key stereo multi-sampled piano engine.
The onboard voice engine features multi-samples meticulously captured from a
full concert grand piano. As such, it truthfully reproduces the characteristic ring
and tone of each individual key. In addition, "Piano Resonance" reproduces
subtle variations in aftertones and string resonance that are characteristic of
grand pianos. With a maximum polyphony of 128 voices, the DP-990R can
handle the most demanding performances without note dropouts.
Authentic sound and expressive response.
3D Sound Control creates a dramatic sense of depth, and
Dynamics Sound Control makes each note distinct. The
DP-990R's high-quality piano sound is reproduced through
a bass-reflex speaker cabinet.
Continuous-detection pedal.
Reproduces subtle changes in the sound according to damper contact with
the strings, and controls the amount of release vibration when the pedal is
stepped on gradually.
Innovative Ivory Feel keyboard.
The DP-990R’s Ivory Feel keys are made of moisture-
absorbent material that offer the natural look and tactile feel of real
ivory and ebony.
The touch and response of an acoustic grand.
The natural touch of a grand piano has been
reproduced based on hammer movement — not
with springs — giving the DP-990R a beautiful
and authentic touch. The keyboard's escapement
mechanism produces the beloved "clicking" feel of
a grand piano.
Lesson functions onboard!
Build your skills with the DP-990R’s built-in metronome and recorder. You can
also divide the keyboard into two zones using the Twin Piano function, allowing
your instructor to play along in the same pitch range during personal lessons.
Play along with your favorite songs.
The DP-990R can play back its onboard songs, music from CDs*1, and music
files stored on USB memory devices. You can even change the tempo and key
in any of these formats. The DP-990R can also play back only the left- or right-
hand parts of its onboard songs and music files for practice. With the optional
CD-2e*2you can create original CDs of your performance.
*1 When used with optional USB CD drive (CD-01A). *2 See www.roland.com/products/en/CD-2e for details.
335
Lid closedLid open
(mm)
311
781
A virtual visualization of the DP-990R’s
3D Sound Control effect.
